Connecting the Power Cords
Uniden recommends connecting the power lead to the Ignition Switch
Accessory Terminal. This way, the transceiver is automatically turned off
when the ignition switch is turned off.
As an alternative, the power cord may be connected to an available
terminal on the fuse block or to a point in the wiring harness. However,
take care to prevent a short circuit. If in doubt, contact your vehicle
dealer for information.
This transceiver may be installed and used in any 12-volt DC negative
ground system vehicle.

Ground Information

Most newer U.S. and foreign made cars and small trucks use a negative
ground system. Some older cars, and some new large trucks, use a
positive ground system.
With a negative ground system, the negative (-) battery terminal is
usually connected to the vehicle motor block. If you cannot determine
the polarity system of your vehicle, contact your vehicle dealer for
information.
Negative Ground System
For negative ground systems, connect the red DC power cord from the
transceiver to the positive (+) battery
terminal or other convenient point.
Then connect the black power cord
to the vehicle chassis or negative (-)
battery terminal.
9
