  • Page 1 Registered by DVGW and DIN CERTCO American Standard: UL 372 FM Class 7610 Registration Number: MH25226 3000072 and 3010410 DURAG GmbH Kollaustraße 105 · D-22453 Hamburg · Tel. +49 40 55 42 18-0 · Fax +49 40 58 41 54 Internet: www.durag.de · Email: info@durag.de...
  • Page 2 Please read this manual carefully before setting the flame monitor into operation. The adjustment of flame monitors shall be carried out only by trained staff. Therefore, DURAG offers suitable courses. Flame Monitors are certified devices. Any modifications will result in a loss of such certification.
  • Page 3: Table Of Contents

    10.5. D-LX 100 … /94 Ex and D-LX 100…/95Ex Housing for Hazardous Areas ......16 10.6. Wiring Diagram for D-LX 100…/94Ex and D-LX 100…/95Ex..........17 10.7. D-LX 100 … /96 Ex for Hazardous Areas Class I, Div. 2, Group A,B,C&D......18 10.8. D-LX 100 … /97 Ex for Hazardous Areas Zone 2..............19 10.9.
  • Page 4 Adjusting an explosion-proof flame scanner................9 (Fig. 6) Dimensional drawing: D-LX 100 ..................14 (Fig. 7) Wiring diagram: D-LX 100…-P, D-LX 100…/96Ex and D-LX 100…/97Ex......15 (Fig. 8) Dimensional drawing: Ex-proof housing type K..............16 (Fig. 9) Wiring diagram: D-LX 100…/94Ex and D-LX 100…/95Ex ..........17 (Fig.
  • Page 5: General Information

    Thanks to the fail-safe design of the hardware, and the software’s continuous checks of all safety- related functions, the D-LX 100 meets the European standards EN 230 (oil) and EN 298 (gas), as well as technical guidelines for steam boilers TRD 411 to 414 and TRD 604 for intermittent, continuous and 72-hour operation.
  • Page 6: Block Diagram

    Data compare Current output 0 / 4 - 20mA Synchronization Flame intensity Read back flame relay Flame ON K2.2 ready for operation Dynamic Internal reset K1.2 Power safety circuit supply K1.1 Power supply L+ PE (Fig. 1) D-LX 100 block diagram...
  • Page 7: Functional Description

    DURAG also offers a D-LX 100 flame scanner employing a UV photocell, which can monitor flames in the UV-C range, where wavelength is very short. In this range it is unnecessary to suppress any non- dynamic flame energy.
  • Page 8: Self-Check

    If employed for continuous operation, any component failure that jeopardizes the safety-related functions of a scanner must trigger an error shutdown. The D-LX 100 is therefore equipped with a dual-channel microprocessor system.
  • Page 9: Installation

    LED’s will blink alternately. Pressing the reset button on the front panel of the D-LX 100 acknowledges a fault in the unit and allows flame scanning functions to continue after restart. When the reset button is pressed, all LEDs will go off.
  • Page 10: Start-Up

    The 6° angle of view should always be oriented toward the root of the flame, that is, the bottom third of the flame. The D-LX 100 is mounted onto a sighting tube with a 1¼” pipe (male thread connection).
  • Page 11: Setting The Flame Recognition Threshold

    LED goes out (flame intensity current is less than 8 (or 5) mA). Once the scanner’s alignment and flame recognition threshold have been properly determined, the D-LX 100 must reliably report if a burner is shut down or if an impermissible deterioration of the flame image occurs. Consideration must be given in order that ambient light sources do not generate faulty system status.
  • Page 12: Flame Recognition Thresholds As A Function Of The Rocker Switch Setting

    Page 8 D-LX 100 7.2. Flame Recognition Thresholds as a Function of the Rocker Switch Setting Rocker Switch Beginning of Shut-off Switch-On End of Range Setting Range 0/4 mA Threshold 5/8 mA Threshold 5/8 mA 20 mA 2048 2560 2816...
  • Page 13: Setting The Amplification

    V2 to position V1. As mentioned above, this is not a feature of the D-LX 100 UL. Switching to V1 reduces signal amplification by a factor of three.
  • Page 14: D-Zs 087-20 Digital Display Unit

    ON signal. The D-LX 100 has a standard safety time of 1 s. Safety times of 3 and 5 s are available upon request. Should the safety time need to be changed, the following steps must be followed: 9.
  • Page 15: Infrared Flame Scanner

    Compared to a UV flame scanner, however, it is more sensitive to ambient light. A silicon photo element with a spectral sensitivity of λ= 300 nm to 1100 nm is used in the D-LX 100 IS. This flame scanner detects visible light. If the flame is red or gold in color, it is ”visible” to the scanner, on the pre-condition, however, that there is movement in the flame, i.e., the flame is dynamic.
  • Page 16: Selection Criteria For The D-Lx 100 All-In-One Flame Scanner

    D-LX 100 IS/96Ex D-LX 100 IS/97Ex 9.5. Options The D-LX 100 All-In-One Flame Scanner is normally delivered with the options listed in the table below. Should other options be required, please make them known when ordering. “Flame intensity” current output...
  • Page 17: Technical Data

    • Weight: ...........approx. 1.8 kg (4 lb.) 10.1. Technical Data of the Integrated Flame Scanner • Optical angle of view ......6°; for the D-LX 100 UL: 6° horiz., 12° vert. • Spectral sensitivity......185 nm – 260 nm D-LX 100 UL...
  • Page 18: D-Lx 100 Dimensional Drawing

    Page 14 D-LX 100 10.3. D-LX 100 Dimensional Drawing Cover Set screw Purge air connection G 1/2" Scanning tube connection G 1¼" Viewing angle 6° (D-LX 100 UL vert. 12°) (Fig. 6) Dimensional drawing: D-LX 100...
  • Page 19: D-Lx 100 Wiring Diagram

    Not Connected Plug M2 (Fig. 7) Wiring diagram: D-LX 100…-P, D-LX 100…/96Ex and D-LX 100…/97Ex The Flame-On-Message has to be supplied via fuse F2 on the “Contact Circuit Supply” input. Only such components are allowed to be connected to the output “Read for Operation”...
  • Page 20: D-Lx 100

    Page 16 D-LX 100 10.5. D-LX 100 … /94 Ex and D-LX 100…/95Ex Housing for Hazardous Areas D-LX 100 …/94 Ex D-LX 100 …/95 Ex 1/2” NPT(F) M20x1.5 (Fig. 8) Dimensional drawing: Ex-proof housing type K Explosion protection: ........D-LX 100…/94Ex:...
  • Page 21: Wiring Diagram For D-Lx 100

    D-LX 100 Page 17 10.6. Wiring Diagram for D-LX 100…/94Ex and D-LX 100…/95Ex ge / YE AC Mains sw / BK ´ DC Supply gn/ge Protective Earth Protective Earth GN/YE D-NG 24/05 ws / WH AC-Power Supply Flame Message ON Flame Relay K2.2...
  • Page 22: D-Lx 100

    Page 18 D-LX 100 10.7. D-LX 100 … /96 Ex for Hazardous Areas Class I, Div. 2, Group A,B,C&D Cover Set screw Purge air connection G 1/2" Scanning tube connection G 1¼" Viewing angle 6° (D-LX 100 UL vert. 12°) (Fig.
  • Page 23: D-Lx 100

    D-LX 100 Page 19 10.8. D-LX 100 … /97 Ex for Hazardous Areas Zone 2 ca. 22 Cover Set screw Purge air connection G / ” Scanning tube connection G 1 / ” Viewing angle 6° Viewing angle 6° (D-LX 100 UL vert. 12°) (Fig.
  • Page 24: Cable And Shielding

    D-LX 100 10.9. Cable and Shielding The D-LX 100 is designed for the connection of 230 VAC via the fault contact and flame contact, while the system operates in the low-voltage 24 VDC range. If the contacts are to be used in the ”high-voltage” 230 VAC range, either an appropriately insulated cable must be used to cover the entire distance from the flame scanner, or a distributor panel needs to be installed, with separate cables used after it.
  • Page 25: Maintenance And Service

    If the outside of the lens regularly accumulates deposits, the purge air flow should be adjusted to alleviate this problem. 11.1 Replacement of the Shutter and the UV-Photocell on the D-LX 100 UL The UV-photocell has a limited lifespan.
  • Page 26: (Fig. 15) Layout Of The Shutter Block With The Uv-Cell

    Page 22 D-LX 100 The replacement of the Shutter block and the UV Cell is to be done in the following manner: 1. Disconnect the scanner cable. 2. Remove the cover (4 x M3) and the housing (4 x M5 – Allen screws).
  • Page 27: Available Accessories

    D-ZS 129 - 30/40 ... LED bar graph for display of flame intensity. kle8xAWG20SIHSI ..unshielded silicone cable with DURAG color code, with UL approval, for flame sensors with wiring length up to 5m kle8xAWG18CY190..shielded PVC cable with DURAG color code, with UL approval, for flame sensors with wiring length up to 200m D-WSH 603 ....
  • Page 28: D-Ng 24/05 Ac-Power Supply

    Dimensional drawing: D-NG 24/05 Technical Data on the D-NG 24/05 AC Power Supply: • Power supply series connector: ....for operation of two D-LX 100 flame scanners • Input:............115/230 VAC +10% -15% , 42-60 Hz , approx. 15 VA •...
  • Page 29: D-Zs 033-I Ball Type Adjustment Flange

    D-LX 100 Page 25 12.3. D-ZS 033-I Ball Type Adjustment Flange Flame sensor G 1¼” Viewing pipe Flame Item Qty. Designation Material Welding flange 1.0718, galvanized Flange Al, Leg. 230 Ball joint Al, Leg. 230 Hexagon head bolt M10x50 DIN 558 Plain washer 10.5 DIN 125...
  • Page 30: D-Zs 033-Iii Ball Type Adjustment Flange

    Page 26 D-LX 100 12.4. D-ZS 033-III Ball Type Adjustment Flange Flame Sensor G 1” Purge Air G 1/2” Sighting Tube Flame Pos. Count Description Material Welding flange 1.0718, galvanized surface Flange 1.0718, galvanized surface Ball 1.0718, galvanized surface Hexagonal bolt...
  • Page 31: Weather Protection Hood

    Page 27 12.5. Weather Protection Hood On outdoor installations the D-WSH 603 Weather Protection Hood protects all D-LE 603 or D-LX 100 flame scanner against becoming rained when they are installed vertically, looking downwards. The plastic hood just has to be slipped over the flame scanner and so the flame scanner is protected ideally against rain and water.
  • Page 32: Approvals

    Page 28 D-LX 100 13. Approvals 13.1. DIN-CERTCO 13.2. EC Gas Appliance Directive 90/396/EC...
  • Page 33: Ec Pressure Equipment Directive 97/23/Ec

    D-LX 100 Page 29 13.3. EC Pressure Equipment Directive 97/23/EC 13.4. UL-Listing...
  • Page 34: Cul-Listing

    DURAG Flame Monitor System, Type D-UG110 control unit (operating voltage: 24/48/110/115/220/230 V ac, 50/60 Hz or 24/48 V dc, flame failure response time can be adjusted by DURAG between 1 and 4 sec, flame intensity output current 0-20 mA or 4- 20 mA).
  • Page 35: Atex Certificate

    D-LX 100 Page 31 13.7. ATEX Certificate...
  • Page 36: Ec Declaration Of Conformity

    (2000) **) Remark regarding to the ex-protection directive 94/9/EC The D-LX 100…/94 Ex fulfils the requirements for II 2 G EEx de IIC T5/T6. The D-LX 100…/97 Ex fulfils the requirements for II 3 G EEx nC IIC T5/T6. Remark regarding to the pressure device directive 97/23/EC As an equipment part having a safety function, the described product falls into category IV under the terms of the Pressure Equipment Directive 97 / 23 / EC.
