- Page 1 TECHNICAL DATA & SERVICE MANUAL INDOOR UNIT: MCAF185R5 MCAF225R5 SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. MCAF185R5 MCAF185R5TAA MCAF225R5 MCAF225R5TAA 0.8180.466.0 07/05...
- Page 2 • Ground the unit following local electrical codes. IMPORTANT! • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 3: Table Of Contents
Table of Contents Page 1. SPECIFICATIONS 1-1 Unit specifications 1-2 Major Component specifications 1-3 Other Component specifications 2. DIMENSIONAL DATA 3. SOUND LEVEL CHARACTERISTICS 3-1 Sound pressure levels 4. ELECTRICAL DATA 4-1 Electric Wiring Diagrams 5. CONTROL SYSTEM 5-1 Electronic control 5-2 Legend 5-3 PCB 5-4 General Functions... -
Page 4: Specifications
1. SPECIFICATIONS 1-1 Unit Specifications MCAF185R5 220 - 240V ~ 50Hz Power source 230V - 50 Hz Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity Air circulation (High) m³/h Features Microprocessor/ I.C. thermostat Controls/Temperature controls Wireless remote control unit... - Page 5 MCAF225R5 220 - 240V ~ 50Hz Power source 230V - 50 Hz Voltage rating Cooling Heating Performance See catalogue with the requested matching Capacity Air circulation (High) m³/h Features Microprocessor/ I.C. thermostat Controls/Temperature controls Wireless remote control unit Control unit Timer ON/OFF 24 hours 3 and Auto...
-
Page 6: Major Component Specifications
1-2 Major Component Specifications MCAF185R5 Controller PCB Part No. Controls Microprocessor Control circuit fuse 250 V - 3,15 A RC-7 (RC) Remote Control Unit Fan & Fan Motor Cross - flow Type 1…. Ø 92 Q'ty ……. Dia. and lenght RPS18M-2…1... - Page 7 MCAF225R5 Controller PCB Part No. Microprocessor Controls Control circuit fuse 250 V - 3,15 A RC-7 (RC) Remote Control Unit Fan & Fan Motor Cross - flow Type 1…. Ø 92 Q'ty ……. Dia. and lenght RPS30G-2…1 Fan motor model…Q'ty 4…1300 No.
-
Page 8: Other Component Specifications
1-3 Other Component Specifications MCAF185R5 MCAF225R5 NTC-THERMISTOR Thermistor ( Coil sensor ) ΚΩ 10 at 25 °C Resistance NTC-THERMISTOR Thermistor ( Room sensor ) ΚΩ 10 at 25 °C Resistance... -
Page 9: Dimensional Data
2. DIMENSIONAL DATA... -
Page 10: Sound Level Characteristics
3. SOUND LEVEL CHARACTERISTICS MCAF185 MCAF225... -
Page 11: Electrical Data
4. ELECTRICAL DATA 4-1 Electric Wiring Diagrams... - Page 47 R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
