- Page 1 Stand Fan User Manual Model No.: FSF1616 *Before operating the appliance, please read this manual and all the safety instructions thoroughly and retain it for future reference.
-
Page 2: Table Of Contents
PAGE CONTENT SAFETY INSTRUCTION PARTS DESCRIPTION INSTALLATION INSTRUCTION OPERATION INSTRUCTION MAINTENANCE INSTRUCTION SPECIFICATION WARRANTY... -
Page 3: Safety Instruction
SAFETY INSTRUCTION IMPORTANT SAFETY INSTRUCTIONS – READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. 1. To avoid electric shock, fire or injury, please read the user manual carefully before using the appliance and keep it for future reference. 2. This appliance is for household use only. Please use suitable power source (Please refer to SPECIFICATION). -
Page 4: Parts Description
PARTS DESCRIPTION Guard ring Front guard Rear guard Motor Fan blade Head unit Height adjustment Power cord Inner pole Height adjustment ring Height adjustment outer pole Base plate - 3-... -
Page 5: Installation Instruction
INSTALLATION INSTRUCTION Caution: Please unplug the appliance before installation. 1. Base and head unit installation Loosen the height adjustment ring in anticlockwise direction. Lift the inner pole to certain height and screw the height adjustment ring in clockwise direction. Rotate out the connecting sheet and connecting bar at the bottom of the outer pole (Fig. - Page 6 2. Guard and fan blades installation A. Rear guard Unscrew the fan blade knob from the motor shaft in clockwise direction (Fig. 6). Unscrew the rear grille knob from the motor shaft in anticlockwise direction (Fig.6). Set the rear guard and fit it well on the two position holes and make sure these holes are properly put through the holes on the rear guard (Fig.
- Page 7 Blade knob Fig. 10 C. Front guard Normally, the guard ring is installed with the front guard. Loosen the screw on the bottom of the guard and fit the front guard with guard ring into the rear guard. After that, lock the guard clip and tighten the screw (Fig.11).
-
Page 8: Operation Instruction
OPERATION INSTRUCTION 1. Power on / speed adjustment Press fan speed button for speed adjustment： 0:Off / Stop 1:Soft Speed 2:Low Speed 3:Medium Speed 4：High Speed Note: If the timer knob is turned to “OFF”, the fan is turned off. Please ensure the timer knob is turned to “ON”... -
Page 9: Maintenance Instruction
· Do not swash with water. · Do not use hard objects to clean the fan. · Regular cleaning is suggested to avoid dirt blockage that may result in mechanical failure. SPECIFICATION FSF1616 Model No. Product name Stand fan Rated Voltage/Frequency... - Page 10 3. CUSTOMER MUST PRESENT THE SALES INVOICE OR RECEIPT FOR 2 YEAR WARRANTY SERVICES. 4. Please bring along the product and sales invoice or receipt to our services center for warranty services during office hour: Address Unit A, 20/F, Yip Shing Industrial Centre, No.19, Yip Shing Street, Kwai Chung.
