USER MANUAL

MODBUS TCP INTERFACE

RIGHT FROM

THE START

Contents

1. Warnings .............................................................................................. 2

2. Important User Information ................................................................ 2

3. Installation ........................................................................................... 3

4. Device Configuration ........................................................................... 6

5. PLC Configuration ............................................................................... 8

6. Feedback LEDs .................................................................................... 8

7. Operation ............................................................................................. 9

8. Modbus Registers .............................................................................. 10

9. Network Design ................................................................................. 21

10. Specifications .................................................................................... 23

Product Compatibility

The Modbus TCP Interface is compatible with the following AuCom soft starters:

• CSX - 24 VAC/VDC and 110/240 VAC control voltage.

The Modbus TCP Interface is not suitable for use with CSX starters using 380/440

VAC control voltage.

• EMX3 - all models.

• MV - all models.

Disclaimer

The examples and diagrams in this manual are included solely for illustrative

purposes. The information contained in this manual is subject to change at any time

and without prior notice. In no event will responsibility or liability be accepted for

direct, indirect or consequential damages resulting from the use or application of this

equipment.

Modbus TCP Interface

Rev D 3/2019

Table of Contents

Need help?

Do you have a question about the EMX3-0053B and is the answer not in the manual?

Questions and answers

Summary of Contents for AuCom EMX3-0053B

Page 1: Table Of Contents
10. Specifications ..................23 Product Compatibility The Modbus TCP Interface is compatible with the following AuCom soft starters: • CSX – 24 VAC/VDC and 110/240 VAC control voltage. The Modbus TCP Interface is not suitable for use with CSX starters using 380/440 VAC control voltage.
Page 2: Warnings
USER MANUAL 1. Warnings WARNING For your safety, isolate the soft starter completely from mains voltage before attaching or removing accessories. WARNING Observe all necessary safety precautions when controlling the soft starter remotely. Alert personnel that machinery may start without warning. 2.
Page 3: Installation
USER MANUAL 3. Installation CAUTION Remove mains and control voltage from the soft starter before attaching or removing accessories. Failure to do so may damage the equipment. 3.1 Installation Procedure 1. Remove control power and mains supply from the soft starter. 2.
Page 4 USER MANUAL To remove the interface: 1. Remove control power and mains supply from the soft starter. 2. Disconnect all external wiring from the interface. 3. Fully pull out the top and bottom retaining clips on the interface. [A] 4. Pull the interface away from the soft starter. 3.2 Soft Starter Connection The device is powered from the soft starter.
Page 5 USER MANUAL 3.3 Network Connection Ethernet Ports The device has two Ethernet ports. If only one connection is required, either port can be used. Cables Use Category 5, 5e, 6 or 6e cable to connect to the device. EMC Precautions To minimise electromagnetic interference, Ethernet cables should be separated from motor and mains cables by 200 mm.
Page 6: Device Configuration
USER MANUAL 4. Device Configuration NOTE The Error LED flashes whenever the device is receiving power but is not connected to a network. The Error LED will flash occasionally during the configuration process. 4.1 Overview The Modbus TCP Interface is configured with a static IP address as default. To avoid IP address conflicts and to ensure successful deployment, we recommend that the device is connected directly to a PC or laptop to configure the IP address, before connecting to the network.
Page 7 PC must both be connected to the Ethernet network. The Ethernet Device Configuration Tool can be downloaded from www.aucom.com. NOTE If your PC has a firewall enabled, you must add the tool to the list of authorised programs.
Page 8: Plc Configuration
USER MANUAL 5. PLC Configuration The PLC must be configured to map registers within the interface to addresses within the PLC. Example mapping of PLC registers to registers within the Modbus TCP Interface (Target): The device must be configured directly in the PLC. No additional files are required. 6.
Page 9: Operation
USER MANUAL 7. Operation The Modbus TCP Interface must be controlled by a Modbus client (such as a PLC) which complies with the Modbus Protocol Specification. For successful operation, the client must also support all functions and interfaces described in this document. 7.1 Device Classification The Modbus TCP Interface is a Modbus server and must be managed by a Modbus client over Ethernet.
Page 10: Modbus Registers
The Modbus TCP Interface supports two modes of operation. • In Standard Mode, the interface uses registers defined in the Modbus Protocol Specification. • In Legacy Mode, the interface uses the same registers as AuCom's Modbus Interface. Some registers differ from those specified in the Modbus Protocol Specification.
Page 11 USER MANUAL 8.3 Standard Mode Command and Configuration Registers (Read/Write) Register Description Bits Details 40001 Command 0 to 7 To send a command to the starter, write the (single write) required value: 00000000 = Stop 00000001 = Start 00000010 = Reset 00000100 = Quick stop (coast to stop) 00001000 = Forced communication trip 00010000 = Start using Parameter Set 1...
Page 12 USER MANUAL Status Reporting Registers (Read Only) NOTE For models EMX3-0053B and smaller, current reported via communications is 10 times greater than the actual value (displayed on the keypad). Register Description Bits Details 30240 Starter state 0 to 3 1 = Ready...
Page 13 USER MANUAL Register Description Bits Details Reserved 30254 Starter state 0 to 4 1 = Ready 2 = Starting 3 = Running 4 = Stopping 5 = Not ready (restart delay, restart temperature check, run simulation) 6 = Tripped 7 = Programming mode 8 = Jog forward 9 = Jog reverse 1 = Warning...
Page 14 USER MANUAL Register Description Bits Details 30262 Current 0 to 13 Phase 2 current (rms) Reserved 14 to 15 30263 Current to 13 Phase 3 current (rms) Reserved 14 to 15 30264 Voltage 0 to 013 Phase 1 voltage, rms (medium voltage products only) Reserved 14 to 15...
Page 15 USER MANUAL 8.4 Legacy Mode Registers NOTE For models EMX3-0053B and smaller, current reported via communications is 10 times greater than the actual value (displayed on the keypad). NOTE Legacy Mode reports read-only status information in registers 40003 onwards, to match the register definitions of the clip-on Modbus Module for use with older soft starters.
Page 16 USER MANUAL Register Description Bits Details 40005 Motor current 0 to 7 Average 3-phase motor current (A) Reserved 8 to 15 40006 Motor temperature 0 to 7 Motor 1 thermal model (%) Reserved 8 to 15 Reserved 40007 Reserved 40008 40009 Parameter 0 to 7...
Page 17 USER MANUAL Register Description Bits Details 40605 Current 0 to 13 Average rms current across all three phases Reserved 14 to 15 40606 Current 0 to 9 Current (% motor FLC) Reserved 10 to 15 40607 Motor temperature 0 to 7 Motor 1 thermal model (%) Reserved 8 to 15...
Page 18 USER MANUAL Register Description Bits Details 40618 Digital input state 0 to 15 For all inputs, 0 = open, 1 = closed (shorted) 0 = Start 1 = Stop 2 = Reset 3 = Input A 4 = Input B 5 = Input C, if fitted 6 = Input D, if fitted Reserved...
Page 19 USER MANUAL 8.5 Trip Codes Trip Description EMX3 Code Excess start time Motor overload Motor thermistor Current imbalance Frequency Phase sequence Instantaneous overcurrent Power loss Undercurrent Heatsink (starter) overtemperature Motor connection Input A trip FLC too high Unsupported option (function not available in inside delta) Starter communication (between device and soft starter)
Page 20 USER MANUAL Trip Description EMX3 Code RTD/PT100 C RTD/PT100 D RTD/PT100 E RTD/PT100 F RTD/PT100 G RTD circuit fail Analog input trip Available with EMX3 only if the appropriate option card is fitted. For EMX3, time-overcurrent protection is only available on internally bypassed models.
Page 21: Network Design
USER MANUAL 9. Network Design The device supports star, line and ring topologies. 9.1 Star Topology In a star network, all controllers and devices connect to a central network switch. 9.2 Line Topology In a line network, the controller connects directly to one port of the first interface. The second Ethernet port connects to another interface, which in turn connects to another device until all devices are connected.
Page 22 USER MANUAL 9.3 Ring Topology In a ring topology network, the controller connects to the first interface, via a network switch. The second Ethernet port of the interface connects to another device, which in turn connects to another device until all devices are connected. The final device connects back to the switch.
Page 23: Specifications
USER MANUAL 10. Specifications • Enclosure Dimensions ..........40 mm (W) x 166 mm (H) x 90 mm (D) Weight ......................250 g Protection ....................... IP20 • Mounting Spring-action plastic mounting clips (x 2) • Connections Soft starter ................6-way pin assembly Contacts ...................
