4015
4015 Marine Automatic
Antenna Tuner
Operating Manual
BCM401500/01
© Barrett Communications
Head Office:
Barrett Communications Pty Ltd
47 Discovery Drive, Bibra Lake, WA 6163 Australia
Tel: +61 8 9434 1700 Fax: +61 8 9418 6757
Email: information@barrettcommunications.com.au
www.barrettcomms.com
Advertisement
Table of Contents
Related Manuals for Barrett 4015
Summary of Contents for Barrett 4015
- Page 1 4015 4015 Marine Automatic Antenna Tuner Operating Manual BCM401500/01 © Barrett Communications Head Office: Barrett Communications Pty Ltd 47 Discovery Drive, Bibra Lake, WA 6163 Australia Tel: +61 8 9434 1700 Fax: +61 8 9418 6757 Email: information@barrettcommunications.com.au www.barrettcomms.com...
-
Page 2: Table Of Contents
Ground (Earth) System ..................... 8 Corrosion ........................... 9 Electrical Checkout ......................9 Connection Details For a 4050 Transceiver and 4015 Automatic Antenna Tuner in a Marine Installation ..................10 Setting the Tuner in a 4050 ..................12 Connector ........................ 13 Control Connector ...................... -
Page 3: Introduction
The 4015 ATU features a memory facility that stores the configuration required to tune to a frequency. On any subsequent use of that frequency, the 4015 reconfigures to the stored settings in, typically, less than 130 milliseconds. Fol- lowing initial tuning, the antenna’s VSWR is monitored. -
Page 4: Installation
4015 MARINE AUTOMATIC ANTENNA TUNER Installation The Barrett 4015 automatic antenna tuner is designed for use in land base sta- tion and maritime HF services. Primarily designed for operation with end-fed unbalanced antennas such as whips and long wires, the tuner is built in a water- proof impact resistant, moulded ABS plastic enclosure. -
Page 5: Antenna
4015 MARINE AUTOMATIC ANTENNA TUNER Antenna On sailing vessels the antenna can either be an insulated backstay or a whip antenna mounted vertically, usually on the stern. Best performance will be achieved by using an insulated backstay as the radiating length will be longer than that available when using a whip. - Page 6 Tuner positions Good - High position Better - Mid position Best - Low position Antenna wire positions Best - Two-wire Better - Inverted L Good - Vertical inverted L Please contact Barrett Communications with your vessel’s specifications for addi- tional assistance.
-
Page 7: Transceiver And Tuner Mounting
4015 MARINE AUTOMATIC ANTENNA TUNER Transceiver and Tuner Mounting Select a suitable position in the vessel to mount the transceiver. It should be a position that is out of the weather and easily accessible to the operator, whilst as close as practical to the 13.8 V DC power source. -
Page 8: Ground (Earth) System
Ideally the vessel should be fitted with an external copper ground (earth) sheet, connected to the interior of the vessel by suitable stud or an ground (earth) plate (“E” plate Barrett P/N BCA91700) Should neither of these methods be available, acceptable ground points include stainless steel stanchion, through mast, through hull or a metal water tank. -
Page 9: Corrosion
When received, the Barrett 4015 automatic antenna tuner memory system will usually not have any pre-stored tuning information appropriate to your installation. To allow the 4015 to ‘learn’ its tuning information simply proceed from one channel to the next allowing the normal tune cycle to take place. -
Page 10: Connection Details For A 4050 Transceiver And 4015 Automatic Antenna Tuner In A Marine Installation
4015 MARINE AUTOMATIC ANTENNA TUNER Connection Details For a 4050 Transceiver and 4015 Automatic Antenna Tuner in a Marine Instal- lation... - Page 11 10000V that can occur in HF transmission. Flexible 56/0.30 stranding. Feed Through Insulator (P/N BCA91701) Barrett 4015 Marine Automatic Antenna Tuner (P/N BC401500) Copper Earth Strap 50 mm (w) x 0.5 mm (d) x appropriate length Control cable 6 m - integral coaxial/control with connectors to suit...
-
Page 12: Setting The Tuner In A 4050
4015 MARINE AUTOMATIC ANTENNA TUNER Setting the Tuner in a 4050 From the Settings menu of a Barrett 4050 HF SDR Transceiver, select I/O followed by Antenna 1 type (if using in the antenna 1 position. Settings Select 4011/4015 Auto Tuner. -
Page 13: Connector
4015 MARINE AUTOMATIC ANTENNA TUNER Connector Control Connector Signal Level A. GND and shield Ground and cable shield Unused Unused Unused Unused D. Scan ATU Scan line Tuned ATU Tuned signal ATU V+ ATU Voltage 13V8 G. Unused Unused... -
Page 14: Warranty Statement
Warranty Statement Barrett Communications (hereafter referred to as ‘Seller’) provides a three (3) year warranty on all Barrett products from the date of shipment from the Seller. A one (1) year warranty from the date of shipment from the Seller is provided for all batteries. - Page 15 4015 MARINE AUTOMATIC ANTENNA TUNER to ensure that the purchaser receives full benefit on any warranty given by the original equipment manufacturer. This warranty is restricted to the original purchaser except where the original purchaser is a reseller authorised by the Seller who has purchased for the pur- pose of resale, warranty shall be extended to the reseller’s customer.
- Page 16 Head Office: Barrett Communications Pty Ltd 47 Discovery Drive, Bibra Lake, WA 6163, Australia Tel: +61 8 9434 1700 Fax: +61 8 9418 6757 Email: info@barrettcommunications.com.au Europe: Barrett Communications - Europe Unit 9, Fulcrum 2, Solent Way, Whiteley, Hampshire, PO15 7FN, United Kingdom Tel: +44 (0) 1489 880 332 Fax: +44 (0) 1489 565 422 Email: uksales@barrettcommunications.co.uk...
