Page 11
VAXIS · ATOM 500 SDI Wireless Video System To Our Vaxis Customers: Thank you for your recent purchase of the Vaxis Atom 500 SDI. We created this product with you in mind and hope you will find the Atom 500 SDI useful.
Page 12
Features ·500 feet transmission range ·Automatically switch channels ·<0.1s latency ·Firmware Upgrades via USB ·Enclosed Antenna Design ·OLED display screen ·Stable & Reliable industrial metal ·HDMI input and SDI input ·Support USB-C voltage input housing ·iOS & Android App support Packing list Instructions Transmitter*1...
Page 13
Transmitter Interface SDI IN Power Switch OLED display USB interface HDMI input SDI input Down Menu/OK...
Page 14
Receiver interface SDI OUT Power Switch OLED display USB interface HDMI output SDI output Down Menu/OK...
Page 15
OLED Display Channel change Press either the up or down button on the transmitter to change the channel, then press the OK button to confirm the selected channel. The receiver will change to the same channel as the transmitter automatically and simultaneously.
Page 17
Troubleshooting Connection issue 1.Check and make sure the power supply functions well on both the transmitter and the receiver. 2.Check if the battery level is enough, If the battery level is too low, Please change another battery. 3.Change to another channel to troubleshoot 4.Re-paring the device Display issue 1.Please check if the video source is connected to the HDMI IN interface correctly.
Page 18
Specification HDMI input/SDI input HDMI output/SDI output Interface voltage 5V DC 5V DC Power <5w <3w 720P@50/60Hz HDMI Input 1080I@50/60Hz Video Format 1080P@24/25/30/50/60Hz 720P@50/60Hz HDMI Output 1080I@50/60Hz Video Format 1080P@24/25/30/50/60Hz 720P@50/60Hz 1080I@50/59.94/60Hz SDI Input 1080P@23.98/24/25/29.97/30 Video Format 50/59.94/60Hz 1080PSF23.98/24//25/29.97/30Hz 720P@50/60Hz SDI Output 1080I@50/60Hz Video Format...
