Acer Extensa 5420G Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

TravelMate 5520/5520G/5220/5220G Series
Service Guide
Service guide files and updates are available
on the ACER/CSD web; for more information,
please refer to
http://csd.acer.com.tw
PRINTED IN TAIWAN

Advertisement

Table of Contents
loading

Related Manuals for Acer Extensa 5420G

Summary of Contents for Acer Extensa 5420G

  • Page 1 TravelMate 5520/5520G/5220/5220G Series Service Guide Service guide files and updates are available on the ACER/CSD web; for more information, please refer to http://csd.acer.com.tw PRINTED IN TAIWAN...

  • Page 2: Revision History

    Revision History Please refer to the table below for the updates made on TravelMate 5520/5520G/5220/5220G Series service guide. Date Chapter Updates...
  • Page 3 Copyright Copyright © 2007 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated.
  • Page 4 Conventions The following conventions are used in this manual: SCREEN MESSAGES NOTE WARNING CAUTION IMPORTANT Denotes actual messages that appear on screen. Gives bits and pieces of additional information related to the current topic. Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 5 DIFFERENT part number code to those given in the FRU list of this printed Service Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and service of customer machines.

  • Page 7: Table Of Contents

    Acer eRecovery Management ........23...
  • Page 8 Table of Contents External Modules Disassembly Flowchart ......59 Removing the Battery Pack ........60 Removing the SD dummy card .
  • Page 9 FRU (Field Replaceable Unit) List TravelMate 5520/5520G/5220/5220G Exploded Diagram ....130 TravelMate 5520/5520G/5220/5220G Series ......140 Model Definition and Configuration Test Compatible Components Microsoft®...
  • Page 10 Table of Contents...

  • Page 11: System Specifications

    WMV9 (VC-1) and H.264 (AVC) support (acceleration/full decode) (for selected models) S-video/TV-out (NTSC/PAL) support Storage subsystem 80/120/160 GB or larger hard disk drive with enhanced Acer DASP (Disk Anti-Shock Protection) (for selected models) 80/120/160 GB or larger hard disk drive with Acer DASP (Disk Anti-Shock Protection) (for selected...

  • Page 12: Input Devices

    Acer SignalUp™ with InviLink™ Nplify™ wireless technology (for selected models), or Intel® PRO/Wireless 3945ABG (dual-band tri-mode 802.11a/b/g) Wi-Fi CERTIFIED® network connection, supporting Acer SignalUp™ wireless technology (for selected models), or Acer InviLink 802.11b/g Wi-Fi CERTIFIED® solution, supporting Acer SingalUp™ wireless technology (for selected models) WPAN: Bluetooth®...
  • Page 13 Line-in jack Microphone jack Ethernet (RJ-45) port Modem (RJ-11) port DC-in jack for AC adaptor Environment Temperature: Operating: 5 °C to 35 °C Non-operating: -20 °C to 65 °C Humidity (non-condensing): Operating: 20% to 80% Non-operating: 20% to 80% Chapter 1...

  • Page 14: System Block Diagram

    System Block Diagram Chapter 1...

  • Page 15: Your Acer Notebook Tour

    The left and right buttons function like the left and right mouse buttons. *The center button serves as Acer BioProtect fingerprint reader supporting Acer FingerNav 4- way control function (manufacturing option) or a 4-way scroll button (manufacturing option).

  • Page 16: Closed Front View

    Icon Status indicators Keyboard Power button Closed Front View Icon Item Icon Speakers 5-in-1 card reader Line-in jack Microphone jack Headphones/ speaker/line-out jack Infrared port Bluetooth communication switch Wireless communication switch Latch Item Light-Emitting Diodes (LEDs) that light up to show the status of the computer's functions and components.

  • Page 17: Left View

    Left View Icon Right View Icon Optical drive Optical disk access indicator Optical drive eject button Chapter 1 Item Kensington lock slot Connects to a Kensington-compatible computer security lock. Ethernet (RJ-45) Connects to an Ethernet 10/100/1000-based port network. External display Connects to a display device (e.g., external (VGA) port monitor, LCD projector).

  • Page 18: Rear Panel

    Icon Emergency eject hole Rear Panel Icon Three USB 2.0 ports Modem (RJ-11) port DC-in jack Ventilation slots Bottom Panel Icon Memory compartment Item Description Ejects the optical drive tray when the computer is turned off. Item Description Connect to USB 2.0 devices (e.g., USB mouse, USB camera).

  • Page 19: Indicators

    Icon Battery lock Battery release latch Battery bay Hard disk bay Ventilation slots Indicators The computer has several easy-to-read status indicators: The front panel indicators are visible even when the computer cover is closed. Icon Function Power Battery Bluetooth Wireless LAN Num Lock Caps Lock NOTE: 1.

  • Page 20: Easy-Launch Buttons

    “and one user-programmable button. Press “ “ to run the Acer Empowering Technology. The mail and Web browser buttons are pre-set to email and Internet programs, but can be reset by users. To set the Web browser, mail and programmable buttons, run the Acer Launch Manager.

  • Page 21: Touchpad Basics

    Touchpad Basics The following teaches you how to use the touchpad: Move your finger across the touchpad (2) to move the cursor. Press the left (1) and right (4) buttons located beneath the touchpad to perform selection and execution functions. These two buttons are similar to the left and right buttons on a mouse. Tapping on the touchpad is the same as clicking the left button.
  • Page 22 Function Left Button (1) Scroll NOTE: When using the touchpad, keep it - and your fingers - dry and clean. The touchpad is sensitive to finger movement; hence, the lighter the touch, the better the response. Tapping too hard will not increase the touchpad’s responsiveness.

  • Page 23: Using The Keyboard

    Using the Keyboard The keyboard has full-sized keys and an embedded numeric keypad, separate cursor, lock, Windows, function and special keys. Lock Keys and embedded numeric keypad The keyboard has three lock keys which you can toggle on and off. Lock key Caps Lock When Caps Lock is on, all alphabetic characters typed are...

  • Page 24: Windows Keys

    Windows Keys The keyboard has two keys that perform Windows-specific functions. Windows Pressed alone, this key has the same effect as clicking on the Windows Start button; it launches the Start menu. It can also be used with other keys to provide a variety of functions: <...

  • Page 25: Hot Keys

    <Fn> + <→> <Fn> + < ← > Chapter 1 Function Hotkey help Displays help on hotkeys. Acer eSettings Launches Acer eSettings in Acer Empowering Technology. Acer ePower Launches Acer ePower Management in Acer Management Empowering Technology. Sleep Puts the computer in Sleep mode.

  • Page 26: Special Key

    Special Key You can locate the Euro symbol and the US dollar sign at the upper-center and/or bottom-right of your keyboard. The Euro symbol Open a text editor or word processor. Either press < > at the bottom-right of the keyboard, or hold <Alt Gr> and then press the <5> key at the upper-center of the keyboard.

  • Page 27: Acer Empowering Technology

    Acer Empowering Technology The Empowering Technology toolbar makes it easy for you to access frequently used functions and manage your new Acer system. Displayed by default in the upper half of your screen, it provides access to the following utilities: Acer eNet Management hooks up to location-based networks intelligently.
  • Page 28 Acer eNet Management can save network settings for a location to a profile, and automatically switch to the appropriate profile when you move from one location to another. Settings stored include network connection settings (IP and DNS settings, wireless AP details, etc.), as well as default printer settings. Security and safety concerns mean that Acer eNet Management does not store username and password information.

  • Page 29: Acer Epower Management

    To access this utility, select "Acer ePower Management" from the Empowering Technology toolbar, run the program from the Acer Empowering Technology program group in Start menu, or right-click the Windows power icon in the system tray and select "Acer ePower Management".

  • Page 30: Acer Epresentation Management

    Acer ePresentation Management Acer ePresentation Management lets you project your computer's display to an external display device or projector using the hotkey: <Fn> + <F5>. If auto-detection hardware is implemented in the system and the...

  • Page 31: Acer Edatasecurity Management

    For projectors and external devices that are not auto-detected, launch Acer ePresentation Management to choose an appropriate display setting. NOTE: If the restored resolution is not correct after disconnecting a projector, or you need to use an external resolution that is not supported by Acer ePresentation Management, adjust your display settings using Display Properties or the utility provided by the graphics vendor.

  • Page 32: Acer Elock Management

    Acer eLock Management Acer eLock Management is simple yet effective utility that allows you to lock removable storage, optical and floppy drive devices to ensure that data can't be stolen while your system is unattended. Removable Storage Devices — includes USB disk drives, USB pen drives, USB flash drives, USB MP3 drives, USB memory card readers, IEEE 1394 disk drives, and any other removable storage devices that can be mounted as a file system when plugged into the system.

  • Page 33: Acer Erecovery Management

    To use Acer eLock Management, the Empowering Technology password must be set first. Once set, you can apply locks to any of the devices types. Lock(s) will immediately be set without any reboot necessary, and will remain after rebooting, until removed.

  • Page 34: Acer Esettings Management

    For more information, please refer to "Acer eRecovery Management" on page 61 in the AcerSystem User's Guide. NOTE: If your computer did not come with a Recovery CD or System CD, please use Acer eRecovery Management's "System backup to optical disc" feature to burn a backup image to CD or DVD. To...

  • Page 35: Windows Mobility Center

    The Windows Mobility Center collects key mobile-related system settings in one easy-to-find place, so you can quickly configure your Acer system to fit the situation as you change locations, networks or activities. Settings include display brightness, power plan, volume, wireless networking on/off, external display settings, display orientation and synchronization status.

  • Page 36: Using The System Utilities

    Acer Bio-Protection Fingerprint Solution also allows you to navigate through web browsers and documents using Acer FingerNav. With Acer Bio-Protection Fingerprint Solution, you can now enjoy an extra layer of protection for your personal computer, as well as the convenience of accessing your daily tasks with a simple swipe of your finger! For more information refer to the Acer Bio-Protection help files.

  • Page 37: Acer Gridvista (Dual-Display Compatible)

    Settings Apply Acer GridVista is a handy utility that offers four pre-defined display settings so you can view multiple windows on the same screen. To access this function, please go to Start>All Programs and click on Acer GridVista. You may choose any one of the four display settings indicated below:...

  • Page 38: Launch Manager

    Double (verticle), Triple (primary at left), Triple (primary at right), or Quad Acer Gridvista is dual-display compatible, allowing two displays to be partitioned indepently. Acer Gridvista is dual-display compatible, allowing two displays to be partitioned independently. AcerGridVista is imple to set up: Run Acer GridVista and select your preferred screen configuration for each display from the task bar.
  • Page 39 Select Run Scan to scan your system. When the scan is complete, review the results of the scan. NOTE: For optimal security, run a Full System Scan when scanning your computer for the first time. You can schedule customized virus scans that run unattended on specific dates and times or at periodic intervals.

  • Page 40: Hardware Specifications And Configurations

    Hardware Specifications and Configurations Processor Item CPU type Core logic CPU package CPU core voltage CPU Fan True Value Table DTS(degree C) Fan Speed (rpm) 45-50 0-3000 55-66 0-3300 68-74 3300-3800 78-83 3800-4100 86-91 4100-4800 ° Throttling 50%: On= 99 C; OFF=93 C °...
  • Page 41 System Memory Item Memory controller Memory size DIMM socket number Supports memory size per socket Supports maximum memory size Supports DIMM type Supports DIMM Speed Supports DIMM voltage Supports DIMM package Memory module combinations Memory Combinations Slot 1 256MB 256MB 256MB 256MB 512MB...
  • Page 42 723 bps (full speed data rate) Bluetooth 1.1 (Upgradeable to Bluetooth 1.2 when SIG specification is ratified). USB 1.1 Specification Acer InviLink™ 802.11b/g Wi-Fi CERTIFIED® solution, supporting Acer SignalUp™ with InviLink™ Nplify™ wireless technology Acer InviLink™ 802.11a/b/g/Draft-N Wi-Fi CERTIFIED® solution, supporting Acer SignalUp™ wireless technology 11~54 Mbps, up to 270 Mbps for Draft-N 802.11b+g, Draft-N...
  • Page 43 Hard Disk Drive Interface Item Interface SATA Max. media transfer rate (disk-buffer, Mbytes/s) Data transfer 100 MB/Sec. rate Ultra DMA mode-5 (host~buffer, Mbytes/s) DC Power Requirements Voltage 5V(DC) +/- 5% tolerance Combo Drive module Item Vendor & model name Performance Specification Transfer rate (KB/sec) Buffer Memory Interface...
  • Page 44 Super-Multi Drive module Item Vendor & model name Performance Specification Transfer rate (KB/sec) Buffer Memory Interface Applicable disc format Loading mechanism Power Requirement Input Voltage Audio Interface Item Audio Controller Audio onboard or optional Mono or Stereo Specification HLDS Super-Multi Drive GSA-T20N, PHILIPS Super-Multi Drive DS- 8A1P, PIONEER Super-Multi Drive DVR-K17RS With CD Diskette Sustained:...
  • Page 45 Audio Interface Item Resolution Compatibility Sampling rate Internal microphone Internal speaker / Quantity Video Interface Item Chipset Package Interface Supports ZV (Zoomed Video) port Video Memory Item Chipset Memory size Interface Item Chipset USB Compliancy Level OHCI Number of USB port Location Serial port function control PCMCIA Port...
  • Page 46 System Board Major Chips Item USB 2.0 Super I/O controller MODEM Bluetooth Wireless 802.11 b+g PCMCIA/ 5 in 1 Card Reader Audio Codec Keyboard Item Keyboard controller Total number of keypads Windows logo key Internal & external keyboard work simultaneously Battery Item Vendor &...
  • Page 47 LCD 15.4” inch Item Vendor & model name Screen Diagonal (mm) Active Area (mm) Display resolution (pixels) Pixel Pitch Pixel Arrangement Display Mode Typical White Luminance (cd/m also called Brightness Luminance Uniformity Contrast Ratio Response Time (Optical Rise Time/Fall Time)msec Nominal Input Voltage VDD Typical Power Consumption (watt) Weight...
  • Page 48 AC Adaptor Item Input rating Maximum input AC current Inrush current Efficiency System Power Management ACPI mode Mech. Off (G3) Soft Off (G2/S5) Working (G0/S0) Suspend to RAM (S3) Save to Disk (S4) Specification 90V AC to 264V AC, 47Hz to 63Hz 1.7A 220A@115VAC 220A@230VAC...

  • Page 49: System Utilities

    System Utilities BIOS Setup Utility The BIOS Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/ Output System). Your computer is already properly configured and optimized, and you do not need to run this utility. However, if you encounter configuration problems, you may need to run Setup.

  • Page 50: Navigating The Bios Utility

    Navigating the BIOS Utility There are six menu options: Information, Main, Advanced, Security, Boot, and Exit. Follow these instructions: To choose a menu, use the left and right arrow keys. To choose an item, use the up and down arrow keys. To change the value of a parameter, press F5 or F6.

  • Page 51: Information

    Information The Information screen displays a summary of your computer hardware information. P h o e n i x Tr u s t e d C o r e ( t m ) S e t u p U t i l i t y I n f o r m a t i o n M a i n C P U Ty p e :...

  • Page 52: Main

    Main The Main screen allows the user to set the system time and date as well as enable and disable boot option and recovery. P h o e n i x Tr u s t e d C o r e ( t m ) S e t u p U t i l i t y I n f o r m a t i o n M a i n S y s t e m Ti m e :...
  • Page 53 The table below describes the parameters in this screen. Settings in boldface are the default and suggested parameter settings. Parameter System Time Sets the system time. The hours are displayed with 24-hour format. System Date Sets the system date. System Memory This field reports the memory size of the system.

  • Page 54: Advanced

    Advanced P h o e n i x Tr u s t e d C o r e ( t m ) S e t u p U t i l i t y I n f o r m a t i o n M a i n I n f r a r e d P o r t : A S F C o n f i g u r a t i o n...

  • Page 55: Security

    Security The Security screen contains parameters that help safeguard and protect your computer from unauthorized use. Information Main Supervisor Password Is : User Password Is : HDD 0 Password Set Supervisor Password Set User Password Set HDD 0 Password Password on Boot Help ↑...

  • Page 56: Setting A Password

    The table below describes the parameters in this screen. Settings in boldface are the default and suggested parameter settings. Parameter Supervisor Password is Shows the setting of the Supervisor password User Password is Shows the setting of the user password. HDD Password is Shows the setting of the hard disk drive password...

  • Page 57: Removing A Password

    Removing a Password Follow these steps: Use the w and y keys to highlight the Set Supervisor Password parameter and press the e key. The Set Password box appears: Type the current password in the Enter Current Password field and press e. Press e twice without typing anything in the Enter New Password and Confirm New Password fields.
  • Page 58 If the current password entered does not match the actual current password, the screen will show you the Setup Warning. If the new password and confirm new password strings do not match, the screen will display the following message. Chapter 2...

  • Page 59: Boot

    Boot This menu allows the user to decide the order of boot devices to load the operating system. Bootable devices includes the distette drive in module bay, the onboard hard disk drive and the CD-ROM in module bay. I n f o r m a t i o n M a i n B o o t p r i o r i t y o r d e r : 1 : I D E 0 : X X X X X X X X X X X - ( X X )

  • Page 60: Exit

    Exit The Exit screen contains parameters that help safeguard and protect your computer from unauthorized use. I n f o r m a t i o n M a i n E x i t S a v i n g C h a n g e s E x i t D i s c a r d i n g C h a n g e s L o a d S e t u p D e f a u l t s D i s c a r d C h a n g e s...

  • Page 61: Bios Flash Utility

    BIOS Flash Utility The BIOS flash memory update is required for the following conditions: New versions of system programs New features or options Restore a BIOS when it becomes corrupted. Use the Phlash utility to update the system BIOS flash ROM. NOTE: If you do not have a crisis recovery diskette at hand, then you should create a Crisis Recovery Diskette before you use the Phlash utility.

  • Page 62: Remove Hdd/Bios Utility

    Remove HDD/BIOS Utility This section provide you with removing HDD/BIOS method: Remove HDD Password: If you key in wrong HDD password for three time, “HDD password error code” would display on the screen. See the image below. If you need to solve HDD password locked problem, you can run HDD_PW.EXE Key in “hdd_pw 15494 0”...
  • Page 63 Remove BIOS Password: If you key in wrong Supervisor Password for three time, “System Disabled” would display on the screen. See the image below. Chapter 2...
  • Page 64 If you need to solve BIOS password locked problem, you can run BIOS_PW.EXE Key in “bios_pw 14452 0” Choose one upper-case string Reboot the system and key in “qjjg9vy” or “07yqmjd” to BIOS user password. Chapter 2...
  • Page 65 Chapter 2...
  • Page 66 Chapter 2...

  • Page 67: Machine Disassembly And Replacement

    Machine Disassembly and Replacement This chapter contains step-by-step procedures on how to disassemble the notebook computer for maintenance and troubleshooting. Disassembly Requirements To disassemble the computer, you need the following tools: Wrist grounding strap and conductive mat for preventing electrostatic discharge Flat screwdriver Philips screwdriver Hex screwdriver...

  • Page 68: General Information

    General Information Pre-disassembly Instructions Before proceeding with the disassembly procedure, make sure that you do the following: Turn off the power to the system and all peripherals. Unplug the AC adapter and all power and signal cables from the system. Place the system on a flat, stable surface.

  • Page 69: External Module Disassembly Process

    External Module Disassembly Process External Modules Disassembly Flowchart The flowchart below gives you a graphic representation on the entire disassembly sequence and instructs you on the components that need to be removed during servicing. For example, if you want to remove the main board, you must first remove the keyboard, then disassemble the inside assembly frame in that order.

  • Page 70: Removing The Battery Pack

    Removing the Battery Pack Turn base unit over. Slide the battery lock/unlock latch to the unlock position (1). Slide and hold the battery release latch to the release position (2), then remove the battery from the main unit (3). Removing the SD dummy card Push the SD dummy card all the way in to eject it (1, 2).

  • Page 71: Removing The Pc And Expresscard Dummy Cards

    Pull it out from the slot (2). Removing the PC and ExpressCard dummy cards Press the eject button to pop out the button. Press it again (1) to pop out the PC dummy card (2). Remove the PC dummy card from the slot. Chapter 3...

  • Page 72: Removing The Lower Cover

    Push the ExpressCard dummy card all the way in to eject it. Pull it out from the slot. Removing the Lower Cover See “Removing the Battery Pack” on page 60. See “Removing the SD dummy card” on page 60. See “Removing the PC and ExpressCard dummy cards” on page 61. Remove the seven screws (B) on the lower cover.

  • Page 73: Removing The Dimm

    Use a plastic screw driver to carefully pry open the lower cover. Remove the lower cover from the lower case. Removing the DIMM See “Removing the Battery Pack” on page 60. See “Removing the SD dummy card” on page 60. See “Removing the PC and ExpressCard dummy cards”...

  • Page 74: Removing The Wlan Board Modules

    Remove the DIMM module. Removing the WLAN Board Modules See “Removing the Battery Pack” on page 60. See “Removing the SD dummy card” on page 60. See “Removing the PC and ExpressCard dummy cards” on page 61. See “Removing the Lower Cover” on page 62. Remove the tape holding the gray antenna.

  • Page 75: Removing The Hard Disk Drive Module

    Move the antenna away from the WLAN board and remove the two screws (F) on the WLAN board to release the WLAN board. Step Size (Quantity) M2 x L3 (2) Detach the WLAN board from the WLAN socket. NOTE: When attaching the antenna back to the WLAN board, make sure the cable are arranged properly. Removing the Hard Disk Drive Module See “Removing the Battery Pack”...

  • Page 76: Removing The Optical Drive Module

    Disconnect the hard disk module from the connector by pulling on the mylar tab on the hard disk module. Remove the hard disk module. NOTE: To prevent damage to device, avoid pressing down on it or placing heavy objects on top of it. Remove the four screws (G) as shown.
  • Page 77 Turn the base unit over, then remove the one screw (A) on the bottom side of the unit. Step Size (Quantity) M2.5 x L6 (1) Carefully use a plastic screw driver (1) to eject the optical drive tray (2). Pull the optical drive module out from the main unit. Chapter 3 Color Torque...
  • Page 78 Remove the one screw (C) securing the locker bracket and remove the locker bracket from the optical disk drive module. Step Size (Quantity) Color Torque M2 x L4 (1) Silver 1.6 kgf-cm Chapter 3...

  • Page 79: Main Unit Disassembly Process

    Main Unit Disassembly Process Main Unit Disassembly Flowchart HEAT SINK FAN C x9 (Cx5 for UMA module) CPU/VGA THERMAL MODULE BOARD LEFT AND RIGHT USB BOARD SPEAKER MODULE Screw List Chapter 3 MAIN UNIT DISASSEMBLY MAIN UNIT MIDDLE COVER Fx 2 KEYBOARD A x 2 H x 2...

  • Page 80: Removing The Modem Board

    Removing the Modem Board See “Removing the Battery Pack” on page 60. See “Removing the Lower Cover” on page 62. See “Removing the DIMM” on page 63.. See “Removing the WLAN Board Modules” on page 64.. Remove the 2 screws (C) securing the modem card. Step Size (Quantity) M2 x L4 (2)

  • Page 81: Removing The Cpu And Vga Heatsink Module

    Disconnect the heatsink fan connector from FAN1 on the main board. Remove the two screws (C) securing the heatsink fan module. Step Size (Quantity) M2 x L4 (2) Remove the heatsink fan module from the main board. Removing the CPU and VGA Heatsink Module See “Removing the Battery Pack”...
  • Page 82 Remove the five screws (C) securing the CPU module in place. Step Size (Quantity) M2 x L4 (5) For Discrete model, remove the nine screws (C) securing the CPU and VGA heatsink module in place. Step Size (Quantity) M2 x L4 (9) Color Torque Silver...

  • Page 83: Removing The Cpu

    Slide out and remove the heatsink module. For Discrete model, slide out and remove the heatsink. Removing the CPU See “Removing the Battery Pack” on page 60.. See “Removing the Lower Cover” on page 62.. See “Removing the Heatsink Fan Module” on page 70. Chapter 3...

  • Page 84: Removing The Vga Board (For Discrete Model Only)

    See “Removing the CPU and VGA Heatsink Module” on page 71. Using a flat screwdriver, turn the CPU socket latch counter-clockwise to release the CPU, then remove the CPU. NOTE: When installing the CPU, make sure to install the CPU with PIN 1 at the corner as shown. Removing the VGA board (for Discrete model only) See “Removing the Battery Pack”...

  • Page 85: Removing The Middle Cover And The Power Board

    Remove the two screws (D) securing the VGA board. Step Size (Quantity) M2.5 x L5 (2) Carefully remove the VGA board from the main board. Removing the Middle Cover and the Power Board See “Removing the Battery Pack” on page 60. Open the LCD screen all the way to facilitate the easy removal of the middle cover.
  • Page 86 Detach the cover and turn it over on the keyboard. Disconnect the Power board cable from the main board and disconnect the Power board cable. Chapter 3...

  • Page 87: Removing The Keyboard

    Remove the Middle Cover together with the Power board. Remove the one screw (F) securing the Power board to the middle cover, and remove the Power board from the middle cover. Step Size (Quantity) M2 x L3 (1) Removing the Keyboard See “Removing the Battery Pack”...
  • Page 88 Remove the two screws (F) securing the keyboard to the upper case. Step Size (Quantity) M2 x L3 (2) Carefully pry the keyboard out of the latch and slide it out; then turn it over on the touchpad area. Color Torque Silver 1.6 kgf-cm...

  • Page 89: Removing The Lcd Module

    Disconnect the keyboard cable from the main board to remove the keyboard. Removing the LCD Module See “Removing the Battery Pack” on page 60. See “Removing the Lower Cover” on page 62. See “Removing the WLAN Board Modules” on page 64. See “Removing the Middle Cover and the Power Board”...
  • Page 90 Remove the acetic tape and disconnect the LCD coaxial cable from the LCD1 connector on the main board and release it from the latch. Remove the internal microphone cable from the INTMIC1 connector on the main board. Chapter 3...
  • Page 91 Release the wireless LAN antenna cables from the hole and latches as shown. Remove the two screws (A) from the base of the unit. Step Size (Quantity) M2.5 x L6 (2) 10. Remove the two screws (H) from the left and right hinge of the LCD module. Step Size (Quantity) M2.5 x L8 (2)

  • Page 92: Separating The Upper Case From The Lower Case

    Separating the Upper Case from the Lower Case See “Removing the Battery Pack” on page 60. See “Removing the SD dummy card” on page 60. See “Removing the PC and ExpressCard dummy cards” on page 61. See “Removing the Lower Cover” on page 62. See “Removing the DIMM”...
  • Page 93 19. Disconnect the Launch board cable from the SWITCHCN1 from the main board. 20. Disconnect the fingerprint cable (select model only) from the FPCN1 connector on the main board. Chapter 3...
  • Page 94 21. Disconnect the touchpad cable from the TOUCHPAD1 on the main board. 22. Remove the fourteen screws (A) on the bottom panel. Step Size (Quantity) Color Torque 1~14 M2.5 x L6 (14) Black 3.0 kgf-cm 23. Gently raise the upper case from the main unit. Chapter 3...

  • Page 95: Removing The Launch Board

    Removing the Launch Board See “Removing the Battery Pack” on page 60. See “Removing the SD dummy card” on page 60. See “Removing the PC and ExpressCard dummy cards” on page 61. See “Removing the Lower Cover” on page 62. See “Removing the DIMM”...

  • Page 96: Removing Thetouch Pad Board Module

    19. Remove the one screw (F) holding the launch board and remove the launch board from the upper cover. Step Size (Quantity) M2 x L3 (1) Removing theTouch Pad Board Module See “Removing the Battery Pack” on page 60. See “Removing the SD dummy card” on page 60. See “Removing the PC and ExpressCard dummy cards”...
  • Page 97 18. Remove the fingerprint cable from the fingerprint board. 19. Remove the touch pad cable from the touch pad board. Chapter 3...
  • Page 98 20. Remove the two screws (F) on the touch pad bracket and remove the touch pad bracket from the upper case. Step Size (Quantity) M2 x L3 (2) 21. Remove the two screws (F) from the fingerprint board. Step Size (Quantity) M2 x L3 (2) 22.

  • Page 99: Removing The Main Board

    23. Carefully pry loose and remove the touch pad board. WARNING:The touchpad board is glued to the upper case, only remove the touchpad board if it is defective. Removing the main board See “Removing the Battery Pack” on page 60. See “Removing the SD dummy card”...
  • Page 100 19. Disconnect the speaker cable from the SPKR1 on the main board. 20. Remove the two screws (C) holding the main board. Step Size (Quantity) Color Torque M2 x L4 (2) Silver 1.6 kgf-cm 21. Carefully detach the main board and turn it over to access the USB board cable. 22.

  • Page 101: Removing The Speaker Modules

    Removing the Speaker Modules See “Removing the Battery Pack” on page 60. See “Removing the SD dummy card” on page 60. See “Removing the PC and ExpressCard dummy cards” on page 61. See “Removing the Lower Cover” on page 62. See “Removing the DIMM”...

  • Page 102: Removing The Usb Board

    21. Remove the four screws (C) holding the left and right speakers. Step Size (Quantity) M2 x L4 (4) 22. Remove the left and right speakers from the upper case. Removing the USB Board See “Removing the Battery Pack” on page 60. See “Removing the SD dummy card”...
  • Page 103 19. Remove the one screw (C) securing the USB board to the lower case. Step Size (Quantity) Color Torque M2 x L4 (1) Silver 1.6 kgf-cm 20. Partially lift the USB Board from the lower case. 21. Detach the cable from the USB board. Chapter 3...

  • Page 104: Lcd Module Disassembly Process

    LCD Module Disassembly Process LCD Module Disassembly Flowchart LCD ASSEMBLY LCD FPC LEFT LCD RIGHT LCD CABLE BRACKET Main Screw List Item LCD MODULE DISASSEMBLY LCD MODULE LCD BEZEL INVERTER BOARD Ex 1 LEFT HINGE BRACKET ANTENNAS Screw M2.5 x L6 M2.5 x L5 M2 x L3 A x 8...

  • Page 105: Removing The Lcd Bezel

    Removing the LCD Bezel See “Removing the Battery Pack” on page 60. See “Removing the Lower Cover” on page 62. See “Removing the DIMM” on page 63. See “Removing the WLAN Board Modules” on page 64. See “Removing the Middle Cover and the Power Board” on page 75. See “Removing the Keyboard”...

  • Page 106: Removing The Lcd Module With The Brackets

    Removing the LCD module with the Brackets See “Removing the Battery Pack” on page 60. See “Removing the Lower Cover” on page 62. See “Removing the DIMM” on page 63. See “Removing the WLAN Board Modules” on page 64. See “Removing the Middle Cover and the Power Board” on page 75. See “Removing the Keyboard”...

  • Page 107: Removing The Inverter Board And Fpc Cable

    Removing the Inverter Board and FPC Cable See “Removing the Battery Pack” on page 60. See “Removing the Lower Cover” on page 62. See “Removing the DIMM” on page 63. See “Removing the WLAN Board Modules” on page 64. See “Removing the Middle Cover and the Power Board” on page 75. See “Removing the Keyboard”...

  • Page 108: Removing The Lcd Brackets

    Removing the LCD Brackets See “Removing the Battery Pack” on page 60. See “Removing the Lower Cover” on page 62. See “Removing the DIMM” on page 63. See “Removing the WLAN Board Modules” on page 64. See “Removing the Middle Cover and the Power Board” on page 75. See “Removing the Keyboard”...

  • Page 109: Removing The Antennas

    10. Remove the two screws (E) securing the left and right hinge to the back cover. Step Size (Quantity) M2.5 x L5 (2) 11. Remove the left and right hinge from the back cover. Removing the Antennas See “Removing the Battery Pack” on page 60. See “Removing the Lower Cover”...

  • Page 110: Removing The Internal Microphone And Web Camera

    12. Remove the tapes together with the antenna cables from the back cover. Removing the Internal Microphone and Web Camera See “Removing the Battery Pack” on page 60. See “Removing the Lower Cover” on page 62. See “Removing the DIMM” on page 63. See “Removing the WLAN Board Modules”...
  • Page 111 14. Remove the internal microphone from the back cover. 15. Remove the Web camera from the back cover. Chapter 3...
  • Page 112 Chapter 3...

  • Page 113: Troubleshooting

    Troubleshooting Use the following procedure as a guide for computer problems. NOTE: The diagnostic tests are intended to test only Acer products. Non-Acer products, prototype cards, or modified options can give false errors and invalid system responses. Obtain the failing symptoms in as much detail as possible.

  • Page 114: System Check Procedures

    System Check Procedures External Diskette Drive Check Do the following to isolate the problem to a controller, driver, or diskette. A write-enabled, diagnostic diskette is required. NOTE: Make sure that the diskette does not have more than one label attached to it. Multiple labels can cause damage to the drive or cause the drive to fail.

  • Page 115: Memory Check

    External keyboard If any of these devices do not work, reconnect the cable connector and repeat the failing operation. Memory check Memory errors might stop system operations, show error messages on the screen, or hang the system. Boot from the diagnostics diskette and start the doagmpstotics program (please refer to main board. Go to the diagnostic memory in the test items.

  • Page 116: Check The Power Adapter

    Check the Power Adapter Unplug the power adapter cable from the computer and measure the output voltage at the plug of the power adapter cable. See the following figure If the voltage is not correct, replace the power adapter. If the voltage is within the range, do the following: Replace the System board.

  • Page 117: Touchpad Check

    Check the Battery Pack To check the battery pack, do the following: From Software: Check out the Power Management in control Panel In Power Meter, confirm that if the parameters shown in the screen for Current Power Source and Total Battery Power Remaining are correct.

  • Page 118: Power-On Self-Test (Post) Error Message

    Power-On Self-Test (POST) Error Message The POST error message index lists the error message and their possible causes. The most likely cause is listed first. NOTE: Perform the FRU replacement or actions in the sequence shown in FRU/Action column, if the FRU replacement does not solve the problem, put the original part back in the computer.

  • Page 119: Index Of Error Messages

    Index of Error Messages Error Code List Error Codes <No error code> <No error code> Error Message List Error Messages Failure Fixed Disk Stuck Key Keyboard error Keyboard Controller Failed Keyboard locked - Unlock key switch Monitor type does not match CMOS - Run Setup Shadow RAM Failed at offset: nnnn System RAM Failed at offset: nnnn...
  • Page 120 Error Message List Error Messages System timer error Real time clock error Previous boot incomplete - Default configuration used Memory size found by POST differed from CMOS Diskette drive A error Incorrect Drive A type - run SETUP System cache error - Cache disabled CPU ID: DMA Test Failed Software NMI Failed...
  • Page 121 Error Message List No beep Error Messages No beep, power-on indicator turns off and LCD is blank. No beep, power-on indicator turns on and LCD is blank. No beep, power-on indicator turns on and LCD is blank. But you can see POST on an external CRT.

  • Page 122: Phoenix Bios Beep Codes

    Phoenix BIOS Beep Codes Code 1-2-2-3 1-3-1-1 1-3-1-3 1-3-4-1 1-3-4-3 1-4-1-1 Beeps POST Routine Description Verify Real Mode Disable Non-Maskable Interrupt (NMI) Get CPU type Initialize system hardware Initialize chipset with initial POST values Set IN POST flag Initialize CPU registers Enable CPU cache Initialize caches to initial POST values Initialize I/O component...
  • Page 123 Code 2-1-2-3 2-2-3-1 Chapter 4 Beeps POST Routine Description Advanced configuration of chipset registers Load alternate registers with CMOS values Initialize interrupt vectors POST device initialization Check ROM copyright notice Check video configuration against CMOS Initialize PCI bus and devices Initialize all video adapters in system QuietBoot start (optional) Shadow video BIOS ROM...
  • Page 124 Code Beeps POST Routine Description Detect and install external RS232 ports Configure non-MCD IDE controllers Detect and install external parallel ports Initialize PC-compatible PnP ISA devices Re-initialize onboard I/O ports Configure Motherboard Configurable Devices (optional) Initialize BIOS Area Enable Non-Maskable Interrupts (NMIs) Initialize Extended BIOS Data Area Test and initialize PS/2 mouse Initialize floppy controller...
  • Page 125 Code Code Chapter 4 Beeps POST Routine Description Prepare Boot Initialize DMI parameters Initialize PnP Option ROMs Clear parity checkers Display MultiBoot menu Clear screen (optional) Check virus and backup reminders Try to boot with INT 19 Initialize POST Error Manager (PEM) Initialize error logging Initialize error display function Initialize system error handler...
  • Page 126 Code Beeps Boot to Mini DOS Clear Huge Segment Boot to Full DOS Chapter 4...

  • Page 127: Index Of Symptom-To-Fru Error Message

    Index of Symptom-to-FRU Error Message LCD-Related Symptoms Symptom / Error LCD backlight doesn't work LCD is too dark LCD brightness cannot be adjusted LCD contrast cannot be adjusted Unreadable LCD screen Missing pels in characters Abnormal screen Wrong color displayed LCD has extra horizontal or vertical lines displayed.
  • Page 128 Power-Related Symptoms Symptom / Error The system doesn’t power-off. Battery can’t be charged PCMCIA-Related Symptoms Symptom / Error System cannot detect the PC Card (PCMCIA) PCMCIA slot pin is damaged. Memory-Related Symptoms Symptom / Error Memory count (size) appears different from actual size.
  • Page 129 Power Management-Related Symptoms Symptom / Error The system doesn't resume from hibernation mode. The system doesn't resume from standby mode after opening the LCD. Battery fuel gauge in Windows doesn’t go higher than 90%. System hangs intermittently. Peripheral-Related Symptoms Symptom / Error System configuration does not match the installed devices.
  • Page 130 Keyboard/Touchpad-Related Symptoms Symptom / Error Touchpad does not work. Modem-Related Symptoms Symptom / Error Internal modem does not work correctly. NOTE: If you cannot find a symptom or an error in this list and the problem remains, see “Undetermined Problems” on page 122. Action in Sequence Reconnect touchpad cable.

  • Page 131: Intermittent Problems

    Intermittent Problems Intermittent system hang problems can be caused by a variety of reasons that have nothing to do with a hardware defect, such as: cosmic radiation, electrostatic discharge, or software errors. FRU replacement should be considered only when a recurring problem exists. When analyzing an intermittent problem, do the following: Run the advanced diagnostic test for the system board in loop mode at least 10 times.

  • Page 132: Undetermined Problems

    System Check” on page 105.): Power-off the computer. Visually check them for damage. If any problems are found, replace the FRU. Remove or disconnect all of the following devices: Non-Acer devices Printer, mouse, and other external devices Battery pack Hard disk drive...

  • Page 133: Jumper And Connector Locations

    Jumper and Connector Locations Top View Description Power Cable Connector LCD Cable Connector Touchpad Board Connector Keyboard Connector Chapter 5 Description Fingerprint/Touchpad Connector Bluetooth Connector Speaker Connector Chapter 5...

  • Page 134: Bottom View

    Bottom View Description SATA Connector PC Card Reader LAN Connector CRT Connector 1394 Connector Description USB Connector Card Reader Line-out jack Mic-in jack Headphone jack Chapter 5...
  • Page 135 Standard Operation Procedures of Password Bypassing and BIOS Recovery Bios/KBC update : The firmware are combined into one binary file and support both DOS and Windows mode update - DOS mode DO make sure you have plugged in the AC adapter to prevent flashing failure. Before flashing the BIOS, you should unzip the compressed file to one directory.
  • Page 136 PIN pad Location The system board provides one hardware Pin pad under the keyboard pad. RD/CSD can enable this function by shorting this pad. The Pin Pad location should look as the figure below. Clear Password PIN Pad: Bypassing Password Check Keep shorting the 2 triangle PIN pad as shown above and then powering on the system will force the BIOS to clear Supervisor and User passwords.
  • Page 137 Enable this function by pressing Fn+ESC, and the Power Button. To use this function, it is strongly recommended that the AC adapter is plugged and battery is inserted into the battery slot. If this function is enabled, the system will force the BIOS to enter into a special BIOS block, called BootBlock. RD/CSD can use this special BIOS code to recover the BIOS to a successful one if previous BIOS flashing process fails.
  • Page 138 Chapter 5...

  • Page 139: Fru (Field Replaceable Unit) List

    Guide. For ACER AUTHORIZED SERVICE PROVIDERS, your Acer office may have a DIFFERENT part number code from those given in the FRU list of this printed Service Guide. You MUST use the local FRU list provided by your regional Acer office to order FRU parts for repair and service of customer machines.

  • Page 140: Travelmate 5520/5520G/5220/5220G Exploded Diagram

    TravelMate 5520/5520G/5220/5220G FRU List Category Adapter Battery- Part Name and Description ADAPTER 90W DELTA ADP-90SB BBDAR ADAPTER 90W DELTA ADP-90SB BBEA LF ADAPTER 90W LITEON PA-1900- 04WR ADAPTER 90W LITEON PA-1900- 24AR Acer Part No. AP.09001.010 AP.09001.013 AP.09003.005 AP.09003.011 Chapter 6...
  • Page 141 TOUCHPAD BOARD SYNAPTICS TM00372-012 INVERTER BOARD 17” DARFON VK.21189.801 INVERTER BOARD 17” FOXCONN T62I249.00 INVERTER BOARD 17” SUMIDA IV12151/T-LF INVERTER BOARD 17” YEC YNV- MODEM BOARD FOXCONN T60M955.00 3.3V Acer Part No. BT.00603.029 BT.00604.015 BT.00605.014 BT.00607.008 BT.00803.022 BT.00804.019 BT.00805.010 BT.00807.013 23.TCZV1.004 KI.GLN01.001 KI.GLN01.002...
  • Page 142 FINGER PRINT BOARD CABLE TOUCHPAD CABLE LAUNCH BOARD CABLE POWER BOARD CABLE BLUETOOTH CABLE MODEM CABLE USB BOARD CABLE DC-IN CABLE COVER SWITCH CABLE LCD CABLE 15.4” Acer Part No. 50.TK901.001 50.TK901.002 50.TK901.003 50.TK901.004 50.TK901.005 50.TK901.006 50.TK901.007 50.TK901.008 50.TK901.009 50.TK901.011...
  • Page 143 VGA BOARD BRACKET MXM BRACKET ASSEMBLY TOUCH PAD BRACKET ASSEMBLY PCMCIA DUMMY CARD MIDDLE COVER ASSEMBLY NEW CARD DUMMY CARD SD DUMMY CARD LOWER CASE W/SPEAKER W/O FIR & DVI Acer Part No. 27.T30V1.001 27.01518.641 27.01518.781 27.T30V1.004 27.01518.731 27.01518.541 27.03118.001 27.01518.561 27.01518.671...
  • Page 144 CPU YONAH T2250 1.73GHZ/533 INTEL CPU YONAH T2350 1.86GHZ INTEL CPU YONAH T2450 2.0GHZ INTEL CPU MEROM T5200 1.6GHZ INTEL CPU MEROM T5300 1.73GHZ INTEL CPU MEROM T5500 1.66GHZ INTEL PGA B Acer Part No. 60.TKC01.002 60.TK901.003 33.TK901.002 42.TK901.002 42.TK501.002 33.TK901.003 33.TK901.004 33.TK901.005...
  • Page 145 PANASONIC UJ-850UAA1-A LF W/O BEZEL DVD-RW DRIVE 8X S-MULTI PHILIPS DS-8A1P LF W/O BEZEL DVD-RW DRIVE 8X S-MULTI HLDS GSA-T20N LF W/O BEZEL 15” FAN FORCECON CPU HEATSINK W/SCREW W/O FAN Acer Part No. KC.55L01.DTP KC.56001.DTP KC.56L01.DTP KC.72001.DTP KC.74001.DTP KC.76001.DTP KC.N0001.430 KC.ND001.430...
  • Page 146 BLACK SLOVENIAN (BIG ERGO) DARFON KEYBOARD 14_15KB-EV2 88KS BLACK RUSSIAN (BIG ERGO) DARFON KEYBOARD 14_15KB-EV2 89KS BLACK PORTUGUESE (BIG ERGO) DARFON KEYBOARD 14_15KB-EV2 89KS BLACK NORWEGIAN (BIG ERGO) DARFON Acer Part No. KH.08001.030 KH.08007.021 KH.08008.033 KH.12001.031 KH.12007.010 KH.12008.018 KH.16001.026 KH.16007.011 KH.16008.019 KB.INT00.002 KB.INT00.003...
  • Page 147 GLARE W/ ANTENNA & 0.3M CAMERA LCD 15.4” WXGA AU B154EW02-V0 NONE GLARE LCD 15.4” WXGA LG LP154WX4- TLA2 NONE GLARE LCD MODULE 15.4” WXGA GLARE W/ ANTENNA & 0.3M CAMERA Acer Part No. KB.INT00.018 KB.INT00.019 KB.INT00.020 KB.INT00.023 KB.INT00.024 KB.INT00.025 KB.INT00.026 KB.INT00.029...
  • Page 148 SDIMM 1GB DDRII533 SAMSUNG M470T2953EZ3-CD5 LF SDIMM 1GB DDRII667 HYNIX HYMP512S64CP8-Y5 LF SDIMM 1GB DDRII667 PROMOS V916765G24QBFW-F5 LOGO PLATE FOR PANEL LOGO PLATE FOR BEZEL NAME PLATE TM5710 Acer Part No. LK.15405.014 LK.15408.028 57.TK501.001 57.TK901.001 57.TKC01.001 25.TK901.001 25.TK901.002 23.TK901.003 MB.TK401.001 MBTK601.001...
  • Page 149 SCREW M2.5 x 5 NI SCREW MACH WAFER M3 x L4 NI SCREW M2.5 x L5 BLACK ZN+NYLOK SCREW DIMM COVER STEEL SCREW M2 x 4 WAFER NI SCREW NI M2 x L6 Acer Part No. 40.TK601.001 47.TK501.001 86.00C07.220 86.00E33.736 86.00E34.738 86.TK901.001 886.9A524.4R0...

  • Page 150: Travelmate 5520/5520G/5220/5220G Series

    Model Definition and Configuration TravelMate 5520/5520G/5220/5220G Series Acer Model Country Part AS505 India LX.AV AS5051AN 1ANW 30C.0 WXMi LINPUSIL1 UMAC 1*512/80/ 6L/5R/ CB_bg_0.3 C_AN AS505 Indonesia LX.AV AS5051AN 1ANW 30C.0 WXMi LINPUSIN1 UMAC 1*512/80/ 6L/5R/ CB_bg_0.3 C_AN AS505 Malaysia LX.AV...
  • Page 151 Acer Model Country Part AS505 USA/ LX.AV 1AWX Canada - 30J.00 Canadian French AS505 USA/ LX.AV 1AWX Canada - 30J.00 Canadian French AS505 Australia/ LX.AV 1AWX 305.00 Zealand AS505 USA/ LX.AV 1AWX Canada 305.00 AS505 ACLA- LX.AV 1AWX Spanish 305.01...
  • Page 152 Acer Model Country Part AS505 Thailand LX.AV 1AWX 305.00 AS505 Vietnam LX.AV 1AWX 305.00 AS505 Singapore LX.AV 1AWX 305.00 AS505 ACLA- LX.AV 1AWX Portuguese 305.01 AS505 GCTWN S2.AV 1AWX 305.00 AS505 GCTWN S2.AV 2WXM 305.00 AS505 GCTWN S2.AV 5WXM 305.00...
  • Page 153 Acer Model Country Part AS505 GCTWN LX.AV 1AWX 305.01 AS505 GCTWN LX.AV 1AWX 305.01 AS505 GCTWN LX.AV 1AWX 305.01 AS505 Australia/ LX.AV 1AWX 30J.01 Zealand AS505 Singapore LX.AV 1AWX 30J.01 AS505 India LX.AV 1AWX 30J.01 AS505 Indonesia LX.AV 1AWX 30J.01...
  • Page 154 Acer Model Country Part AS505 Thailand LX.AV 1AWX 30J.01 AS505 Vietnam LX.AV 1AWX 30J.01 AS505 Australia/ LX.AV 1AWX 306.00 Zealand AS505 Australia/ LX.AV 2WXM 30J.00 Zealand AS505 India LX.AV 2WXM 30J.00 AS505 Indonesia LX.AV 2WXM 30J.00 AS505 Singapore LX.AV 2WXM 30J.00...
  • Page 155 Acer Model Country Part AS505 Thailand LX.AV 2WXM 30J.00 AS505 Vietnam LX.AV 2WXM 30J.01 AS505 Australia/ LX.AV 2WXM 306.00 Zealand AS505 India LX.AV 1ANW 30C.0 AS505 Vietnam LX.AV 1ANW 30C.0 AS505 Thailand LX.AV 1ANW 30C.0 AS505 Singapore LX.AV 1ANW 30C.0...
  • Page 156 Acer Model Country Part AS505 Philippines LX.AV 1ANW 30C.0 AS505 Malaysia LX.AV 1ANW 30C.0 AS505 Thailand LX.AV 1ANW 30C.0 AS505 Thailand LX.AV 2WXM 30J.01 AS505 EMEA Belgium LX.AV 1AWX 30J.03 AS505 EMEA Middle LX.AV 1AWX East 30J.04 AS505 EMEA Middle LX.AV...
  • Page 157 Acer Model Country Part AS505 EMEA Eastern LX.AV 1AWX Europe 30J.03 AS505 EMEA Denmark LX.AV 1AWX 30J.02 AS505 EMEA France LX.AV 1AWX 30J.02 AS505 EMEA Germany LX.AV 1AWX 30J.02 AS505 EMEA Germany LX.AV 1AWX 30J.02 AS505 EMEA Holland LX.AV 1AWX 30J.03...
  • Page 158 Acer Model Country Part AS505 EMEA Slovenia/ LX.AV 1AWX Croatia 30J.03 AS505 EMEA Portugal LX.AV 1AWX 30J.03 AS505 EMEA Sweden/ LX.AV 1AWX Finland 30J.02 AS505 EMEA Turkey LX.AV 1AWX 30J.04 AS505 EMEA Switzerland LX.AV 1AWX 30J.04 AS505 EMEA LX.AV 1AWX 30J.04...
  • Page 159 Acer Model Country Part AS505 EMEA France LX.AV 1AWX 30J.02 AS505 EMEA Belgium LX.AV 1AWX 305.01 AS505 EMEA Middle LX.AV 1AWX East 305.03 AS505 EMEA Eastern LX.AV 1AWX Europe 305.02 AS505 EMEA Germany LX.AV 1AWX 305.02 AS505 EMEA Greece LX.AV 1AWX 305.03...
  • Page 160 Acer Model Country Part AS505 EMEA Holland LX.AV 1AWX 305.02 AS505 EMEA France LX.AV 1AWX 305.02 AS505 EMEA Eastern LX.AV 1AWX Europe 305.02 AS505 EMEA Spain LX.AV 1AWX 305.03 AS505 EMEA Slovenia/ LX.AV 1AWX Croatia 305.03 AS505 EMEA Eastern LX.AV...
  • Page 161 Acer Model Country Part AS505 EMEA South LX.AV 1AWX Africa 305.01 AS505 EMEA Norway LX.AV 1AWX 305.02 AS505 EMEA Russia LX.AV 1AWX 305.02 AS505 EMEA Sweden/ LX.AV 1AWX Finland 305.02 AS505 EMEA France LX.AV 1AWX 305.02 AS505 EMEA Italy LX.AV 1AWX 305.03...
  • Page 162 Acer Model Country Part AS505 USA/ LX.AV 2WXM Canada - 30J.02 Canadian French AS505 ACLA- LX.AV 2WXM Spanish 30J.02 AS505 ACLA- LX.AV 1AWX Spanish 30J.04 AS505 Australia/ LX.AV 1ANW 30C.0 Zealand AS505 Malaysia LX.AV 1AWX 305.04 AS505 Malaysia LX.AV 1ANW 30C.0...
  • Page 163 Acer Model Country Part AS505 EMEA Russia LX.AV 1AWX 30J.05 AS505 EMEA Holland LX.AV 1AWX 30J.05 AS505 EMEA Russia LX.AV 1AWX 305.04 AS505 EMEA Sweden/ LX.AV 1AWX Finland 30J.05 AS505 EMEA Slovenia/ LX.AV 1AWX Croatia 30J.05 AS505 Thailand LX.AV 2NWX 30C.0...
  • Page 164 Acer Model Country Part AS505 EMEA Middle LX.AV 1ANW East 30C.0 AS505 EMEA France LX.AV 1ANW 30C.0 AS505 EMEA Russia LX.AV 1ANW 30C.0 AS505 EMEA Middle LX.AV 1AWX East 305.04 AS505 EMEA Eastern LX.AV 1AWX Europe 30J.05 AS505 EMEA Russia LX.AV...
  • Page 165 Acer Model Country Part AS505 EMEA Switzerland LX.AV 1AWX 30J.06 AS505 EMEA Portugal LX.AV 1AWX 30J.06 AS505 EMEA Spain LX.AV 1AWX 30J.06 AS505 EMEA Germany LX.AV 1AWX 30J.06 AS505 EMEA Germany LX.AV 1AWX 30J.06 AS505 EMEA Middle LX.AV 1AWX East 30J.07...
  • Page 166 Acer Model Country Part AS505 EMEA Holland LX.AV 1AWX 30J.06 AS505 EMEA Italy LX.AV 1AWX 30J.07 AS505 EMEA Denmark LX.AV 1AWX 30J.07 AS505 EMEA France LX.AV 1AWX 30J.06 AS505 EMEA Norway LX.AV 1AWX 30J.07 AS505 EMEA Norway LX.AV 1AWX 30J.07...
  • Page 167 Acer Model Country Part AS505 EMEA Eastern LX.AV 1AWX Europe 30J.06 AS505 EMEA Sweden/ LX.AV 1AWX Finland 30J.06 AS505 EMEA LX.AV 1AWX 30J.08 AS505 EMEA LX.AV 1AWX 30J.08 AS505 EMEA Turkey LX.AV 1AWX 30J.07 AS505 EMEA Italy LX.AV 1AWX 30J.07...
  • Page 168 Acer Model Country Part AS505 EMEA Germany LX.AV 1AWX 305.05 AS505 EMEA Middle LX.AV 1AWX East 305.06 AS505 EMEA Denmark LX.AV 1AWX 305.04 AS505 EMEA Belgium LX.AV 1AWX 305.05 AS505 EMEA Eastern LX.AV 1AWX Europe 305.05 AS505 EMEA LX.AV 1AWX 30J.08...
  • Page 169 Acer Model Country Part AS505 EMEA Greece LX.AV 1AWX 305.05 AS505 EMEA Israel LX.AV 1AWX 305.06 AS505 EMEA France LX.AV 1AWX 305.04 AS505 EMEA Italy LX.AV 1AWX 305.05 AS505 EMEA Eastern LX.AV 1AWX Europe 305.05 AS505 EMEA Holland LX.AV 1AWX 305.06...
  • Page 170 Acer Model Country Part AS505 EMEA Russia LX.AV 1AWX 305.04 AS505 EMEA Sweden/ LX.AV 1AWX Finland 305.05 AS505 EMEA Slovenia/ LX.AV 1AWX Croatia 305.06 AS505 EMEA Portugal LX.AV 1AWX 305.06 AS505 EMEA Switzerland LX.AV 1AWX 305.06 AS505 EMEA LX.AV 1AWX 305.06...
  • Page 171 Acer Model Country Part AS505 India LX.AV 2NWX 30C.0 Descriptio DIMM DIMM AS5052N ATTL5 N14.1 SO512 WXMi WXGA MBII5 LINPUSIL1 UMAC 1*512/80/ BT/6L/5R/ CB_bg_0.3 C_AN Wirele HDD 1 Blueto VOIP (GB) Phone N80G NSM8 ABT_ FOX_ B5.4K ATH54 BRM_ 13BG...
  • Page 172 Appendix A...

  • Page 173: Test Compatible Components

    Appendix B Test Compatible Components This computer’s compatibility is tested and verified by Acer’s internal testing department. All of its system ® ® functions are tested under Windows XP Home, Windows XP Pro environment. Refer to the following lists for components, adapter cards, and peripherals which have passed these tests.

  • Page 174: Microsoft® Windows® Vista Environment Test

    USB Flash Drive USB HDD ® Vista Environment Test Device Name Acer 211c 21”, ViewSonic G220F, ViewSonic PF790 19”, Sony TV Trinitron (S-Video) Acer FP751 17” TFT LCD, Acer AL1521, Acer AL1721, ViewSonic VD201b, Westinghouse W37G, HP LP2065, HP S9500 Dell 3300MP...
  • Page 175 Item USB ODD IR Test IR Printer IR Mobile Phone 1394 Test 1394 Storage Drive 1394 Camera 1394 Hub Access Point 802.11a Access Point 802.11b Access Point 802.11g Access Point 802.11n Bluetooth Test Bluetooth Device PCMCIA Test LAN/Modem Card Storage Card 1394 Card USB2.0 Card GPRS Card...
  • Page 176 Item Memory Card Test (SD/MS/MMC/SM/CF/Microdrive/XD) SD Card MS Card MMC Card XD Card Device Name Apacer 128/256MB Transcend 256MB SanDisk 256MB Apacer 2GB (150x Hi-Speed) KINGMAX 1GB (66x Hi-Speed) SanDisk 1GB RiDATA 4GB SD PRO Memory Card I-O DATA 64MB MS Apacer 128MB MS Sony 512 MS PRO Lexar 512MB MS PRO...

  • Page 177: Online Support Information

    This section describes online technical support services available to help you repair your Acer Systems. If you are a distributor, dealer, ASP or TPM, please refer your technical queries to your local Acer branch office. Acer Branch Offices and Regional Business Units may access our website. However some information sources will require a user i.d.
  • Page 178 Appendix C...

  • Page 179: Index

    AFLASH Utility Antennas Audio Battery Pack BIOS package password control ROM size ROM type vendor Version BIOS Supports protocol 39–51 BIOS Utility Navigating Onboard Device Configuration 43, 45 Security System Security Board Layout Top View brightness hotkeys Cache controller size caps lock on indicator CardBus...
  • Page 180 LCD Brackets LCD Module Disassembly Flowchart LCD with the Brackets lower cover Main Unit Disassembly Flowchart Mainboard media access on indicator Memory Check Middle Cover and Power Board Model Definition Modem Board Notebook Manager hotkey num lock on indicator Online Support Information optical drive module Panel Bottom...

This manual is also suitable for:

5520 5929 - travelmate - turion 64 x2 2 ghzTravelmate 5520 seriesTravelmate 5220 seriesTravelmate 5220g series5520g

Table of Contents
