- Page 1 330 Club Springs Road Elmwood, TN 38560 Phone: (615) 897-2011 Fax: (615) 897-2023 www.zena.net ZENA mobile welding system ™ Power Generator Testing/Cleaning for All ZENA Mobile Welders Utilizing Factory Installed ™ ZENA Series 150, 200, or 250 Power Generators ™...
- Page 2 Elmwood, Tennessee 38560 Printed in U.S.A. ™ ZENA is a trademark owned by ZENA, Inc. for its welding systems and related products. ™ ZENA is a trademark owned by ZENA, Inc. for its farm tools and equipment. Protected by US Pat. 6,512,119. Other US & Foreign Patents Pending...
-
Page 3: Table Of Contents
Table of Contents ZENA™ Power Generator Testing (all models)............................1 Belt Drive ............................1 Electrical Function ..........................1 ZENA™ Power Generator Care & Maintenance ............................3 A . Lubrication ............................. 3 B. Wet Conditions ..........................3 C. Cleaning............................3 D . DO NOT… ............................ 4 Cleaning Slip Rings/Brushes......................................5... -
Page 5: Zena™ Power Generator Testing (All Models)
ZENA™ Power Generator Testing (all models) Belt Drive Proper belt drive efficiency is key to insuring long term trouble free generator operation. This is achieved by having three things in balance -- drive pulley size, drive pulley belt wrap, and proper belt tension. Not too loose and definitely not too tight. If things are in balance, belt tension will be correct and the belt will not slip. - Page 6 typically an indication that grease, or some similar material may have caused “fouling” or glazing of the brushes and/or internal slip-rings. Cleaning can be accomplished in the field, if necessary , but is best done under factory (dust free) conditions. Disconnect the generator’s output terminal from any load, and check in the electrical resistance between each of the terminals and the case of the Power Generator.
-
Page 7: Zena™ Power Generator Care & Maintenance
ZENA™ Power Generator Care & Maintenance The ZENA power generator is very robust. Other than keeping it clean, NO regular preventive maintenance is required. A. Lubrication Not required. All moving parts are permanently lubricated. B. Wet Conditions All critical electrical parts are sealed from moisture and all mechanical components are designed to operate in wet conditions (but not when immersed in water). -
Page 8: Do Not
the generator to its normal operating speed to allow the cooling fan to remove most excess moisture from inside the case. If available, compressed air can be used to good advantage at this time to assist in the process of “drying” the generator. 4) After Operating in Wet Conditions Excess water should be removed from the Welding Power Generator by operating the vehicle’s engine briefly to allow the cooling fan to remove most excess moisture from... -
Page 9: Cleaning Slip Rings/Brushes
Cleaning Slip Rings/Brushes Cleaning can be accomplished in the field, if necessary -- but is best done under factory (dust free) conditions. Factory cleaning will be performed free of any labor charge, with charges only for return freight cost. However, if circumstances dictate that you need to clean the unit yourself, carefully follow these instructions: Step 1 –... -
Page 10: Step Three - Slip Ring Cleaning
Then, using a properly sized, unworn, Allen wrench, loosen first one pair of opposing bolts – then the second pair. When all four bolts have all been loosened, remove all four bolts from the case and set them aside. Locate the point where the front case and the iron lamination of the stator assembly meet. With a small screwdriver, working around the case perimeter, gently pry the front case assembly away from the stator assembly. -
Page 11: Step Four - Reassembly
Step Four – Reassembly Place the rear generator case on the bench top – orienting the generator case so that the rotor assembly can be gently lowered into the case until the end of the rotor shaft enters the rear needle bearing. At this time take particular care that the output terminals are positioned, in relation to the generator mounting foot and tensioning tab so as to meet the needs of your particular installation. -
Page 12: Return For Service
If you determine that you have a problem which requires either further troubleshooting assistance from our tech support department or need a return authorization for a possibly malfunctioning component for test/repair call 877-ZENA INC (toll free in the USA) or 615- 897-2011, e-mail us at support@zena.net...
