MOEM 3-Wheel Combination Lock DW Instruction Manual

Instruction Manual
3-Wheel Combination Lock (DW)
____________________________________________________________________________________
NOTE: READ COMPLETE INSTRUCTIONS BEFORE OPERATING THE LOCK OR CHANGING THE COMBINATION
Important: Turn dial slowly and evenly. Do not turn back to regain alignment if you rotate past number. If an error is made, clear
and re-dial entire combination. Do not count turns. Count how many times each number is aligned with the opening index (at the 12
o'clock position). Always view dial and ring straight on, not at an angle. It is the owners' responsibility to maintain the code.

TO OPEN (Factory setting 10-20-30)

Turn anti-clockwise ↺ (Left) 4 times (10) or (your 1
1.
stopping when (10) is aligned with the opening line the fourth time
Turn clockwise ↻ (Right) 3 times (20) or (your 2nd number), stopping
2.
when (20) is aligned with the opening line the third time
Turn anti-clockwise ↺ (Left) 2 times (30) or (your 3rd number),
3.
stopping when (30) is aligned with the opening line the second time
Turn clockwise ↻ until stop
4.
(If correctly done, number should stop at zero on the opening line)

CHANGING TO A NEW COMBINATION

NOTE: With door in opening position, turn handle so that bolts in a shooting position
STEP 1:Insert existing numbers (e.g. 10-20-30) on setting/resetting line
Turn anti-clockwis ↺ (Left) 4 times (10) or (your 1
1.
setting / resetting line the fourth time
Turn clockwise ↻ (Right) 3 times (20) or (your 2nd number), stopping when (20) is aligned with the
2.
setting/ resetting line the third time
Turn anti-clockwise ↺ (Left) 2 times (30) or (your 3rd number), stopping when (30) is aligned with the
3.
setting/resetting line the second time
4. At last number, hold the combination dial lock
NOTE: If the number is inserted correctly, you will be able to insert change key (STEP 2)
____________________________________________________________________________________
Version 2.0: 3/12/2018
st
number),
st
number), stopping when (10) is aligned with the
Page | 1
