- Page 1 User‘s Guide AR006087 AR005892 AR004525 AR006092 AR006088 AR006089 AR006090 AR003954 AR006779 AR006091 AR006093 AR005348 GSM modem dataloggers...
- Page 2 All rights reserved. The Guilcor company continuously developing and improving its product. Guilcor reserves the right to carry out technical changes in equipment or product without any previous notice. Contact address of this device Guilcor Route de Carolles, 50530 Sartilly-Baie-Bocage,France...
-
Page 3: Table Of Contents
List of contents INTRODUCTION ..................4 DATALOGGER ................;.... 5 SAFETY MEASURES AND UNAUTHORIZED MANIPULATIONS ..... 6 GUIDE TO INSTALLATION AND USAGE OF THE DEVICE ...... 7 Inserting the SIM card into the device ........... 7 Installing the datalogger, placing the probes ......... 8 Device set-up ................ -
Page 4: Introduction
Introduction This datalogger is designed for autonomous measurements and recording of physical and electrical data, with the data recording interval from 1 s to 24 h. The inputs and ranges of quantities to be measured are determined by the model type the user has bought. The user cannot modify them. This portable device can be mounted in a fixed-position. -
Page 5: Datalogger
Datalogger (AR004525 model) -
Page 6: Safety Measures And Unauthorized Manipulations
Safety measures and unauthorized manipulations Read the following safety directions carefully before putting the device into operation. Follow these instructions when using the device! • Legislative conditions. This datalogger contains a radio transmitter working in GSM frequency bands and using power values that are shown in its Technical parameters. These bands and power values are used in the countries of the European Union. -
Page 7: Guide To Installation And Usage Of The Device
Guide to installation and usage of the device Inserting the SIM card into the device • Prepare suitable SIM card - depending on the intended use, prepare a SIM card for the 2G network that will meet the expected amount of sent SMS messages and transmitted data. -
Page 8: Installing The Datalogger, Placing The Probes
Search another installation location if the signal quality is not satisfactory. It is especially in iron concrete constructions, cellars, metal AR006087 chambers or other shielded rooms that the GMS signal may be insufficient. - Page 9 • This device may be operated as a portable one. In this kind of operation avoid the device falling. Try to maintain the proper working position. • You can screw the device on the wall or some other solid base •...
-
Page 10: Device Set-Up
For more information refer to the chapter „MODELS PRODUCED“. • Install the software into your computer - is available for free on the address www.guilcor.com. • Run software • Connect the device to the computer - on the datalogger side, use a USB cable provided with a USB-C terminal. -
Page 11: Device Disposal Procedure
the charging speed with the power on is deliberately slowed down to avoid excessive measurement influence. If you want to charge the device as soon as possible, turn it off first. When the device is turned off, the fast charging mode is automatically activated. Fully charged battery is indicated on the display of the device usually within 6 hours. -
Page 12: Operating The Datalogger From The Keypad
Operating the datalogger from the keypad Displaying the device data Data memory occupancy - this display section offers information about the current condition of the free space existing in the data memory. The blinking of the Memory symbol indicates that the preset memory occupancy limit has been exceeded. - Page 13 A continuous recording with a preset interval is ON and running. The recording is ON in the device and it is running at present. This kind of display is utilized, when the record activity is dependent on the alarm or the external input condition. The recording is ON in the device but it is not running at present.
- Page 14 Battery condition this symbol provides overview information about the current battery charging condition. The charging is indicated by flashing one of these symbols. Battery conditions during battery operation of the device: Fully charged battery Partly discharged battery Heavily discharged battery Totally discharged battery, the device will be switched OFF.
- Page 15 take place only manually by the aid of push buttons situated beside the display unit. The upper push button serves to toggle between the measured values („the screens“): The lower push button serves to toggle between the currently measured values and the Min/Max values: The device can also be set up to toggle the „screens“...
-
Page 16: Menu Options
Menu Options The menu can be entered by pressing a combination of both keys. In any case, using the keypad must be enabled in the device configuration. Individual menu items, too, may be disabled in the device setup. It is e. g. possible to switch on the device in this way, but it is not possible to switch it off. -
Page 17: Models Produced
The user cannot change the type and range of the values to be measured. If GSM communication is used, it is necessary to pay attention to a sufficient level of GSM signal at the location. AR006087 One-channel thermometer This model is equipped with only one internal temperature sensor, no additional probes and sensors can be connected. - Page 18 AR004525 Four-channel thermometer for external probes This model can measure up to four temperature values transmitted by Pt1000/E series external probes. The response temperature jump depends on the connected probe design. As a rule, this model is few times faster than that using the inner sensor. It is often used to monitor locations where the device itself is not directly in the measuring space and only probes are in.
- Page 19 AR006089 Thermometer – hygrometer for external probe This model measures temperature, relative humidity and dew point temperature using an outdoor Guilcor Digi/E series probe. response temperature or relative humidity jump is significantly faster than by models with internal sensor.
- Page 20 immediately. The device alone is suitable for measuring in places where there is no rapid change in temperature or relative humidity, and there is no condensation of water vapours. If water vapour condensation occurs inside the datalogger, then the resulting water will remain there and may damage its electronics.
- Page 21 at the installation location. As the internal battery creates a parasitic heat during the charging period, the measurement accuracy may be affected by up to 1 ºC. In battery mode, this model has significantly shorter battery life than models without CO concentration measurement.
- Page 22 AR006092 Two-channel binary-input thermometer for external probes This model can measure up to two temperature values, which are sensed by outdoor Pt1000/0 series probes. In addition, it is provided with two binary inputs for monitoring voltage-signal changes or changes of a signal coming from voltage-free...
- Page 23 AR006779 Datalogger with 3 inputs 0 – 10 V and 1 binary input This model is used to measure up to three voltage inputs 0-10 V DC while allowing one binary input to be monitored. The voltage inputs are not galvanically separated from one another.
- Page 24 AR006091 Datalogger with 3 inputs 0 - 20 mA and 1 binary input This model is used to measure up to three signals from current loops (0 to 20) mA DC while allowing one binary input to be monitored. The current inputs are passive and are not galvanically separated from one another.
- Page 25 AR006093 Two-channel binary-input counter This model includes four inputs. Two of them can function as counters, and all four inputs can function as binary inputs. Both counter and binary inputs serve to monitor voltage signals or signals coming from a voltage-free contact. The binary input changes are registered immediately, irrespectively of the recording interval setting.
-
Page 26: Vision Program
The program is used to set up devices, to obtain the recorded data and the currently measured values. The program is available free of charge (www.guilcor.com), any number of devices can be connected simultaneously (e. g. data from several devices can be downloaded concurrently; several online displays may be running at a time). -
Page 27: Setting Up The Device
Setting up the device After the datalogger has been switched on, it starts measuring, data recording and evaluating alarms according to the device’s setting up performed by the user. Complete device setup can be performed by the aid of the user software (hereinafter SW). During configuration editing the device can work normally, nevertheless the access to some functions (record download, contemporary configuration editing by other users) is limited. - Page 28 General - Preferences _____________________________ In this panel you can choose the unit with which the device will measure the temperature (Default temperature unit °C/°F). With some devices the pressure unit can be chosen, too (Default atmospheric pressure unit). When the device does not measure the atmospheric pressure, but when it is necessary to know its value to measure some quantities (calculated humidity and CO ), the atmospheric pressure value must...
- Page 29 in the measurement values and a long battery lifetime is what matters, you can set the measurement interval to 1 minute. The CO concentration channel measures with a 2-minute interval and can be extended up to 10 minutes to save more battery life. For details concerning power consumption, see Technical parameters.
- Page 30 Channels_______________________________________ In this panel you can set all input channels. The assignment of the measurement value and its range to a channel is factory-set and cannot be changed. Supply a suitable name of the location to be measured for each channel and decide whether it will be switched on for measurement and for recording.
- Page 31 momentary overshoots of the limit value. The hysteresis, too, has a similar significance (Alarm hysteresis). It prevents the alarm from oscillating in the case that the measurement value varies around the alarm limit value. It is not recommended to set it equal zero. Thus, the setting for generating an alarm is completed.
- Page 32 An alarm can be signalized by a fast flashing of the LED diode on the device panel (Optical signalling - LED). In the case that only one alarm originating from a measurement value is active, a yellow LED is flashing. In the case that more alarms occur simultaneously, or a system alarm or an alarm originating from an exceeded memory occupancy limit...
- Page 33 Deactivation of the signalling can be according to the device configuration: - permanent - the optical and/or acoustic signalling is deactivated until new alarm occurs. In this case, the "Reactivate muted alarm signalling" item must be switched off in the device configuration. - time-limited (temporary) - if the alarm after the set time interval is still current, the optical and/or acoustic signalling is activated again.
- Page 34 Modem - General _________________________________ In the configuration enter the PIN code for your SIM card, if required (given by the settings of the SIM card used). By default, your device is set to not require the PIN code. If the PIN code is set on the SIM card and the required pin is set incorrectly in the device configuration, the SIM card will be blocked when attempting to connect to the GSM network, see Display warnings chapter.
- Page 35 Modem – Text message - Keep alive SMS ______________ In this panel you can set Keep-alive SMS sending parameters. It means sending information messages at regular intervals, regardless of alarm status. Set the interval for sending Keep-alive text messages. Such messages can be sent by the device to all selected recipients on regular interval basis.
- Page 36 • Periodically in preset interval. The interval is selectable from 5 minutes to once per week and you can set different interval when battery powered and when it have external power available. • Asynchronously (immediately) when preset alarm occur. For battery mode you can select „Buffered mode“ option which collects data into internal buffer and then sends them together in preset interval.
-
Page 37: Application Notes
Application notes Operation with a constantly connected charger __________ Datalogger is primarily intended to be operated as an autonomous unit powered by its built-in batteries. Nevertheless, you can also operate it with a charger which is constantly connected to it, or with a computer. The datalogger’s internal charging circuitry controls the battery charging process based on its instantaneous condition, thus protecting it against damage. - Page 38 Problems with measurement correctness ______________ Incorrect measurement values of temperature or relative humidity may, in most cases, be caused by an unsuitable probe location or improper methodology. Some notes concerning these problems are mentioned following chapter Recommendations operation and maintenance. In probes using current and voltage outputs incorrect measurement results may be induced by latent coupling between individual components, e.g.
- Page 39 fast for a short time (registration in the network), then more slowly (message sending) to finally go off (finishing). • If the blue diode does not start flashing at all, then the datalogger‘s radio section has not been activated at all. It may be caused by an improper setting: A non-functioning SIM card has been inserted, the SIM Card has been blocked because a wrong PIN has been entered, the alarm is not activated at all, no phone number is...
-
Page 40: Recommendations For Operation And Maintenance
Recommendations for operation and maintenance Datalogger operation in several application areas________ Before putting the device into operation, it should be considered, if its usage is suitable for the intended purpose. In connection with this consideration the device‘s optimum settings should be determined. In the case that the device is part of a larger measurement system, instructions for its metrological and operational checks should be developed... - Page 41 Positioning of humidity sensors: The positioning of humidity sensors depends again on the application requirements. Humidity measurements in refrigerators without additional humidity stabilization can be very questionable. When the cooling is switched on/off, there may be significant changes in humidity in the range of tens of percent, even if the mean value is correct.
- Page 42 Service recommendations _________________________ Engineering support and service activities are provided by the device distributor. His contact person‘s address is given in the Certificate of warranty included with the product. WARNING - Unskilled intervention into the device may lead to loss of warranty!
-
Page 43: Technical Parameters
Technical parameters Power supply The device is supplied from an internal Li-ion battery, which is placed under the rear cover. The battery may be replaced by the producer or an authorized service provider only. Battery _________________________________________ Battery model used: BAT26001S2P Li-ion 2 PACK US18650VTC5 5200 mAh SONY (2x 2600mAh) Operating lifetime relating to a single charge of the Li-ion accumulator:... -
Page 44: Usb Communication Interface
the power on is deliberately slowed down to prevent excessive influence of measured values. If you want to charge the device as soon as possible, turn it off first. When the device is turned off, the fast charging mode is automatically activated. Fully charged battery is indicated on the display of the device usually within 6 hours. -
Page 45: Radio Section
Radio section The datalogger includes a GSM modem intended for data transfer and sending SMS messages. This modem is only powered up and registered in the GSM network only when SMS messages' sending off is required. Otherwise it is switched off. GSM modem: Quad-band 850/900/1800/1900MHz GPRS Mobile Station Class B... -
Page 46: Parameters Of Datalogger Inputs
Recommended calibration interval: 2 years AR005892 ________________________________________ Measured values: 2 x temperature sensed by an external Guilcor Pt1000/E series probe Temperature range: (-200 to +260) °C, Pt1000/3850 ppm sensor Measuring current: ca 0.5 mA with pulses of ca 60 ms... - Page 47 0.1 °C Recommended calibration interval: 2 years AR004525________________________________________ Measured values: 4 x temperature sensed by an external Guilcor Pt1000/E series probe Temperature range: (-200 to +260) °C, Pt1000/3850 ppm sensor Measuring current: ca 0.5 mA with pulses of ca 60 ms...
- Page 48 AR006088 ________________________________________ Measured values: Internal temperature, relative humidity. Dew-point temperature calculated from the internal temperature and relative humidity. Ranges: Temperature: (-20 to +60) °C Relative humidity: (0 to 100) %RH without lasting condensation. Dew-point temperature: -90 to +60 °C (*1) Accuracy Temperature: ±...
- Page 49 1 year (according to the connected probe) AR006090 ________________________________________ Measured values: Internal temperature, relative humidity. 1x External temperature measured by an external Guilcor Pt1000/E probe. Dew-point temperature calculated from the internal temperature and relative humidity. Difference of external temperature and dew point temperature. Ranges: Internal temperature: (-20 to +60) °C...
- Page 50 Dew-point temperature: ±1.5 °C at an ambient temperature of T< 25 °C and RH >30 %. For details see diagrams in Annex 3. External temperature input (without probe): ± 0.2 °C in the range -90 °C to +100 °C ± 0.2 % of the measured value in the range +100 °...
- Page 51 Ranges: Temperature: (-20 to +60) °C Relative humidity: (0 to 100) %RH without lasting (*2) condensation Barometric pressure (absolute): 700 hPa to 1100 hPa Concentration of CO in the air: 0 to 5000 ppm Dew-point temperature: -90 to +60 °C (*1) Accuracy Temperature: ±...
- Page 52 AR006092 ________________________________________ Measured values: 2 x temperature by an external Guilcor Pt1000/0 probe 2 x binary input intended for voltage to be applied to it or a voltage-free contact open-collector transistor) to be connected to it. This device is not suitable for catching the „voltage applied/not applied”...
- Page 53 Response time: Is determined by the response time of the used probe. Resolution: 0.1 °C converter range: 16 bits Recommended calibration interval: 2 years AR006779 ________________________________________ Measured values: 3 x voltage (0 – 10) V 1 x binary input. This input can be configured to accept voltage signals or a voltage-free contact (as e.g.
- Page 54 AR006091 ________________________________________ Measured values: 3x current input, 1 x binary input. This input can be configured to accept voltage signals or a voltage-free contact (as e.g. an open-collector transistor). Unlike the AR006092 model, this input can capture connected/disconnected voltage status. Range and input levels: Current input: Range: (0 to 20) mA DC...
- Page 55 AR006093 ________________________________________ Measured values: 2x user configurable binary input for applying voltage or connecting voltage-free contact (as e.g. AR006092 open-collector transistor). Unlike model, this input is able to catch also the „voltage applied/not applied“ states. 2 x counting input. This input, like the binary one, can be configured to accept voltage signals or a voltage-free contact e.g.
-
Page 56: Operating And Storage Conditions
AR005348 ________________________________________ Measured values: Concentration of CO in the air. Ranges: Concentration of CO2 in the air: 0 to 5000 ppm (the device it is possible to deliver with a range of 0 to 10000 ppm) Accuracy: concentration in the air: 50 + 0.03 ×... -
Page 57: Mechanical Properties
Mass: Ca 250 g including batteries Case material: Polycarbonate LEXAN EXL1434T resin Ingress protection: Protection class Device case with temperature and type electronics rel. humidity sensor AR006087 AR005892 IP67 AR004525 AR006089 AR006088 IP67 IP30 AR006090 AR003954 IP20 IP20 AR006092... -
Page 58: Declaration Of Conformity
Declaration of conformity This datalogger is in compliance with the requirements of Directive 2014/35/EU. The original Declaration of Conformity can be found on the manufacturer's website www.guilcor.com. -
Page 59: Dimensions
Dimensions AR006087, AR005348 AR005892... - Page 60 AR004525 AR006088, AR003954...
- Page 61 AR006089 AR006090...
- Page 62 AR006092, AR006779, AR006091,...
-
Page 63: Annexes
Annexes Annex 1: Selected error messages of the device Error Description and debugging A/D converter is at low limit, 0x0000. Error 1 Contact support. Error 2 Temperature probe is not connected or cable is damaged. Internal converter communication error. Error 3 Contact support. -
Page 64: Annex 2: Connection Of The Pt1000/E Serie Probe Connector
Error Description and debugging The source value of the calculated quantities is not available. Check in the SW whether measurement values are available Error 20 (temperature and relative humidity) for this calculated quantity in question (e.g. the dew-point temperature). Calculation failure, incorrect device calibration. Error 21 Have the device repaired. -
Page 65: Annex 3: Accuracy Of The Dew-Point Temperature Measurement
Annex 3: Accuracy of the dew-point temperature measurement Annex 4: Connecting block Some inputs are equipped with a split self- locking WAGO connector block. Connect wires block with corresponding a screwdriver the size: insert a screwdriver into the connecting block’s angular opening situated... -
Page 66: Annex 5: Sms Message Format
Annex 5: SMS message format SMS message format for SYSTEM ALARM: The message header includes: SYSTEM ALARM<enter> „Description of the device DescDev“<enter>“ Depending on the type of alarm, the corresponding text: Data memory limit overflow, Battery warning, Battery empty, Battery Ok, External power lost, External power Ok;... - Page 67 DataKeepAliveSMS format (suitable for automated data processing): All data coded into ASCII, it means 1 Byte will be sent as 2 ASCII characters. (hex. value 0x9E will be sent as two ASCII characters ‘9’ ’E’) Initial text "Datalogger" 10 ASCII chars Space 1 ASCII char Serial number...
- Page 68 HumanKeepAliveSms format: The Text of the message is gradually consisting of the items in the order below. The length of this report is limited to max 160 characters. If the message was longer, then it sends only the first 160 characters. The format of the message: - description of the device from the configuration: max.
-
Page 69: Annex 6: Firmware Updates
Annex 6: Firmware updates FW version 0.0.129 changes: - added new JSON data version format Version6 - added new parameter: TimeNow Device time at the moment of sending JSON data as count of seconds since 1.1.2000. FW version 0.0.118 changes: - added new JSON data version format Version5 - added new parameter: BatteryPercentage. - Page 70 available yet) and is going to be send at next sending time again. It means, unsent data packet is not lost and will be delivered later together with newer one. This is very useful function if mobile network or server connection is temporary lost.
