GSM Scout Serie

Softwareversion 37

This sign indicates important informations that have to be read

most carefully. Please observe these informations in order to

avoid missunderstandings and malfunctions.

The Ssf-sign indicates spezial functiones that become activ if

the device is switched to the Ssf- mode (please refer to chapter

12).

Table of Contents

Need help?

Do you have a question about the GSM Scout Series and is the answer not in the manual?

Questions and answers

Summary of Contents for ConiuGo GSM Scout Series

Page 1 GSM Scout Serie Softwareversion 37 This sign indicates important informations that have to be read most carefully. Please observe these informations in order to avoid missunderstandings and malfunctions. The Ssf-sign indicates spezial functiones that become activ if the device is switched to the Ssf- mode (please refer to chapter 12).
Page 2 Introduction / Declaration of Conformity Valued customer, thank you very much for purchasing a ConiuGo GSM Module. This product was built according to the latest technology. This module is a micro-controller device for long- distance data transfer using GSM functionality.
Page 3: Table Of Contents
GSM Scout Serie Softwareversion 37 Table of contents Table of contents ...................... 3 1. Limited Warranty / Limitation of Liability ............4 2. Use as agreed ....................... 5 3. Safety warnings ....................6 4. Mounting ....................... 7 5. Description of switching functions ..............7 6.
Page 4: Limited Warranty / Limitation Of Liability
2 years from the date of deli- very. This warranty is limited to repair or replacement at ConiuGo’s sole option. War- ranty covers costs for material and personal. Costs for mounting and de-mounting as well as for return transport to ConiuGo are not covered.
Page 5: Use As Agreed
GSM Scout Serie Softwareversion 37 2. Use as agreed De GSM Scout is designed for use in Germany and the European community. Ac- cording to the rules of CE- conformity, it is not allowed to distribute this device with- out a manual in the national language. The manual has to be authorised by the ma- nufacturer.
Page 6: Safety Warnings
GSM Scout Serie Softwareversion 37 3. Safety warnings This devices of the GSM Scout series correspond to the broadly known GSM stan- dards. Certain specific safety precautiones have to be observed strictly. GSM-devices can ignite explosive or inflammable gasses. It has...
Page 7: Mounting
4. Mounting Fig.1 The devices of the GSM Scout Series with IP 31 enclosure have two mounting holes („B“ Fig.1) at the enclosure. Please note that the other two holes („A“ Fig.1) are to be used to fasten the lid of the enclosure. (look at fig.1) 5.
Page 8 Fig.2 The GSM Scout series has 5 inputs for schwitches or relay contacts. (refering Fig.2 a= AUX (auxilliaries), b= FEUER (fire), c= WASSER (water), d= EINBRUCH (rob- bery), e= SCHARF (set device active). No voltage is allowed to be connected to those inputs.
Page 9 GSM Scout Serie Softwareversion 37 Set device active by SMS: In addition to the input it is possible to set the device active / de-active by SMS. This can be done by sending an SMS with the text „Scharf” (set ac- tive) or „Unscharf”...
Page 10 GSM Scout Serie Softwareversion 37 sent, if the switch or contact of this input is closed (SMS only, if the device is switched into the actice mode). The functionality is indicated by three additional LED: LED 1 (Fig.2) shows, if the device is activated or deactivated. The activation / de-activation is set by the input „Scharf“...
Page 11: Configuration By Using The Phonebook
Running the system in a GSM- network cost will cause costs. If wrong phone numbers are used it may happen that high costs are resulting. ConiuGo® GmbH is not liable for such costs cau- sed by faults in configuration. It is recommended to test care- fully the correct function and programming of the device.
Page 12 GSM Scout Serie Softwareversion 37 Insert the SIM- card into a mobile phone. Switch off / deactivate the PIN- number of the SIM- card by the specific function of the mobile phone (menue safety). (SIM- cards, that do not allow the de- activation of the PIN are not suited).
Page 13: Insert Sim- Card And Connecting Of The Aerial
GSM Scout Serie Softwareversion 37 Please note that for use of the Ssf- functions the following entry has to be made in the phonebook of the SIM- card: Ssf0000000000 (look for details in chapter 12 „Ssf- funktions“). 7. Insert SIM- card and connecting to the aerial Fig.4 When SIM- card is inserted, the aerial is connected and the power supply is attached...
Page 14: Remote Switching (Gsm Scout Activ And Gps Only)
GSM Scout Serie Softwareversion 37 The correct voltage, as indicated on the identification label has to be applied! For other power- supply (12 Volt battery, mains power 115 / 230 Volt, etc.) you can buy suited accessories from the manufacturer. As well available from the manufacturer are accu- stations and charging- cables for different types of accus and batteries.
Page 15 GSM Scout Serie Softwareversion 37 Fig.5 „ „ „ The digital out are relays that provide a common”, a normally open” and a nor- mally closed” contact: („common“) („normally closed“) („normally open) The GSM Scout with those relays react on the following SMS that have to be sent at the phone number of the SIM- card that is inserted into the device.
Page 16: Location By Gps (Gsm Scout Gps Only)
GSM Scout Serie Softwareversion 37 It always is possible that the GSM- network has a malfunction for a while. Therefore it may happen that you are unable to transfer a command by SMS. For that reason it is strongly rec- ommended not to switch on permanently a dangerous device by the GSM Scout.
Page 17 GSM Scout Serie Softwareversion 37 Pos1 and Pos2 describe the degree of latitude and degree of longitude. The co-ordinates are stored in the device encoded according to the NMEA- protocol National Marine Electronics Association) (NMEA= , as soon as the GPS- re- ceiver has determined a valid position.
Page 18 GSM Scout Serie Softwareversion 37 If the object does leave this aerea the device will send a SMS with the following content: GPS Alarm: 1234 m (example) The 1234 at „meter“ define the distance to the home position of the object that was stored at least.
Page 19: Reading Of The Gps String (Gsm Scout Gps)
E=east, W=west Checksum <CR><LF> end of message To understand the GPS data those should be put into a suited software in order to show those on a map. You may use the following links in intenet: http://www.coniugo.de/html/gps_tracking.html http://earth.google.de/...
Page 20: Ssf - Special Sim Funktiones
GSM Scout Serie Softwareversion 37 a.) Input of data on the ConiuGo Webpage $GPRMC,102253.146,A,5239.7287.N.01317.1914.E.0.08.263.53.050706,,*04 deg. latitude 52° , minutes, 43,7 seconds [seconds in decimal (60*0.7287)] deg. longitude 13° , minutes, seconds [seconds in decimal (60*0.1914)] b.) Input of data in Google Earth $GPRMC,102253.146,A,5239.7287.N.01317.1914.E.0.08.263.53.050706,,*04...
Page 21 GSM Scout Serie Softwareversion 37 To activate the Ssf- function the setting of the Mini- DIP- switches 1 and 2 has to be changed: Fig.7 On Scout & Scout activ On Not used Ssf- functions Off Scout GPS Using the Ssf- mode the GPS function of the GSM Scout GPS is de- activated.
Page 22 GSM Scout Serie Softwareversion 37 a.) Send Information of send quality with every SMS b.) Send value of the account of prepaid- SIM with every SMS c.) Use Input 1 as a non-inverting input d.) Send an acknowledge for all incoming SMS e.) Use a PIN- identification for incoming SMS f.) Configurable SMS texts g.) Reserved for futuree use...
Page 23 GSM Scout Serie Softwareversion 37 Service numbers (for Germany): *101# Vodafone: *102# E-Plus: Please ask the provider! T-Mobil: *100# c.) Use Input 1 as a non-inverting input (Ssf- key 3) If this key is set to 1 the first input „Einbruch“ (robbery) is working as non- inverting input with a delay of 30 seconds.
Page 24 GSM Scout Serie Softwareversion 37 book entry. If no text is attached the standard text Alarm1 to Alarm4 will be used. The text may have a length of up to 12 characters. Example: Name SMS that is sent Remark Sms1 Alarm1 Standardtext Sms2Failure...
Page 25: Change Of The Language Version
Softwareversion 37 13. Change of the language version The GSM Scout Series can send out SMS- messages in german, english, french and spanish language. The language version can be changed by the user by setting of the DIP- switches 3 and 4.
Page 26: Connecting An External Gps Receiver
GSM Scout Serie Softwareversion 37 14. Connecting an external GPS receiver If you haved purchased the GSM Scout GPS with external GPS-receiver you are able to mount the GPS receiver apart from the GSM Scout at a position of good reception.
Page 27: Troubleshooting
GSM Scout Serie Softwareversion 37 15. Troubleshooting Problem Manage the problem None of the LED 1 – 3 is If the device is switched to the „active mode“ (scharf) permanently enlighted the LED at the input „SCHARF“ is enlighted perma- after flashing or LED test nently afer 40 seconds.
Page 28: Scope Of Supply And Accessories
GSM Scout Serie Softwareversion 37 16. Scope of supply and accessories The scope of supply of the GSM Scout Series is: • The device itself • Srews for the enclosure • Manual for use • Miniature antenna MMCX • Cable with DC-plug •...
