U-Line U-2224WCINT-00A User Manual & Service Manual page 45

Parts
2
16
10
6
5
9
14 15
1
19
7
22
39
11
3 4
24
Item
21
1 Anti tip brackets w/screws
8
2 Back panel
3 Compressor electricals only
4 Compressor w/electricals
5 Condenser assembly
6 Condenser fan w/screws
30 32
7 Display module
8 Door assembly w/o hinges
9 Drain pan w/double sided tape
10 Drain trough assembly
12 13
11 Drier
34 35
12 Evaporator assembly
13 Evaporator cover
27
14 Evaporator fan
15 Evaporator fan w/cover and screws
17 16 Frame assembly
17 Gasket, door, injection molded
29
18 Grille w/ screws
19 Hinge covers (2 pcs)
28 33
20 Hinge mounting hole covers(2)
21 Hinges (2) w/screws and covers
22 LED light strip and cover assy
18
23 Leg Levelers (4)
24 Main board (no case or wires)
23
25 Packaging
26 Power cord
27 Rack assembly
28 Rack assembly bottom
29 Rack Assembly, lower
30 Rack Assembly, middle
31 Reed switch
32 Slide assembly, long
33 Slide assembly, short
34 Thermistor (1 pc)
35 Thermistor cover and pin
36 Tool, leg leveler
37 WIFI antenna
38 Wire Harness, board
39 Wood fronts w/screws
45
U-2224WCINT-00A
Description U-Line P/N
80-54012-00
80-54086-00
80-54149-00
80-54193-00
80-54043-00
80-54014-00
80-54007-00
80-54085-00
80-54217-00
80-54399-00
80-54055-00
80-54057-00
80-54042-00
80-54321-00
80-54151-00
80-54820-00
80-54039-00
80-54040-00
80-54001-00
80-54024-00
80-54013-00
80-54000-00
80-54019-00
80-54008-00
80-54159-00
80-54171-00
80-54010-00
80-54091-00
80-54817-00
80-54818-00
80-54134-00
80-54047-00
80-54048-00
80-54006-00
80-54023-00
80-54794-00
80-54804-00
80-54251-00
80-54498-00
Parts 1
