TM 4670/4270/4210 Outlook View

A general introduction of ports allow you to connect peripheral devices, as you would with a desktop PC.

Open View

#
#
1 Display screen
2 Microphone
3 Keyboard
4 Touchpad
5 Click buttons
(Left, center and
right)
6 Palmrest
7 Power button
8 Easy-launch buttons Buttons for launching frequently used programs.
9 Status indicators
Chapter 1
Item Description
Item
Also called Liquid-Crystal Display (LCD), displaying computer
output.
Internal microphone for sound recording.
Inputs data into your computer.
Touch-sensitive pointing device which functions like a
computer mouse.
The left and right buttons function like the left and right mouse
buttons; the center button serves as a 4-way scroll button.
Comfortable support area for your hands when you use the
computer.
Turns the computer on and off.
Light-Emitting Diodes (LEDs) that turn on and off to show the
status of the computer's functions and components.
