Matco MT1719 Operating Instructions, Warning Information, Parts Breakdown

Long barrel t-handle air hammer
Table of Contents

Advertisement

Available languages

Available languages

Quick Links

• Operating Instructions • Warning Information
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Blows Per Minute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2,200 BPM min.
Bore Diameter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/4"
Piston Stroke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1/2"
Air Inlet Thread . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1/4"-18 NPT
Hose Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/8" I.D.
Avg. Air Consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.77 CfM
Rec. Air Pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90 psig (6.2bar)
Sound Pressure Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101.7 dBA
Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10.49"
Shipping Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.5 Lbs.
ALwAYS reAd
inSTruCTionS
before uSing
power TooLS
ALwAYS weAr
SAfeTY goggLeS
weAr heAring
proTeCTion
Avoid
proLonged
expoSure To
vibrATion
MT1719
• Parts Breakdown
S P ECI FIC AT ION S
Some dust created by power sanding, sawing, grinding, drilling, and other construction
activities contains chemicals known to cause cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area, and
work with approved safety equipment, such as those dust masks that are specially
designed to filter out microscopic particles.
MT1719
Copyright © Professional Tool Products, 2007
1
MT1719
Long Barrel
T-Handle
Air Hammer
All rights reserved.
Rev. 06/01/07
