Summary of Contents for UAI LCC RESPIRA 1
- Page 1 Manual LCC RESPIRA 1 Low Cost & Comfortable Powered Air Purifying Respirator Hak cipta terdaftar 2020...
- Page 2 Manual LCC RESPIRA 1 LCC Respira 1 adalah Low Cost & Comfortable Powered Air Purifying Respirator yaitu Alat Perlindungan Diri (APD) aman dan murah, yang berfungsi untuk menyaring udara bagi tenaga medis dalam menangani pasien dengan resiko penularan tinggi atau highly infectious disease. Alat telah lolos BPFK Kemenkes RI sebagai APD pernafasan.
- Page 3 Manual LCC RESPIRA 1 B. Instalasi LCC Respira 1 1. Buka tutup HEPA Filter dengan cara diputar. Lakukan penggantian jika filter sudah digunakan selama 40 Jam (Gambar 2.a) 2. Pasangkan filter pada Hepa Filter (Gambar 2.b), kemudian tutup kembali sampai tertutup sempurna(Gambar 2.c) Gambar 2.
- Page 4 Manual LCC RESPIRA 1 Gambar 3. (a) LCC Respira 1, (b) LCC Respira 1 siap digunakan 4. Masukkan mesin dan blower (Gambar 2.c) LCC Respira 1 pada tas pinggang yang telah disediakan. 5. LCC Respira 1 siap digunakan (Gambar 3.b).
- Page 5 Manual LCC RESPIRA 1 D. Langkah Penggantian Baterai LCC Respira 1 Jika baterai tidak berhasil diisi ulang, kemungkinan terjadi kerusakan pada baterai lithium yang terpasangan pada bagian dalam mesin. Jika hal ini terjadi lekas ganti baterai Anda dengan cara: 1.Buka Kotak hitam mesin 2.Keluarkan baterai pada mesin...
- Page 6 4. Pasang masker hingga menutupi hidung dan mulut dengan mengaitkan head loop. 5. Pasang pelindung muka dengan mengaitkan head loop. Ukuran headloop dapat disesuaikan dengan ukuran kepala. 6. Lalu bernafaslah seperti biasa. Tabel 1. Spesifikasi komponen LCC Respira 1 Komponen Spesifikasi Air flow Adjustable 7-15 LPM...
- Page 7 Manual LCC RESPIRA 1 Manual LCC RESPIRA 1 English version Low Cost & Comfortable Powered Air Purifying Respirator Copyright 2020...
- Page 8 Manual LCC RESPIRA 1 LCC Respira 1 is a Low Cost & Comfortable Powered Air Purifying Respirator, designed as respiratory Personal Protective Equipment (PPE) for medical staff dealing with highly infectious disease. As an air-purifying respirator (APR) it can also be used in other respiratory-hazardous condition.
- Page 9 (Figure 2.c) so as to connect all components (Figure 3.a). 4. Insert motor container (Figure 2.c) to the waist bag. 5. LCC Respira 1 is ready to use (Figure 3.b). Figure 2. (a) Opening filter closure, (b) Replacing filter, (c) Ready to...
- Page 10 Manual LCC RESPIRA 1 Figure 3. (a) complete LCC Respira 1, (b) LCC Respira 1 ready to use C. Operational 1. Make sure the Hepa Filter is well installed and still good for use. 2. Make sure the battery is full charged. The usage capacity is 8 hours on intermediate blowing level.
- Page 11 6. The equipment is ready to reuse. Figure 5. Battery reaplacement D. Procedures to use LCC Respira 1 1. Make sure all components are complete and rightly installed. 2. Put on the waist bag of electronic container, on right and comfortable position (Figure 6).
- Page 12 Manual LCC RESPIRA 1 Face protection Half Mask Filter, blower & elektronics Figure 6. Putting on LCC-Respira 1 (front and side look) Table 1. Specification of LCC Respira 1 Components Specifications Air flow Adjustable 7-15 LPM Bacterial filter HEPA Blower material anti-bacterial PLA Mask &...
