Summary of Contents for MultiChannel XCLEF MT-200
- Page 1 D I G I T A L A U D I O P L A Y E R M T- 2 0 0 User Manual...
- Page 2 Thank you for purchasing MT-200. Before using this product, please read user manual carefully. It prevents you from wrong operation and let you know use your player more conveniently. Thank you. Notice 1. Please read carefully user manual and keep it well. 2.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Basic Package Installation Manual Installing Software on PC Connecting to PC Installing USB driver Manual Installation of USB Driver Manager Program Manual Program starting Description of menu User Manual Parts Description Structure of display panel (LCD) Inserting Battery & Connecting earphone Power-On Pause / Power-Off Volume Control... -
Page 4: Basic Package
Basic Package MT-200 User Manual Installation CD AAA size battery Earphone USB cable connecting to PC Necklace strap... -
Page 5: Installation Manual Installing Software On Pc
Installation Manual Installing Software on PC Insert the installation CD into your CD Rom. Click <Next> and install DIGITAL AUDIO MANAGER. Click <Finish> and then the installation is complete. Then DIGITAL AUDIO MANAGER will be registered in 'Program' of 'starting menu'. -
Page 6: Connecting To Pc
Connecting to PC ❶ ❷ Connecting to PC 1. Plug one end of USB cable into the USB port on the back of computer. 2. Plug the other end of USB cable into USB port on the player. Notice !! If you connect USB cable while playing, it may cause malfunction. -
Page 7: Installing Usb Driver
Installing USB driver (Automatic) Installing USB driver (Automatic) 1. Plug USB cable to PC. 2. USB driver will be installed with a message saying that it is searching for a new device. 3. If you failed to install USB driver, restart your PC and try again. (If USB driver is not installed at the second attempt, contact your PC manufacturer.) 4. -
Page 8: Manual Installation Of Usb Driver
Manual Installation of USB Driver If USB driver does not install automatically, there is not "USB FOR DIGITAL AUDIO DEVICE" in <System Properties> --> <Device Manager> Connect the player to PC to install the driver manually. 1. Windows XP Follow the below sequence. If you complete installation, Click <Finish>... - Page 9 2. Windows 98 Follow the below sequence.
- Page 10 3. Windows 2000 Follow the below sequence.
-
Page 11: Manager Program Manual
Manager Program Manual Program starting Click DIGITAL AUDIO MANAGER. If you start Manager Program, you will see the above screen. -
Page 12: Description Of Menu
Description of menu FILE EXIT PROGRAM EXIT OPERATION DOWNLOAD SELECTED FILES Download selected data or files in PC into IN PC TO PLAYER internal/external memory (Drag & Drop) UPLOAD SELECTED FILES Upload selected data or files in internal/external IN PLAYER TO PC memory into PC (Drag &... -
Page 13: User Manual
User Manual Parts Description 1. Rec : Voice Recording / Repeat (A <-> B) 2. Mode : Conversion Audio mode into Voice mode and vice versa / Repeat / EQ Setting etc. 3. Hold : Button lock 4. Earphone Jack 5. - Page 14 Parts Description 13. SMC card Eject Plate 14. Battery Lock Plate 15. Battery Cover 16. Insert SMC card in right direction as shown...
-
Page 15: Structure Of Display Panel (Lcd)
Structure of display panel (LCD) 1. BATTERY indicator 2. PLAY TYPE indicator 3. SMC CARD indicator and shown only if SMC card is inserted 4. HOLD Indicator 5. REPEAT MODE indicator 6. REPEAT SETTING indicator 7. PLAY STATUS indicator 8. PLAYING TIME indicator 9. -
Page 16: Inserting Battery & Connecting Earphone
Inserting Battery & Connecting earphone ❶ Hold off battery lock plate. ❷ Push battery cover on your right side to open it.. ❸ Insert "AAA" battery as shown. ❹ Push the battery cover on your left side to close it. ❺... -
Page 17: Power-On
Power-On ❶ Press " ▶" button shortly. ❷ Upon turning on the power, a music starts immediately. (Autoplay) -
Page 18: Pause / Power-Off
Pause / Power-Off ❶ If you press "▶" button shortly while playing, the music stops. ❷ Then press "▶" button again for more than 2 seconds, and the player will be "Power Off". -
Page 19: Volume Control
Volume Control ❶ Press Vol. +/- on the left side of the player to adjust the volume with 0~30 figures while playing. -
Page 20: Fast Backward / Fast Forward
Fast Backward & Fast Forward ❶If you're pressing " ◀◀" or "▶ ▶" button while playing, Fast Backward or Fast Forward works. -
Page 21: Moving To The First Of The Song
Moving to the first of the song ❶ When you press " ◀◀ " or "▶ ▶" button shortly while playing, you can move to the first of the song. * Note : This feature does not work if playing time passed over 5 seconds. -
Page 22: Loop Repeating
Loop Repeating ❶ While playing music, press the "Rec." button shortly at the beginning of the loop you want to set. "A▶" flickers in the display ❷ Press the "Rec." button shortly again at the end of the loop you want. "A▶B"... -
Page 23: Previous / Next Track
Previous / Next Track ❶ Press "▶ ▶" button shortly, if you want to move next song(track). ❷ Press "◀ ◀" button shortly, if you want to move previous song(track). -
Page 24: Deleting Files
Deleting Files ❶ Press "Rec." button long while playing, current playing song is deleted. -
Page 25: Intro On / Off
Intro On / Off ❶ If you press "▶" button long, each music is played in sequence for 10 seconds. ❷ Press the "▶" button again to exit from Intro mode. -
Page 26: Mode Setting
MODE Setting ❶ Press "▶" button shortly to pause music while playing. ❷ Then press MODE button long and will be converted into MODE setting mode. ❸ Select item of MODE using Vol. +/-. ❹ Select detail function using "◀◀" or "▶▶ " button. ❺... - Page 27 Items of Mode Detail Functions Remark Type < music play mode AUDIO> (Play mode) < voice recording & voice play mode VOICE> REPEAT < repeat 1 song 1SONG> < repeat all ALL> PLAY-M Play only once <Normal> <Auto-reverse> Infinity repeat <Intro>...
-
Page 28: Eq Setting & Navigation While Playing
EQ Setting & Navigation while playing EQ Setting ❶ Press MODE button shortly while playing. ❷ EQ lamp of display panel flicks, then change EQ pressing "◀ ◀" or "▶ ▶" button. ❸ After setting, press MODE button shortly to exit. Navigation ❹... -
Page 29: Recording Function (Voice Recording)
Recording function (Voice Recording) Mike ❶ Press "▶" button to stop music while playing. ❷ "Recording now..." is appeared on the display panel when pressing "Rec." button longer than 2 seconds, and recording starts.When recording voice, voice file is created automatically. ❸... -
Page 30: Playback & Deleting Voice File(S)
Playback & Deleting Voice file(s) ❶ ❷ 1. Playback of recorded file is the same as playback of music file. Select a file using "◀ ◀" or "▶▶ " and then press "▶" for playback. ❸ When deleting a voice file that is playing currently, press "Rec" button longer than 2 seconds. -
Page 31: Returning To Audio Mode
Returning to Audio Mode ❶ Press "▶" button shortly to pause while playing a voice file. And press "Mode" button long to be in MODE setting mode. ❷ Press vol. "+/-" button to select TYPE. ❸ Press "◀◀ " or "▶▶ " button to change into "Audio" mode. ❹... -
Page 32: Hold On/Off
Hold On/Off Hold-On Hold-Off ❶ Slide the "hold" switch on your left side for Hold-On. ❷ Slide the "hold" switch on your right side for Hold-Off. -
Page 33: Troubleshooting
Troubleshooting Cause and Action Problem - Check battery is inserted correctly - Check the battery is exhausted out The power will not turn on - The player may not operate normally in a cold weather. If temperature goes up, it works - Check "Hold"... -
Page 34: Technical Specifications
Technical Specifications M T - 2 0 0 Specifications MPEG 1/2/2.5 LAYER 3 Playback Supported MP3 file format 32Kbps ~ 320Kbps & VBR(Variable Bit Rate) MP3 Bit Rate 16/22.05/24/32/44.1/48KHz MP3 Sampling Frequency WMA playback (64Kbps ~ 128Kbps) WMA supported 64/128/256MB Internal (built-in) memory User Selectable (8/16/32Kbps) Voice Recording supported... -
Page 35: Limited Warranty
Limited Warranty 1. This product is manufactured under strict quality system. 2. We guarantee the product against defects in material and workmanship within 1 year from the date of purchase. 3. This guarantee does not cover any incompatibilities, user needs to pay for repair charge within guarantee period or after guarantee period. - Page 36 FCC NOTICE THIS DEVICE COMPLIES WITH PART 15 OF THE FCC FULES. OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITION: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDERSIRED OPERATION. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 37 PRINTED IN KOREA. R20020521MT200...
