Table Of Contents; Hoist Specifications - Coffing Hoists ELC Series Operating, Maintenance & Parts Manual

Safety Precautions ......................................................................................................................................................................2
Hoist Specifications.....................................................................................................................................................................3
Application Information ...............................................................................................................................................................4
Safety Information .......................................................................................................................................................................4
Installation ...................................................................................................................................................................................4
Operation ....................................................................................................................................................................................6
Maintenance ...............................................................................................................................................................................6
Trouble Shooting .......................................................................................................................................................................12
Wiring Diagrams .......................................................................................................................................................................13
Inspection and Maintenance Check List ...................................................................................................................................16
Recommended Lubrication Schedule.......................................................................................................................................17
Replacement Parts List.............................................................................................................................................................18
Parts Depot & Warranty Repair Centers...................................................................................................................................34
Warranty .....................................................................................................................................................................Back Cover
Coffing ELC series electric chain hoists are rugged, portable
hoists that provide quick, precise lifting. The hoists are
constructed of tough, but lightweight, die cast aluminum alloy
housings. An oil bath transmission, equipped with heat-treated,
alloy steel gears and an overload limiting clutch, provides
smooth and reliable operation. With a pushbutton station that
fits comfortably in one hand, the operator can safely control the
hoist while the other hand is free to guide the load. The
electrical controls use a low voltage circuit (24V standard,
115V optional). Terminal blocks allow for easy voltage
conversions on dual-voltage models.
Other features that ensure the safe operation of Coffing electric
chain hoists include a magnetic disc brake that delivers sure
stopping and secure holding of the load. Adjustable upper and
lower limit switches regulate the load travel. As a standard,
hooks are supplied with safety latches. For additional safety,
a chain stop is attached to the slack end of the load chain.
Coffing electric chain hoists are designed and tested in
accordance with the American Society of Mechanical
Engineers Code B30.16, "Safety Standard for Overhead
Hoists." Hoists are built in compliance with CSA, file number
LR 44484. Made in U.S.A.
Table 1 - Hoist Specifications
Lifting
Model* Capacity Speed
(lbs) (fpm)
ELC0232 250
ELC0516 500
ELC0532 500
ELC1016 1000
ELC1032 1000
ELC2016 2000
ELC4008 4000
*Note: ELCET models are equivalent to the corresponding ELC, but
are supplied with a push-type trolley. Reference in this manual
to ELC models also applies to ELCET models.

TABLE OF CONTENTS

HOIST SPECIFICATIONS

HP Reeving
32 1/4 Single-chained
16 1/4 Single-chained
32 1/2 Single-chained
16 1/2 Single-chained
32 1 Single-chained
16 1 Single-chained
8 1 Double-chained
Table 2 - Motor Amperage of 1-Speed Hoist Models
Full Load Amps
Hoist 1-Phase
Horsepower 115/230V
1/4 HP 4.3/2.2
1/2 HP 7.6/3.8
1 HP 14/7*
* The 1HP, 115/230V models (ELC1032-1, ELC2016-1,
ELC4008-1) must have a dedicated power circuit rated for at
least 20A, 125V when they are wired for 115V. It is not
unusual for these models to draw up to 20 amps at 115V
when lifting at rated capacity depending on the quality of the
voltage source.
Table 3 - Motor Amperage of 2-Speed Hoist Models
Hoist Full Load Amps (fast/slow)
Horsepower
(fast/slow) 208V 230V
.25/.083 1.2/1.3 1/1.1
.5/.17 1.9/2.4 1.7/2.1
1/.33 3.6/4.3 3.2/3.8
NOTE: The above data is the nominal motor current at full
load. At full load, it is not unusual for the hoist to draw
in excess of the values listed when lifting. It is critical to ensure
that the voltage at the reversing contactor does not drop below
10% of the nominal voltage while lifting a load. Low voltage will
result in higher amp draw, damage to the hoist, and potential
fire hazards. Coffing Hoists is not responsible for any damages
caused by an inadequate power source.
Failure to comply with Safety Precautions outlined
throughout this manual can result in serious injuries
or death. Before using this hoist, each operator
should become thoroughly familiar with all warnings,
instructions and recommendations in this manual.
3
Country Club Road
P.O. Box 779
Wadesboro, NC 28170 USA
TEL: (800) 477-5003
FAX: (800) 374-6853
3-Phase
208V 230/460V 380V 575V
1.3 1.2/.6 .73
2.3 2/1 1.2
3.6 3.2/1.6 1.9
3-Phase Only
380V 460V 575V
.61/.67 .5/.55 .4/.44
1.1/1.3 .88/1.1 .7/.85
1.9/2.3 1.6/1.9 1.3/1.5
.35
.76
1.2
