Assembly Instructions
Versare Solutions, LLC
3236 California St. NE • Minneapolis, MN 55418
1-855-457-1473 • customerservice@versare.com
Quick-Wall Folding (Wheel A) Page 1
Quick-Wall Folding (Wheel B) Page 4
Quick-Wall Sliding (Wheel A) Page 6
Quick-Wall Sliding (Wheel B) Page 8
Work Station (Wheel A) Page 10
Work Station (Wheel B) Page 12
Wall Bracket Set Page 13
100045 REV CW
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for VERSARE Quick-Wall Folding
-
Page 1: Table Of Contents
Assembly Instructions Quick-Wall Folding (Wheel A) Page 1 Quick-Wall Folding (Wheel B) Page 4 Quick-Wall Sliding (Wheel A) Page 6 Quick-Wall Sliding (Wheel B) Page 8 Work Station (Wheel A) Page 10 Work Station (Wheel B) Page 12 Wall Bracket Set Page 13 Versare Solutions, LLC 3236 California St. -
Page 2: Quick-Wall Folding (Wheel A)
Quick-Wall Folding Hardware included: Assembly Instructions Bolts Washers Nuts Feet Screws Wheels Button Screws If wheels are desired, screw two wheels onto each foot with one washer and one nut per wheel. If not using wheels skip to step 4. - Page 3 Remove two bolts from outside, bottom edge of each outer panel and one screw from the side of each outer panel. Then attach foot base with bolts fi rst, screws second. Repeat for other side. Assemblly complete. If not using wheels, insert button head screw down into foot end and secure with two washers and a nut.
- Page 4 Then attach foot base with bolts fi rst, screws second. Repeat for other side. Assembly complete! We hope you enjoy your new Quick-Wall Folding! For questions regarding your Quick-Wall Folding please contact us at 1-855-457-1473 or customerservice@versare.com...
-
Page 5: Quick-Wall Folding (Wheel B)
Quick-Wall Folding Hardware included: Assembly Instructions Bolts Washers Nuts Feet (type B) Screws Wheels If wheels are desired, screw two wheels onto each foot with one washer and one nut per wheel. If not using wheels skip to step 3. - Page 6 Remove a bolt and two screws from outer panel. Then attach foot base with bolt fi rst, screws second. Repeat for other side. Assembly complete! We hope you enjoy your new Quick-Wall Folding! For questions regarding your Quick-Wall Folding please contact us at 1-855-457-1473 or customerservice@versare.com...
-
Page 7: Quick-Wall Sliding (Wheel A)
Hardware included: Quick-Wall Sliding Assembly Instructions Bolts Washers Nuts Feet Screws Wheels Button Screws Screw two wheels onto each foot with one washer and one nut per wheel. To attach wheel to panel, locate square nut in bottom track of outer panel and slide to outer edge. - Page 8 Then attach foot base with bolts fi rst, screws second. Repeat for other side. Assembly complete! We hope you enjoy your new Quick-Wall Sliding! For questions regarding your Quick-Wall Sliding please contact us at 1-855-457-1473 or customerservice@versare.com...
-
Page 9: Quick-Wall Sliding (Wheel B)
Quick-Wall Sliding Hardware included: Assembly Instructions Bolts Washers Nuts Feet (type B) Screws Wheels Screw two wheels onto each foot with one washer and one nut per wheel. To attach wheel to panel, locate square nut in bottom track of outer panel and slide to outer edge. - Page 10 Remove a bolt and two screws from outer panel. Then attach foot base with bolt fi rst, screws second. Repeat for other side. Assembly complete! We hope you enjoy your new Quick-Wall Sliding! For questions regarding your Quick-Wall Sliding please contact us at 1-855-457-1473 or customerservice@versare.com...
-
Page 11: Work Station (Wheel A)
Work Station Screen Hardware included: Assembly Instructions Button Screws Bolts Screws Feet Washers Nuts Insert button head screw down into foot end and secure with two washers and a nut. Repeat for other side of foot. Repeat for second foot. Remove two bolts from outside, bottom edge of outer panel(s) and one... - Page 12 Assembly complete! We hope you enjoy your new Work Station! For questions regarding your Work Station please contact us at 1-855-457-1473 or customerservice@versare.com...
-
Page 13: Work Station (Wheel B)
Feet (type B) Screws Bolts Remove two bolts. Then attach feet base with bolts fi rst, screws second. Assembly complete! We hope you enjoy your new Work Station! For questions regarding your Work Station please contact us at 1-855-457-1473 or customerservice@versare.com... - Page 14 Wall Mount Bracket Set Hardware included: Assembly Instructions Brackets Bolts Screws Gently place partition on its side. Remove any bolts from top and bottom of the end of the panel. Once bolts are removed, attach brackets to corners with two bolts included with bracket kit.
- Page 15 * Use two people for installation. One to hold panels fl ush to the wall and one to attach brackets to the wall. Assembly complete! For questions regarding your Wall Mount Bracket Set please contact us at 1-855-457-1473 or customerservice@versare.com...
