epcom TITANIUM TT314A Quick Start Manual

SPLITTER 1X4 HDMI 4K X 2K @ 30HZ
Introduction:
This product distributes 1 way HDMI signal from
STB,DVD,notebook,D-VHS and HD-Player etc.to 4
ways identical HDMI signal simultaneously.It supports
3D HDMI and 4Kx2K HDMI signal.
Safety notes :
1.Use DC 5V/2A power supply only,make sure specification
matched if using adapters not supplied by factory.
2.Put this product in dry and ventilated place for normal
heat dissipation.
3.Keep this product away from the strong static and
magnetic environment.
1. Package contents
HDMI splitter
Power adapter DC5V/2A Screws * 4pcs (hang on wall)
2. Installation requirement
1.HDTV or other display with HDMI port.
2.HDMI video source,such as DVD,PS3,STB,PC etc.
3.High standard HDMI cable ( supports HDMI 4Kx2K).
TT314A
User manual
3. Installation steps
Please connect the devices according to the above
image and operate as following steps :
HD displayX4
PC DVD
DC5V/2A
