- Page 1 VSN# MS49-096-035-02 Instruction Manual 28” Round Steel Fire Pit Questions, problems, missing parts? Before returning to the store, Call Yayi Customer Care. at 855-600-9294 From 9:00 AM to 5:00 EST or email customercare@china-yayi.com...
- Page 2 VSN# MS49-096-035-02 Safety Information: PLEASE READ AND UNDERSTAND THIS ENTIRE MANUAL BEFORE ATTEMPTING TO ASSEMBLE, OPERATE OR INSTALL THE PRODUCT. Warnings: This fire bowl is intended for outdoor use only, never burn in vehicles, tents or indoor. Do not use the fire bowl to cook food, the fire bowl is not designed for grilling food.
-
Page 3: Hardware List
VSN# MS49-096-035-02 FIRE PIT PARTS LIST PARTS Handle HARDWARE LIST Safety Mesh Screen Wood Grate Fire Bowl Hardware Legs M6 Nut Fix Ring M6x8mm Bolt Poker M6x16mm Bolt Cover Page No.3... - Page 4 VSN# MS49-096-035-02 Step By Step Assembly Instructions: Step 1: Insert Handle (A) into hole in Safety Mesh Screen (B) and tighten it with M6 Nut (AA) underside to secure. Step 2: Connect the Legs (E) to the Fire Bowl (D) by using M6 x 8mm bolt (BB), Please DO NOT tighten the hardware at this time.
- Page 5 VSN# MS49-096-035-02 Step 3: Attach Fix Ring (F) to the Legs (E) by using M6 x 16mm Bolt (CC). Tighten all the hardware at this time. Step 4: For fire pit use, put Wood Grate(C) into Fire Bowl (D), and then put Safety Mesh Screen (B) onto the Fire Bowl (D).
- Page 6 VSN# MS49-096-035-02 Operating Instruction: WARNING: Before using this outdoor Fire pit , make sure you have read, understand and are following all information provided in the important Safeguards presented on page 2. Failure to Follow those instructions can cause death, serious injury or property damage.
- Page 7 VSN# MS49-096-035-02 Maintenance: To extend the life of your fire pit, clean it after each use. To Protect fire pit finish, use a soft cloth in lieu of bare hands while handling. Clean the fire bowl after each use once ashes have cooled.
