GZ5

Operation

Manual

5-Axis

Zirconia Dental Cutting Machine

Table of Contents

Need help?

Do you have a question about the GZ5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Glorious GZ5

Page 1 Operation Manual 5-Axis Zirconia Dental Cutting Machine...
Page 2: Table Of Contents
4.3 Solution After An Alarm Occurs..............10 4.4 Material Saving Mode Fixture Adjustment Method........12 4.5 CERCON Φ105mm Large Size Fixture Adjustment Method...... 12 4.6 Accuracy Calibration Method..............13 GZ5 Typesetting Software Post-Processing (Only for reference by CAM software application engineers)................16 4.8 Tool size......................18...
Page 3: Equipment Introduction
Equipment Introduction 1.1 Equipment Destription Glorious GZ5 is a 5-axis 5-linkage denture cutting machine ,mainly used for cutting zirconia materials. The structure of the equipment is compact and powerful. It can cut various types of dentures to fit the individual needs of customers.
Page 4 The equipment is compatible with any CAM system on the market， such as： WorkNC、 Millbox,Sum3D,Hyperdent,etc. Feature four Large-Angle 5-Axis 5-Linkage Cutting The angle of the A-axis can be ±25; the angle of the B-axis can be 0~360; and 5-axis 5-linkage processing. Glorious GZ5 Operation Manual/...
Page 5 These can save time and materials. Feature six Various Fixture Modes The equipment fixture can be adjusted to a material-saving mode, and a large-size plate material (such as CERCON) can also be installed. 【Material-Saving Fixture Φ98mm】【CERCONΦ105mm】 Glorious GZ5 Operation Manual/...
Page 6: Equipment Parameters
The equipment is a box structure, each axis has 4 sliders, with high rigidity, which can ensure that the body is not deformed during use or transportation, maintain the accuracy of the equipment for a long time, and make the life of the machine longer. 1.3 Equipment Parameters Glorious GZ5 Operation Manual/...
Page 7: Installation Environment
Installation Environment 2.1 GZ5`s Installation Environment and Conditions As some parts of the equipment have certain requirements on the environment, please confirm the following installation environment and conditions before installing the Glorious GZ5 Operation Manual/...
Page 8: Equipment Accessories And Installation
Equipment Accessories and Installation 3.1 Whiteth GZ5 Accessories List 3.2 Installation guide of GZ5 Glorious GZ5 Operation Manual/...
Page 9 1）Equipment Size 2）Package Size 3）Installation instructions of GZ5 Glorious GZ5 Operation Manual/...
Page 10 F.Power port: Connect to 220V power supply. You can replace the spare fuse when it needs. G.Standby power button: For the daily use of the equipment, and only controls the power supply of components except the computer. Glorious GZ5 Operation Manual/...
Page 11: Equipment Operation Guidance
If the machine is not used for a long time, please Turn off the main power switch on the back of the machine. 4) Regular maintenance (according to actual usage) to reduce machine failures and Glorious GZ5 Operation Manual/...
Page 12: Solution After An Alarm Occurs
Solution: Check whether or not use the processing files of other machines or the Dental typesetting software configuration is wrong. 4)The warning message show error tool change failed Alarm reason: Automatic tool change failed; Glorious GZ5 Operation Manual/...
Page 13 Glorious GZ5 Operation Manual/...
Page 14: Material Saving Mode Fixture Adjustment Method
Typesetting, saving the materials. * Plastic secondary fixture are disposable consumables, which is used for one plate at a time and can buy from the machine supplier. 4.5 CERCON Φ105mm Large Size Fixture Adjustment Method Glorious GZ5 Operation Manual/...
Page 15: Accuracy Calibration Method
1) Turn off the machine, turn to the back of the fixture, remove the secondary fixture screws, and remove fixture No.①. 2) Replace the fixture cover No. ②, and install the CERCON plate material. 4.6 Accuracy Calibration Method 1) Close the main program DentMill5, and open the program Calibrate. Glorious GZ5 Operation Manual/...
Page 16 Calibrate304 (the difference between the two is limited to the different layout positions, which can be selected according to the remaining material), and the material rotation angle can be installed for multiple cuttings next time. 【Calibrate304 Around】【Calibrate304 Middle】 Glorious GZ5 Operation Manual/...
Page 17 4) After processing the calibration block, use a vernier caliper to measure the size of the calibration block, modify the value column, and confirm that it is correct. Click [CALIBRATE] to complete the calibration. Glorious GZ5 Operation Manual/...
Page 18: Gz5 Typesetting Software Post-Processing (Only For Reference By Cam Software Application Engineers)
GZ5 Typesetting Software Post-Processing (Only for reference by CAM software application engineers) (Program Begin) gosub check_empty_tool Confirm there is no tool on the spindle at the beginning ； of the program. g0 g17 g40 g49 g54 g80 g90 G code initialization.
Page 19 Spindle tool return. ；；Back to the second reference point of the machine tool. m101 Back to origin. ； End of program. ； The positive direction of the X axis is the international standard direction Glorious GZ5 Operation Manual/...
Page 20: Tool Size
The positive direction of the A axis is the opposite of the international standard direction International standard direction of the positive direction of B axis 4.8 Tool size 1)Tool Position 2)Tool Detail Size Tool NO.1 R1*L18mm Tool NO.2 R0.5*L16mm Tool NO.3 R0.3*L10 Glorious GZ5 Operation Manual/...
Page 21 Glorious GZ5 Operation Manual/...
