18 GAUGE FLOORING STAPLER
CALIFORNIA PROPOSITION 65
WARNING: You can create dust
when you cut, sand, drill or grind
materials such as wood, paint,
metal, concrete, cement, or other
masonry. This dust often contains
chemicals known to cause cancer,
birth defects, or other
reproductive harm. Wear
protective gear.
WARNING: This product or its
power cord may contain
chemicals, including lead, known
to the State of California to cause
cancer and birth defects or other
reproductive harm. Wash hands
after handling.
Important!
When using equipment, a few safety
precautions must be observed to
avoid injuries and damage. Please
read the complete operating manual
with due care. Keep this manual in a
safe place, so that the information is
available at all times. If you give the
equipment to any other person, give
them these operating instructions as
well. We accept no liability for
damage or accidents which arise due
to non-observance of these
instructions and the safety
information herein.
For Customer Service, please call 1-800-348-5004 or
email feedback@natitools.com
SPECIFICATIONS
Minimum Operating Pressure:
60 PSI
Maximum Operating Pressure:
100 PSI
Stapler Size: 18 gauge
Staple Length: 3/8 in. - 1/4"
Magazine Capacity: 100 nails
Air Inlet: 1/4 in.
Air Consumption: 1 CFM
CAUTION:
FOR YOUR OWN SAFETY READ
INSTRUCTION MANUAL
COMPLETELY AND
CAREFULLY BEFORE
OPERATING THIS FLOORING
STAPLER.
Any failures made in following
the safety regulations and
instructions may result in an
electric shock, fire and/or
serious injury.
1
Models: 7560
SAFETY INSTRUCTIONS
• KEEP WORK AREA CLEAN.
Cluttered areas invite injuries.
• DON'T ALLOW CHILDREN
AROUND THE WORK AREA.
Do not let children handle the
tool.
• DO NOT OPERATE THIS
TOOL IF UNDER THE
INFLUENCE OF ALCOHOL OR
DRUGS. Read the warning
labels on prescriptions to
determine if your judgment or
reflexes are impaired while
taking drugs. If there is any
doubt, do not attempt to
operate.
• USE SAFETY GLASSES.
Safety glasses should conform
to ANSI z87.1 specifications.
Safety glasses should be worn
against flying to debris from the
front and side. Safety glasses
should be worn when loading,
operating, unloading, or
servicing the tool.
• USE EAR PROTECTION. The
working area may be exposed to
high noise levels that can lead
to hearing damage.
• NEVER USE OXYGEN,
COMBUSTIBLE GASES,
BOTTLED GASES, OR HIGH
8807560
05/13
Advertisement
Table of Contents
Related Manuals for North American Tool 7560
Summary of Contents for North American Tool 7560
- Page 1 18 GAUGE FLOORING STAPLER Models: 7560 CALIFORNIA PROPOSITION 65 SPECIFICATIONS SAFETY INSTRUCTIONS WARNING: You can create dust Minimum Operating Pressure: • KEEP WORK AREA CLEAN. when you cut, sand, drill or grind 60 PSI Cluttered areas invite injuries. materials such as wood, paint, Maximum Operating Pressure: •...
- Page 2 PRESSURE COMPRESSED GAS outside use. See manufacturer’s SETTING AS A POWER SOURCE FOR manual for the AWG required for Your air tool is fully assembled THIS TOOL. The tool may explode the compressor’s amperage draw. when you receive it. Before and cause serious injury.
- Page 3 If you are using an automatic in- OPERATING THE TOOL 2. Use a small amount of oil on all line oiler, check and add oil if moving surfaces and pivots. Test the driving depth in a necessary sample piece of wood before 3.
- Page 4 Symptom Possible Cause(s) Corrective Action O-Ring in trigger valve is damaged Check and replace O-Ring. Air leak near top of tool or in Trigger valve head is damaged Check and replace trigger valve head. trigger area Check and replace trigger valve stem, seal, or O- Trigger valve stem, seal or O-Ring is damaged.
- Page 5 DO NOT RETURN TO STORE North American Tool Industries (NATI) makes every effort to ensure that this product meets high quality and durability standards. NATI warrants to the original retail consumer a 1-year limited North American Tool (NAT) Industries makes every effort to ensure that this product meets high warranty from the date the product was purchased at retail and each product is free from defects in quality and durability standards.
- Page 6 18 GAUGE FLOORING STAPLER Model: 7560 For Customer Service, please call 1-800-348-5004 or 8807560 05/13 email feedback@natitools.com...
- Page 7 Description Description Screw m4*10 Washer Bushing Trigger Assembly Exhaust Cover Trigger Pin Washer Screw M4*16 Screw M5*20 Washer Spring Washer 5 Oblique Block Cylinder Cap Screw M5*25 Gasket Screw M5*8 Spring Cover Plate Valve Seat Limited Blick O-Ring 15.7*2 Slide Plate O-Ring 38.8*3 Bushing Valve...
