  • Page 2 Foreword Congratulations on choosing a SUBARU vehicle. This Owner’s Manual has all the information necessary to keep your SUBARU in excellent condition and to properly maintain the emission control system for minimizing emission pollutants. We urge you to read this manual carefully so that you may understand your vehicle and its operation.
  • Page 3 HBF046AA...
  • Page 4 Warranties B Warranties for U.S.A. All SUBARU vehicles distributed by Subaru of America, Inc. and sold at retail by an authorized SUBARU dealer in the United States come with the following warranties: D SUBARU Limited Warranty D Emission Control Systems Warranty...

  • Page 5: Instruments And Controls

    This chapter informs you how to start and operate your SUBARU. Chapter 8: Driving tips This chapter informs you how to drive your SUBARU in various condi- tions and explains some safety tips on driving. Chapter 9: In case of emergency This chapter informs you what to do if you have a problem while driving, such as a flat tire or engine overheating.

  • Page 6: Specifications

    Chapter 11: Maintenance and service This chapter informs you when you need to take your SUBARU to the dealer for scheduled maintenance and informs you how to keep your SUBARU running properly. Chapter 12: Specifications This chapter informs you about dimension and capacities of your SUBARU.

  • Page 7: Safety Precautions When Driving

    J Safety symbol You will find a circle with a slash through it in this manual. This symbol means “Do not”, “Do not do this”, or “Do not let this happen”, depending upon the context. Safety precautions when driving SEATBELT AND SRS AIRBAG WARNING D All persons in the vehicle should fasten their seatbelts BE- FORE the vehicle starts to move.
  • Page 8 deploys could suffer very serious injuries. Because the SRS air- bag needs enough space for deployment, the driver should al- ways sit upright and well back in the seat as far from the steering wheel as practical while still maintaining full vehicle control and the front passenger should move the seat as far back as possible and sit upright and well back in the seat.
  • Page 9 CLOSE TO THE SRS AIRBAG. D Always use the child safety locks whenever a child rides in the rear seat. Serious injury could result if a child accidentally opened the door and fell out. Refer to the “Door locks” section in chapter 2.
  • Page 10 D If at any time you suspect that exhaust fumes are entering the vehicle, have the problem checked and corrected as soon as pos- sible. If you must drive under these conditions, drive only with all windows fully open. DRINKING AND DRIVING WARNING Drinking and then driving is very dangerous.
  • Page 11 If you are taking any drugs, check with your doctor or pharmacist or read the literature that accompanies the medication to determine if the drug you are taking can impair your driving ability. Do not drive after taking any medications that can make you drowsy or otherwise affect your abil- ity to safely operate a motor vehicle.
  • Page 12 MODIFICATION OF YOUR VEHICLE CAUTION Your vehicle should not be modified. Modification could affect its performance, safety or durability, and may even violate govern- mental regulations. In addition, damage or performance problems resulting from modification may not be covered under warranties. DRIVING WITH PETS Unrestrained pets can interfere with your driving and distract your atten- tion from driving.
  • Page 13 Refer to the “Tires and wheels” section in chapter 11 for detailed information. CALIFORNIA PROPOSITION 65 WARNING WARNING Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

  • Page 14: Table Of Contents

    Table of contents Seat, seatbelt and SRS airbags Keys and doors Instruments and controls Climate control Audio Interior and exterior equipments Starting and operating Driving tips In case of emergency Appearance care Maintenance and service Specifications Consumer information and Reporting safety defects Index –...

  • Page 15: Illustrated Index

    Illustrated index J Exterior Hood lock release (page 11-5) Headlight switch (page 3-17) Bulb replacement (page 11-54) Wiper switch (page 3-24) Moonroof (page 2-30) Roof rail (page 6-23) Door locks (page 2-3) Tire pressure (page 11-37) Flat tires (page 9-11) Tire chains (page 8-14) Fog light switch (page 3-22) Tie-down hooks (page 9-22)
  • Page 16 Rear window defogger switch (page 3-26) Fuel filler lid (page 7-4) Child safety locks (page 2-20) Towing hook (page 9-22) Tailgate (page 2-23) Tie-down hooks (page 9-22) Bulb replacement (page 11-52) Licence plate bracket (page 2-24) – CONTINUED – HBF048BB xiii...
  • Page 17 J Interior B Passenger compartment area Lower anchorage for child restraint system (page 2-20) Seatbelt (page 1-14) Parking brake lever (page 7-26) Front seat (page 1-2) Rear seat (page 1-8) HBF049BB...
  • Page 18 Moonroof (page 2-30) Interior lights (page 6-2) Sun visors (page 6-3) Map light (page 6-3) Inside mirror (page 3-28) – CONTINUED – HBF050BB...
  • Page 19 Cup holder (page 6-7) Center console (page 6-5) Glove box (page 6-5) Cigarette lighter (page 6-9) Ashtray (page 6-12) Rear center console (page 6-6) HBF051BB...
  • Page 20 B Cargo bed/spare tire/jack Cargo lamp (page 6-20) Cargo tie-down hooks (page 6-16) Temporary spare tire (page 9-9) HBF053BB Switchback door (page 2-26) Jack/Maintenance tools (page 9-3) Cargo bed extender (page 6-17) – CONTINUED – HBF052BB xvii...

  • Page 21: Door Locks (Page

    J Instrument panel Door locks (page 2-3) Outside mirror (page 3-30) Light control lever (page 3-17) Combination meter (page 3-7) Wiper control lever (page 3-22) Hazard warning flasher switch (page 3-6) Climate control (page 4-1) Gear shift lever (MT) (page 7-11)/Selector lever (AT) (page 7-14) xviii Audio (page 5-1)
  • Page 22 J Light control and wiper control levers/switches Parking light switch (page 3-21) Windshield wiper (page 3-22) Mist (page 3-24) Windshield washer (page 3-24) Wiper control lever (page 3-24) Illumination brightness control (page 3-20) Light control lever (page 3-17) Headlight ON/OFF (page 3-17) Headlight flasher High/Low beam change (page 3-17)

  • Page 23: Combination Meter

    J Combination meter B Overview SRS airbag system warning light (page 3-10) Brake system warning light (page 3-14) Seatbelt warning light (page 3-10) Turn signal indicator light (page 3-16) Door ajar warning light (page 3-15) High beam indicator light (page 3-16) CHECK ENGINE warning light/ Malfunction indicator lamp (page 3-11)
  • Page 24 B Warning and indicator light Mark Seatbelt warning light SRS airbag system warning light AIRBAG CHECK ENGINE warning light/ Malfunction indicator lamp Charge warning light Oil pressure warning light AT OIL temperature warning light (if equipped) ABS warning light Brake system warning light Door ajar warning light Low fuel warning light Front-wheel drive warning light (if equipped)
  • Page 25 ABS (Anti-lock Brake System) ABS warning light ..............Air cleaner element .
  • Page 26 Catalytic converter ............. . . Center console .
  • Page 27 Emergency Locking Retractor (ELR) Engine ................Engine compartment overview Engine coolant .
  • Page 28 Hazard warning flasher Headlight ................Heater operation .
  • Page 29 Maintenance precautions Maintenance schedule Manual heating and air conditioning system Manual transmission ............. Manual transmission oil Map light .
  • Page 30 Rear center console ............. Rear combination lights Rear differential gear oil Rear headrest...
  • Page 31 SRS airbag system monitors SRS airbag system servicing SRS airbag system warning light SRS frontal airbag ..............Starting a flooded engine Starting the engine .
  • Page 32 Treadwear ................Turn signal indicator lights Turn signal lever .
  • Page 33 Seat, seatbelt and SRS airbags Front seats ..............Seat heater (if equipped) Rear seats .

  • Page 34: Front Seats

    Front seats WARNING D Never adjust the seat while driving to avoid the possibility of loss of vehicle control and of personal injury. D Never drive the vehicle with the head restraints removed be- cause they are designed to reduce the risk of serious neck injury in the event that the vehicle is struck from the rear.

  • Page 35: Seat, Seatbelt And Srs Airbags

    adults, their risk of being injured from deployment is greater. For that reason, we strongly recommend that ALL children (including those in child seats and those that have outgrown child restraint devices) sit in the REAR seat properly restrained at all times in a child restraint device or in a seatbelt, whichever is appropriate for the child’s age, height and weight.

  • Page 36: Fore And Aft Adjustment

    Put children in the rearseat properly restrained at all times. B Fore and aft adjustment n Driver’s seat (Power seat) To adjust the seat forward or backward, move the control switch for- ward or backward. Do not recline the seatback while vehicle is moving.
  • Page 37 Seat, seatbelt and SRS airbags n Front passenger’s seat (Manual type) HB1058BA Pull the lever upward and slide the seat to the desired position. Then release the lever and move the seatback and forth to make sure that it is securely locked into place. B Seat cushion angle and height adjustment (Driver’s seat only) HB1078BA HB1062BA...
  • Page 38 B Reclining the seatback Pull the reclining lever up and adjust the seatback to the desired posi- tion. Then release the lever and make sure the seat is securely locked into place. The seatback placed in a reclined position can spring back upward with force when released.

  • Page 39: Seat Heater (If Equipped)

    B Lumbar support Pull the lever forward or backward. Pulling the lever forward will increase the amount of support for your lower back. Seat heater (if equipped) CAUTION D Use of the seat heater for a long period of time while the engine is not running can cause battery discharge.

  • Page 40: Rear Seats

    To turn on the seat heater, push the “LO” or “HI” position on the switch, as desired, depending on the temperature. Selecting the “HI” position will make the seat to heat up quickly. LO: Normal heating HI: Rapid heating The indicator located on the switch comes on when the seat heater is in operation.
  • Page 41 D To avoid the possibility of serious injury or death, passengers must never be allowed to sit on the rear center console while the vehicle is in motion. The rear seat of this vehicle is designed for no more than two passengers and is equipped with only two seat- belts.

  • Page 42: Folding Down The Rear Seat

    J Rear headrest Rear headrest are hot adjustable, nor removable. J Folding down the rear seat WARNING D After returning the rear seat to its original position, be certain to place all of the seatbelts and the tab attached to the seat cush- ion above the seat cushion.
  • Page 43 Seat, seatbelt and SRS airbags B Folding down the seatback HB1109BB HB1110BA 1. Unlock the seatback by pulling the release knob up and then fold the seatback down. B Folding down the seat cushion and seatback 1. Move the front seat forward. 2.
  • Page 44 4. Unlock the seatback by pulling the release knob up and fold the seatback down. Confirm that the pin located at the bottom of the seat cushion is inserted into the slot at the top of the seatback. CAUTION Be careful not to pinch your hand or fingers with the seat cushion or the seatback when performing the fold down operation.
  • Page 45 Seat, seatbelt and SRS airbags 5. To return the rear seat to its original position, raise the seatback and seat cushion until they lock into place and make sure that they are securely locked. Make sure that the rear seatbelt buckles are not under the seat cush- ion or seatback, when returning the seat cushion and the seatback to their original position.

  • Page 46: Seatbelt Safety Tips

    Seatbelts J Seatbelt safety tips WARNING D All persons in the vehicle should fasten their seatbelts BE- FORE the vehicle starts to move. Otherwise, the possibility of se- rious injury becomes greater in the event of a sudden stop or ac- cident.
  • Page 47 According to accident statistics, children are safer when properly restrained in the rear seating positions than in the front seating positions. For instructions and precautions concerning the child restraint system, see the “Child restraint systems” section in this chapter. B Infants or small children Use a child restraint system that is suitable for your vehicle.

  • Page 48: Automatic/Emergency Locking Retractor (A/Elr)

    Expectant mothers also need to use the seatbelts. They should con- sult their doctor for specific recommendations. The lap belt should be worn securely and as low as possible over the hips, not over the waist. J Emergency Locking Retractor (ELR) The driver’s seatbelt has an Emergency Locking Retractor (ELR).

  • Page 49: Fastening The Seatbelt

    This device causes the seatbelt warning light on the instrument panel to light up for about six seconds when the ignition switch is turned to the “ON” position to remind the driver to wear the seatbelt. If the driver’s seatbelt is not fastened, a warning chime sounds at the same time. J Fastening the seatbelt WARNING D Never use a belt that is twisted or reversed.
  • Page 50 Always wear the seatbelts correctly. Adjust the seatback to upright position. Sit well back and upright. CAUTION Metallic parts of the seatbelt can become very hot in a vehicle that has been closed up in sunny weather; they could burn an oc- cupant.
  • Page 51 2. Sit well back in the seat. 3. Pick up the tongue plate and pull the belt out slowly. Do not let it get twisted. If the belt stops before reaching the buckle, return the belt slightly and pull it out more slowly. If the belt still cannot be unlocked, let the belt retract slightly after giving it a strong pull, then pull it out slowly again.
  • Page 52 Always adjust the anchor height so that the shoulder belt passes over the middle of the shoulder without touching the neck. n Unfastening the seatbelt Push HB0303 Push the button on the buckle. Before closing the door, make sure that the belts are retracted prop- erly to avoid catching the belt webbing in the door.

  • Page 53: Seatbelt Maintenance

    then pull it out slowly again. 3. Insert the tongue plate into the buckle until you hear a click. 4. To make the lap part tight, pull up on the shoulder belt. And place the lap belt as low as possible on your hips, not on your waist. n Unfastening the seatbelt Push Push the button on the buckle.

  • Page 54: Front Seatbelt Pretensioners

    For required servicing of front seatbelt retractors equipped with seatbelt pretensioners, see your nearest SUBARU dealer. D When discarding front seatbelt retractor assemblies or scrap- ping the entire car due to collision damage or for other reasons, consult your SUBARU dealer.
  • Page 55 SUBARU dealer as soon as possible. D If the front seatbelt retractor assembly or surrounding area has been damaged, contact your SUBARU dealer as soon as pos- sible. D When you sell your vehicle, we urge you to explain to the buy- er that it has seatbelt pretensioners by alerting the buyer to the contents of this section.
  • Page 56 D All related wiring In the event of a malfunction indicated by any of following, the vehicle should be taken promptly to your nearest SUBARU dealer to have the system checked. Unless checked and repaired, the seatbelt preten- sioners and airbags will not function reliably: D Flashing or flickering of the indicator light.
  • Page 57 WARNING D When discarding a seatbelt retractor assembly or scrapping the entire car damaged by a collision, consult your SUBARU deal- D Tampering with or disconnecting the system’s wiring could re- sult in accidental activation of the seatbelt pretensioner and/or airbag or could make the system inoperative, which may result in serious injury.

  • Page 58: Child Restraint Systems

    D Installation of a tire of different size and construction from the tires specified on the tire placard attached to the door jamb. Always consult your SUBARU dealer if you want to install any acces- sory parts to your vehicle.
  • Page 59 For that reason, be sure to secure ALL types of child restraint devices (including forward facing child seats) in the REAR seats at all times. You should choose a restraint device which is appropriate for the child’s age, height and weight. According to accident statistics, children are safer when properly restrained in the rear seating positions than in the front seating positions.
  • Page 60 WARNING D Child restraint systems and seatbelts can become hot in a ve- hicle that has been closed up in sunny weather; they could burn a small child. Check the child restraint system before you place a child in it. D Do not leave an unsecured child restraint system in your vehi- cle.
  • Page 61 B Installing child restraint systems with seatbelt and tether anchorages NOTE When the child restraint system is no longer in use, remove it and restore the ELR function of the retractor. The function is restored by retracting the seatbelt fully. CAUTION When you install a child restraint system, follow the manufactur- er’s instructions supplied with it.
  • Page 62 HB1134BA 2. Pull the seatback locking knob and fold the seatback forward to see the tether anchorage on the backside of the seatback. HB1144BA 3. Connect the tether belt hook onto the tether anchorage on the backside of the seatback. Take up any slack in the tether belt after connecting it to the tether anchorage.
  • Page 63 Seat, seatbelt and SRS airbags HB1146BA 4. Put the other end of the tether belt through under the headrest. 5. Return the seatback to the locked position. Confirm that the red mark on the locking knob is no longer visible and check that the seat- back is securely locked by moving it back and forth.
  • Page 64 12. To remove the child restraint system, follow the reverse proce- dures of installation. Unbuckle the seatbelt and allow the belt to retract completely. The belt will return to the ELR mode. If you have any question concerning proper child restraint system installation, ask your SUBARU dealer. 1-32...
  • Page 65 B Installation of child restraint system by seatbelt only NOTE When the child restraint system is no longer in use, remove it and restore the ELR function of the retractor. The function is restored by retracting the seatbelt fully. CAUTION When you install a child restraint system, follow the manufactur- er’s instructions supplied with it.
  • Page 66 The belt will return to ELR mode. If you have any question concerning proper child restraint system installation, ask your SUBARU dealer. B Installation of child restraint systems by use of lower and teth- er anchorages Some types of child restraint systems can be installed on the rear seat of your vehicle without use of the seatbelts.
  • Page 67 Seat, seatbelt and SRS airbags HB1154BA Your vehicle is equipped with four lower anchorages (bars) on the back panel behind the markings on the bottom part of the rear seat- back and two upper anchorages (tether anchorages) on the back side of the seatback for accommodating such child restraint systems.
  • Page 68 CAUTION When you install a child restraint system, follow the manufactur- er’s instructions supplied with it. After installing the child restraint system, check to ensure that it is held securely in position. If it is not held tight and secure, the danger of your child suffering per- sonal injury in the event of an accident may be increased.
  • Page 69 4. Put the other end of the tether belt through under the headrest. 5. Return the seatback to the locked position. Confirm that the red mark on the locking knob is no longer visible and check if the seat- back has been securely locked by moving it back and forth. 6.
  • Page 70 9. Put the loose end of the tether belts behind the seatback. 10. To remove the child restraint system, follow the reverse proce- dures of installation. If you have any question concerning proper child restraint system installation, ask your SUBARU dealer. 1-38 HB1131BA HB1147BA...

  • Page 71: Srs Airbag

    *SRS airbag (Supplemental Restraint System airbag) *SRS: This stands for supplemental restraint system. This name is used because the airbag system supplements the vehicle’s seatbelts. J Vehicle with driver’s and front passenger’s SRS air- bags and lap/shoulder restraints WARNING D To obtain maximum protection in the event of an accident, the driver and all passengers in the vehicle should always wear seat- belts when the vehicle is moving.
  • Page 72 D The SRS airbags deploy with considerable speed and force. Occupants who are out of proper position when the SRS airbag deploys could suffer very serious injuries. Because the SRS air- bag needs enough space for deployment, the driver should al- ways sit upright and well back in the seat as far from the steering wheel as practical while still maintaining full vehicle control and the front passenger should move the seat as far back as possible...
  • Page 73 The SRS airbag deploys with considerable force and can injure or even kill the child. Put children in the REAR seat prop- erly restrained at all times. CAUTION D When the SRS airbag deploys, some smoke will be released. This smoke could cause breathing problems for people with a history of asthma or other breathing trouble.
  • Page 74 NOTE When you sell your vehicle, we urge you to explain to the buyer that it is equipped with SRS airbags by alerting him to the applicable section in this owner’s manual. B Components Airbag control module (including impact sensors) Airbag module (driver’s side) Airbag module (passenger’s side)

  • Page 75: Srs Frontal Airbag

    J SRS frontal airbag WARNING D NEVER INSTALL A REARWARD FACING CHILD SAFETY SEAT IN THE FRONT SEAT. DOING SO RISKS SERIOUS INJURY OR DEATH TO THE CHILD BY PLACING THE CHILD’S HEAD TOO CLOSE TO THE SRS AIRBAG. D Never allow a child to stand up, or to kneel on the front pas- senger’s seat, or never hold a child on your lap or in your arms.
  • Page 76 Never hold a child on your lap or in your arms. Adjust the seatback to upright position. Sit well back and upright. Move the seat as far back as possible. WARNING D Do not put any objects over the steering wheel pad and dash- board.
  • Page 77 The driver’s SRS frontal airbag is stowed in the center portion of the steering wheel. The passenger’s SRS frontal airbag is stowed near the top of the dashboard under an “SRS AIRBAG” mark. In a moderate to severe frontal collision, the driver’s and front passen- ger’s SRS frontal airbags deploy and supplement the seatbelts by reduc- ing the impact on the driver’s and front passenger’s head and chest.
  • Page 78 Driver’s side SRS airbags deploy as soon as a collision occurs. After deployment, SRS airbags start to deflate immediately so that the driver’s vision is not obstructed. The SRS airbag can function only when the ignition switch is in the “ON”...
  • Page 79 Seat, seatbelt and SRS airbags When the SRS airbag deploys, a sudden, fairly loud inflation noise will be heard and some smoke will be released. These occurrences are normal result of the deployment. This smoke does not indicate a fire in the vehicle.
  • Page 80 n Examples of the types of accidents in which it is possible that the SRS frontal airbag will deploy. The SRS frontal airbag may be activated when the vehicle sustains a hard impact in the undercarriage area from the road surface (such as when the vehicle plunges into a deep ditch, is severely bumped or knocked hard against an obstacle on the road such as a curb).
  • Page 81 Seat, seatbelt and SRS airbags n Examples of the types of accidents in which the SRS frontal airbag will basically not deploy. The SRS frontal airbag is basically not designed to deploy if the vehicle is struck from side or from behind, or if it rolls onto its side or roof, or if it is involved in a low-speed frontal collision.

  • Page 82: Srs Airbag System Monitors

    D All related wiring In the event of a malfunction indicated by any of following, the vehicle should be taken promptly to your nearest SUBARU dealer to have the system checked. Unless checked and repaired, the SRS airbags will not function reliably: D Flashing or flickering of the indicator light.

  • Page 83: Srs Airbag System Servicing

    CAUTION If you need service or repair in areas listed below, we recommend that you have an authorized SUBARU dealer perform the work. The SRS airbag control module, impact sensors and airbag modules are stored in these areas.

  • Page 84: Precautions Against Vehicle Modification

    SUBARU dealer ten years after the date of manufacture, which is shown on the certification label attached to the driver’s door. NOTE In the following cases, contact your SUBARU dealer as soon as pos- sible. D The front part of the vehicle was involved in an accident in which the SRS frontal airbags did not deploy.
  • Page 85 D Installation of a tire of different size and construction from the tires specified on the tire placard attached to the driver’s door jamb. Always consult your SUBARU dealer if you want to install any accessory parts to your vehicle. Seat, seatbelt and SRS airbags –...
  • Page 86 Keys and doors Keys ................Door locks .

  • Page 87: Keys

    Keys Master key Submaster key Three types of keys are provided for your vehicle. Master key, submaster key and valet key. The master key and submaster key fit all locks on your vehicle. D Ignition switch D Doors D Glove box The valet key fits only the ignition switch and door locks.

  • Page 88: Keys And Doors

    Keys and doors Door locks B Locking and unlocking from the outside OM-H2394 To lock the door from the outside with the key, insert the key into the keyhole and turn the key toward the rear. To unlock the door, turn the key toward the front.
  • Page 89 Always make sure that all doors are locked before leaving your vehicle. NOTE Make sure that you do not leave the key inside the vehicle before locking the doors from the outside without the key. B Locking and unlocking from the inside WARNING Keep all doors locked when you drive, especially when small chil- dren are in your vehicle.

  • Page 90: Power Door Locking Switches

    Keys and doors J Power door locking switches HB2008CB HB2009BB All doors can be locked and unlocked by the power door locking switches located at the driver’s side and the front passenger’s side doors. To lock the doors, push the switch forward. To unlock the doors, push the switch rearward.

  • Page 91: Remote Keyless Entry System (If Equipped)

    Remote keyless entry system (if equipped) CAUTION D Do not expose the transmitter to severe shocks, such as those experienced as a result of dropping or throwing. D Do not take the transmitter apart except when replacing the battery. D Do not get the transmitter wet. If it gets wet, wipe it dry with a cloth immediately.
  • Page 92 Keys and doors HB1000BF B Locking the doors Briefly press the “LOCK/ARM” button (for less than two seconds) to lock all doors. An electronic chirp will sound one time and the turn signal lights will flash one time. If any of the doors is not fully closed, an electronic chirp will sound five times and the turn signal lights will flash five times to alert you that the doors are not properly closed.

  • Page 93: Vehicle Finder Function

    LOCK/DISARM” button (for unlocking of all of the doors is ex- tremely short, the system may not respond. B Illuminated entry The interior (dome) light will illuminate when the “UNLOCK/DISARM” button is pressed. These lights stay illuminated for approximately 30 seconds if any of the doors is not opened.
  • Page 94 DISARM” button and then simultaneously depress “LOCK/ARM” and “UNLOCK/DISARM” buttons for more than two seconds. An electronic chirp will sound one time and the turn signal lights will flash one time to inform you that the audible signal has been turned on. B Replacing the battery CAUTION Do not let dust, oil or water get on or in the transmitter when...
  • Page 95 the “LOCK/ARM” or “UNLOCK/DISARM” button six times to syn- chronize the unit. B Replacing lost transmitters If you lose a transmitter or want to purchase additional transmitters (up to four can be programmed), you should re-program all of your transmitters for security reasons. It is recommended that you have your dealer program all of your transmitters into your system.
  • Page 96 Keys and doors HB2032BB 4. Place the ignition key into the ignition switch and cycle the switch from LOCK to ON ten times within 15 seconds. Be sure to stop at the LOCK position. The horn will sound once to indicate that you are in the transmitter programming mode.
  • Page 97 that the transmitter has been programmed. Any additional transmitters can also be programmed at this time. Repeat steps 1 through 3 for an additional transmitter. To exit the programming mode: 1. After all of your transmitters are programmed, remove the key from the ignition switch.

  • Page 98: Security System (If Equipped)

    Security system (if equipped) The security system helps to protect your vehicle and valuables from theft. The horn sounds and the turn signal lights flash if someone attempts to break into your vehicle. The starter motor is also interrupted to prevent starting the vehicle without a key. The system can be armed and disarmed with the remote transmitter.
  • Page 99 transmitter is used for locking and unlocking. The security system indicator light in the combination meter flashes twice per second to show that the valet mode is selected. For details, refer to “Valet mode” in this section. B Arming the system n To arm the system using remote transmitter Press to Arm the...
  • Page 100 Keys and doors n To arm the system using power door locking switches HB2024CC 1. Close all windows and the moonroof. 2. Remove the key from the ignition switch. 3. Open the doors and get out of the vehicle. 4. Make sure that the engine hood and switchback door are locked. 5.
  • Page 101 a second time. n Emergency disarming If you cannot disarm the system using the transmitter (i.e. the trans- mitter is lost, broken or the transmitter battery is too weak), you can disarm the system without using the transmitter. To disarm the system: 1.
  • Page 102 remote transmitter. Note that in this mode, DOORS MUST BE MANU- ALLY LOCKED. n To enter the passive mode WARNING Do not disconnect or tamper with any yellow connector and/or any harness covered with yellow insulation and/or tape. Doing so could result in accidental inflation of the SRS airbag or could make the SRS airbag system inoperative, which may result in serious injury.
  • Page 103 n Arming the system CAUTION In passive mode, the system will automatically activate the alarm but WILL NOT automatically lock the doors. In order to lock the doors you must either lock them as indicated in step 4 below or with the key once they have been closed.
  • Page 104 Keys and doors the transmitter. B Tripped sensor identification If an electronic chirp sounds four times and the turn signal lights flash four times when you disarm the system, this indicates that the alarm was triggered. The number of times the indicator light flashes indi- cates what sensor caused the alarm condition.

  • Page 105: Child Safety Locks

    Child safety locks WARNING Always use the child safety lock whenever a child rides in the rear seat. Serious injury could result if a child accidentally opened the door and fell out. Each rear door has a child safety lock that prevents the doors from being opened even if the inside door handle is pulled.

  • Page 106: Windows

    Windows J Power windows WARNING To avoid serious personal injury caused by entrapment, you must observe the following warnings: D When operating power windows, be extremely careful to pre- vent anyone’s fingers, arms or head from being caught in the window.
  • Page 107 HB2008DB All door windows can be controlled by the power window switch clus- ter at the driver side door. n Operating the driver’s window To open: Push the switch down lightly and hold it. The window will open as long as the switch is held.

  • Page 108: Tailgate

    CAUTION Keep the tailgate closed when the vehicle is moving. If you must drive with the tailgate open, use the optional Subaru Bed Extender and place the License Plate Bracket at its fully lowered/ open position. Cargo must not stick out beyond the Extender.

  • Page 109: License Plate Bracket

    Before opening the tailgate, remove any object on the upper surface of the rear bumper to avoid damaging the tailgate. To open the tailgate, lift up on its handle while pulling the tailgate toward you. The support cables hold the tailgate open. See “Loading your vehicle”...
  • Page 110 the license plate bracket must be placed at its fully lowered/open posi- tion to make the rear license plate visible. CAUTION In order to avoid damaging the license plate bracket or the bum- per, the license plate bracket must be in its fully lowered/open position before the tailgate is lowered.

  • Page 111: Switchback Door

    CAUTION In order to avoid damaging the license plate bracket or the bum- per, the license plate bracket must be restored to its original posi- tion until it clicks. Switchback door With the switchback door open, you can increase the usable cargo space and can carry long objects.
  • Page 112 Keys and doors To open the switchback door: HB1112BA 1. Pull up the rear seat cushion. Refer to “Rear seats” section in Chapter 1 for operating details. HB1112CB HB1113BA 2. Unlock the rear seatback by pulling up on the knob and fold down the rear seatback.
  • Page 113 3. Fold down the switchback door by releasing the lock knob. Then you can have a flat and larger cargo space. 4. Place the long object on the cargo bed through the switchback door opening. Be sure all items are secured in place. NOTE D When opening the switchback door in snow, accumulated snow in the cargo bed may enter the passenger compartment which could...

  • Page 114: Switchback Door Indicator Light

    To close the switchback door, firmly push it upward until it latches. Return the seatback and seat cushion to their original positions and make sure they are securely locked. CAUTION After returning the seatback to its original position, make sure that the rear seatback has been securely locked.

  • Page 115: Moonroof

    Moonroof WARNING Never let anyone’s hands, arms, head or any objects protrude from the moonroof. He/she could be seriously injured if the vehicle stops suddenly or turns sharply or if the vehicle is in- volved in an accident. To avoid serious personal injury caused by entrapment, you must observe the following warnings: D Before closing the moonroof, make sure that no one’s hands, arms, head or other objects will be accidentally caught in the...
  • Page 116 Keys and doors HB2034BB B To raise or lower the moonroof The tilting function will only operate when the moonroof is fully closed. Push the rear side of the “Tilt” switch to raise the moonroof. Push the front side of the “Tilt” switch to lower the moonroof. Release the switch after the moonroof has been raised or has been lowered completely.
  • Page 117 gency”. B Sun shade OM-H2355 The sun shade can be slid forward or backward by hand while the moonroof is closed. If the moonroof is opened, the sun shade also moves back. 2-32...
  • Page 118 Instruments and controls Ignition switch ............. Key reminder chime .
  • Page 119 Rear window defogger switch Windshield wiper deicer (if equipped) Mirrors ............... . Inside mirror .

  • Page 120: Instruments And Controls

    Ignition switch WARNING Never turn the ignition switch to “LOCK” while the vehicle is be- ing driven or towed because that will lock the steering wheel, pre- venting steering control. And when the engine is turned off, it takes a much greater effort than usual to steer. The ignition switch has four positions: LOCK, ACC, ON and START.
  • Page 121 n Automatic transmission vehicles HB4016BA HB2032CA The key can be turned from “ACC” to “LOCK” only when the selector lever is in the “P” position. n Manual transmission vehicles OM-H0144 The key can be turned from “ACC” to “LOCK” only when the key is pushed in while turning it.

  • Page 122: Ignition Switch Light

    B START CAUTION Do not turn the ignition switch to the “START” position while the engine is running. The engine is started in this position. The starter cranks the engine to start it. When the key is released (after the engine has started), the key automatically returns to the “ON”...

  • Page 123: Hazard Warning Flasher

    2. Remove the cover under the steering column using a phillips screwdriver. 3. Turn the ignition key while pressing the key interlock release lever. Take your vehicle to the nearest SUBARU dealer immediately to have the key interlock system repaired. Hazard warning flasher The hazard warning flasher is used to warn other drivers when you have to park your vehicle under emergency conditions.

  • Page 124: Meters And Gauges

    To turn on the hazard warning flasher, push the hazard warning button on the instrument panel. To turn off the flasher, push the button again. NOTE When the hazard warning flasher is on, the turn signals do not work. Meters and gauges J Speedometer The speedometer shows the vehicle speed.

  • Page 125: Outside Temperature Indicator (If Equipped)

    To change the mode indication, briefly push the knob. Each press of the knob changes the function alternately. A trip meter To set the trip meter to zero, select either the A trip or B trip meter and push the knob and keep it pushed for more than 1 second. NOTE If the connection between the combination meter and battery is bro- ken for any reason such as vehicle maintenance or fuse replace-...

  • Page 126: Fuel Gauge

    J Fuel gauge The fuel gauge shows the approximate amount of fuel remaining in the tank. The gauge does not return to “E” even though the ignition switch is in the “ACC” or “LOCK” position. The gauge may move slightly during braking, turning or acceleration due to fuel level movement in the tank.

  • Page 127: Warning And Indicator Lights

    If any lights fail to come on, it indicates a burned-out bulb or a malfunc- tion of the corresponding system. Consult your authorized SUBARU dealer for repair. J Seatbelt warning light and chime When the ignition switch is turned to the “ON” position, the seatbelt warning light will come on and the reminder chime will sound for about six seconds to remind the driver to fasten the seatbelt.

  • Page 128: Check Engine Warning Light/Malfunction

    6 seconds from when the ignition has been turned on, it may indicate that the SRS frontal airbag system or seatbelt pretensioner system is not working properly. Contact your nearest SUBARU dealer im- mediately. J CHECK ENGINE warning light/Malfunction...

  • Page 129: Charge Warning Light

    It may take several driving trips. If the light does not go out, take your vehicle to your authorized SUBARU dealer immediately. B If the light is blinking: If the light is blinking while driving, an engine misfire condition has been detected which may damage the emission control system.

  • Page 130: At Oil Temperature Warning Light (For At Vehicles)

    If the oil level is low, add oil immediately. If the engine oil is at the proper level but the light remains on, contact your nearest SUBARU dealer immediately.

  • Page 131: Brake System Warning Light

    D Driving with the brake system warning light on is dangerous. This indicates your brake system may not be working properly. If the light remains on, have the brakes inspected by a SUBARU dealer immediately. D If at all in doubt about whether the brakes are operating prop- erly, do not drive the vehicle.

  • Page 132: Front-Wheel Drive Warning Light (For At Vehicles)

    “ON”), it could be an indication of leaking of brake fluid or worn brake pads. Have your vehicle checked by a SUBARU dealer immediately. J Door ajar warning lights The specific door ajar warning light comes on if any door is not fully closed.

  • Page 133: Shift Position Indicator (For At Vehicles)

    purposes. J Security system status indicator light (if equipped) This light is found at the bottom center of the combination meter panel. On vehicles equipped with a security system, it blinks to show the driver the operational status of the security system. For detailed information, re- fer to the “Security system”...

  • Page 134: Clock

    Clock To set the time, turn the setting knob clockwise to advance and counter- clockwise to retard the time. Light control switch WARNING To prevent battery discharge resulting from accidentally leaving your lights on when your vehicle is parked, the light switch oper- ates only when the ignition switch is in the “ON”...
  • Page 135 The light switch operates only when the ignition switch is in the “ON” position. B Headlights To turn on the headlights, turn the knob on the end of the turn signal lever. first position Parking lights, instrument panel illumination, tail lights and license plate light are on.

  • Page 136: Daytime Running Light System

    To flash the headlights, pull the lever toward you and then release it. The high beam will stay on for as long as you hold the lever. The headlight flasher works even though the lighting switch is in the “OFF” position.

  • Page 137: Illumination Brightness Control

    ished, the lever will return automatically. If the lever does not return after cornering, return the lever to the neutral position by hand. To signal a lane change, push the turn signal lever up or down slightly and hold it during the lane change. The turn signal indicator lights will flash in the direction of the turn or lane change.

  • Page 138: Parking Light Switch

    Parking light switch The parking light switch operates regardless of the ignition switch posi- tion. By pushing the front end of this switch, following lights will come on. – Parking lights – Front and rear side marker lights – Tail lights –...

  • Page 139: Fog Light Switch (If Equipped)

    Fog light switch (if equipped) The fog lights operate only when the headlights are on low beam. Push the fog light switch to turn the fog lights on. Press the switch again to turn them off. The indicator light located on the switch will illuminate when the fog lights are on.
  • Page 140 D Use clean water if windshield washer fluid is unavailable. In areas where water freezes in winter, use SUBARU Windshield Washer Fluid or the equivalent. (See “Windshield washer fluid” section in chapter 11.) Also, when driving the vehicle when there are freezing tempera- tures, use non-freezing type wiper blades.

  • Page 141: Windshield Wiper And Washer Switches

    windshield or rear window. D Grease, wax, insects or other material on the windshield or the wiper blades results in jerky wiper operation and streaking on the glass. If you cannot remove those streaks after operating the washer or if the wiper operation is jerky, clean the outer surface of the windshield or rear window and the wiper blades using a sponge or soft cloth with a neutral detergent or mild-abrasive cleaner.
  • Page 142 B Wiper intermittent time control When the wiper switch is in the “ the operating interval of the wiper. The operating interval can be adjusted continuously from the shortest interval to the longest. Two click stop positions of the dial may help you to aim at your de- sired interval.

  • Page 143: Rear Window Defogger Switch

    er control lever. The washer fluid sprays until you release the washer button. The wipers operate while you push the button. Rear window defogger switch CAUTION D Do not use sharp instruments or window cleaner containing abrasives to clean the inner surface of the rear window. They may damage the conductors printed on the window.

  • Page 144: Windshield Wiper Deicer (If Equipped)

    defogger is operating. Windshield wiper deicer (if equipped) CAUTION To prevent the battery from being discharged, do not operate the windshield wiper deicer continuously for any longer than neces- sary. The windshield wiper deicer operates only when the ignition switch is in the “ON”...

  • Page 145: Mirrors

    Mirrors Always check that the inside and outside mirrors are properly adjusted before you start driving. J Inside mirror The inside mirror has a day and night position. Pull the tab at the bottom of the mirror toward you for the night position. Push it away for the day position.
  • Page 146 Instruments and controls D By pressing and releasing the left button, the automatic dimming function is toggled on or off. When the automatic dimming function is on, the auto dimming indicator light (green) located to the right of the button will illuminate. D By pressing and releasing the right button, the compass display is toggled on or off.

  • Page 147: Outside Mirrors

    structures and make certain the ignition switch is in the “ON” position. 3. Press and hold the left button for 3 seconds then release, and the compass will enter the calibration mode. “CAL” and direction will be displayed. 4. Drive slowly in a circle until “CAL” disappears from the display (about two or three circles).
  • Page 148 Instruments and controls B Adjusting mirrors To adjust the mirrors by hand, push where indicated by the arrows. OM-H2737 B Remote control mirror switch The remote control mirrors operate only when the ignition switch is in the “ON” or “ACC” position. HB4004BB 1.

  • Page 149: Tilt Steering Wheel

    B Outside mirror defogger (if equipped) CAUTION To prevent the battery from being discharged, do not operate the defogger continuously for any longer than necessary. The outside mirror defogger operates only when the ignition switch is in the “ON” or “ACC” position. To turn on the outside mirror defogger, push the switch while the en- gine is running.

  • Page 150: Horn

    Instruments and controls HB4002BA 1. Adjust the seat position. Refer to the “Front seat” section (chapter 1). 2. Pull the tilt lock lever down. 3. Move the steering wheel to the desired level. 4. Push the lever up to lock the steering wheel in place. 5.
  • Page 151 Climate control Ventilator ..............Manual heating and air conditioning system Heater operation .

  • Page 152: Ventilator

    Ventilator B Center and side ventilators B Adjustable side defroster grille (driver’s side – if equipped) Normal position Side defroster grille The driver’s side defroster grille is adjustable. The normal position as shown in the diagram directs warm air to the side glass. When more rapid defrosting of the windshield is desired, the air flow can be directed temporarily toward the windshield to assist the windshield defroster.

  • Page 153: Air Flow Selection

    Climate control B Air flow selection HB5006BA HB5006CA HB5006DA HB5006EA HB5006FA – CONTINUED –...

  • Page 154: Manual Heating And Air Conditioning System

    Manual heating and air conditioning system B Control panel 1. Temperature control dial 2. Fan speed control dial 3. Air flow control dial 4. Air conditioner button 5. Air inlet selection button 6. Rear window defogger button (Refer to “Rear window defogger” in chapter 3.) n Temperature control dial This dial regulates the temperature of air flow from the air outlets over...
  • Page 155 : Air flows through the foot outlets and some through the wind- shield defroster outlets. : Air flows through the windshield defroster outlets and foot outlets. : Air flows through the windshield defroster outlets. NOTE When the dial is placed in the “ conditioner compressor operates automatically regardless of the position of the air conditioner button to defog the windshield quickly.
  • Page 156 n Air inlet selection button WARNING Continued operation in the ON position may fog up the windows. Switch to the OFF position as soon as the outside dusty condi- tion clears. ON position (Recirculation): Interior air is recirculated inside the ve- hicle.

  • Page 157: Heater Operation

    Climate control J Heater operation B Defrosting or defogging the windshield HB5011AA To direct warm air to the windshield and front door windows: 1. Set the air flow control dial to “ ”. 2. Turn the temperature control dial all the way to the right. 3.
  • Page 158 To direct warm air toward the floor and the windshield: 1. Set the air flow control dial to “ 2. Set the temperature control dial to the desired temperature level. 3. Set the fan speed control dial to the desired speed. NOTE Warm air also comes out from the right and left air outlets.
  • Page 159 B Bi-level heating This setting allows you to direct air of different temperatures from the instrument panel and foot outlets. The air from the foot outlets is slightly warmer than from the instrument panel outlets. 1. Set the air inlet selection button to the “OFF” position. 2.

  • Page 160: Air Conditioner Operation

    To force outside air through the instrument panel outlets: 1. Set the air inlet selection button to the “OFF” position. 2. Set the air flow control dial to “ 3. Set the temperature control dial all the way left. 4. Set the fan speed control dial to the desired speed. When driving on a dusty road, set the air inlet control button to the “ON”...
  • Page 161 Climate control 1. Set the air inlet selection button to the “OFF” position. 2. Set the air flow control dial to “ ”. 3. Set the air conditioner button to the “ON” position. 4. Set the temperature control dial to the blue area. 5.

  • Page 162: Operating Tips For Heater And Air Conditioner

    B Checking air conditioning system before summer season Check the air conditioner unit for refrigerant leaks, hose conditions, and proper operation each spring. This check is best performed by your SUBARU dealer. 4-12...

  • Page 163: Air Filtration System (If Equipped)

    Your air conditioner uses ozone friendly refrigerant HFC134a. There- fore, the method of adding, changing or checking the refrigerant is different from the method for CFC12 (freon). Consult your SUBARU dealer for service. Repairs needed as a result of using the wrong refrigerant are not covered under warranty.
  • Page 164 Audio Antenna system ............Installation of accessories Audio set .

  • Page 165: Antenna System

    Installation of accessories Always consult your SUBARU dealer before installing a citizen band ra- dio or other transmitting device in your vehicle. Such devices may cause the electronic control system to malfunction if they are incorrectly installed or if they are not suited for the vehicle.

  • Page 166: Audio

    Audio set Your SUBARU is equipped with the following audio set. See the pages indicated in this section for operating details. B AM/FM radio with CD player D Radio operation: refer to page 5-4 D CD (compact disc) player operation: refer to page 5-7 D CD changer control: refer to page 5-10 B In-dash 6 CD auto changer (Optional audio unit —...

  • Page 167: Radio Operation

    AM/FM radio with CD player The audio set will operate only when the ignition switch is in the “ACC” or “ON” position. Radio operation Power switch/Volume, Tone, Balance, Fader control dial BAND button Tuning buttons B Power switch and volume/bass/treble/fader/balance control n Power switch and volume control (PWR/VOL) The dial is used for both power (ON/OFF) and volume control.
  • Page 168 Choose desired volume level for each mode by turning the volume control dial. The control function returns to volume control mode after about 5 seconds. To change control modes: Each brief press of the “AUDIO” button changes control modes in the following sequence starting from vol- ume control mode.
  • Page 169 display indicates which one is currently selected. B Stereo indicator The stereo indicator “ST” will come on when an FM stereo broadcast is received. B Tuning (TUNE) n Manual tuning (TUNE) Press the tuning button marked “Y” to increase the tuning frequen- cy and press the tuning button marked “B”...

  • Page 170: Compact Disc Player Operation

    desired station frequency is displayed. 3. Press one of the preset buttons for more than 2 seconds to store the frequency. At this time, there will momentarily be no sound from the radio. If the button is pressed for less than 2 seconds, the preced- ing selection will remain in memory.
  • Page 171 the disc, then insert it in to the slot (with the label side up) and the player will automatically pull the disc into position. A 8 cm/3 inch CD may also be used without any adapter. NOTE D DO NOT INSERT TWO DISCS INTO THE DISC INSERTION SLOT AT A TIME.
  • Page 172 B Fast forwarding and fast reverse n Fast forward Press the “Y” button forward the disc. Release the button to stop fast forwarding. n Fast reverse Press the “B” button reverse the disc. Release the button to stop fast reverse. B Repeat playback Use this to play a certain track repeatedly.

  • Page 173: Cd Changer Control (If Optional In Dash Cd Changer Is Connected)

    CD changer control (If optional in dash CD changer is connected) An optional CD changer can be connected to this audio unit. See your SUBARU dealer for more information. For procedures for loading and un- loading CDs, refer to “In-dash 6 CD auto changer” in this chapter. CD button...
  • Page 174 Audio NOTE D If the “CD” button is pressed during a radio broadcast, the CD changer will interrupt the broadcast. D At the end of the disc, playback automatically continues with the next disc. D After playback on the last disc finishes, the player will auto- matically return to the first disc.
  • Page 175 To cancel the random mode, press the button again. Then the “RAND” indicator goes out, and normal playback mode is restored. B Scan (a convenient way to become familiar with a disc) 1. Press the “SCAN” button – The display shows “SCAN” and the track number being scanned.

  • Page 176: In-Dash 6 Cd Auto Changer (If Equipped)

    In-dash 6 CD auto changer (if equipped) Disc slot Disc indicators (disc No.1 to CAUTION D Do not attempt to insert two or more discs into the slot at a time. Doing so can cause mechanical damage to the CD changer. D Use only music CDs identified by a D Do not use CDs listed below which could cause damage to the CD player.
  • Page 177 B To insert a disc 1. Press one of the “Disc select” buttons (numbered from 1 to 6) for which the disc indicator light is “OFF”. The Disc indicator lights are located directly above the corresponding “Disc select” buttons. 2. The indicator will begin blinking. The blinking will last for 15 se- conds.
  • Page 178 Audio B To remove all discs at one time 1. Press and hold the “Eject” button until all “Disc” indicators begin blinking (about 1.5 seconds), and the first disc will be ejected. 2. When the disc is removed, the next one will be ejected, and so on. B To replace a playing disc with another Simply press the desired one of “Disc select”...

  • Page 179: Precautions To Observe When Handling A Compact Disc (Cd)

    Precautions to observe when handling a compact disc (CD) Use only compact discs (CDs) that have the mark shown below. CD- RWs cannot be used. Also, some CD-Rs cannot be played. HB5062AA D In cold and/or rainy weather, dew can form inside the CD player, pre- venting normal operation.
  • Page 180 Audio HB5061BA – CONTINUED – 5-17...
  • Page 181 Interior and exterior equipments Interior light ..............Dome light .

  • Page 182: Interior Light

    Interior light J Dome light HS6003BC The dome light switch has three positions: ON: The light stays on continuously. DOOR (middle position): The light comes on when any of the doors is open. The light remains on for several seconds and gradually goes out after all doors are closed.

  • Page 183: Interior And Exterior Equipments

    Interior and exterior equipments Map light HB2034CC To turn on the map light, push the switch. To turn it off, push the switch again. When leaving the vehicle, make sure the light is turned off to avoid bat- tery discharge. Sun visors HB7001BA To block out glare, swing down the visors.

  • Page 184: Vanity Mirror

    J Vanity mirror To use the vanity mirror, swing down the sunvisor and open the vanity mirror cover. The light beside the vanity mirror comes on when the ignition switch is either in the “ACC” or “ON” position and the mirror cover is opened. Storage compartment Your vehicle has some storage compartments such as a glove box, a center console and so forth, for storage of small items that you often use.

  • Page 185: Glove Box

    Interior and exterior equipments J Glove box Unlock Lock HS0090 To open the glove box, pull the handle. To close it, push the lid firmly upward. To lock the glove box, insert the key and turn it clockwise. J Center console HB6022BA To open the lid, pull up the lock release.

  • Page 186: Rear Center Console

    J Rear center console HB6028BA To open the lid, push the button. J Coin compartment HS0096 To open the coin compartment, pull the upper edge of the lid.

  • Page 187: Rear Quarter Storage Box

    J Rear quarter storage box The rear quarter storage box is located on the right side of the back panel behind the rear seatback. To open the box: 1. Unlock the rear seatback locks by pulling the lock release knob up and fold the rear seatback forward.
  • Page 188 B Front cup holder HB6030BA A dual cup holder is built in the center console, beside the parking brake lever. B Rear passenger’s cup holder HB6029BA A dual cup holder is built in the rear center console.

  • Page 189: Cigarette Lighter Socket

    CAUTION D The electrical power socket located on the lower part of the instrument panel is originally designed to use a SUBARU genuine cigarette lighter plug. Do not use non-genuine cigarette lighter plugs in the socket. Doing so may cause a short-circuit and over- heating, resulting in a fire.
  • Page 190 B Use with a cigarette lighter WARNING To avoid being burned, never grasp the lighter by the end with the heating element. Doing so could result in injury and could also damage the heating element. CAUTION Do not hold the lighter pushed in, because it will overheat. The cigarette lighter operates only when the ignition switch is in “ON”...
  • Page 191 If you want to use the socket for a cigarette lighter again, or to protect your purchaser before you sell your car, have your SUBARU dealer replace the socket with a new one. Interior and exterior equipments – CONTINUED –...

  • Page 192: Ashtray

    Ashtray CAUTION Do not use ashtrays as waste receptacles or leave a lighted ciga- rette in an ashtray. This could cause a fire. Fully close the ashtray after using it to help reduce residual smoke. To open the ashtray, pull the lid out. To remove the ashtray for cleaning, open it and pull it out while pushing the inner plate down.

  • Page 193: Cargo Net Hooks

    Interior and exterior equipments HB6025BA The coat hook is attached to each rear passenger’s hand grip. J Cargo net hooks HB6031BA There are four hooks on the back panel behind the rear seatback. These hooks can be used for installing a cargo net so that small and light items can be held next to the back panel when the rear seatback is in the down position.

  • Page 194: Floor Mat (If Equipped)

    CAUTION After returning the seatback to its original position, make sure that the rear seatback has been securely locked. When securely locked, the red marks on the locking knobs are no longer visible. Floor mat (if equipped) CAUTION Make sure the driver’s floor mat is placed back in its proper loca- tion and correctly secured on its retaining pin.

  • Page 195: Cargo Bed

    Cargo bed WARNING D Never fill gasoline containers on the cargo bed. Static electric- ity may ignite gasoline vapor when filling portable containers. Ap- proved containers must be removed from the vehicle and placed on the ground when filling. Do not fill any portable container on a vehicle. D Never allow anyone to ride in the cargo bed.

  • Page 196: Cargo Tie-Down Hooks

    Subaru Bed Extender is used. Cargo should be placed in the cargo bed. Make sure all items are secured in place. Be careful to keep the vehicle balanced. Locating the weight as low and far forward as possible helps maintain balance.

  • Page 197: Bed Extender (If Equipped)

    Bed extender (if equipped) The bed extender is designed to increase the usable cargo area of the bed. CAUTION D When the tailgate and bed extender are in the “open/outward” position, the license plate bracket must be lowered and locked into position before the vehicle is driven (see section “License plate bracket”...
  • Page 198 B Operation Open/Outward Position – To use the bed extender in the open/out- ward position, simply lower your license plate bracket (see section “Licence plate bracket” under heading of “Tailgate” in Chapter 2), open your tailgate, and rotate the bed extender until it sits on the tail- gate.
  • Page 199 NOTE Use care when rotating bed extender. Do not permit the buckles to come in contact with vehicle sheet metal and bed trim. Closed/Inward Position – With the tailgate closed and the bed extender in the inward position, small loads can be placed inside the vehicle bed between the tailgate and the extender (groceries, ice chests, etc.).

  • Page 200: Cargo Lamp

    The bed extender can be removed from the vehicle by rotating the extender into a vertical position then lifting straight up. Cargo lamp The cargo lamp comes on and goes off whenever the cargo lamp switch is pushed regardless of the position of the ignition switch. The cargo lamp indicator light located in the meter panel will illuminate when the cargo lamp is on.

  • Page 201: Bed Cover (If Equipped)

    Bed cover (if equipped) The bed cover is designed to cover the cargo area of the bed. The bed cover is water resistant, but not waterproof. CAUTION D Do not place cargo on top of the bed cover. D Do not use the hard bed cover section as a step. D Do not use the bed cover to secure cargo.

  • Page 202: Cover Reinstallation

    B Cover removal HB6035AA HB6036BA The soft portion of the bed cover can be removed from the bed cov- er’s hard section for cleaning or storage. Unfasten the Velcro on the roll bar closeout wraps and firmly pull the cover out to one side. B Cover reinstallation HB6037BA The soft portion of the bed cover can be reinstalled onto the bed cov-...

  • Page 203: Roof Rail And Crossbar

    As you insert (and pull) the soft portion of the bed cover into the bed cover’s hard section, make sure the next 10 to 15 inches (250 to 380 mm) of the soft portion are straight and ready to enter the flared out portion of the hard section.
  • Page 204 The roof rail is not designed to carry cargo by itself. Cargo can be car- ried after securing the roof crossbar kit to the roof rail and installing the appropriate carrying attachment. When installing the roof crossbar kit, follow the manufacturer’s instructions. When you carry cargo on the roof using the roof crossbar kit and a carry- ing attachment, never exceed the maximum load limit explained below.
  • Page 205 NOTE Remember that the vehicle’s center of gravity is altered with the weight of the load on the roof, thus affecting the driving charac- teristics. Drive carefully. Avoid rapid starts, hard cornering and abrupt stops. Crosswind effects will be increased. B Removal and installation of the crossbars CAUTION Do not carry cargo on the roof when the crossbars are removed.
  • Page 206 NOTE It may be necessary to move the Front crossbar rearward, near the center of the roof rail for easier removal. Use care not to cross-thread the screw in the insert if it has been removed. n To install the crossbar NOTE Both Crossbars have a label indicating the direction of mount.
  • Page 207 Interior and exterior equipments HB6052BB HB6051BB 1. Before placing the crossbar on the roof rails, make sure that the T-30 torxR head screw is fully loosened from each end support. 2. Spread the inner clamp and the end support as far apart as pos- sible.
  • Page 208 5. Adjust the alignment of the crossbar on the roof rails, and if avail- able, use a T-30 torxR bit and torque wrench and tighten the T-30 torxR head screws to 30 to 35 inch lbs. (3.4 to 4.0 N-m, 0.35 to 0.41 kg-m) of torque (or tighten securely with the torxR wrench provided).

  • Page 209: Sport Activity Lights (If Equipped)

    Interior and exterior equipments bar clamp screws have been checked, and retightened if necessary to 35 inch lbs. (4.0 N-m, 0.41 kg-m), as outlined in Step #5 above. Sport activity lights (if equipped) HB6041BB The sport activity lights will operate only when the parking brake is engaged.
  • Page 210 HB3019AA The sport activity lights mount to the vehicle front cross bar. The sport activity lights cross bar wire harness connects to the roof wire harness and then to the vehicle’s electrical system. A tool is provided which will enable the sport activity lights’ positioning to be modified, so that each lamp can be aimed or rotated.
  • Page 211 Starting and operating Fuel ................Fuel requirements .

  • Page 212: Fuel

    Fuel CAUTION Use of a fuel which is low in quality or use of an inappropriate fuel additive may cause engine damage. J Fuel requirements The 2.5 Liter engine is designed to operate using unleaded gasoline with an octane rating of 87 AKI or higher. B Fuel octane rating This octane rating is the average of the Research Octane and Motor Octane numbers and is commonly referred to as the Anti Knock Index...

  • Page 213: Starting And Operating

    Starting and operating and may produce a sulfur exhaust odor or smell. SUBARU recom- mends that you try a different brand of unleaded gasoline having low- er sulfur to determine if the problem is fuel related before returning your vehicle to an authorized dealer for service.

  • Page 214: Fuel Filler Door And Cap

    Fuels may cause paint damage, which is not covered under the SUBARU Limited Warranty. D Always use a genuine SUBARU fuel filler cap. If you use the wrong cap, it may not fit or have proper venting, and your fuel...
  • Page 215 tank and emission control system might be damaged. 1. To open the fuel filler door, pull it outward. 2. Remove the fuel filler cap by turning it slowly counterclockwise. 3. Stop filling the tank after the fuel filler pump automatically clicks off. Do not add any more fuel.

  • Page 216: State Emission Testing (U.s. Only)

    CAUTION Resultant vehicle damage due to improper testing is not covered under the SUBARU Limited Warranty and is the responsibility of the state inspection program or its contractors or licensees. HG3016AA...
  • Page 217 Starting and operating At state inspection time, remember to tell your inspection or service station in advance not to place your Subaru AWD vehicle on a two- wheel dynamometer. Otherwise, serious transmission damage will result. Some states have started using dynamometers in their state inspection programs in order to meet their obligation under federal law to implement stricter vehicle emission standards to reduce air pollution from cars.

  • Page 218: Preparing To Drive

    Under this condition, the vehicle operator should be instructed to drive his/her vehicle for a few days to set the monitors and return for an emission re-inspection. D Owners of rejected or failing vehicles should contact their Subaru Dealer for service. Preparing to drive You should perform the following checks and adjustments every day be- fore you start driving.

  • Page 219: Starting The Engine

    9. Check the gauges, indicator and warning lights after starting the en- gine. NOTE Engine oil, engine coolant, brake fluid, washer fluid and other fluid levels should be checked daily, weekly or at fuel stops. Starting the engine CAUTION Do not operate the starter motor continuously for more than ten seconds.
  • Page 220 J Starting the engine for automatic transmission ve- hicle CAUTION If you restart the engine while the vehicle is moving, shift the se- lector lever into the “N” position. Do not attempt to place the se- lector lever of a moving vehicle into the “P” position. 1.

  • Page 221: Starting A Flooded Engine

    J Starting a flooded engine If the engine does not start, it may be flooded (excessive fuel in the en- gine). In case of a flooded engine, turn the starter motor for five seconds with the accelerator pedal fully depressed. Repeat this two or three times until the engine starts.

  • Page 222: Shifting Speeds

    The manual transmission is a fully synchromeshed 5-forward and 1-re- verse speed transmission. The shift pattern is shown on the shift lever knob. When shifting from 5th gear to reverse gear, first return the shift lever to the neutral position then shift into reverse gear.

  • Page 223: Driving Tips

    n Maximum allowable speeds WARNING When shifting down a gear, ensure that the vehicle is not travel- ling at a speed exceeding the Maximum Allowable Speed for the gear which is about to be selected. Failure to observe this pre- caution can lead to engine over-revving and this in turn can result in engine damage.

  • Page 224: Automatic Transmission

    ing corners, or driving up steep hills, downshift to a lower gear before the engine starts to labor. On steep downgrades, downshift the transmission to 4th, 3rd or 2nd gear as necessary; this helps to maintain a safe speed and to extend brake pad life.

  • Page 225: Selector Lever

    Starting and operating speeds and 1-reverse speed. NOTE Immediately after a disconnected battery is reconnected or ATF (au- tomatic transmission fluid) is replaced, you may feel that the auto- matic transmission operation is somewhat unusual. This results from erasure or invalidation of data the on-board com- puter has collected and stored in memory to allow the transmission to shift at the most appropriate times for the current condition of your vehicle.
  • Page 226 B P (Park) This position is for parking the vehicle and starting the engine. In this position, the transmission is mechanically locked to prevent the vehicle from rolling freely. When you park the vehicle, first set the parking brake fully, then shift into the “P”...
  • Page 227 Starting and operating During coasting, the engine braking does not act. B D (Drive) This position is for normal driving. The transmission automatically shifts into a suitable gear from 1st to 4th according to the vehicle speed and the acceleration you require. When more acceleration is required in this position, press the acceler- ator pedal fully to the floor and hold that position.
  • Page 228 braking as required. Also, downshifting when braking downhill will not occur at speeds above approximately 50 mph (80 km/h). B 3 (Third) This position is for using engine braking when going down a hill or for climbing a grade. The transmission automatically shifts into a suitable gear from 1st to 3rd according to the vehicle speed and the acceleration you require.
  • Page 229 an accident increased. The following tables show the maximum speeds that are possible with each different gear. The tachometer’s (if so equipped) needle will enter the red area if these speeds are exceeded. When shifting down a gear, it is important to confirm that the current vehicle speed is not in excess of the Maximum Allowable Speed of the gear which is about to be selected.

  • Page 230: Shift Lock Release

    5. Push down on the screwdriver and move the selector lever from the “P” to the “N” position. 6. Remove the screwdriver from the hole. Depress the brake pedal and start the engine. Take your vehicle to the nearest SUBARU dealer immediately to have the system repaired. 7-20...

  • Page 231: Rear Viscous Limited Slip Differential (Lsd) (If Equipped)

    Rear viscous limited slip differential (LSD) (if equipped) CAUTION D Never start the engine while a tire on one side is jacked up, as the vehicle may move. D If one rear tire is spinning in mud, avoid continued spinning at high speed as this could adversely affect the LSD.

  • Page 232: Braking

    Braking J Braking tips WARNING Never rest your foot on the brake pedal while driving. This can cause dangerous overheating of the brakes and needless wear on the brake pads and linings. B When the brakes get wet When driving in rain or after washing the vehicle, the brakes may get wet.

  • Page 233: Disc Brake Pad Wear Warning Indicators

    The disc brake pad wear warning indicators on the disc brakes give a warning noise when the brake pads are worn. If a squeaking or scraping noise is heard from the disc brakes while braking, immediately have your vehicle checked by your SUBARU deal- Starting and operating OM-H0163 –...

  • Page 234: Abs (Anti-Lock Brake System)

    ABS (Anti-lock Brake System) WARNING Always use the utmost care in driving – overconfidence because you are driving with an ABS equipped vehicle could easily lead to a serious accident. CAUTION D The ABS system does not always decrease stopping distance. You should always maintain a safe following distance from other vehicles.

  • Page 235: Abs Warning Light

    “ON” position, but it does not go out even when the vehicle speed exceeds approximately 8 mph (12 km/h). D The warning light comes on during driving. If these occur, have the ABS system repaired at the first available opportunity by your SUBARU dealer. Starting and operating HB4010GA – CONTINUED –...

  • Page 236: Parking Your Vehicle

    NOTE If the warning light behavior is as described below, the ABS sys- tem may be considered normal. D The warning light comes on right after the engine is started but goes out immediately, remaining off. D The warning light remains on after the engine has been started, but it goes out when the vehicle speed reaches about 8 mph (12 km/h).
  • Page 237 CAUTION Never drive while the parking brake is set because this will cause unnecessary wear on the brake linings. Before starting to drive, always make sure that the parking brake has been fully released. To set the parking brake, press the brake pedal firmly and hold it down while fully pulling up the parking brake lever.

  • Page 238: Cruise Control

    When parking on a hill, always turn the steering wheel. When the vehicle is headed up the hill, the front wheels should be turned away from the curb. When facing downhill, the front wheels should be turned into the curb. Cruise control WARNING Do not use the cruise control under any of the following condi-...
  • Page 239 B To set cruise control 1. Push the “CRUISE” main switch. The indicator light on the switch will come on. 2. Depress the accelerator pedal until the vehicle reaches the de- sired speed. 3. Push the control lever downward in the “SET, COAST” direction and release it.
  • Page 240 B To turn off the cruise control There are two ways to turn off the cruise control: D Push the main switch again. D Turn the ignition switch to the “ACC” position (but only when the vehicle is completely stopped). B To change the cruising speed n To increase the speed (by control lever) Push the control lever upward in the “ACCEL, RESUME”...
  • Page 241 Starting and operating When the difference between the actual vehicle speed and the set speed is less than 4 mph (6.8 km/h), the set speed can be lowered 1 mph (1.6 km/h) each time by pressing the control lever downward in the “SET, COAST”...
  • Page 242 Driving tips New vehicle break-in driving – the first 1,000 miles (1,600 km) Fuel economy hints ............Engine exhaust gas (Carbon monoxide) Catalytic converter .

  • Page 243: New Vehicle Break-In Driving - The First 1,000 Miles (1,600 Km)

    New vehicle break-in driving – the first 1,000 miles (1,600 km) The performance and long life of your vehicle are dependent on how you handle and care for your vehicle while it is new. Follow these instructions during the first 1,000 miles (1,600 km): D Do not race the engine.

  • Page 244: Driving Tips

    D Avoid carrying unnecessary luggage or cargo. Engine exhaust gas (Carbon monoxide) WARNING D Never inhale engine exhaust gas. Engine exhaust gas contains carbon monoxide, a colorless and odorless gas which is danger- ous, or even lethal, if inhaled. D Always properly maintain the engine exhaust system to pre- vent engine exhaust gas from entering the vehicle.

  • Page 245: Catalytic Converter

    D Keep your engine tuned-up. If you feel the engine running rough (mis- firing, backfiring or incomplete combustion), have your vehicle checked and repaired by an authorized SUBARU dealer. D Do not apply undercoating or rust prevention treatment to the heat shield of catalytic converter and the exhaust system.

  • Page 246: Periodic Inspections

    Driving tips Periodic inspections To keep your vehicle in the best condition at all times, always have the recommended maintenance services listed in the maintenance schedule in the “Warranty and Maintenance Booklet” performed at the specified time or mileage intervals. Driving in foreign countries When planning to use your vehicle in another country: D Confirm the availability of the correct fuel.

  • Page 247: Driving Tips For Awd Vehicles

    By shifting power between the front and rear wheels, SUBARU AWD can also pro- vide added traction during acceleration, and added engine braking force during deceleration.

  • Page 248: Off Road Driving

    Because of the AWD feature and higher ground clearance, your Subaru can be driven on ordinary roads or off-road. But please keep in mind that an AWD Subaru is neither a conventional off-road vehicle nor an all-ter- rain vehicle. If you do take your Subaru off-road, certain common sense...
  • Page 249 D Make certain that you and all of your passengers are wearing seat belts. D Carry some emergency equipment, such as a towing rope or chain, a shovel, wheel blocks, first aid kit and portable phone or citizens band radio. D Drive carefully.
  • Page 250 “Warranty and Maintenance Booklet”. Remember that damage done to your Subaru while operating it off-road and not using common sense precautions such as those listed above is...

  • Page 251: Winter Driving

    not eligible for warranty coverage. Winter driving B Operation during cold weather Carry some emergency equipment, such as tire chains, a window scraper, a bag of sand, flares, a small shovel, and jumper cables. Check the battery and cables. Cold temperatures reduce battery ca- pacity.
  • Page 252 because that could make the pedals slippery and dangerous. While warming up the vehicle before driving, check that the accelera- tor pedal, brake pedal, and all other controls operate smoothly. Clear away ice and snow that has accumulated under the fenders to avoid making steering difficult.
  • Page 253 When an antifreeze additive is used, its effect lasts longer if the tank is refilled whenever the fuel level reaches half empty. If your SUBARU is not going to be used for an extended period, it is best to have the fuel tank filled to capacity.

  • Page 254: Corrosion Protection

    flow control dial in “ imum warmth. After the windshield gets warmed enough to melt the frozen snow on it, wash it away using the windshield washer. Snow stuck on the wiper arm prevents the wiper from working effec- tively. If snow is stuck on the wiper arm, pull off the road to a safe place, then remove it.

  • Page 255: Tire Chains

    Your vehicle is equipped with “all season tires” which are designed to provide an adequate measure of traction, handling and braking perfor- mance in year-round driving. In winter, it may be possible to enhance performance through use of tires designed specifically for winter driving conditions.

  • Page 256: Rocking The Vehicle

    When driving with tire chains, drive at speeds below 19 mph (30 km/h). When a temporary spare tire is on a front wheel, replace the temporary spare tire with the rear tire on the same side of the vehicle, and then fit chains on the front tires.
  • Page 257 D Secure lengthy items properly to prevent them from shooting forward and causing serious injury during a sudden stop. D Never exceed the maximum load limit. If you do, some parts on your vehicle can break, or it can change the way your vehicle handles.

  • Page 258: Vehicle Capacity Weight

    Driving tips J Vehicle capacity weight HB8031BA HB8042BA The load capacity of your vehicle is determined by weight, not by avail- able cargo space. The total weight you can carry in your vehicle is shown as the Vehicle Capacity Weight on the tire information label at- tached to the driver’s side door jamb.

  • Page 259: Gvwr And Gawr

    J GVWR and GAWR (Gross Vehicle Weight Rating and Gross Axle Weight Rating) HB8043BA The certification label attached to the driver’s side door shows GVWR (Gross Vehicle Weight Rating) and GAWR (Gross Axle Weight Rating). The GVW (Gross Vehicle Weight) must never exceed the GVWR. GVW is the combined total of weight of the vehicle, fuel, driver, all passengers, luggage, any optional equipment and trailer tongue load.

  • Page 260: Trailer Hitch (If Equipped)

    Trailer hitch (if equipped) WARNING D Never exceed the maximum weight specified for the trailer hitch. Exceeding the maximum weight could cause an accident resulting in serious personal injuries. Permissible trailer weight changes depending on the situation. Refer to the next section “Trailer towing”...
  • Page 261 B Connecting a trailer CAUTION The license plate bracket will hit the hitch ball and may be dam- aged if the tailgate is opened and the license plate bracket is at the lowered/open position. Close the tailgate and return the license plate bracket to its normal position flush against the tail- gate itself whenever you tow a trailer or whenever a trailer is hitched to the vehicle.
  • Page 262 Driving tips HB8018BA 4. Insert the safety pin into the hitch pin securely. HB8019BA – CONTINUED – 8-21...
  • Page 263 5. Pull the ball mount to make sure it does not come off the hitch re- ceiver. HB8020AA 6. Use only a hitch ball that is appropriate for the ball mount and your trailer. The hitch ball must be securely installed on the ball mount. 7.
  • Page 264 9. Connect the hitch wire harness’s black four–pin wire connector to the towing trailer’s wire harness. 10. Confirm proper function of the hitch wire harness by individually activating the brake, right turn signal, left turn signal, stop, and park- ing lights on the trailer. NOTE Always disconnect the trailer wire harness before launching or retrieving a watercraft.

  • Page 265: Trailer Towing

    If you do decide to tow a trailer, your safety and satisfaction depend upon proper use of correct equipment and cautious operation of your ve- hicle. Seek the advice of your SUBARU dealer to assist you in purchas- ing a hitch and other necessary towing equipment appropriate for your vehicle.
  • Page 266 CAUTION D Adequate size trailer brakes are required when the trailer and its cargo exceed 1,000 lbs (453 kg) total weight. D Before towing a trailer, check the trailer total weight, GVW, GAWs and tongue load. Make sure the load and its distribution in your vehicle and trailer are acceptable.
  • Page 267 n Gross Vehicle Weight (GVW) and Gross Vehicle Weight Rating (GVWR) The Gross Vehicle Weight (GVW) must never exceed the Gross Vehicle Weight Rating (GVWR). Gross Vehicle Weight (GVW) is the combined total of the weight of the vehicle, driver, passengers, luggage, trailer hitch, trailer tongue load and any other optional equipment installed on your vehicle.
  • Page 268 To check both GVWR and GAWR and to confirm that the total weight and weight distribution are within safe driving limits, you should have your vehicle and trailer weighed at a commercial weighing station. Be sure that all cargo is firmly secured to prevent a change in weight distribution while driving.
  • Page 269 Tongue load OM-H2785 HB8040BB The tongue load can be adjusted by proper distribution of the load in the trailer. Never load the trailer with more weight in the back than in the front; approximately 60 percent of the trailer load should be in the front and approximately 40 percent in the rear.
  • Page 270 D Do not use axle-mounted hitches as they can cause damage to the axle housing, wheel bearings, wheels or tires. The use of a genuine SUBARU trailer hitch is recommended. A genu- ine SUBARU hitch is available from your SUBARU dealer.
  • Page 271 Check that your trailer’s brakes conform with Federal, state/province and/or other applicable regulations. Your SUBARU’s brake system is not designed to be tapped into the trailer’s hydraulic brake system. Please ask your SUBARU dealer and professional trailer supplier for more information about the trailer’s brake system.
  • Page 272 To ensure the trailer lights are connected properly, please consult your SUBARU dealer. Check for proper operation of the turn signals, the brake lights and parking lights each time you hitch up.
  • Page 273 n Tires WARNING Never tow a trailer when the temporary spare tire is used. The temporary spare tire is not designed to sustain the towing load. Use of the temporary spare tire when towing can result in failure of the spare tire and/or less stability of the vehicle. Make sure that all the tires on your vehicle are properly inflated.
  • Page 274 n Before starting out on a trip D Check that the vehicle and vehicle-to-hitch mounting are in good condition. If any problems are apparent, do not tow the trailer. D Check that the vehicle sits horizontally with the trailer attached. If the vehicle is tipped sharply up at the front and down at the rear, check the total trailer weight, GVW, GAWs and tongue load again, then confirm that the load and its distribution are acceptable.
  • Page 275 D If the ABS warning light illuminates while the vehicle is in motion, stop towing the trailer and have repairs performed immediately by the nearest SUBARU dealer. n Driving on grades D Before going down a steep hill, slow down and shift into lower gear (if necessary, use 1st gear) in order to utilize the engine braking effect and prevent overheating of your vehicle’s brakes.
  • Page 276 Driving tips gauge pointer approaches the OVERHEAT zone or the AT OIL TEMP warning light illuminates, immediately switch off the air conditioner and stop the vehicle at the nearest safe place. Refer to the “Engine overheat” section in Chapter 9, and “Warning and indicator lights” section in Chapter 3.
  • Page 277 In case of emergency If you park your vehicle in an emergency Jack and tools ............. Spare tire .

  • Page 278: If You Park Your Vehicle In An Emergency

    If you park your vehicle in an emergency HB8002BA The hazard warning flasher should be used in day or night to warn other drivers when you have to park your vehicle under emergency conditions. Avoid stopping on the road. It is best to safely pull off the road if a prob- lem occurs.

  • Page 279: In Case Of Emergency

    Jack and tools The jack supplied with the vehicle is designed only for changing a tire. Before using the jack, see the “Flat tire” section in this chapter for instructions and precautions. B Location of jack and tools The jack and tool bag are located in the left side rear quarter pocket at the back side of the rear seatback.
  • Page 280 B Removing jack and tool bag HB1109BB 1. Pull the rear seatback locks up and fold down the rear seatback to gain access to the rear quarter pockets at both sides. HB9074BA 2. Open the left side lid by turning the knob. 3.
  • Page 281 In case of emergency HB9075BA 4. Loosen the jack holding screw by turning counterclockwise and remove the jack from the pocket. NOTE D Be careful not to lose the jack holding screw after removing it. D Make sure the jack is well lubricated before using it. B Restoring jack and tools HB9076BA HB9075CA...

  • Page 282: Spare Tire

    NOTE Confirm no looseness exists after securing the jack. Looseness may cause a rattle while the vehicle is moving. CAUTION After the jack and the tool bag have been restored in the rear quarter pocket, make sure that the rear seatback has been securely locked.
  • Page 283 2. Open the tailgate and remove the rubber cap from the cargo bed. Pull up the “RELEASE” portion of the cap when removing it. 3. Locate the hex-headed hoist shaft end inside the hole. 4. Turn the hoist shaft end counterclockwise with the wheel nut wrench until the temporary spare tire is on the ground with enough cable slack to allow you to pull it out from under the vehicle.
  • Page 284 5. Tilt the retainer at the end of the cable and pull it through the cen- ter of the temporary spare tire. 6. After the temporary spare tire is removed from the cable, the cable must be wound up completely by turning the hoist nut shaft clockwise until you hear a clicking sound.

  • Page 285: Temporary Spare Tire

    B Re-storage of spare tire 1. Turn the spare tire hoist shaft end counterclockwise with the wheel nut wrench to loosen the cable sufficiently enough to allow the cable end retainer go through center hole of the temporary spare tire. 2.
  • Page 286 The temporary spare tire is smaller and lighter than a conventional tire and is designed for emergency use only. Remove the temporary spare tire and re-install the conventional tire as soon as possible because the spare tire is designed only for temporary use. Check the inflation pressure of the temporary spare tire periodically to keep the tire ready for use.

  • Page 287: Changing A Flat Tire

    Flat tires If you get a flat tire while driving, never brake suddenly; keep driving straight ahead while gradually reducing speed. Then slowly pull off the road to a safe place. J Changing a flat tire WARNING D Do not jack up the vehicle on an incline or a loose road sur- face.
  • Page 288 4. Put wheel blocks at the front and rear of the tire diagonally opposite the flat tire. 5. Take out the spare tire, jack, and wheel nut wrench. Refer to the sections “Spare tire” and “Jack and tools” in this chapter for their location, instructions and precautions.
  • Page 289 2. Place the jack under the side sill at the front or rear jack-up point closest to the flat tire. Jack-up points are indicated by arrow marks on the side of the side sill skirt. 3. Turn the jackscrew by hand until the groove of the jack head en- gages firmly into the jack-up point.
  • Page 290 4. Insert the jack drive tube into the jackscrew and attach the wheel nut wrench into the jack drive tube, and turn the handle until the tire clears the ground. Do not raise the vehicle higher than necessary. 5. Remove the wheel nuts and the flat tire. 6.
  • Page 291 8. Turn the jack handle counterclockwise to lower the vehicle. 9. Use the wheel nut wrench to securely tighten the wheel nuts to the specified torque, following the tightening order in the illustration. The torque for tightening the nuts is 66 to 81 ft-lb (90 to 110 N-m, 9 to 11 kg-m).
  • Page 292 2. Remove the rubber cap from the cargo bed. Store the rubber cap in a safe place. Pay attention not to lose the rubber cap after removal. 3. Place the flat tire in the cargo bed with the outer side of the wheel facing up.
  • Page 293 In case of emergency HB9063BA 5. Secure the flat tire by tightening the tire holding rod. The tire holding rod and retainer are designed solely to secure a flat tire in emergency. Do not use them for another purpose such as se- curing cargo.

  • Page 294: Jump Starting

    Jump starting WARNING D Battery fluid is SULFURIC ACID. Do not let it come in contact with the eyes, skin, clothing or the vehicle. If battery fluid gets on you, thoroughly flush the exposed area with water immediately. Get medical help if the fluid has entered your eyes.
  • Page 295 B How to jump start 1. Make sure the booster battery is 12 volts and the negative terminal is grounded. 2. If the booster battery is in another vehicle, do not let the two ve- hicles touch. 3. Turn off all unnecessary lights and accessories. 4.
  • Page 296 Connect the other end of the cable. To the engine lifting brack- Make sure that the cables are not near any moving parts and that the cable clamps are not in contact with any other metal. 5. Start the engine of the vehicle with the booster battery and run it at moderate speed.

  • Page 297: Engine Overheating

    Engine overheating WARNING Never attempt to remove the radiator cap until the engine has been shut off and has fully cooled down. When the engine is hot, the coolant is under pressure. Removing the cap while the engine is still hot could release a spray of boiling hot coolant, which could burn you very seriously.

  • Page 298: Towing

    This will cause the vehicle to spin away due to the operation or deterioration of the center differential. If towing is necessary, it is best done by your SUBARU dealer or a com- mercial towing service. Observe the following procedures for safety.
  • Page 299 The towing hooks should be used only in an emergency (e.g., to free a stuck vehicle from mud, sand or snow). The front towing hook is located on the inside of the towing hook cov- er below the right-hand headlight. HB9065BB HB9070BB In case of emergency...
  • Page 300 n Towing hook cover removal procedure HB9068BB HB9067BB The towing hook cover is secured by tabs that fit into corresponding slots in the vehicle body. To remove the cover: 1. Push on the position A while pulling the portion B toward you. 2.
  • Page 301 B Using a flat-bed truck This is the best way to transport your vehicle. Use the following proce- dures to ensure safe transportation. 1. Shift the selector lever into the “P” position for automatic transmis- sion vehicles or “1st” for manual transmission vehicles. 2.
  • Page 302 CAUTION D If transmission failure occurs, transport your vehicle on a flat- bed truck. D Do not run the engine while the vehicle is being towed using this method. Transmission damage could result if the vehicle is towed with the engine running. D For vehicles with automatic transmission, the traveling speed must be limited to less than 20 mph (30 km/h) and the traveling distance to less than 30 miles (50 km).

  • Page 303: Moonroof - If The Moonroof Cannot Be Closed

    3. Insert the wrench in the end of the motor shaft. D To lower the moonroof, turn the wrench clockwise. D To close the moonroof, turn the wrench counterclockwise. Have your vehicle checked by an authorized SUBARU dealer. – CONTINUED – 9-27...
  • Page 304 Appearance care Exterior care ..............Washing .

  • Page 305: Exterior Care

    Exterior care J Washing CAUTION D When washing the vehicle, the brakes may get wet. As a result, the brake stopping distance will be longer. To dry the brakes, drive the vehicle at a safe speed while lightly pressing the brake pedal to heat up the brakes.

  • Page 306: Appearance Care

    B Washing the underbody Chemicals, salts and gravel used for deicing road surfaces are ex- tremely corrosive, accelerating the corrosion of underbody compo- nents, such as the exhaust system, fuel and brake lines, brake cables, floor pan and fenders, and suspension. Thoroughly flush the underbody and inside of the fenders with luke- warm or cold water at frequent intervals to reduce the harmful effects of such agents.

  • Page 307: Cleaning Aluminum Wheels

    When in doubt, it is always best to contact your SUBARU dealer or an auto paint specialist. J Cleaning aluminum wheels D Promptly wipe the aluminum wheels clean of any kind of grime or agent.

  • Page 308: Corrosion Protection

    Corrosion protection Your SUBARU has been designed and built to resist corrosion. Special materials and protective finishes have been used on most parts of the vehicle to help maintain fine appearance, strength, and reliable opera- tion.

  • Page 309: Cleaning The Interior

    If any of them are found to be rusted, they should be given an appropriate rust prevention treatment or should be replaced. Contact your SUBARU dealer to perform this kind of maintenance and treatment if you need assistance.
  • Page 310 A mild detergent suitable for cleaning woolen fabrics may be used to remove difficult dirt spots, rubbing with a soft, dry cloth afterwards to restore the luster. If your SUBARU is to be parked for a long time in bright sunlight, it is recommended that the seats and headrests be covered, or the windows shaded, to prevent fading or shrinkage.
  • Page 311 Maintenance and service Maintenance schedule Maintenance precautions Engine hood ..............Engine compartment overview Engine oil .
  • Page 312 Fuses ............... . . Main fuse .

  • Page 313: Maintenance And Service

    Maintenance precautions When maintenance and service are required, it is recommended that all work be done by an authorized SUBARU dealer. If you perform maintenance and service by yourself, you should familiar- ize yourself with the information provided in this section on general main- tenance and service for your SUBARU.
  • Page 314 This will cause a fire. D Because the fuel system is under pressure, replacement of the fuel filter should be performed only by your SUBARU dealer. D Wear adequate eye protection to guard against getting oil or fluids in your eyes. If something does get in your eyes, thorough- ly wash them out with clean water.

  • Page 315: Engine Hood

    Maintenance and service J When you do checking or servicing in the engine compartment while the engine is running A running engine can be dangerous. Keep your fingers, hands, clothing, hair and tools away from the cooling fan, belts and any other moving engine parts.
  • Page 316 HBB003BA To open the hood: 1. Pull the hood release knob under the instrument panel. 2. Release the secondary hood release located under the front grille by moving the lever toward the left. Lift up the hood, release the hood prop from its retainer and put the end of the hood prop into the slot in the hood.

  • Page 317: Engine Compartment Overview

    Engine compartment overview Manual transmission oil level gauge (MT) (page 11-21) or Differential gear oil level gauge (AT) (page 11-24) Air cleaner element (page 11-17) Clutch fluid reservoir (page 11-30) Automatic transmission fluid level gauge (page 11-22) Brake fluid reservoir (page 11-28) Fuel filter Maintenance and service...

  • Page 318: Engine Oil

    Engine oil B Checking the oil level Check the engine oil level at each fuel stop. HBB004JA HBB061BB 1. Park the vehicle on a level surface and stop the engine. 2. Pull out the dipstick, wipe it clean, and insert it again. 3.
  • Page 319 Maintenance and service B Changing the oil and oil filter Change the oil and oil filter according to the maintenance schedule in the “Warranty and Maintenance Booklet”. The engine oil and oil filter must be changed more frequently than listed in the maintenance schedule when driving on dusty roads, when short trips are frequently made, or when driving in extremely cold whether.
  • Page 320 6. Remove three clips at the front of the cover under the oil filter. 7. Slide the cover toward the vehicle front to remove it. 8. Remove the oil filter with an oil filter wrench. 9. Before installing a new oil filter, apply a thin coat of engine oil to the seal.
  • Page 321 12. Reinstall the cover under the oil filter. 13. Pour engine oil through the filler neck. Oil capacity (Guideline): 4.2 US qt (4.0 liters, 3.5 Imp qt) The oil quantity indicated above is only a guideline. The necessary quantity of oil depends on the quantity of oil that has been drained. The quantity of drained oil differs slightly depending on the tempera- ture of the oil and the time the oil is left flowing out.
  • Page 322 When adding oil, different brands may be used together as long as they are the same API classification and SAE viscosity as those rec- ommended by SUBARU. Engine oil viscosity (thickness) affects fuel economy. Oils of lower vis- cosity provide better fuel economy. However, in hot weather, oil of higher viscosity is required to properly lubricate the engine.

  • Page 323: Cooling System

    –33°F (–36°C). For adding, use genuine SUBARU coolant or an equivalent: a mixture of 50% soft water and 50% ethylene-glycol basis coolant. Use of improp- er coolants may result in corrosion in the cooling system. It is im- portant to maintain protection against freezing and corrosion, even if freezing temperatures are not expected.

  • Page 324: Engine Coolant

    Check the fuse and replace it if necessary. If the fuse is not blown, have the cooling system checked by your SUBARU dealer. If frequent addition of coolant is necessary, there may be a leak in the engine cooling system.
  • Page 325 Rubber gaskets 3. After refilling the reserve tank and the radiator, reinstall the caps and check that the rubber gaskets inside the radiator cap are in the proper position. B Changing the coolant WARNING Never attempt to remove the radiator cap until the engine has been shut off and has cooled down completely.
  • Page 326 3. Loosen the radiator cap to drain the coolant from the radiator. Then drain the coolant from the reserve tank. Tighten the drain plug secure- 4. Slowly pour the coolant and fill to the radiator filler neck and to the reserve tank’s “FULL”...

  • Page 327: Air Cleaner Element

    Rubber gaskets 5. Put the radiator cap back on and tighten firmly. At this time, make sure that the rubber gasket in the radiator cap is correctly in place. 6. Start and run the engine for more than five minutes at 2,000 to 3,000 rpm.
  • Page 328 Replace the air cleaner element according to the maintenance sched- ule in the “Warranty and Maintenance Booklet”. Under extremely dusty conditions, replace it more frequently. It is recommended that you always use genuine SUBARU parts. HBB063BB HBB064BB 1. Remove the bolt securing the rear air cleaner element case.

  • Page 329: Spark Plugs

    D Make sure the cables are replaced in the correct order. It may be difficult to replace the spark plugs. It is recommended that you have the spark plugs replaced by your SUBARU dealer. The spark plugs should be replaced according to the maintenance schedule in the “Warranty and Maintenance Booklet”.

  • Page 330: Drive Belts

    Drive belts The alternator, power steering pump, and air conditioner compressor de- pend on drive belts. Satisfactory performance requires that belt tension be correct. To check belt tension, place a straightedge (ruler) across two adjacent pulleys and apply a force of 22 lb (98 N, 10 kg) midway between the pulleys by using a spring scale.

  • Page 331: Manual Transmission Oil

    Manual transmission oil B Checking the oil level Check the oil level monthly. 1. Park the vehicle on a level surface and stop the engine. 2. Pull out the dipstick, wipe it clean, and insert it again. 3. Pull out the dipstick again and check the oil level on it. If it is below the lower level, add oil through the dipstick hole to bring the level up to the upper level.

  • Page 332: Automatic Transmission Fluid

    SAE viscosity No. and Applicable Temperature Automatic transmission fluid B Checking the fluid level The automatic transmission fluid expands largely as its temperature rises; the fluid level differs according to fluid temperature. Therefore, there are two different scales for checking the level of hot fluid and cold fluid on the dipstick.
  • Page 333 Maintenance and service HBB004KB HBB079BB 4. Pull out the dipstick and check the fluid level on the gauge. If it is below the lower level on the “HOT” range, add the recommended au- tomatic transmission fluid up to the upper level. n Checking the fluid level when the fluid is cold When the fluid level has to be checked without time to warm up the automatic transmission, check to see that the fluid level is between...

  • Page 334: Front Differential Gear Oil (At Vehicles)

    Front differential gear oil (AT vehicles) B Checking the oil level Check the differential oil level monthly. Upper level Lower level HBA010BB HBB004EB 1. Park the vehicle on a level surface and stop the engine. 2. Pull out the dipstick, wipe it clean, and insert it again. 3.

  • Page 335: Rear Differential Gear Oil

    If the vehicle requires frequent refilling, there may be an oil leak. If you suspect a problem, have the vehicle checked at your SUBARU dealer. Your vehicle may be equipped with a rear differential protector. The differential protector provides protection to the rear differential assem- bly during off-road use.
  • Page 336 Filler plug Drain plug Remove the plug from the filler hole and check the oil level. The oil level should be kept even with the bottom of the filler hole. If the oil level is below the bottom edge of the hole, add oil through the filler hole to raise the level.

  • Page 337: Power Steering Fluid

    SAE viscosity No. and Applicable Temperature Power steering fluid B Checking the fluid level WARNING Be careful not to burn yourself because the fluid may be hot. CAUTION D When power steering fluid is being added, use only clean fluid, and be careful not to allow any dirt into the tank.

  • Page 338: Brake Fluid

    “MIN” and “MAX” line. If the fluid level is extreme low, it may indicate possible leakage. Con- sult your SUBARU dealer for inspection. B Recommended fluid “Dexron III” Type Automatic Transmission Fluid...
  • Page 339 D If the vehicle requires frequent refilling, there may be a leak. If you suspect a problem, have the vehicle checked at your SUBARU dealer. CAUTION D Never use different brands of brake fluid together. D When adding brake fluid, be careful not to allow any dirt into the reservoir.

  • Page 340: Clutch Fluid (Mt Vehicles)

    D If the vehicle requires frequent refilling, there may be a leak. If you suspect a problem, have the vehicle checked at your SUBARU dealer. D Never use different brands of clutch fluid together. D When clutch fluid is added, be careful not to allow any dirt into the tank.

  • Page 341: Brake Booster

    Brake booster If the brake booster does not operate as described below, have it checked by your SUBARU dealer. 1. With the engine off, depress the brake pedal several times, applying the same pedal force each time. The distance the pedal travels should not vary.

  • Page 342: Brake Pedal

    Lightly press the brake pedal down with one finger to check the free play with a force of less than 2 lb (10 N, 1 kg). If the free play is not within proper specification, contact your SUBARU dealer. B Checking the brake pedal reserve distance More than 2.56 in...

  • Page 343: Clutch Pedal (Manual Transmission Vehicles)

    When the measurement is smaller than the specification, or when the pedal does not operate smoothly, contact with your SUBARU dealer. Clutch pedal (Manual transmission vehicles) Check the clutch pedal free play and reserve distance according to the maintenance schedule in the “Warranty and Maintenance Booklet”.

  • Page 344: Replacement Of Brake Pad And Lining

    If you hear this scraping noise each time you apply the brake pedal, have the brake pads serviced by your SUBARU dealer as soon as pos- sible. B Breaking-in of new brake pads and linings When replacing the brake pad or lining, use only genuine SUBARU parts.

  • Page 345: Parking Brake Stroke

    (about 44 lb, 196 N, 20 kg). If the parking brake lever stroke is not within the specified range, have the brake system checked and adjusted at your SUBARU dealer. Maintenance and service –...

  • Page 346: Types Of Tires

    Tires and wheels J Types of tires You should be familiar with type of tires present on your vehicle. B All season tires The factory-installed tires on your new vehicle are all season tires. All season tires are designed to provide an adequate measure of trac- tion, handling and braking performance in year-round driving includ- ing snowy and icy road conditions.

  • Page 347: Tire Pressures And Wear

    Check on a daily basis that the tires are free from serious damage, nails, and stones. At the same time, check the tires for abnormal wear. Contact your SUBARU dealer immediately if you find any problem. NOTE D When the wheels and tires strike curbs or are subjected to harsh treatment as when the vehicle is driven on a rough surface, they can suffer damage that cannot be seen with the naked eye.
  • Page 348 Driving even a short distance warms up the tires and increases the tire pressures. Also, the tire pressures are affected by the ambient tempera- ture. It is best to check tire pressure outdoors before driving the vehicle. When a tire becomes warm, the air inside it expands, causing the tire pressure to increase.
  • Page 349 Maintenance and service D Correct tire pressure (tread worn evenly) HGB033AA Roadholding is good, and steering is responsive. Rolling resistance is low, so fuel consumption is also lower. D Abnormally low tire pressure (tread worn at shoulders) HSB012AA Rolling resistance is high, so fuel consumption is also higher. –...

  • Page 350: Wheel Balance

    If you suspect that the wheels are not correctly balanced, have them checked and adjusted by your SUBARU dealer. Also have them adjusted after tire repairs and after tire rotation.

  • Page 351: Wear Indicators

    Loss of correct wheel alignment* causes the tires to wear on one side and reduces the vehicle’s running stability. Contact your SUBARU dealer if you notice abnormal tire wear. * : The suspension system is designed to hold each wheel at a certain alignment (relative to the other wheels and to the road) for optimum straight-line stability and cornering performance.

  • Page 352: Tire Rotation

    J Tire rotation OM-H0230 Tire wear varies from wheel to wheel. To maximize the life of each tire and ensure that the tires wear uniformly, it is best to rotate the tires every 7,500 miles (12,500 km). Rotating the tires involves switching the front and rear tires on the right-hand side of the vehicle and similarly switching the front and rear tires on the left-hand side of the vehicle.

  • Page 353: Wheel Replacement

    All four tires must be the same in terms of manufacturer, brand (tread pattern), construction, and size. You are advised to replace the tires with new ones that are identical to those fitted as standard equipment. For safe vehicle operation, SUBARU recommends replacing all four tires at the same time. WARNING...

  • Page 354: Aluminum Wheels

    D Be sure to fit tire chains on uniformly and completely around the tire, otherwise the chains may scratch the wheel. D When wheel nuts, balance weights, or the center cap is replaced, be sure to replace them with genuine SUBARU parts designed for aluminum wheels. Windshield washer fluid...

  • Page 355: Replacement Of Windshield Wiper Blades

    Washer Fluid Concentration 100% Replacement of windshield wiper blades Grease, wax, insects, or other materials on the windshield or the wiper blade results in jerky wiper operation and streaking on the glass. If you cannot remove the streaks after operating the windshield washer or if the wiper operation is jerky, clean the outer surface of the windshield (or rear window) and the wiper blades using a sponge or soft cloth with a neutral detergent or mild-abrasive cleaner.
  • Page 356 1. Raise the wiper arm off the windshield. 2. Remove the wiper blade assembly by holding its pivot area and push- ing it in the direction shown by the arrow while depressing the wiper blade stopper. Stopper 3. Grasp the locked end of the blade rubber assembly and pull it firmly until the stoppers on the rubber are free of the metal support.
  • Page 357 Maintenance and service 4. If the new blade rubber is not provided with two metal spines, remove the metal spines from the old blade rubber and install them in the new blade rubber. Metal spines HS0192 5. Align the claws of the metal support with the grooves in the rubber and slide the blade rubber assembly into the metal support until it locks.

  • Page 358: Battery

    Battery WARNING D Before beginning work on or near any battery, be sure to extin- guish all cigarettes, matches, and lighters. Never expose a bat- tery to an open flame or electric sparks. Batteries give off a gas which is highly flammable and explosive. D For safety, in case an explosion does occur, wear eye protec- tion or shield your eyes when working near any battery.

  • Page 359: Fuses

    It is unnecessary to periodically check the battery fluid level or periodi- cally refill with distilled water. Fuses CAUTION Never replace a fuse with one having a higher rating or with mate- rial other than a fuse because serious damage or a fire could re- sult.
  • Page 360 5. Inspect the fuse. If it has blown, replace it with a spare fuse of the same rating. 6. If the same fuse blows again, this indicates that its system has a problem. Contact your SUBARU dealer for repairs. 11-50...

  • Page 361: Main Fuse

    SUBARU dealer. Installation of accessories Always consult your SUBARU dealer before installing fog lights or any other electrical equipment in your vehicle. Such accessories may cause the electronic system to malfunction if they are incorrectly installed or if they are not suited for the vehicle.

  • Page 362: Replacing Bulbs

    Replacing bulbs Headlight Low beam High beam Front turn signal Map light Dome light Door step light Front turn signal light/ parking and front side marker light Front fog light 11-52 Wattage Bulb No. 12V–55W 12V–60W 9005 (HB3) 12V–27W 1156NA (Amber) 12V–8W —...
  • Page 363 Licence plate light Cargo light High mount stop light Backup light Brake@rear turn signal/tail light Tail light Sports activity lights Maintenance and service HBF048CB HB3019BB Wattage Bulb No. 12V–5W 12V–13W 12V–13W 12V–21W 7440 12V–21/5W 7443 12V–5W 12V–55W – CONTINUED – 11-53...
  • Page 364 NOTE If headlight aiming is required, consult your SUBARU dealer for proper adjustment of the headlight aim. Remove the headlight bulb cover, by turning it counterclockwise. 11-54...
  • Page 365 B Low beam light bulbs 1. Disconnect the electrical connector for the black cable. 2. Remove the retainer spring. 3. Replace the bulb, then set the retainer spring securely. 4. Reconnect the electrical connector for black cable. 5. Install the headlight bulb cover. B High beam light bulbs 1.

  • Page 366: Front Fog Light

    6. Install the headlight bulb cover. J Front fog light It may be difficult to replace the bulbs. Have your SUBARU dealer replace the bulbs if necessary. J Front turn signal light, parking light and side marker light The headlight assembly must be removed before the front turn signal light and parking light bulbs can be replaced.

  • Page 367: Rear Combination Lights

    3. Remove the bulb socket from the headlight assembly by turning it counterclockwise. 4. Remove the bulb from the socket by pushing it and turning counter- clockwise. Install a new bulb in the socket. 5. Set the bulb socket into the headlight assembly and turn it clockwise until it locks.
  • Page 368 HBB084BA HBB083BA 1. Open the tailgate. 2. Pry the cover from the side of the rear combination light. 3. Remove the rear combination light mounting bolts. Then, slide the rear combination light assembly to the rear and remove it from the vehicle.

  • Page 369: Tail Light (On The Tailgate)

    9. Install the cover by inserting the knobs into the places. J Tail light (on the tailgate) 1. Open the tailgate. 2. Remove the tailgate trim by loosening the installation screws. 3. Remove the tail light cover by loosening the installation screws. 4.

  • Page 370: License Plate Light

    J License plate light HB2054BA HBB095BA 1. Remove the upper cover located above the license plate. 2. Push two release buttons and pull the license plate bracket up until it clicks. 3. Remove the two cover installation screws. 4. Push the license plate bracket back to the original position. HBB092BA 5.

  • Page 371: Map Light, Dome Light And Door Step Light

    Maintenance and service HBB093BA 7. Remove the bulb socket from the license plate bracket by turning it counterclockwise. 8. Pull the bulb out of the socket. 9. Install a new bulb in the socket by pushing it. 10. Install the bulb socket into the license plate bracket. 11.
  • Page 372 HSA005BB HBS037AB 1. Remove the lens by prying the edge of the lens with a regular screw- driver. 2. Pull the bulb out of the socket. Install a new bulb. 3. Reinstall the lens. 11-62...
  • Page 373 Maintenance and service J High mount stop and cargo light assembly HBB089BA 1. Remove the high mount stop light mounting screws. HBB090BB 2. Remove the bulb socket from the light assembly by turning it counter- clockwise. – CONTINUED – 11-63...
  • Page 374 HBB048BA 3. Remove the bulb from the socket by pulling it. 4. Install a new bulb in the socket by pushing it. 5. Set the socket into the light assembly and turn it clockwise until it clicks. 6. Mount the light assembly with the mounting screws. J Sport activity lights (if equipped) HBB082AA HBB081BA...
  • Page 375 Maintenance and service NOTE Other bulbs may be difficult to replace. Have your SUBARU dealer replace these bulbs if necessary. – CONTINUED – 11-65...
  • Page 376 Specifications Specifications ............. . Dimensions .

  • Page 377: Specifications

    Specifications These specifications are subject to change without notice. J Dimensions Overall length Overall width Overall height Ground clearance Front tread Rear tread Wheelbase J Engine Engine model Engine type Engine displacement Bore Stroke Compression ratio Firing order J Electrical system Battery type and capacity Alternator Spark plugs type...

  • Page 378: Specifications

    Transmission oil (MT) Transmission fluid (AT) AT differential gear oil Rear differential gear oil Power steering gear fluid Engine coolant J Tires Type Size Temporary spare Pressure Front Light load Full load Trailer towing Rear Light load Full load Trailer towing Temporary spare Wheel size J Wheel alignment...

  • Page 379: Fuse Panel Located Behind The Coin Tray

    Fuses and circuits J Fuse panel located behind the coin tray Fuse panel Fuse rating 12-4 Circuit D Heater fan D Heater fan D Power door lock D Keyless entry D Cigarette lighter D Remote controlled rear view mirrors D Tail light D Parking light D SRS airbag HBC001BB...
  • Page 380 Fuse panel Fuse rating Circuit D Front fog light D ABS solenoid D Radio D Clock D Trailer D Engine ignition system D SRS airbag D Illumination brightness control D Fuel pump D Rear window wiper and washer D Windshield wiper and washer D Brake light D Air conditioner D Backup light...

  • Page 381: Fuse Panel Located In The Engine Compartment

    J Fuse panel located in the engine compartment Fuse panel Fuse rating 12-6 Circuit D Radiator cooling fan (Main) D Radiator cooling fan (Sub) D ABS motor D Rear window defogger D Hazard warning flasher D Horn D Meter D SRS airbag system warning light D Automatic transmission control unit D ABS UNIT D Alternator...

  • Page 382: Bulb Chart

    Fuse panel Fuse rating Bulb chart Headlight Low beam High beam Front turn signal Spot light Dome light Door step light Parking and front side marker light Front fog light Backup light High mount stop light Brake@Rear turn signal light/Tail light 12V–21/5W Rear finisher light Licence plate light Cargo light...

  • Page 383: Vehicle Identification

    Vehicle identification Emission control label Vehicle identification number Radio noise label (Canada model) Vacuum hose connections label 12-8 Tire inflation pressure label Certification and bar cord label Vehicle identification number plate Model number plate HBC008BB...

  • Page 384: Consumer Information And Reporting Safety Defects

    Consumer information and Reporting safety defects Uniform tire quality grading standards Treadwear ..............Traction AA, A, B, C .

  • Page 385: Traction Aa, A, B, C

    For U.S.A. The following information has been compiled according to Code of Fed- eral Regulations “Title 49, Part 575”. Uniform tire quality grading standards This information indicates the relative performance of passenger car tires in the area of treadwear, traction, and temperature resistance. This is to aid the consumer in making an informed choice in the purchase of tires.

  • Page 386: Temperature A, B, C

    Consumer information and Reporting safety defects phalt and concrete. A tire marked C may have poor traction perfor- mance. WARNING The traction grade assigned to this tire is based on straight- ahead braking traction tests, and does not include acceleration, cornering, hydroplaning, or peak traction characteristics.

  • Page 387: Reporting Safety Defects (Usa)

    However, NHTSA cannot become involved in individual problems between you, your dealer, or Subaru of America, Inc. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1-800-424-9393 (or 366-0123 in the Washington D.C.
  • Page 388 We reserve the right to make changes at any time without prior notice. This information applies to “BAJA–S”. For information not covered in this supplement, refer to the OWNER’S MANUAL for 2003 BAJA. After reading the following information, keep it with your owner’s manual for future reference.
  • Page 389 Front seats WARNING Never adjust the seat while driving to avoid the possibility of loss of vehicle control and of personal injury. Never drive the vehicle with the head restraints removed be- cause they are designed to reduce the risk of serious neck injury in the event that the vehicle is struck from the rear.
  • Page 390 properly restrained. Because children are lighter and weaker than adults, their risk of being injured from deployment is greater. For that reason, we strongly recommend that ALL children (including those in child seats and those that have outgrown child restraint devices) sit in the REAR seat properly restrained at all times in a child restraint device or in a seatbelt, whichever is appropriate for the child's age, height and weight.
  • Page 391 Put children in the rearseat properly restrained at all times. Fore and aft adjustment Pull the lever upward and slide the seat to the desired position. Then release the lever and move the seatback and forth to make sure that it is securely locked into place.
  • Page 392 Reclining the seatback Pull the reclining lever up and adjust the seatback to the desired posi- tion. Then release the lever and make sure the seat is securely locked into place. The seatback placed in a reclined position can spring back upward with force when released.
  • Page 393 Ignition switch WARNING Never turn the ignition switch to “LOCK” while the vehicle is being driven or towed because that will lock the steering wheel, prevent- ing steering control. And when the engine is turned off, it takes a much greater effort than usual to steer. The ignition switch has four positions: LOCK, ACC, ON and START.
  • Page 394 " Automatic transmission vehicles The key can be turned from “ACC” to “LOCK” only when the selector lever is in the “P” position. " Manual transmission vehicles The key can be turned from “ACC” to “LOCK” only when the key is pushed in while turning it.
  • Page 395 START CAUTION Do not turn the ignition switch to the “START" position while the engine is running. The engine is started in this position. The starter cranks the engine to start it. When the key is released (after the engine has started), the key automatically returns to the “ON”...
  • Page 396 2. Remove the cover under the steering column using a phillips screw- driver. 3. Turn the ignition key while pressing the key interlock release lever. Take your vehicle to the nearest SUBARU dealer immediately to have the key interlock system repaired.
  • Page 397 Replacing bulbs – Headlight 1) Headlight Wattage Bulb No. 12V–65/55W 9007 (HB5) HBS115BB...
  • Page 398 If there are finger prints or grease on the bulb sur- face, wipe them away with a soft cloth moistened with alcohol. NOTE If headlight aiming is required, consult your SUBARU dealer for prop- er adjustment of the headlight aim. BAJA–S 1.
  • Page 399 Bulb chart Headlight Front turn signal Spot light Dome light Door step light Parking and front side marker light Front fog light Backup light High mount stop light Brake Rear turn signal light/Tail light 12V–21/5W • Rear finisher light Licence plate light Cargo light Sports activity light Wattage...
  • Page 400 Issued: December 2002 A Printed in Japan H-10.1 TOKYO, JAPAN B2311BE...

Table of Contents

Save PDF
