Page 2 RX-8_8V89-EA-06F_Edition1 Page1 Friday, May 19 2006 9:49 AM Black plate (1,1) Form No.8V89-EA-06F...
Page 3 RX-8_8V89-EA-06F_Edition1 Page2 Friday, May 19 2006 9:49 AM Black plate (2,1) Form No.8V89-EA-06F...
Page 4 Mazda product. Important Notes About This Manual Keep this manual in the glove box as a handy reference for the safe and enjoyable use of your Mazda. Should you resell the vehicle, leave this manual with it for the next owner.
Page 5: How To Use This Manual
Illustrations complement the words of the manual to best explain how to enjoy your Mazda. By reading your manual, you can find out about the features, important safety information, and driving under various road conditions.
Page 6: Table Of Contents
RX-8_8V89-EA-06F_Edition1 Page5 Friday, May 19 2006 9:49 AM Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags.
Page 7 RX-8_8V89-EA-06F_Edition1 Page6 Friday, May 19 2006 9:49 AM Black plate (6,1) Form No.8V89-EA-06F...
Page 8: Your Vehicle At A Glance
RX-8_8V89-EA-06F_Edition1 Page7 Friday, May 19 2006 9:49 AM Your Vehicle at a Glance Interior, exterior views and part identification of your Mazda. Dashboard and Interior Overview ... 1-2 Exterior Overview ... 1-4 Form No.8V89-EA-06F Black plate (7,1)
Page 9 RX-8_8V89-EA-06F_Edition1 Page8 Friday, May 19 2006 9:49 AM Black plate (8,1) Your Vehicle at a Glance Dashboard and Interior Overview The equipment and installation position varies by model. Refer to Navigation System at the end of the manual (if equipped). Form No.8V89-EA-06F...
Page 10 RX-8_8V89-EA-06F_Edition1 Page9 Friday, May 19 2006 9:49 AM Power door lock switch ... page 3-30 Outside mirror switch ... page 3-53 Dashboard illumination ... page 5-38 DSC OFF switch ... page 5-24 Lighting control/Turn signals ... page 5-55 Audio control switch ... page 6-40 Instrument cluster ...
Page 11: Exterior Overview
RX-8_8V89-EA-06F_Edition1 Page10 Friday, May 19 2006 9:49 AM Black plate (10,1) Your Vehicle at a Glance Exterior Overview The equipment and installation position varies by model. Form No.8V89-EA-06F...
Page 12 RX-8_8V89-EA-06F_Edition1 Page11 Friday, May 19 2006 9:50 AM Trunk lid ... page 3-33 Rear window defroster ... page 5-60 Antenna ... page 6-10 Power windows ... page 3-37 Outside mirror ... page 3-53 Tires ... page 8-24 Light bulbs ... page 8-29 Hood ...
Page 13 RX-8_8V89-EA-06F_Edition1 Page12 Friday, May 19 2006 9:50 AM Black plate (12,1) Form No.8V89-EA-06F...
Page 14: Essential Safety Equipment
RX-8_8V89-EA-06F_Edition1 Page13 Friday, May 19 2006 9:50 AM Essential Safety Equipment Use of safety equipment, including seats, seat belt system, child-restraint systems and SRS air bags. Seats ... 2-2 Front Seats (Manually Operated Seats) ... 2-2 Front Seats (Electrically Operated Seats) ... 2-5 Rear Seat ...
Page 15: Seats
Such modifications could damage the supplemental restraint system and result in serious injury. Consult an Authorized Mazda Dealer if there is any need to remove or reinstall the front seats. Do not drive with damaged front seats: Driving with damaged front seats is dangerous.
Page 16 RX-8_8V89-EA-06F_Edition1 Page15 Friday, May 19 2006 9:50 AM Make sure the lever returns to its original position and the seat is locked in place by attempting to push it forward and backward. qSeat Recline WARNING Do not drive with the seats reclined: Sitting in a reclined position while the vehicle is moving is dangerous because you don't get the full...
Page 17 RX-8_8V89-EA-06F_Edition1 Page16 Friday, May 19 2006 9:50 AM Essential Safety Equipment Seats CAUTION When returning a rear-reclined seatback to its upright position, make sure you hold onto the seatback with your other hand while operating the lever. If the seatback is not supported, it will flip forward suddenly and could cause injury.
Page 18 Such modifications could damage the supplemental restraint system and result in serious injury. Consult an Authorized Mazda Dealer if there is any need to remove or reinstall the front seats. Do not drive with damaged front seats: Driving with damaged front seats is dangerous.
Page 19 RX-8_8V89-EA-06F_Edition1 Page18 Friday, May 19 2006 9:50 AM Essential Safety Equipment Seats qSeat Recline WARNING Do not drive with the seats reclined: Sitting in a reclined position while the vehicle is moving is dangerous because you don't get the full protection from seat belts.
Page 20 RX-8_8V89-EA-06F_Edition1 Page19 Friday, May 19 2006 9:50 AM Rear of seat bottom Raise or lower the back of the switch to adjust the rear height of the seat bottom. qLumbar Support Adjustment The amount of lumbar support can be adjusted by pressing the switch. To increase the seat firmness, press and hold the front part of the switch to the desired position, then release it.
Page 21: Rear Seat
RX-8_8V89-EA-06F_Edition1 Page20 Friday, May 19 2006 9:50 AM Essential Safety Equipment Seats qSeat Warmer The front seats are electrically heated. The ignition switch must be in the ON position. Press the switch to turn the seat warmer on or off. When the switch is in the ON position, the indicator light will come on.
Page 22: Seat Belt Systems
Using a damaged seat belt is dangerous. An accident could damage the belt webbing of the seat belt in use. A damaged seat belt cannot provide adequate protection in a collision. Have an Authorized Mazda Dealer inspect all seat belt systems in use during an accident before they are used again.
Page 23 Always have an Authorized Mazda Dealer inspect the seat belt pretensioners and air bags after any collision. Expended seat belt pretensioners and air bags must be replaced after any collision which caused them to deploy.
Page 24 RX-8_8V89-EA-06F_Edition1 Page23 Friday, May 19 2006 9:50 AM qPregnant Women and Persons with Serious Medical Conditions Pregnant women should always wear seat belts. Ask your doctor for specific recommendations. The lap belt should be worn SNUGLY AND AS LOW AS POSSIBLE OVER THE HIPS. The shoulder belt should be worn across your shoulder properly, but never across the stomach area.
Page 25: Location Of Seat Belt
RX-8_8V89-EA-06F_Edition1 Page24 Friday, May 19 2006 9:50 AM Black plate (24,1) Essential Safety Equipment Seat Belt Systems Location of Seat Belt For rear seat For front seat 2-12 Form No.8V89-EA-06F...
Page 26: Seat Belt
RX-8_8V89-EA-06F_Edition1 Page25 Friday, May 19 2006 9:50 AM Seat Belt qFastening the Seat Belt 1. Grasp the tongue. 2. Slowly pull out the lap/shoulder belt. 3. Insert the tongue into the buckle until you hear a click. Tongue Buckle Form No.8V89-EA-06F WARNING Positioning the Shoulder Portion of the Seat Belt:...
Page 27: Front Seat Belt Pretensioner And Load Limiting Systems
Even if the pretensioners have not fired, the load limiting function must be checked by an Authorized Mazda Dealer.
Page 28 Always have an Authorized Mazda Dealer inspect the seat belt pretensioners and air bags after any collision. Expended seat belt pretensioners and air bags must be replaced after any collision which caused them to deploy.
Page 29 ON position. If either of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident.
Page 30: Seat Belt Extender
When ordering an extender, only order one that provides the necessary additional length to fasten the seat belt properly. Please contact your Authorized Mazda Dealer for more information. WARNING Do not use a seat belt extender unless...
Page 31: Seat Belt Warning Light/Beep
Minder NOTE The belt minder can be deactivated. Consult an Authorized Mazda Dealer to deactivate and restore the seat belt minder. 2-18 Form No.8V89-EA-06F Black plate (30,1) The belt minder is a supplemental warning to the seat belt warning function.
Page 32: Child Restraint
Even if the front passenger air bag is shut off, Mazda strongly recommends that children be properly restrained and child-restraint systems of all kinds are properly secured on the rear seats which are the best place for children.
Page 33 RX-8_8V89-EA-06F_Edition1 Page32 Friday, May 19 2006 9:50 AM Essential Safety Equipment Child Restraint Use the correct size child-restraint system: For effective protection in vehicle accidents and sudden stops, a child must be properly restrained using a seat belt or child-restraint system depending on age and size.
Page 34 RX-8_8V89-EA-06F_Edition1 Page33 Friday, May 19 2006 9:50 AM Do not install a front-facing child-restraint system on the front passenger seat unless it is unavoidable: In a collision, the force of a deploying air bag could cause serious injury or death to the child.
Page 35 To avoid burning yourself or a child, check them before you or your child touches them. NOTE Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seat. When using these anchors to secure a child-restraint system, refer to LATCH Child-Restraint Systems (page 2-29).
Page 36: Installing Child-Restraint Systems
Some child-restraint systems now come with tethers and therefore must be installed on the seats that take tethers to be effective. In your Mazda, tethered child-restraint systems can only be accommodated in the two positions on the rear seat.
Page 37 RX-8_8V89-EA-06F_Edition1 Page36 Friday, May 19 2006 9:50 AM Essential Safety Equipment Child Restraint 1. Secure the child-restraint system with the lap portion of the lap/shoulder belt. See the manufacturer's instructions on the child-restraint system for belt routing instructions. 2. To get the retractor into the automatic locking mode, pull the shoulder belt portion of the seat belt until the entire length of the belt is out of the retractor.
Page 38 RX-8_8V89-EA-06F_Edition1 Page37 Friday, May 19 2006 9:50 AM WARNING Use the tether and tether anchor only for a child-restraint system: Using the tether or tether anchor to secure anything but a child-restraint system is dangerous. This could weaken or damage the tether or tether anchor and result in injury.
Page 39 Child Restraint NOTE To check if your front seats have side air bags: Mazda vehicles equipped with side air bag will have a SRS AIRBAG tag on the outboard shoulder of the front seats. To check if your vehicle has curtain...
Page 40 RX-8_8V89-EA-06F_Edition1 Page39 Friday, May 19 2006 9:50 AM qFront Passenger's Seat Child- Restraint System Installation 1. Slide the seat as far back as possible. 2. Secure the child-restraint system with the lap portion of the lap/shoulder belt. See the manufacturer's instructions on the child-restraint system for belt routing instructions.
Page 41 Authorized Mazda Dealer as soon as possible. 2-28 Form No.8V89-EA-06F Black plate (40,1)
Page 42: Latch Child-Restraint Systems
Friday, May 19 2006 9:50 AM LATCH Child-Restraint Systems Your Mazda is equipped with LATCH lower anchors for attachment of specially designed LATCH child-restraint systems in the rear seat. Both anchors must be used, otherwise the seat will bounce around and put the child in danger. Most LATCH child-restraint systems must also be used in conjunction with a tether to be effective.
Page 43 RX-8_8V89-EA-06F_Edition1 Page42 Friday, May 19 2006 9:50 AM Essential Safety Equipment Child Restraint qLATCH Child-Restraint System Installation Procedure (Rear Seats) 1. Expand the open seams on the rear of the seat bottom slightly to verify the locations of the LATCH lower anchors. NOTE The markings above the LATCH lower anchors indicate the locations of...
Page 44 RX-8_8V89-EA-06F_Edition1 Page43 Friday, May 19 2006 9:50 AM WARNING Use the tether and tether anchor only for a child-restraint system: Using the tether or tether anchor to secure anything but a child-restraint system is dangerous. This could weaken or damage the tether or tether anchor and result in injury.
Page 45: Srs Air Bags
RX-8_8V89-EA-06F_Edition1 Page44 Friday, May 19 2006 9:50 AM Essential Safety Equipment SRS Air Bags Supplemental Restraint Systems (SRS) Precautions The front and side supplemental restraint systems (SRS) include up to 6 air bags (verify SRS AIRBAG location indicator marks). They are located in: The steering wheel hub (driver air bag) The front passenger dashboard (front passenger air bag) The outboard sides of the front seatbacks (side air bags)
Page 46 RX-8_8V89-EA-06F_Edition1 Page45 Friday, May 19 2006 9:50 AM Seat belts must be worn in air bag equipped vehicles: Depending only on the air bags for protection during an accident is dangerous. Alone, air bags may not prevent serious injuries. The appropriate air bags can be expected to inflate only in the first collision with frontal, near frontal or side forces that are at least moderate.
Page 47 RX-8_8V89-EA-06F_Edition1 Page46 Friday, May 19 2006 9:50 AM Essential Safety Equipment SRS Air Bags Sit in the center of the seat and wear seat belts properly: Sitting too close to the side air bag modules or placing hands on them is extremely dangerous.
Page 48 It also includes installing extra electrical equipment on or near system components or wiring. An Authorized Mazda Dealer can provide the special care needed in the removal and installation of front seats.
Page 49 Should you sell your Mazda, we urge you to tell the new owner of its air bag systems and that familiarization with all instructions about them, from the Owner's Manual, is important.
Page 50: Supplemental Restraint System Components
RX-8_8V89-EA-06F_Edition1 Page49 Friday, May 19 2006 9:50 AM Supplemental Restraint System Components The supplemental restraint systems (SRS) have two basic subsystems: The air bag system with inflators and air bags. The electrical system with crash sensors and diagnostic module. The air bags are mounted in the following locations: The steering wheel hub The front passenger dashboard The outboard sides of the front seatbacks...
Page 51 RX-8_8V89-EA-06F_Edition1 Page50 Friday, May 19 2006 9:50 AM Black plate (50,1) Essential Safety Equipment SRS Air Bags qFront Air Bag System Components (10) (1) Driver seat slide position sensor (page 2-40) (2) Front seats (3) Front dual stage inflators and air bags (4) Front air bag sensor (5) Front passenger air bag deactivation indicator light (page 2-40) (6) Front seat belt pretensioner and load limiting systems (page 2-14)
Page 52 RX-8_8V89-EA-06F_Edition1 Page51 Friday, May 19 2006 9:50 AM qSide and Curtain Air Bag System Components (1) Side and curtain inflators and air bags (2) Front seats (3) Side crash sensor (4) Crash sensors and diagnostic module (SAS unit) Form No.8V89-EA-06F Black plate (51,1) Essential Safety Equipment SRS Air Bags...
Page 53: How The Air Bags Work
The front air bags will function only once. After that, the front air bags will not work again and must be replaced. Only an Authorized Mazda Dealer can replace the system components. The front, dual stage air bags control air bag inflation in two energy stages. During an impact of moderate severity the front air bags deploy with lesser energy, whereas during more severe impacts, they deploy with more energy.
Page 54 RX-8_8V89-EA-06F_Edition1 Page53 Friday, May 19 2006 9:50 AM Front passenger seat weight sensors Your vehicle is also equipped with the front passenger air bag deactivation indicator light (page 2-27). These sensors are located under both of the front passenger seat rails. These sensors determine the total seated weight on the front passenger seat.
Page 55 ON position and does not illuminate as indicated in the above chart, do not allow a child to sit in the front passenger seat and consult an Authorized Mazda Dealer as soon as possible. The system may not work properly in an accident.
Page 56 RX-8_8V89-EA-06F_Edition1 Page55 Friday, May 19 2006 9:50 AM Do not decrease the total seated weight on the front passenger seat: When an adult or large child sits on the front passenger seat, decreasing the total seated weight on the front passenger seat from the total seated weight of approximately 42 kg (93 lb) required for air bag deployment is dangerous.
Page 57 RX-8_8V89-EA-06F_Edition1 Page56 Friday, May 19 2006 9:50 AM Essential Safety Equipment SRS Air Bags Do not increase the total seated weight on the front passenger seat: When an infant or small child sits on the front passenger seat, increasing the total seated weight on the front passenger seat from the total seated weight of approximately 30 kg (66 lb) is dangerous.
Page 58 If the front passenger air bag deactivation indicator light does not illuminate after installing a child-restraint system on the front passenger seat, install the child-restraint system on the rear seat and consult an Authorized Mazda Dealer as soon as possible. Driver and front passenger buckle switches The buckle switches on the front seat belts detect whether or not the front seat belts are securely fastened and further control the deployment of the air bags.
Page 59 The side and curtain air bags will function only once. After that, the side and curtain air bags will not work again and must be replaced. Only an Authorized Mazda Dealer can replace the systems. The side and curtain air bags will deploy only on the side the vehicle receives the force of the impact.
Page 60 RX-8_8V89-EA-06F_Edition1 Page59 Friday, May 19 2006 9:50 AM Front air bag activation The front air bags will inflate if the severity of impact is above the designed threshold level. Hitting a solid wall straight on at greater than about 22 km/h (14 mph). Hitting a curb, pavement edge or hard object.
Page 61 RX-8_8V89-EA-06F_Edition1 Page60 Friday, May 19 2006 9:50 AM Essential Safety Equipment SRS Air Bags Rear-ending or running under a truck's tail gate may not provide the stopping force necessary for air bag deployment. Non-activation of front air bags Front air bags will not normally inflate in the following cases: Collision from the rear.
Page 62 RX-8_8V89-EA-06F_Edition1 Page61 Friday, May 19 2006 9:50 AM Vehicle roll-over may not provide enough side force to deploy the side and curtain air bags. Side impacts with two-wheeled vehicles may not provide enough force to deploy the side and curtain air bags. Non-activation of side and curtain air The side and curtain air bags will not normally inflate in the following cases:...
Page 63 ON position. If either of these occur, consult an Authorized Mazda Dealer as soon as possible. The system may not work in an accident.
Page 64 Unless all safety procedures are followed, injury can result. Ask an Authorized Mazda Dealer how to safely dispose of an air bag or how to scrap an air bag equipped vehicle.
Page 65 RX-8_8V89-EA-06F_Edition1 Page64 Friday, May 19 2006 9:50 AM Black plate (64,1) 2-52 Form No.8V89-EA-06F...
Page 66: Knowing Your Mazda
RX-8_8V89-EA-06F_Edition1 Page65 Friday, May 19 2006 9:50 AM Knowing Your Mazda Explanation of basic operations and controls; opening/closing and adjustment of various parts. Advanced Keyless Entry and Start System ... 3-2 Advanced Keys Operation Using Advanced Keyless Functions ... 3-7 Operation Using Advanced Key Functions ...
Page 67: Advanced Keyless Entry And Start System
RX-8_8V89-EA-06F_Edition1 Page66 Friday, May 19 2006 9:50 AM Knowing Your Mazda Advanced Keyless Entry and Start System Advanced Keys The advanced keyless functions (advanced keyless entry and start system) enables the following operations while the advanced key is being carried (page 3-7).
Page 68 Also write down the code number and keep it in another safe and handy place, but not in the vehicle. If your key is lost, consult your Authorized Mazda Dealer with the code number ready. Form No.8V89-EA-06F Black plate (67,1)
Page 69 (green) flashes in the instrument cluster. Refer to Advanced Key Battery Dead Warning on page 3-19. Additional advanced keys can be obtained at an Authorized Mazda Dealer. Up to 6 advanced keys can be used with the advanced keyless functions per vehicle.
Page 70 Form No.8V89-EA-06F Black plate (69,1) Knowing Your Mazda Replacing the battery at an Authorized Mazda Dealer is recommended to prevent damage to the advanced key. If replacing the battery by yourself, follow the instruction below. Replacing the advanced key battery 1.
Page 71 Authorized Mazda Dealer. If your advanced key is lost or stolen, bring all remaining advanced keys to an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen advanced key inoperative.
Page 72: Operation Using Advanced Keyless Functions
The system may not operate if you are too close to the windows, door handles. Form No.8V89-EA-06F Black plate (71,1) Knowing Your Mazda Opening the trunk lid The operational range for opening the trunk lid is an area of up to 80 cm (2.6 ft) from the center of the trunk lid.
Page 73 RX-8_8V89-EA-06F_Edition1 Page72 Friday, May 19 2006 9:50 AM Knowing Your Mazda Advanced Keyless Entry and Start System NOTE The trunk is out of the operational range, however, starting the engine may be possible. The engine may not start if the...
Page 74 If your prefer, the beep sound can be turned off (page 3-20). Form No.8V89-EA-06F Black plate (73,1) Knowing Your Mazda NOTE The setting can be changed so that the doors are locked automatically without pressing the request switch (page 3-20).
Page 75 RX-8_8V89-EA-06F_Edition1 Page74 Friday, May 19 2006 9:50 AM Knowing Your Mazda Advanced Keyless Entry and Start System qOpening the Trunk Lid with Request Switch The trunk lid can be opened by pressing the request switch on the under side of the trunk lid above the license plate while the advanced key is being carried.
Page 76 ON position. The brake warning light can be checked after the engine is started (page 5-39). Form No.8V89-EA-06F Black plate (75,1) Knowing Your Mazda Starting the engine NOTE Engine-starting is controlled by the spark ignition system.
Page 77 RX-8_8V89-EA-06F_Edition1 Page76 Friday, May 19 2006 9:50 AM Knowing Your Mazda Advanced Keyless Entry and Start System 5. (Manual transmission) Depress the clutch pedal all the way and shift into neutral. Keep the clutch pedal depressed while cranking the engine.
Page 78 Form No.8V89-EA-06F Black plate (77,1) Knowing Your Mazda Turning off the engine 1. Shift the shift lever to the P position (Automatic transmission). 2. Turn the ignition switch from the ON position to the ACC position.
Page 79: Operation Using Advanced Key Functions
RX-8_8V89-EA-06F_Edition1 Page78 Friday, May 19 2006 9:50 AM Knowing Your Mazda Advanced Keyless Entry and Start System NOTE When turning the ignition switch to the LOCK position, the ignition switch has to be pushed in from the ACC position and turned. Without...
Page 80 A beep will be heard twice and the hazard warning lights will flash twice. To unlock all doors , press the unlock button again within 3 seconds and two more beep sounds will be heard. Black plate (79,1) Knowing Your Mazda 3-15...
Page 81 RX-8_8V89-EA-06F_Edition1 Page80 Friday, May 19 2006 9:50 AM Knowing Your Mazda Advanced Keyless Entry and Start System NOTE (Without theft-deterrent system) The hazard warning lights will flash twice to indicate that all doors are unlocked. (With theft-deterrent system) The hazard warning lights will not flash.
Page 82: Advanced Key Suspend Function
The engine can be started with the auxiliary key, refer to Ignition Switch (page 5-2). Form No.8V89-EA-06F Black plate (81,1) Knowing Your Mazda Advanced Key Suspend Function If an advanced key is left in the vehicle or the trunk, the functions of the advanced...
Page 83: Warning And Beep Sounds
Park the vehicle in a safe place and use the auxiliary key to continue driving the vehicle. Have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. Refer to Ignition Switch (page 5-2). qStart Knob Not in LOCK Warning Beep...
Page 84 LOCK position. The advanced key battery is dead. Form No.8V89-EA-06F Black plate (83,1) Knowing Your Mazda The advanced key is not within operational range. The advanced key is placed in areas where it is difficult for the system to detect the signal (page 3-7).
Page 85: Setting Change (Function Customization)
RX-8_8V89-EA-06F_Edition1 Page84 Friday, May 19 2006 9:50 AM Knowing Your Mazda Advanced Keyless Entry and Start System Setting Change (Function Customization) The following function settings are possible. These settings can only be changed by an Authorized Mazda Dealer. Setting Advanced key battery dead...
Page 86: When Warning Indicator/Beep Is Activated
Refer to Advanced Key Maintenance on page 3-5. The advanced key is malfunctioning. Park the vehicle in a safe place, and use the auxiliary key to continue driving the vehicle. Have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. 3-21...
Page 87: Doors And Locks
Write down the code number and keep it in a separate safe and convenient place, but not in the vehicle. If your key is lost, consult your Authorized Mazda Dealer and have your code number ready. Key extend/retract method (Retractable type key) To extend the key, press the release button.
Page 88: Keyless Entry System (With Retractable Type Key)
Friday, May 19 2006 9:50 AM To retract the key, rotate it into the holder while pressing the release button. Form No.8V89-EA-06F Black plate (87,1) Knowing Your Mazda Doors and Locks Keyless Entry System (with Retractable Type Key) This system remotely locks and unlocks the doors and opens the trunk lid.
Page 89 To install a new battery, refer to Maintenance (page 3-26). Additional transmitters can be obtained at an Authorized Mazda Dealer. Up to 3 transmitters can be used with the keyless entry system per vehicle. Bring all transmitters to an Authorized Mazda Dealer when additional transmitters are required.
Page 90 To unlock all doors, press the unlock button again within 5 seconds. Form No.8V89-EA-06F Black plate (89,1) Knowing Your Mazda Doors and Locks NOTE (Without theft-deterrent system) The hazard warning lights will flash twice to indicate that all doors are unlocked.
Page 91 RX-8_8V89-EA-06F_Edition1 Page90 Friday, May 19 2006 9:50 AM Knowing Your Mazda Doors and Locks Turning on the alarm Pressing the panic button for 1 second or more will trigger the alarm for about 2 minutes and 30 seconds, and the following will occur: The horn sounds intermittently.
Page 92 Authorized Mazda Dealer. If your transmitter is lost or stolen, bring all remaining transmitters to an Authorized Mazda Dealer as soon as possible for a replacement and to make the lost or stolen transmitter inoperative. 3-27...
Page 93: Door Locks
RX-8_8V89-EA-06F_Edition1 Page92 Friday, May 19 2006 9:50 AM Knowing Your Mazda Doors and Locks CAUTION Radio equipment like this is governed by laws in the United States. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Page 94 Keyless Entry System (page 3-23). Form No.8V89-EA-06F Black plate (93,1) Knowing Your Mazda Doors and Locks qLocking, Unlocking with Door- Lock Knob To lock either front door from the inside, push the door-lock knob.
Page 95 RX-8_8V89-EA-06F_Edition1 Page94 Friday, May 19 2006 9:50 AM Knowing Your Mazda Doors and Locks NOTE (With advanced key) The driver's door cannot be locked using the door-lock knob from the outside. (Without advanced key) The driver's door cannot be locked...
Page 96 Opening the freestyle doors 1. Open the front door first. Unlock Lock 2. Pull the rear door handle and open the rear door. Rear door handle Knowing Your Mazda Front door 3-31...
Page 97 RX-8_8V89-EA-06F_Edition1 Page96 Friday, May 19 2006 9:50 AM Knowing Your Mazda Doors and Locks CAUTION Before closing a front door make sure other passengers are not operating a rear door and a rear passenger's head or hands are away from the rear door. If...
Page 98: Trunk Lid
This could cause the front door to open unexpectedly while driving and may result in an accident. Form No.8V89-EA-06F Black plate (97,1) Knowing Your Mazda Doors and Locks Trunk Lid WARNING Never allow a person to ride in the trunk: Allowing a person to ride in the trunk is dangerous.
Page 99 RX-8_8V89-EA-06F_Edition1 Page98 Friday, May 19 2006 9:50 AM Knowing Your Mazda Doors and Locks qOpening and Closing the Trunk WARNING Close the trunk lid and do not allow children to play inside the vehicle: Leaving the trunk lid open or leaving children in the vehicle with the keys is dangerous.
Page 100 Pull up on the trunk lid to make sure it is secured. Handle Form No.8V89-EA-06F Black plate (99,1) Knowing Your Mazda Doors and Locks qTrunk Light The trunk light is on when the lid is open and off when it's closed.
Page 101: Inside Trunk Release Lever
RX-8_8V89-EA-06F_Edition1 Page100 Friday, May 19 2006 9:50 AM Knowing Your Mazda Doors and Locks Inside Trunk Release Lever Your vehicle is equipped with an inside trunk release lever that provides a means of escape for children and adults in the event they become locked inside the trunk.
Page 102: Power Windows
The inside trunk release lever is located on the inside of the trunk end trim. Form No.8V89-EA-06F Black plate (101,1) Knowing Your Mazda Doors and Locks Power Windows The ignition switch must be in the ON position for the power windows to operate.
Page 103 RX-8_8V89-EA-06F_Edition1 Page102 Friday, May 19 2006 9:50 AM Knowing Your Mazda Doors and Locks qOperating the Driver's Side Power Window Manual opening/closing To open the window to the desired position, lightly hold down the switch. To close the window to the desired position, lightly pull up the switch.
Page 104: Rear Quarter Windows
Form No.8V89-EA-06F Black plate (103,1) Knowing Your Mazda Doors and Locks Rear Quarter Windows Open or close a swing-out rear quarter window by releasing the latch and moving the window.
Page 105: Fuel-Filler Lid And Cap
CAUTION Always use only a genuine Mazda fuel cap or an approved equivalent, available at an Authorized Mazda Dealer. The wrong cap can result in a serious malfunction of the fuel and emission control systems.
Page 106 If the light remains on (even after you have tightened the cap securely, driven, and restarted the engine several times), it may indicate a different problem. Contact an Authorized Mazda Dealer as soon as possible. Close Knowing Your Mazda 3-41...
Page 107: Hood
RX-8_8V89-EA-06F_Edition1 Page106 Friday, May 19 2006 9:50 AM Knowing Your Mazda Doors and Locks Hood WARNING Always check that the hood is closed and securely locked: A hood that is not closed and securely locked is dangerous as it could fly...
Page 108: Moonroof Í
Black plate (107,1) Knowing Your Mazda Doors and Locks NOTE After washing your Mazda or after it rains, wipe the water off the moonroof before operating it to avoid water penetration which could cause rust and water damage to your headliner.
Page 109 RX-8_8V89-EA-06F_Edition1 Page108 Friday, May 19 2006 9:50 AM Knowing Your Mazda Doors and Locks To close to the desired position, push the front of the tilt or slide switch. Open Close Close qSunshade The sunshade can be opened and closed by hand.
Page 110: Security System
Form No.8V89-EA-06F Black plate (109,1) Knowing Your Mazda Security System CAUTION Do not allow the following when starting the engine with the auxiliary key due to an advanced key dead battery or other malfunction.
Page 111 If the security indicator light flashes continuously while you are driving, don't shut off the engine. Go to an Authorized Mazda Dealer and have it checked. If the engine is shut off while the indicator light is flashing, you won't be able to restart it.
Page 112 Always keep a spare advanced key in case one is lost. If an advanced key is lost, consult an Authorized Mazda Dealer as soon as possible. If you lose an advanced key (including auxiliary key), an Authorized Mazda Dealer will reset...
Page 113: Immobilizer System (Without Advanced Key)
RX-8_8V89-EA-06F_Edition1 Page112 Friday, May 19 2006 9:50 AM Knowing Your Mazda Security System Immobilizer System (without Advanced Key) The immobilizer system allows the engine to start only with a key the system recognizes. If someone attempts to start the engine...
Page 114 If the security indicator light flashes continuously while you are driving, don't shut off the engine. Go to an Authorized Mazda Dealer and have it checked. If you shut off the engine while the light is flashing you won't be able to restart it.
Page 115 They are only available through an Authorized Mazda Dealer. Always keep a spare key, in case one is lost. If a key is lost, contact an Authorized Mazda Dealer as soon as possible. If you lose a key, an Authorized Mazda Dealer will reset the electronic codes of your remaining keys and immobilizer system.
Page 116: Theft-Deterrent System
(Without advanced key) The following method will also arm the theft-deterrent system: Close the hood and the trunk lid . Press the area on the door-lock switch marked LOCK once. Close all doors. í Some models. Knowing Your Mazda 3-51...
Page 117 Authorized Mazda Dealer. qTheft-Deterrent Labels A label indicating that your vehicle is equipped with a Theft-Deterrent System is in the glove box. Mazda recommends that you affix it to the lower rear corner of a front door window.
Page 118: Steering Wheel And Mirrors
After adjusting, push the wheel up and down to be certain it's locked before driving. Form No.8V89-EA-06F Black plate (117,1) Knowing Your Mazda Steering Wheel and Mirrors Mirrors qOutside Mirrors Check the mirror angles before driving. Mirror type Flat type (driver's side) Flat surface mirror.
Page 119 RX-8_8V89-EA-06F_Edition1 Page118 Friday, May 19 2006 9:50 AM Knowing Your Mazda Steering Wheel and Mirrors 2. Depress the mirror switch in the appropriate direction. Outside mirror Selector switch Mirror switch After adjusting the mirror, lock the control by placing the selector switch in the middle position.
Page 120 ON position. Form No.8V89-EA-06F Black plate (119,1) Knowing Your Mazda Steering Wheel and Mirrors Press the OFF button ( ) to cancel the automatic dimming function. The indicator light will go off.
Page 121 RX-8_8V89-EA-06F_Edition1 Page120 Friday, May 19 2006 9:50 AM Knowing Your Mazda Steering Wheel and Mirrors NOTE Do not use glass cleaner or suspend objects on or around the light sensor. Otherwise, light sensor sensitivity will be affected and may not operate normally.
Page 122: Before Driving Your Mazda
RX-8_8V89-EA-06F_Edition1 Page121 Friday, May 19 2006 9:50 AM Before Driving Your Mazda Important information about driving your Mazda. Fuel and Engine Exhaust Precautions ... 4-2 Fuel Requirements ... 4-2 Emission Control System ... 4-4 Engine Exhaust (Carbon Monoxide) ... 4-5 Before Starting the Engine ...
Page 123: Fuel And Engine Exhaust Precautions
Never add fuel system additives. Never add cleaning agents other than those specified by Mazda. Other cleaning agents and additives may damage the system. Consult an Authorized Mazda Dealer. Gasoline blended with oxygenates such as alcohol or ether compounds are generally referred to as oxygenated fuels.
Page 124 RX-8_8V89-EA-06F_Edition1 Page123 Friday, May 19 2006 9:50 AM Gasoline or gasohol containing methanol. Leaded fuel or leaded gasohol. Form No.8V89-EA-06F Black plate (123,1) Fuel and Engine Exhaust Precautions Before Driving Your Mazda...
Page 125: Emission Control System
Either condition will damage the converter and cause poor performance. USE ONLY UNLEADED FUEL. Don't drive your Mazda with any sign of engine malfunction. Don't coast with the ignition switch turned off. Don't descend steep grades in gear with the ignition switch turned off.
Page 126: Engine Exhaust (Carbon Monoxide)
When inhaled, it can cause loss of consciousness and death. If you smell exhaust gas inside your vehicle, keep all windows fully open and contact an Authorized Mazda Dealer immediately. Do not run the engine when inside an enclosed area: Running the engine inside an enclosed area, such as a garage, is dangerous.
Page 127: Before Starting The Engine
RX-8_8V89-EA-06F_Edition1 Page126 Friday, May 19 2006 9:50 AM Before Driving Your Mazda Before Starting the Engine Before Getting In Be sure the windows, outside mirrors, and outside lights are clean. Inspect inflation pressures and condition of tires. Look under the vehicle for any sign of fluid leaks.
Page 128: Driving Tips
No special break-in is necessary, but a few precautions in the first 1,000 km (600 miles) may add to the performance, economy, and life of your Mazda. Don't race the engine. Don't maintain one constant speed, either slow or fast, for a long period of time.
Page 129: Hazardous Driving
RX-8_8V89-EA-06F_Edition1 Page128 Friday, May 19 2006 9:50 AM Before Driving Your Mazda Driving Tips Hazardous Driving WARNING Be extremely careful if it is necessary to downshift on slippery surfaces: Downshifting into lower gear while driving on slippery surfaces is dangerous. The sudden change in tire speed could cause the tires to skid.
Page 130: Rocking The Vehicle
Carry emergency gear, including tire chains, window scraper, flares, a small shovel, jumper cables, and a small bag of sand or salt. Ask an Authorized Mazda Dealer to perform the following precautions: Have the proper ratio of antifreeze in the radiator.
Page 131 If your vehicle is to be used on snow and ice covered roads, Mazda recommends that you replace the tires originally equipped on your vehicle with snow tires during the winter months.
Page 132: Driving In Flooded Area
2. Retighten the chains after driving 1/2 1 km (1/4 1/2 mile). Form No.8V89-EA-06F Black plate (131,1) Before Driving Your Mazda Driving Tips Driving In Flooded Area WARNING Dry wet brakes by driving very slowly and applying the brakes lightly until brake performance returns to normal: Driving with wet brakes is dangerous.
Page 133: Overloading
RX-8_8V89-EA-06F_Edition1 Page132 Friday, May 19 2006 9:50 AM Before Driving Your Mazda Driving Tips Overloading WARNING Be careful not to overload your vehicle: The gross axle weight rating (GAWR) and the gross vehicle weight rating (GVWR) of your vehicle are on the Motor Vehicle Safety Standard Label on the driver's door frame.
Page 134: Towing
RX-8_8V89-EA-06F_Edition1 Page133 Friday, May 19 2006 9:50 AM Trailer Towing The Mazda RX-8 is not designed for towing. Never tow a trailer with your Mazda RX-8. Form No.8V89-EA-06F Black plate (133,1) Before Driving Your Mazda Towing 4-13...
Page 135 RX-8_8V89-EA-06F_Edition1 Page134 Friday, May 19 2006 9:50 AM Black plate (134,1) 4-14 Form No.8V89-EA-06F...
Page 136 RX-8_8V89-EA-06F_Edition1 Page135 Friday, May 19 2006 9:50 AM Driving Your Mazda Explanation of instruments and controls. Starting and Driving ... 5-2 Ignition Switch ... 5-2 Starting the Engine ... 5-4 Brake System ... 5-5 Manual Transmission Operation ... 5-9 Automatic Transmission Controls ... 5-11 Power Steering ...
Page 137: Starting And Driving
RX-8_8V89-EA-06F_Edition1 Page136 Friday, May 19 2006 9:50 AM Driving Your Mazda Starting and Driving Ignition Switch (With advanced key) NOTE When starting the engine using the advanced key, refer to Starting the Engine (page 3-10). When starting the engine with the auxiliary key, perform the following procedure.
Page 138 Unexpected vehicle movement could occur. This could cause an accident. Form No.8V89-EA-06F Black plate (137,1) Driving Your Mazda Starting and Driving NOTE If turning the key is difficult, jiggle the steering wheel from side to side. ACC (Accessory) The steering wheel unlocks and some electrical accessories will operate.
Page 139: Starting The Engine
RX-8_8V89-EA-06F_Edition1 Page138 Friday, May 19 2006 9:50 AM Driving Your Mazda Starting and Driving Starting the Engine NOTE Engine-starting is controlled by the spark ignition system. This system meets all Canadian Interference-Causing Equipment Standard requirements regulating the impulse electrical field strength of radio noise.
Page 140: Brake System
RX-8_8V89-EA-06F_Edition1 Page139 Friday, May 19 2006 9:50 AM Brake System qFoot Brake Your Mazda has power-assisted brakes that adjust automatically through normal use. Should power-assist fail, you can stop by applying greater force than normal to the brake pedal. But the distance required to stop will be greater than usual.
Page 141 If the warning light remains on, or if the brakes do not operate properly, do not drive the vehicle. Have it towed to an Authorized Mazda Dealer. Even if the light goes out have your brake system inspected as soon as possible by an Authorized Mazda Dealer.
Page 142 Friday, May 19 2006 9:50 AM NOTE Having to add brake fluid is sometimes an indicator of leakage. Consult an Authorized Mazda Dealer as soon as possible even if the brake light is no longer illuminated. WARNING Do not drive with the brake system warning light illuminated.
Page 143 If this occurs, your brakes will function normally as if the vehicle had no ABS. Should this happen, consult an Authorized Mazda Dealer as soon as possible. NOTE When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS warning light comes on.
Page 144: Manual Transmission Operation
Driving with worn disc pads is dangerous. The brakes could fail and cause a serious accident. As soon as you hear a screeching noise consult an Authorized Mazda Dealer. Form No.8V89-EA-06F Black plate (143,1) Driving Your Mazda Starting and Driving...
Page 145 RX-8_8V89-EA-06F_Edition1 Page144 Friday, May 19 2006 9:51 AM Driving Your Mazda Starting and Driving WARNING Do not use sudden engine braking on slippery road surfaces or at high speeds: Shifting down while driving on wet, snowy, or frozen roads, or while driving at high speeds causes sudden engine braking, which is dangerous.
Page 146: Automatic Transmission Controls
If you notice the engine speed going higher or hear the engine racing, confirm you have not accidentally slipped into manual shift mode (page 5-13). Form No.8V89-EA-06F Black plate (145,1) Driving Your Mazda Starting and Driving 5-11...
Page 147 RX-8_8V89-EA-06F_Edition1 Page146 Friday, May 19 2006 9:51 AM Driving Your Mazda Starting and Driving qTransmission Ranges The shift lever must be in P or N to operate the starter. P (Park) P locks the transmission and prevents the rear wheels from rotating.
Page 148 1. Depress and hold the brake pedal. 2. Start the engine. 3. Move the shift lever. Form No.8V89-EA-06F Black plate (147,1) Driving Your Mazda Starting and Driving NOTE When the ignition switch is in the LOCK position, the shift lever cannot be shifted from P.
Page 149 RX-8_8V89-EA-06F_Edition1 Page148 Friday, May 19 2006 9:51 AM Driving Your Mazda Starting and Driving NOTE If you change to manual shift mode when the vehicle is stopped, the gear will shift to M1. Indicators Shift position indicator In manual shift mode, the M of the shift position indicator in the instrument panel illuminates.
Page 150 UP switches toward you once with your fingers. UP switches Form No.8V89-EA-06F Black plate (149,1) Driving Your Mazda Starting and Driving WARNING Keep your hands on the steering wheel rim when using fingers or thumbs on the steering shift switches:...
Page 151 RX-8_8V89-EA-06F_Edition1 Page150 Friday, May 19 2006 9:51 AM Driving Your Mazda Starting and Driving Manually Shifting down (M6→M5→M4→M3→M2→M1) To shift down to a lower gear, tap the shift lever forward ( ) once. To shift down to a lower gear with the...
Page 152 Vehicle speed M1 to M2 5 km/h (3 mph) M2 to M3 30 km/h (19 mph) M3 to M4 40 km/h (25 mph) M4 to M5 50 km/h (31 mph) M5 to M6 67 km/h (42 mph) Driving Your Mazda 5-17...
Page 153: Power Steering
RX-8_8V89-EA-06F_Edition1 Page152 Friday, May 19 2006 9:51 AM Driving Your Mazda Starting and Driving Downshifting When you must slow down in heavy traffic or on a steep upgrade, downshift before the engine starts to overwork. This gives better acceleration when you need more speed.
Page 154: Cruise Control
Steering is possible, but requires more physical effort. Form No.8V89-EA-06F Black plate (153,1) Driving Your Mazda Starting and Driving Cruise Control With cruise control, you can set and automatically maintain any speed of more than about 30 km/h (19 mph).
Page 155 RX-8_8V89-EA-06F_Edition1 Page154 Friday, May 19 2006 9:51 AM Driving Your Mazda Starting and Driving qActivation/Deactivation To activate the system, press the ON/OFF switch. The cruise main indicator light illuminates. To deactivate the system, press the switch again. The cruise main indicator light turns off.
Page 156 Accelerate to the desired speed. Press the SET/COAST button and release it immediately. Form No.8V89-EA-06F Black plate (155,1) Driving Your Mazda Starting and Driving NOTE Accelerate if you want to speed up temporarily when the cruise control is on. Greater speed will not interfere with it or change the set speed.
Page 157 RX-8_8V89-EA-06F_Edition1 Page156 Friday, May 19 2006 9:51 AM Driving Your Mazda Starting and Driving qTo Resume Cruising Speed at More Than 30 km/h (19 mph) If some other method besides the ON/ OFF switch was used to cancel cruising speed and the system is still activated, the...
Page 158: Traction Control System (Tcs)
(TCS) alone cannot provide adequate traction and you could still have an accident. Form No.8V89-EA-06F Black plate (157,1) Driving Your Mazda Starting and Driving NOTE To turn off the TCS, press the DSC OFF switch (page 5-26). qTCS/DSC Indicator Light...
Page 159: Dynamic Stability Control (Dsc)
CAUTION The DSC may not operate correctly unless the following are observed: Use tires of the correct size specified for your Mazda on all four wheels. Use tires of the same manufacturer, brand and tread pattern on all four wheels.
Page 160 TCS/DSC is switched off (page 5-26). If the light stays on when the TCS/DSC is not switched off, take your vehicle to an Authorized Mazda Dealer. The dynamic stability control may have a malfunction. Form No.8V89-EA-06F Black plate (159,1)
Page 161 RX-8_8V89-EA-06F_Edition1 Page160 Friday, May 19 2006 9:51 AM Driving Your Mazda Starting and Driving qDSC OFF Switch Press the DSC OFF switch to turn off the TCS/DSC. The DSC OFF indicator light will illuminate. Press the switch again to turn the TCS/ DSC back on.
Page 162: Tire Pressure Monitoring System
Form No.8V89-EA-06F Black plate (161,1) Driving Your Mazda Starting and Driving TPMS does not alleviate your need to check the pressure and condition of all four tires before you drive each day.
Page 163 Authorized Mazda Dealer or a tire repair station. Do not ignore the TPMS Warning Light:...
Page 164 (page 10-6). CAUTION When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. NOTE Perform tire pressure adjustment when the tires are cold. Tire pressure...
Page 165 RX-8_8V89-EA-06F_Edition1 Page164 Friday, May 19 2006 9:51 AM Driving Your Mazda Starting and Driving CAUTION Do not use non-genuine tire sealant. It may damage the tire pressure sensor. Vehicles with optional temporary spare tire If you have bought the optional temporary spare tire, replace the punctured tire with the temporary spare tire .
Page 166 Replacing tires and wheels CAUTION When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors.
Page 167 RX-8_8V89-EA-06F_Edition1 Page166 Friday, May 19 2006 9:51 AM Driving Your Mazda Starting and Driving A new tire pressure sensor is installed to a new wheel. NOTE The tire pressure sensor ID signal code must be registered when a new tire pressure sensor is purchased. For...
Page 168: Instrument Cluster And Indicators
Odometer, Trip Meter and Trip Meter Selector ... page 5-34 Tachometer ... page 5-35 Engine Coolant Temperature Gauge ... page 5-36 Fuel Gauge ... page 5-37 Engine Oil Pressure Gauge ... page 5-37 Form No.8V89-EA-06F Instrument Cluster and Indicators Meters and Gauges Black plate (167,1) Driving Your Mazda 5-33...
Page 169 RX-8_8V89-EA-06F_Edition1 Page168 Friday, May 19 2006 9:51 AM Driving Your Mazda Instrument Cluster and Indicators qSpeedometer The speedometer indicates the speed of the vehicle. qSpeed Unit Selector In some countries, you may have to change the speed units between km/h and mph.
Page 170 The power supply is interrupted (blown fuse or the battery is disconnected). The vehicle is driven over 999.9 km (mile). qTachometer The tachometer shows engine speed in thousands of revolutions per minute (rpm). Automatic transmission Striped zone Driving Your Mazda Red zone 5-35...
Page 171 RX-8_8V89-EA-06F_Edition1 Page170 Friday, May 19 2006 9:51 AM Driving Your Mazda Instrument Cluster and Indicators Manual transmission Striped zone Red zone CAUTION Don't run the engine with the tachometer needle in the RED ZONE. This may cause severe engine damage.
Page 172 3. If the needle still doesn't move, have your vehicle checked at an Authorized Mazda Dealer. CAUTION Don't run the engine if the oil pressure is low. It could result in extensive engine damage. Black plate (171,1) Driving Your Mazda 5-37...
Page 173 Friday, May 19 2006 9:51 AM Driving Your Mazda Instrument Cluster and Indicators NOTE The Mazda RX-8 requires regular checking of the engine oil level. The compact, high performance RENESIS rotary engine in your vehicle consumes a small amount of engine oil due to its structural design.
Page 174: Warning/Indicator Lights And Beep Sounds
Air Bag/Front Seat Belt Pretensioner System Warning Light Low Fuel Warning Light Seat Belt Warning Light/Beep Form No.8V89-EA-06F Warning/Indicator lights will appear in any of the highlighted areas Warning/Indicator Lights Black plate (173,1) Driving Your Mazda Page 5-41 5-42 5-43 5-43 5-44...
Page 175 RX-8_8V89-EA-06F_Edition1 Page174 Friday, May 19 2006 9:51 AM Driving Your Mazda Warning/Indicator Lights and Beep Sounds Signal Door-Ajar Warning Light Low Washer Fluid Level Warning Light Automatic Transmission Warning Light Tire Pressure Monitoring System Warning Light KEY Warning Light (Red)/KEY Indicator Light (Green)
Page 176 Driving Your Mazda NOTE Having to add brake fluid is sometimes an indicator of leakage. Consult an Authorized Mazda Dealer as soon as possible even if the brake light is no longer illuminated. WARNING Do not drive with the brake system warning light illuminated.
Page 177 If this occurs, your brakes will function normally as if the vehicle had no ABS. Should this happen, consult an Authorized Mazda Dealer as soon as possible. NOTE When the engine is jump-started to charge the battery, uneven rpm occurs and the ABS warning light comes on.
Page 178 Don't run the engine if the oil level is low. It could result in extensive engine damage. NOTE The Mazda RX-8 requires regular checking of the engine oil level. The compact, high performance RENESIS rotary engine in your vehicle consumes a small amount of engine oil due to its structural design.
Page 179 3. Check the light. If the light remains illuminated even after you add engine coolant, have your vehicle towed to an Authorized Mazda Dealer. CAUTION Don't run the engine if the engine coolant level is low. It could result in extensive engine damage.
Page 180 Belt minder NOTE The belt minder can be deactivated. Consult an Authorized Mazda Dealer to deactivate and restore the seat belt minder. The belt minder is a supplemental warning to the seat belt warning function. If the driver's seat belt is not fastened...
Page 181 CAUTION If the automatic transmission warning light illuminates, the transmission has an electrical problem. Continuing to drive your Mazda in this condition could cause damage to your transmission. Consult an Authorized Mazda Dealer as soon as possible. qTire Pressure Monitoring System í...
Page 182 (page 10-6). CAUTION When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. NOTE Perform tire pressure adjustment when the tires are cold. Tire pressure...
Page 183 - take it to an Authorized Mazda Dealer which has all the equipment to fix tires, TPMS systems and order the best replacement tire for your vehicle.
Page 184 Park the vehicle in a safe place and use the auxiliary key to continue driving the vehicle. Have the vehicle inspected at an Authorized Mazda Dealer as soon as possible. When flashing Under the following conditions, the...
Page 185 3 seconds and then goes out. If the engine doesn't start with the correct ignition key, and the security indicator light keeps illuminating or flashing, the system may have a malfunction. Consult an Authorized Mazda Dealer. 5-50 Form No.8V89-EA-06F Black plate (184,1) qHeadlight High-Beam Indicator...
Page 186 TCS/DSC is switched off (page 5-26). If the light stays on when the TCS/DSC is not switched off, take your vehicle to an Authorized Mazda Dealer. The dynamic stability control may have a malfunction. Form No.8V89-EA-06F Black plate (185,1)
Page 187 Thereafter, the indicator light will illuminate when the headlight auto- leveling system has a malfunction. If the indicator light illuminates, contact an Authorized Mazda Dealer. qTurn-Signal/Hazard Warning Indicator Lights When operating the turn signal lights, the left or right turn signal indicator light flashes to indicate which turn signal light is operating (page 5-57).
Page 188: Beep Sounds
Form No.8V89-EA-06F Black plate (187,1) Driving Your Mazda Beep Sounds qSeat Belt Warning Beep If the driver's seat belt is not fastened when the ignition switch is turned to the ON position, a beep sound will be heard for about 6 seconds.
Page 189 RX-8_8V89-EA-06F_Edition1 Page188 Friday, May 19 2006 9:51 AM Driving Your Mazda Warning/Indicator Lights and Beep Sounds qEngine Overrev Warning Beep The beep sounds to indicate engine overrev when the tachometer needle enters the striped zone (page 5-35). qTire Inflation Pressure Warning í...
Page 190: Switches And Controls
Consult an Authorized Mazda Dealer when the replacement is necessary. NOTE If the headlights flicker, or the brightness weakens, the bulb-life may be depleted and a replacement is necessary.
Page 191 Thereafter, the indicator light will illuminate when the headlight auto- leveling system has a malfunction. If the indicator light illuminates, contact an Authorized Mazda Dealer. qDaytime Running Lights (Canada) In Canada, vehicles must be driven with the headlights on during daytime operation.
Page 192: Turn And Lane-Change Signals
Form No.8V89-EA-06F Black plate (191,1) Driving Your Mazda Switches and Controls í Fog Lights Use this switch to turn on the fog lights. They help you to see as well as to be seen.
Page 193: Windshield Wipers And Washer
After 5 minutes, turn on the switch and the blades should operate normally. If they don't resume functioning, consult an Authorized Mazda Dealer as soon as possible. Drive to the side of the road and park off the right-of-way. Wait until the weather clears before trying to drive with the wipers inoperative.
Page 194 With the wiper lever in the OFF or INT position, the wipers will operate continuously until the lever is released. If the washer doesn't work, inspect the fluid level (page 8-17). If it's OK, consult an Authorized Mazda Dealer. Form No.8V89-EA-06F Black plate (193,1) Switches and Controls NOTE...
Page 195: Headlight Washer
RX-8_8V89-EA-06F_Edition1 Page194 Friday, May 19 2006 9:51 AM Driving Your Mazda Switches and Controls Headlight Washer The ignition switch must be in the ON position and the headlights must be turned The headlight washers operate automatically once every fifth time the windshield washer operates.
Page 196: Horn
If there is an accumulation of snow on the rear window, remove it before using the defroster. Form No.8V89-EA-06F Black plate (195,1) Driving Your Mazda Switches and Controls Horn To sound the horn, press the mark on the steering wheel.
Page 197: Hazard Warning Flasher
RX-8_8V89-EA-06F_Edition1 Page196 Friday, May 19 2006 9:51 AM Driving Your Mazda Switches and Controls Hazard Warning Flasher The hazard warning lights should always be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other...
Page 198 For further information, contact HomeLink at 1-800-355-3515 or www.homelink.com or your Authorized Mazda Dealer. Always check the areas surrounding garage doors and gates for people or obstructions before programming or during operation of the HomeLimk...
Page 199 RX-8_8V89-EA-06F_Edition1 Page198 Friday, May 19 2006 9:51 AM Driving Your Mazda Switches and Controls qProgramming the HomeLink System CAUTION When programming a garage door opener or a gate, disconnect the power to these devices before performing programming, as continuous operation of the devices could damage the motor.
Page 200 1. For questions or comments, please contact HomeLink at www.homelink.com or 1- 800-355-3515. Form No.8V89-EA-06F Black plate (199,1) Driving Your Mazda Switches and Controls qGate operator/Canadian Programming Canadian radio-frequency laws require transmitter signals to time-out (or quit) after several seconds of transmission...
Page 201 RX-8_8V89-EA-06F_Edition1 Page200 Friday, May 19 2006 9:51 AM Driving Your Mazda Switches and Controls qReprogramming the HomeLink system To program a device to HomeLink using a HomeLink button previously trained, follow these steps: 1. Press and hold the desired HomeLink button.
Page 202: Interior Comfort
RX-8_8V89-EA-06F_Edition1 Page201 Friday, May 19 2006 9:51 AM Interior Comfort Use of various features for drive comfort, including air-conditioning and audio system. Climate Control System ... 6-2 Operating Tips ... 6-2 Vent Operation ... 6-3 Control Panel ... 6-5 Audio System ... 6-10 Antenna ...
Page 203 Have the air conditioner checked before the weather gets hot. Lack of refrigerant may make the air conditioner less efficient. Consult an Authorized Mazda Dealer for refrigerant inspection. The air conditioner is filled with HFC134a (R134a), a refrigerant that will not damage the ozone layer.
Page 204: Climate Control System
RX-8_8V89-EA-06F_Edition1 Page203 Friday, May 19 2006 9:51 AM qAdjusting the Vents Directing airflow Side Vents To adjust the direction of airflow, open the vents and rotate them left and right. Form No.8V89-EA-06F Black plate (203,1) Climate Control System Vent Operation Center vents Center Vents To adjust the direction of airflow, move...
Page 205 RX-8_8V89-EA-06F_Edition1 Page204 Friday, May 19 2006 9:51 AM Interior Comfort Climate Control System qSelecting the Airflow Mode Dashboard Vents Dashboard and Floor Vents Floor Vents Form No.8V89-EA-06F Black plate (204,1) Defroster and Floor Vents Defroster Vents...
Page 206: Control Panel
RX-8_8V89-EA-06F_Edition1 Page205 Friday, May 19 2006 9:51 AM Climate control information is displayed on the information display. Windshield defroster switch Fan control dial qControl Switches Temperature control dial Cold This dial controls temperature. Turn it clockwise for hot and counterclockwise for cold.
Page 207 RX-8_8V89-EA-06F_Edition1 Page206 Friday, May 19 2006 9:51 AM Interior Comfort Climate Control System Mode selector switch Press the mode selector switch to select airflow mode (page 6-4). NOTE To set the air vent to , press the windshield defroster switch. A/C switch Push the A/C switch to turn the air conditioner on.
Page 208 RX-8_8V89-EA-06F_Edition1 Page207 Friday, May 19 2006 9:51 AM WARNING Do not use the position in cold or rainy weather: Using the position in cold or rainy weather is dangerous as it will cause the windows to fog up. Your vision will be hampered, which could lead to a serious accident.
Page 209 RX-8_8V89-EA-06F_Edition1 Page208 Friday, May 19 2006 9:51 AM Interior Comfort Climate Control System CAUTION When using the air conditioner while driving up long hills or in heavy traffic, closely monitor the temperature gauge (page 5-36). The air conditioner may cause engine overheating.
Page 210 RX-8_8V89-EA-06F_Edition1 Page209 Friday, May 19 2006 9:51 AM qDehumidifying (With Air Conditioner) Operate the air conditioner in cool or cold weather to help defog the windshield and side windows. 1. Press the mode selector switch to the desired position. 2. Set the air intake selector to the position.
Page 211: Audio System
RX-8_8V89-EA-06F_Edition1 Page210 Friday, May 19 2006 9:51 AM Interior Comfort Audio System Antenna qRear Window Antenna The rear window antenna receives both AM and FM signals. CAUTION When washing the inside rear window, use a soft cloth dampened in lukewarm water, gently wiping the antenna lines.
Page 212 RX-8_8V89-EA-06F_Edition1 Page211 Friday, May 19 2006 9:51 AM qRadio Reception AM characteristics AM signals bend around such things as buildings or mountains and bounce off the ionosphere. Therefore, they can reach longer distances than FM signals. Because of this, two stations may sometimes be picked up on the same frequency at the same time.
Page 213 RX-8_8V89-EA-06F_Edition1 Page212 Friday, May 19 2006 9:51 AM Interior Comfort Audio System Flutter/Skip noise Signals from an FM transmitter move in straight lines and become weak in valleys between tall buildings, mountains, and other obstacles. When a vehicle passes through such an area, the reception conditions may change suddenly, resulting in annoying noise.
Page 214 Use a good quality head- cleaning tape or a liquid cleaner cassette tape to remove it. Should the unit not operate normally, consult an Authorized Mazda Dealer. Never attempt to repair it or insert a screwdriver or anything else. Handling the cassette tape player The following precautions should be observed.
Page 215 RX-8_8V89-EA-06F_Edition1 Page214 Friday, May 19 2006 9:51 AM Interior Comfort Audio System qOperating Tips for CD Player/In- Dash CD Changer Condensation phenomenon Immediately after turning on the heater when the vehicle is cold, the CD or optical components (prism and lens) in the CD player/In-dash CD changer may become clouded with condensation.
Page 216 RX-8_8V89-EA-06F_Edition1 Page215 Friday, May 19 2006 9:51 AM A new CD may have rough edges on its inner and outer perimeters. If a disc with rough edges is used, proper setting will not be possible and the CD player/In-dash CD changer will not play the CD.
Page 217 RX-8_8V89-EA-06F_Edition1 Page216 Friday, May 19 2006 9:51 AM Interior Comfort Audio System Do not stick paper or tape on the CD. Avoid scratching the reverse side (the side without a label). The disc may not eject resulting in a malfunction. Dust, finger smudges, and dirt can decrease the amount of light reflected from the signal surface, thus affecting...
Page 218 RX-8_8V89-EA-06F_Edition1 Page217 Friday, May 19 2006 9:51 AM qOperating tips for MP3 NOTE Supply of this product only conveys a license for private, non-commercial use and does not convey a license nor imply any right to use this product in any commercial (i.e.
Page 219 RX-8_8V89-EA-06F_Edition1 Page218 Friday, May 19 2006 9:51 AM Interior Comfort Audio System About folders and files The order of hierarchy for MP3 files and folders during playback or other functions is from shallow to deep. The arrangement and playing order of a recorded disc containing MP3 files is as follows: File number...
Page 220 RX-8_8V89-EA-06F_Edition1 Page219 Friday, May 19 2006 9:51 AM CAUTION This unit can only play MP3 files that have an MP3 file extension (.mp3) attached. Do not attach an MP3 file extension to any other type file as it could cause noise to be emitted or a malfunction in the unit.
Page 221 RX-8_8V89-EA-06F_Edition1 Page220 Friday, May 19 2006 9:51 AM Black plate (220,1) Interior Comfort Audio System Abbreviation for Variable Bit Rate. While CBR (Constant Bit Rate) is generally used, VBR varies the bit rate for audio compression according to compression conditions and this allows for compression with preference given to sound quality.
Page 222: Audio Set
RX-8_8V89-EA-06F_Edition1 Page221 Friday, May 19 2006 9:51 AM CD Player (Music CD Player) CD Player (Music CD/MP3 CD Player) Cassette Tape Player Power/Volume/Sound Controls ... page 6-22 Operating the Radio ... page 6-26 Operating the Cassette Tape Player ... page 6-30 Operating the Compact Disc (CD) Player ...
Page 223 RX-8_8V89-EA-06F_Edition1 Page222 Friday, May 19 2006 9:51 AM Interior Comfort Audio System qPower/Volume/Sound Controls Power ON/OFF Turn the ignition switch to the ACC or ON position. Press the power/volume dial to turn the audio system on. Press the power/volume dial again to turn the audio system off.
Page 224 RX-8_8V89-EA-06F_Edition1 Page223 Friday, May 19 2006 9:51 AM BOSE Sound System- equipped model * Depending on the mode selected, the indication changes. 2. Turn the audio control dial to adjust the selected functions as follows: Standard audio-equipped model Indication Turn Left Turn Right Select mode Decrease bass...
Page 225 RX-8_8V89-EA-06F_Edition1 Page224 Friday, May 19 2006 9:51 AM Black plate (224,1) Interior Comfort Audio System The following four modes are available. Select the desired mode. Mode Volume change No change Minimum Medium Maximum Turn the audio control dial to select the ALC OFF, ALC LEVEL1 3 mode.
Page 226 RX-8_8V89-EA-06F_Edition1 Page225 Friday, May 19 2006 9:51 AM Black plate (225,1) MEMO 6-25 Form No.8V89-EA-06F...
Page 227 RX-8_8V89-EA-06F_Edition1 Page226 Friday, May 19 2006 9:51 AM Interior Comfort Audio System qOperating the Radio Satellite button Band selector button Seek tuning button Manual tuning dial/Auto memory button/Electric serial number button Radio ON Press a band selector button ( turn the radio on. Band selection Successively pressing the band selector button (...
Page 228 RX-8_8V89-EA-06F_Edition1 Page227 Friday, May 19 2006 9:51 AM Seek tuning Pressing the seek tuning button ( will cause the tuner to seek a higher or lower frequency automatically. NOTE If you continue to press and hold the button, the frequency will continue changing without stopping.
Page 229 RX-8_8V89-EA-06F_Edition1 Page228 Friday, May 19 2006 9:51 AM Black plate (228,1) Interior Comfort Audio System SATELLITE RADIO (SAT) Vehicles equipped with the separately purchased SIRIUS digital satellite radio unit have the ability to receive up to 100 channels of digital quality programming coast to coast via satellite.
Page 230 RX-8_8V89-EA-06F_Edition1 Page229 Friday, May 19 2006 9:51 AM Black plate (229,1) MEMO 6-29 Form No.8V89-EA-06F...
Page 231 RX-8_8V89-EA-06F_Edition1 Page230 Friday, May 19 2006 9:51 AM Interior Comfort Audio System qOperating the Cassette Tape Player APC button: (next program) (one being played) Repeat button Dolby NR button Cassette tape insert Insert the cassette tape into the slot, open edge to the right and cassette tape will begin play, and TAPE PLAY will be displayed.
Page 232 RX-8_8V89-EA-06F_Edition1 Page231 Friday, May 19 2006 9:51 AM NOTE The cassette tape can be ejected when the ignition switch is in the OFF position. Fast-forward/Rewind Press the fast-forward button ( fast-forward. Press the rewind button ( To stop this operation and play the cassette tape, press the button again.
Page 233 RX-8_8V89-EA-06F_Edition1 Page232 Friday, May 19 2006 9:51 AM Interior Comfort Audio System qOperating the Compact Disc (CD) Player (Music CD player) (Music CD/MP3 CD player) Load button Track up button Track down button Repeat button There are two types of CD players. Check which CD player type you own.
Page 234 RX-8_8V89-EA-06F_Edition1 Page233 Friday, May 19 2006 9:51 AM NOTE When the load button ( the CD will load and play even if the CD eject button ( ) had been previously pressed. Fast-forward/Reverse Press and hold the fast-forward button ) to advance through a track at high speed.
Page 235 If CHECK CD is displayed, it means that there is some CD malfunction. Check for damage, dirt, or smudges on the CD, and then properly reinsert. If the message appears again, take the unit to an Authorized Mazda Dealer for service.
Page 236 RX-8_8V89-EA-06F_Edition1 Page235 Friday, May 19 2006 9:52 AM Black plate (235,1) MEMO 6-35 Form No.8V89-EA-06F...
Page 237 RX-8_8V89-EA-06F_Edition1 Page236 Friday, May 19 2006 9:52 AM Interior Comfort Audio System qOperating the In-Dash CD Changer Channel preset buttons Load button CD slot Track up button Track down button Disc down button Repeat button Disc up button Inserting the CD The CD must be label-side up when inserting.
Page 238 RX-8_8V89-EA-06F_Edition1 Page237 Friday, May 19 2006 9:52 AM Multiple insertion 1. Press and hold the load button ( for about 2 seconds until a beep sound is heard. 2. Wait 3 seconds or press the load button ) again within 3 seconds after the beep sound is heard.
Page 239 RX-8_8V89-EA-06F_Edition1 Page238 Friday, May 19 2006 9:52 AM Interior Comfort Audio System Fast-forward/Reverse Press and hold the fast-forward button ) to advance through a track at high speed. Press and hold the reverse button ( to reverse through a track at high speed. Track search Press the track up button ( ) once to...
Page 240 Friday, May 19 2006 9:52 AM qError Indications If you see an error indication on the display, find the cause in the chart. If you cannot clear the error indication, take the vehicle to an Authorized Mazda Dealer. Indication CD is inserted upside down...
Page 241: Audio Control Switch Operation
CD changer, when all CDs are ejected.) 6-40 Form No.8V89-EA-06F Black plate (240,1) NOTE Mazda has installed this system to prevent distraction while driving the vehicle and using audio controls on the dashboard. Always make safe driving your first priority.
Page 242 RX-8_8V89-EA-06F_Edition1 Page241 Friday, May 19 2006 9:52 AM qChanging the Source Press the mode switch ( ) to change the audio source (FM1 radio> FM2 radio> AM radio> CD player or CD changer> Cassette tape player> SIRIUS1> SIRIUS2> SIRIUS3> cyclical). NOTE Cassette tape, CD, CD changer, and SIRIUS digital satellite radio modes...
Page 243 RX-8_8V89-EA-06F_Edition1 Page242 Friday, May 19 2006 9:52 AM Black plate (242,1) Interior Comfort Audio System qMute Switch Press the mute switch ( ) once to mute audio, press it again to resume audio output. 6-42 Form No.8V89-EA-06F...
Page 244: Safety Certification
This CD player should not be adjusted or repaired by anyone except qualified service personnel. If servicing is required, contact an Authorized Mazda Dealer. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous laser exposure. Never operate the CD player with the top case of the unit removed.
Page 245: Interior Equipment
RX-8_8V89-EA-06F_Edition1 Page244 Friday, May 19 2006 9:52 AM Interior Comfort Interior Equipment Sunvisors When you need a sunvisor, lower it for use in front or swing it to the side. Sunvisor qVanity Mirrors To use the vanity mirror, lower the sunvisor.
Page 246 RX-8_8V89-EA-06F_Edition1 Page245 Friday, May 19 2006 9:52 AM qOverhead Lights Front Switch Front Overhead Lights Position Light off Light on when any door is open Light on or off when the illuminated entry system is on Rear Switch Rear Overhead Lights Position Light off Light on when any door is open...
Page 247: Information Display
RX-8_8V89-EA-06F_Edition1 Page246 Friday, May 19 2006 9:52 AM Interior Comfort Interior Equipment Information Display qInformation Display Functions The information display has the following functions: Clock Ambient Temperature Display (Outside Temperature Display) Climate Control Display Audio Display 6-46 Form No.8V89-EA-06F Black plate (246,1)
Page 248 RX-8_8V89-EA-06F_Edition1 Page247 Friday, May 19 2006 9:52 AM qClock When the ignition switch is in the ACC or ON position, the time is displayed. Time setting 1. Press the CLK switch until a beep sounds, and 12Hr and 24Hr will be displayed.
Page 249: Lighter
RX-8_8V89-EA-06F_Edition1 Page248 Friday, May 19 2006 9:52 AM Interior Comfort Interior Equipment NOTE Under the following conditions, the ambient temperature display may differ from the actual ambient temperature depending on the surroundings and vehicle conditions: Significantly cold or hot temperatures. Sudden changes in ambient temperature.
Page 250: Ashtray
Don't use the lighter socket for plug- in accessories such as shavers and coffee pots. They may damage it or cause electrical failure. Use only a genuine Mazda lighter or the equivalent. If the lighter doesn't pop out within 30 seconds, remove it to prevent overheating.
Page 251: Cup Holder
RX-8_8V89-EA-06F_Edition1 Page250 Friday, May 19 2006 9:52 AM Interior Comfort Interior Equipment Cup Holder WARNING Never use a cup holder to hold hot liquids while the vehicle is moving: Using a cup holder to hold hot liquids while the vehicle is moving is dangerous.
Page 252: Storage Compartments
RX-8_8V89-EA-06F_Edition1 Page251 Friday, May 19 2006 9:52 AM Storage Compartments WARNING Keep storage boxes closed when driving: Driving with the storage boxes open is dangerous. To reduce the possibility of injury in an accident or a sudden stop, keep the storage boxes closed when driving.
Page 253 RX-8_8V89-EA-06F_Edition1 Page252 Friday, May 19 2006 9:52 AM Interior Comfort Interior Equipment qCenter Console Front 1. Slide the lid while pushing the button until you hear a click sound. 2. Open the lid. 6-52 Form No.8V89-EA-06F Black plate (252,1) Rear To open, pull the release catch.
Page 254 RX-8_8V89-EA-06F_Edition1 Page253 Friday, May 19 2006 9:52 AM To open, squeeze the latch and pull the lid down. When closing the storage box, put the storage box back in its original position until you hear a click sound. NOTE When using the storage box to store heavy accessories, remove the storage box before placing or removing the accessories.
Page 255: Accessory Socket
Interior Equipment Accessory Socket The ignition switch must be in the ACC or ON position. Only use genuine Mazda accessories or the equivalent requiring no greater than 120 W (DC 12 V, 10 A). The accessory socket is in the center console.
Page 256: In Case Of An Emergency
RX-8_8V89-EA-06F_Edition1 Page255 Friday, May 19 2006 9:52 AM In Case of an Emergency Helpful information on what to do in an emergency. Parking in an Emergency ... 7-2 Parking in an Emergency ... 7-2 Flat Tire ... 7-3 Spare Tire and Tool Storage ... 7-3 Instant Mobility System (IMS) Emergency Flat Tire Repair Kit ...
Page 257: Parking In An Emergency
RX-8_8V89-EA-06F_Edition1 Page256 Friday, May 19 2006 9:52 AM In Case of an Emergency Parking in an Emergency Parking in an Emergency The hazard warning lights should always be used when you stop on or near a roadway in an emergency. The hazard warning lights warn other drivers that your vehicle is a traffic hazard and that they must take extreme caution...
Page 258: Flat Tire
RX-8_8V89-EA-06F_Edition1 Page257 Friday, May 19 2006 9:52 AM Black plate (257,1) In Case of an Emergency Flat Tire Spare Tire and Tool Storage Tools are stored in the locations illustrated in the diagram. Instant Mobility System (IMS) Emergency Flat Tire Repair Kit Tool box Lug wrench Jack handle...
Page 259 Perform the removal procedure in reverse. qSpare Tire A temporary spare tire is not equipped with your Mazda. If an emergency tire repair is needed, repair the flat tire with the emergency flat tire repair kit (page 7-5). If you require a temporary spare tire, consult an Authorized Mazda Dealer.
Page 260: Instant Mobility System (Ims) Emergency Flat Tire Repair Kit
(IMS) Emergency Flat Tire Repair Kit The IMS emergency flat tire repair kit included with your Mazda is for a temporary repair of a slightly damaged flat tire resulting from running over nails or similar sharp objects on the road surface.
Page 261 RX-8_8V89-EA-06F_Edition1 Page260 Friday, May 19 2006 9:52 AM In Case of an Emergency Flat Tire qAbout the IMS Emergency Flat Tire Repair Kit The IMS emergency flat tire repair kit includes the following items. Compressor Tire sealant Injection hose Repaired tire Spare valve Valve core sticker...
Page 262 Purchase new tire sealant at an Authorized Mazda Dealer. The emergency flat tire repair kit cannot be used in the following cases. Consult an Authorized Mazda Dealer. The period of effective use for the tire sealant has expired. (The period of effectiveness is indicated on the bottle label.)
Page 263 RX-8_8V89-EA-06F_Edition1 Page262 Friday, May 19 2006 9:52 AM In Case of an Emergency Flat Tire NOTE The tire sealant can be used at outside temperatures down to _ 30°C. In extremely cold temperatures (0°C (32°F) or below), the tire sealant hardens easily and injection of the sealant will be difficult.
Page 264 Do not throw away the empty tire sealant bottle after use. Return the empty tire sealant bottle to an Authorized Mazda Dealer when replacing the tire. The empty tire sealant bottle will need to be used to extract and dispose of the used sealant from the tire.
Page 265 RX-8_8V89-EA-06F_Edition1 Page264 Friday, May 19 2006 9:52 AM In Case of an Emergency Flat Tire 14. Install the compressor hose to the tire valve. Valve Compressor hose 15. Insert the compressor plug into the interior accessory socket and turn the ignition switch to the ACC position (page 6-54).
Page 266 19. Put the emergency flat tire repair kit in the trunk and continue driving. CAUTION Drive carefully to an Authorized Mazda Dealer and keep the vehicle speed below 80 km/h (50 mph). If the vehicle is driven 80 km/h (50 mph) or higher, the vehicle might begin to vibrate.
Page 267: Changing The Tire
Flat Tire 21. If the tire inflation pressure remains stable, the tire repair is complete. Drive the vehicle with care to an Authorized Mazda Dealer to have the tire replaced. CAUTION A tire that has been temporarily repaired with the tire sealant cannot be reused.
Page 268 RX-8_8V89-EA-06F_Edition1 Page267 Friday, May 19 2006 9:52 AM 1. Park on a level surface off the right-of- way and firmly set the parking brake. 2. Put a vehicle with an automatic transmission in Park (P), a manual transmission in Reverse (R) or 1, and turn off the engine.
Page 269 Before removing the lug nuts, make sure your Mazda is firmly in position and that it cannot slip or move. 5. Remove the lug nuts by turning them counterclockwise, then remove the wheel.
Page 270 If you lose this key, consult an Authorized Mazda Dealer or use the lock manufacturer's order form, which is with the registration card.
Page 271 Use the lug wrench to tighten the nuts in the order shown. If you're unsure of how tight the nuts should be, have them inspected at an Authorized Mazda Dealer. Nut tightening torque 88 118 N·m (kgf·m, ft·lbf) (9 12, 65 87)
Page 272 Because the wheel studs and lug nuts on your Mazda have metric threads, using a non-metric nut is dangerous. On a metric stud, it would not secure the wheel and would damage the stud, which could cause the wheel to slip off and cause an accident.
Page 273: Overheating
If neither coolant nor steam is escaping: Open the hood and idle the engine until it cools. CAUTION If the cooling fan does not operate while the engine is running, the engine temperature will increase. Stop the engine and call an Authorized Mazda Dealer.
Page 274 CAUTION If the engine continues to overheat or frequently overheats, have the cooling system inspected. The engine could be seriously damaged unless repairs are made. Consult an Authorized Mazda Dealer. Form No.8V89-EA-06F Black plate (273,1) In Case of an Emergency...
Page 275: Emergency Starting
START position for over 10 seconds. It may damage the starter and drain the battery. If the engine still does not start using the above procedure, have your vehicle inspected by an Authorized Mazda Dealer. 7-20 Form No.8V89-EA-06F Black plate (274,1)
Page 276: Jump-Starting
RX-8_8V89-EA-06F_Edition1 Page275 Friday, May 19 2006 9:52 AM Jump-starting is dangerous if done incorrectly. So follow the procedure carefully. If you feel unsure about jump-starting, we strongly recommend that you have a competent service technician do the work. Follow These Precautions Carefully: To ensure safe and correct handling of the battery, read the following precautions carefully before using the battery or inspecting it.
Page 277 RX-8_8V89-EA-06F_Edition1 Page276 Friday, May 19 2006 9:52 AM In Case of an Emergency Emergency Starting Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.
Page 278 RX-8_8V89-EA-06F_Edition1 Page277 Friday, May 19 2006 9:52 AM 1. Remove the engine cover. 2. Remove the rubber hose from the battery cover. 3. Remove the battery cover from its rear side. Form No.8V89-EA-06F Black plate (277,1) In Case of an Emergency Emergency Starting 4.
Page 279: Push-Starting
Verify that the engine cover is securely installed. 7-24 Form No.8V89-EA-06F Black plate (278,1) Push-Starting Do not push-start your Mazda. WARNING Never tow a vehicle to start it: Towing a vehicle to start it is dangerous. The vehicle being towed could surge forward when its engine starts, causing the two vehicles to collide.
Page 280: Emergency Towing
RX-8_8V89-EA-06F_Edition1 Page279 Friday, May 19 2006 9:52 AM Towing Description We recommend that towing be done only by an Authorized Mazda Dealer or a commercial tow-truck service. Proper lifting and towing are necessary to prevent damage to the vehicle. Government and local laws must be followed.
Page 281: Tiedown Hooks
RX-8_8V89-EA-06F_Edition1 Page280 Friday, May 19 2006 9:52 AM In Case of an Emergency Emergency Towing Tiedown Hooks CAUTION Don't use the tiedown hooks under the front and rear for towing. They are designed ONLY for tying down the vehicle when it's being transported.
Page 282: Recreational Towing
RX-8_8V89-EA-06F_Edition1 Page281 Friday, May 19 2006 9:52 AM 4. Hook the tying rope to the tiedown eyelet. Front Rear CAUTION If the tiedown eyelet is not securely tightened, it may loosen or disengage from the bumper when tying down the vehicle.
Page 283 RX-8_8V89-EA-06F_Edition1 Page282 Friday, May 19 2006 9:52 AM Black plate (282,1) 7-28 Form No.8V89-EA-06F...
Page 284: Maintenance And Care
RX-8_8V89-EA-06F_Edition1 Page283 Friday, May 19 2006 9:52 AM Maintenance and Care How to keep your Mazda in top condition. Introduction ... 8-2 Introduction ... 8-2 Scheduled Maintenance ... 8-3 Scheduled Maintenance ... 8-3 Owner Maintenance ... 8-8 Owner Maintenance Schedule ... 8-8 Owner Maintenance Precautions ...
Page 285: Introduction
Claims against the warranty resulting from lack of maintenance, as opposed to defective materials or authorized Mazda workmanship, will not be honored. Any auto repair shop using parts equivalent to your Mazda's original equipment may perform maintenance. But we recommend that it always be done by an Authorized Mazda Dealer using genuine Mazda parts.
Page 286: Scheduled Maintenance
RX-8_8V89-EA-06F_Edition1 Page285 Friday, May 19 2006 9:52 AM Scheduled Maintenance Follow Schedule 1 if the vehicle is operated mainly where none of the following conditions apply. If any do apply, follow Schedule 2 (Canada and Puerto Rico residents follow Schedule 2). Repeated short-distance driving Driving in dusty conditions Driving with extended use of brakes...
Page 287 RX-8_8V89-EA-06F_Edition1 Page286 Friday, May 19 2006 9:52 AM Maintenance and Care Scheduled Maintenance qSchedule 1 Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles ENGINE Engine oil Engine oil filter Drive belt AIR FILTER Air filter IGNITION SYSTEM Spark plugs...
Page 288 *1 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 289 RX-8_8V89-EA-06F_Edition1 Page288 Friday, May 19 2006 9:52 AM Maintenance and Care Scheduled Maintenance qSchedule 2 Number of months or kilometers (miles), whichever comes first Months Maintenance Interval ×1000 km ×1000 miles ENGINE Puerto Rico Engine oil Others Engine oil filter Drive belt AIR FILTER Air filter...
Page 290 *1 According to state/provincial and federal regulations, failure to perform maintenance on these items will not void your emissions warranties. However, Mazda recommends that all maintenance services be performed at the recommended time or mileage/kilometer period to ensure long-term reliability.
Page 291: Owner Maintenance
The owner or a qualified service technician should make these vehicle inspections at the indicated intervals to ensure safe and dependable operation. Bring any problem to the attention of an Authorized Mazda Dealer or qualified service technician as soon as possible.
Page 292: Owner Maintenance Precautions
Improper owner maintenance during the warranty period may affect warranty coverage. For details, read the separate Mazda Warranty statement provided with the vehicle. If you're unsure about any servicing or maintenance procedure, have it done by an Authorized Mazda Dealer.
Page 293 RX-8_8V89-EA-06F_Edition1 Page292 Friday, May 19 2006 9:52 AM Maintenance and Care Owner Maintenance NOTE Once the engine coolant exceeds a preset temperature, an electrical cooling fan turns on. It will continue running for about 10 minutes after the ignition switch is turned to off. 8-10 Form No.8V89-EA-06F Black plate (292,1)
Page 294: Engine Compartment Overview
RX-8_8V89-EA-06F_Edition1 Page293 Friday, May 19 2006 9:52 AM Engine Compartment Overview Engine oil-filler cap Windshield washer fluid reservoir Cooling system cap Engine coolant reservoir Battery Form No.8V89-EA-06F Black plate (293,1) Owner Maintenance Engine oil dipstick Fuse block (near battery) Air filter Maintenance and Care Brake/Clutch fluid reservoir...
Page 295: Engine Oil
Do not use either synthetic or semi- synthetic motor oil. Otherwise engine starting performance could worsen. NOTE Changing the engine oil should be done by an Authorized Mazda Dealer. The Mazda RX-8 requires regular checking of the engine oil level. The compact, high performance...
Page 296 RX-8_8V89-EA-06F_Edition1 Page295 Friday, May 19 2006 9:52 AM Only use oils Certified For Gasoline Engines by the American Petroleum Institute (API). An oil with this trademark symbol conforms to the current engine and emission system protection standards and fuel economy requirements of the International Lubricant Standardization and Approval Committee (ILSAC), comprised of U.S.
Page 297: Engine Coolant
RX-8_8V89-EA-06F_Edition1 Page296 Friday, May 19 2006 9:52 AM Maintenance and Care Owner Maintenance 5. Pull out the dipstick, wipe it clean, and reinsert it fully. Full 6. Pull it out again and examine the level. It's OK between L and F. But if it's near or below L, add enough oil to bring the level to F.
Page 298 10 minutes after the ignition switch is turned to off. NOTE Changing the coolant should be done by an Authorized Mazda Dealer. Inspect the antifreeze protection and coolant level in the coolant reservoir at least once a year at the beginning of the...
Page 299: Brake/Clutch Fluid
(page 8-3). If the coolant reservoir is empty or new coolant is required frequently, consult an Authorized Mazda Dealer. 8-16 Form No.8V89-EA-06F Black plate (298,1) Brake/Clutch Fluid qInspecting Brake/Clutch Fluid Level The brakes and clutch draw fluid from the same reservoir.
Page 300: Washer Fluid
Using nonspecified brake and clutch fluids (page 10-4) will damage the systems. Mixing different fluids will also damage them. If the brake/clutch system frequently requires new fluid, consult an Authorized Mazda Dealer. Form No.8V89-EA-06F Black plate (299,1) Maintenance and Care Owner Maintenance Washer Fluid...
Page 301: Body Lubrication
RX-8_8V89-EA-06F_Edition1 Page300 Friday, May 19 2006 9:52 AM Maintenance and Care Owner Maintenance Inspect fluid level in the washer fluid reservoir; add fluid if necessary. Use plain water if washer fluid is unavailable. But use only washer fluid in cold weather to prevent it from freezing.
Page 302: Wiper Blades
RX-8_8V89-EA-06F_Edition1 Page301 Friday, May 19 2006 9:52 AM Wiper Blades CAUTION Hot waxes applied by automatic car washers have been known to affect the wiper's ability to clean windows. To prevent damage to the wiper blades, don't use gasoline, kerosene, paint thinner, or other solvents on or near them.
Page 303 RX-8_8V89-EA-06F_Edition1 Page302 Friday, May 19 2006 9:52 AM Maintenance and Care Owner Maintenance 2. Hold the end of the rubber and pull until the tabs are free of the metal support. Metal support 3. Remove the metal stiffeners from each blade rubber and install them in the new blade.
Page 304: Battery
RX-8_8V89-EA-06F_Edition1 Page303 Friday, May 19 2006 9:52 AM Wash hands after handling the battery and related accessories: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer and reproductive harm. Read the following precautions carefully before using the battery or inspecting to ensure safe and correct handling: Always wear eye protection when working near the battery:...
Page 305 RX-8_8V89-EA-06F_Edition1 Page304 Friday, May 19 2006 9:52 AM Maintenance and Care Owner Maintenance Keep all flames, including cigarettes, and sparks away from open battery cells: Flames and sparks near open battery cells are dangerous. Hydrogen gas, produced during normal battery operation, could ignite and cause the battery to explode. An exploding battery can cause serious burns and injuries.
Page 306 RX-8_8V89-EA-06F_Edition1 Page305 Friday, May 19 2006 9:52 AM NOTE Remove the engine and battery covers before performing battery maintenance. Engine cover Battery cover If the cover has been removed, install it in the reverse order of removal. qBattery Maintenance To get the best service from a battery: Keep it securely mounted.
Page 307: Tires
Use all radial, all bias-belted, or all bias-type tires. Using Wrong-Sized Tires: Using any other tire size than what is specified for your Mazda (page 10-6) is dangerous. It could seriously affect ride, handling, ground clearance, tire clearance, and speedometer calibration.
Page 308 Because your vehicle is not equipped with a spare tire, you cannot do a tire rotation safely with the jack that comes with your vehicle. Have an Authorized Mazda Dealer perform tire rotation. Form No.8V89-EA-06F Black plate (307,1) Maintenance and Care...
Page 309 CAUTION (With Tire Pressure Monitoring System) When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. 8-26 Form No.8V89-EA-06F Black plate (308,1) NOTE...
Page 310 4 digit. Refer to The tire labeling on page 9-18. qTemporary Spare Tire Your Mazda is not equipped with a spare tire. If you require a spare tire, consult an Authorized Mazda Dealer. Inspect the temporary spare tire at least monthly to make sure it's properly inflated and stored.
Page 311 (With Tire Pressure Monitoring System) When replacing/repairing the tires or wheels or both, have the work done by an Authorized Mazda Dealer, or the tire pressure sensors may be damaged. The wheels equipped on your Mazda are specially designed for installation of the tire pressure sensors.
Page 312: Light Bulbs
RX-8_8V89-EA-06F_Edition1 Page311 Friday, May 19 2006 9:52 AM Brake lights/Taillights Trunk light High-mount brake light License plate light Overhead light/Map lights (Front) Vanity mirror lights Parking lights Fog lights Headlights (High-beam) Form No.8V89-EA-06F Black plate (311,1) Owner Maintenance Light Bulbs Rear side-marker lights Front side-marker lights Front turn signal lights...
Page 313 Consult an Authorized Mazda Dealer when the replacement is necessary. Never touch the glass portion of a halogen bulb with your bare hands...
Page 314 Form No.8V89-EA-06F Black plate (313,1) Maintenance and Care Owner Maintenance The bulbs must be replaced at an Authorized Mazda Dealer. (Halogen bulbs) 1. Detach the electrical connector from the sealing cover by pulling it to the rear. 2. Detach the sealing cover from the bulb.
Page 315 Fog Light Bulb Due to the complexity and difficulty of the procedure, the bulbs should be replaced by an Authorized Mazda Dealer. qReplacing a Bulb (Front) 1. If you are changing the right bulb, start the engine, turn the steering wheel all the way to the right, and turn off engine.
Page 316 RX-8_8V89-EA-06F_Edition1 Page315 Friday, May 19 2006 9:52 AM qReplacing a Bulb (Interior) Overhead light/Map lights (Front) 1. Remove the screws with a Phillips screwdriver. 2. Wrap a flathead screwdriver with a soft cloth to prevent damage to the trim and gently insert it in the overhead light as shown in the figure, and then remove the overhead light unit.
Page 317 Rear turn signal lights Brake lights/Taillights Reverse lights 4. Install the new bulb in the reverse order of removal. Rear side-marker lights Due to the complexity and difficulty of the procedure, the bulbs should be replaced by an Authorized Mazda Dealer.
Page 318 RX-8_8V89-EA-06F_Edition1 Page317 Friday, May 19 2006 9:52 AM High-mount brake light 1. Turn the center section of the plastic retainer counterclockwise and remove the retainers and trunk rear trim. Removal Installation 2. Turn the socket and bulb assembly counterclockwise and remove it. 3.
Page 319: Fuses
If the same fuse blows again, avoid using that system and consult an Authorized Mazda Dealer as soon as possible. qFuse Replacement Replacing the fuses on the driver's side If the electrical system doesn't work, first inspect fuses on the driver's side.
Page 320 Normal Blown WARNING Do not replace the main fuse by yourself. Have an Authorized Mazda Dealer perform the replacement: Replacing the fuse by yourself is dangerous because the MAIN fuse is a high current fuse. Incorrect replacement could cause an electrical shock or a short circuit resulting in a fire.
Page 321 RX-8_8V89-EA-06F_Edition1 Page320 Friday, May 19 2006 9:52 AM Maintenance and Care Owner Maintenance qFuse Panel Description Fuse block (Engine compartment) (Next to air filter) FUSE DESCRIPTION RATING MAIN 120A HEATER AIR PUMP DEFOG ABS/DSC HEAD HEAD LOW R HEAD LOW L SEAT WARM H/CLEAN R.FOG...
Page 322 RX-8_8V89-EA-06F_Edition1 Page321 Friday, May 19 2006 9:52 AM DESCRIPTION A/C MAG IG KEY STOP FUEL PUMP HORN HAZARD WIPER P.WIND ENGINE TAIL ILLUMI EGI COMP1 EGI COMP2 EGI INJ Form No.8V89-EA-06F Owner Maintenance FUSE PROTECTED COMPONENT RATING í Fog lights Air conditioner For protection of various circuits For protection of various circuits...
Page 323 RX-8_8V89-EA-06F_Edition1 Page322 Friday, May 19 2006 9:52 AM Maintenance and Care Owner Maintenance Fuse panel (Driver's side) FUSE DESCRIPTION RATING CIGAR 7.5A AUX PWR 7.5A METER SPARE SPARE M.DEF 7.5A AUDIO D.LOCK P.WIND ROOM SPARE SPARE í 8-40 Some models. Form No.8V89-EA-06F Black plate (322,1) PROTECTED COMPONENT...
Page 324: Appearance Care
Prevention It is necessary to have your Mazda washed and waxed to preserve its finish according to the instructions in this section. This should be done as soon as possible.
Page 325 In low temperatures a vehicle's finish hardens. This increases the chance of paint chipping. Chipped paint can lead to rust forming on your Mazda. Before this happens, repair the damage by using Mazda touch-up paint according to the instructions in this section.
Page 326: Exterior Care
Cleansers or wax containing abrasives are used. NOTE Mazda is not responsible for scratches caused by automatic car washes or improper washing. Scratches are more noticeable on vehicles with darker paint finishes.
Page 327 Exposed metal quickly rusts and can lead to major repairs. CAUTION If your Mazda is damaged and needs metal parts repaired or replaced, make sure the body shop applies anti- corrosion materials to all parts, both repaired and new.
Page 328 RX-8_8V89-EA-06F_Edition1 Page327 Friday, May 19 2006 9:53 AM qUnderbody Maintenance Road chemicals and salt used for ice and snow removal and solvents used for dust control may collect on the underbody. If not removed, they will speed up rusting and deterioration of such underbody parts as fuel lines, frame, floor pan, and exhaust system, even though these parts may be coated with anti-corrosive material.
Page 329: Interior Care
RX-8_8V89-EA-06F_Edition1 Page328 Friday, May 19 2006 9:53 AM Maintenance and Care Appearance Care Interior Care qDashboard Precautions Prevent caustic solutions such as perfume and cosmetic oils from contacting the dashboard. They'll damage and discolor it. If these solutions get on the dashboard, wipe them off immediately.
Page 330 Form No.8V89-EA-06F Black plate (329,1) Maintenance and Care Appearance Care WARNING Have an Authorized Mazda Dealer replace damaged seat belts immediately: Using damaged seat belts is dangerous. In a collision, damaged belts cannot provide adequate protection.
Page 331 RX-8_8V89-EA-06F_Edition1 Page330 Friday, May 19 2006 9:53 AM Black plate (330,1) 8-48 Form No.8V89-EA-06F...
Page 332: Customer Information And Reporting Safety Defects
Mazda Importer/Distributors ... 9-8 Importer/Distributor ... 9-8 Distributor in Each Area ... 9-8 Warranty ... 9-9 Warranties for Your Mazda ... 9-9 Outside the United States ... 9-10 Outside Canada ... 9-11 Registering Your Vehicle in A Foreign Country (Except United States and Canada) ...
Page 333: Customer Assistance
1: Contact Your Mazda Dealer Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 334 4. Purchase date and current mileage 5. Your dealer's name and location 6. Your question(s) If you live outside the U.S.A., please contact your nearest Mazda Distributor. Form No.8V89-EA-06F Black plate (333,1) Customer Information and Reporting Safety Defects...
Page 335: Customer Assistance (Canada)
Your complete and permanent satisfaction is of primary concern to Mazda. All Authorized Mazda Dealers have both the knowledge and tools to keep your Mazda in top condition. In our experience, any questions, problems, or complaints regarding the operation of your Mazda or any other general service transactions are most effectively resolved by your dealer.
Page 336 If a specific item of concern arises, where a solution cannot be reached between an owner, Mazda, and/or one of it's dealers (that all parties cannot agree upon), the owner may wish to use the services offered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 337 British Columbia & Yukon Territories Alberta & Northwest Territories Saskatchewan Manitoba Ontario Atlantic Canada Quebec qRegional Offices REGIONAL OFFICES MAZDA CANADA INC. WESTERN REGION 8171 ACKROYD ROAD SUITE 2000 RICHMOND B.C. V6X 3K1 (604) 303-5670 MAZDA CANADA INC. CENTRAL/ATLANTIC REGION...
Page 338: Customer Assistance (Puerto Rico)
1 Discuss the matter with an Authorized Mazda Dealer. This is the quickest and best way to address the issue. If your concern has not been resolved by the CUSTOMER RELATIONS, SALES, SERVICE, or PARTS MANAGER, then please contact the GENERAL MANAGER of the dealership or the OWNER.
Page 339: Mazda Importer/Distributors
55 Vogell Road, Richmond Hill, Ontario, L4B 3K5 Canada TEL: 1 (800) 263-4680 (in Canada) (905) 787-7000 (outside Canada) qPUERTO RICO/U.S. Virgin Island Plaza Motors Corp. (Mazda de Puerto Rico) P.O. Box 362722, San Juan, Puerto Rico 00936-2722 TEL: (787) 641-9300...
Page 340: Warranty
California Emission Control Warranty (U.S.A. only) Emission Control Warranty (Canada only) Replacement Parts and Accessories Limited Warranty Tire Warranty NOTE Detailed warranty information is provided with your Mazda. Form No.8V89-EA-06F Black plate (339,1) Customer Information and Reporting Safety Defects Warranty...
Page 341: Outside The United States
We strongly recommend that you NOT take your Mazda outside the United States. However, in the event that you are moving to Canada permanently, Mazda vehicles built for use in the United States could be eligible for exportation to Canada with specific vehicle modifications to comply with the Canadian Motor Vehicle Safety requirements (CMVSS).
Page 342: Outside Canada
We strongly recommend that you NOT take your Mazda outside Canada. However, in the event that you are moving to the United States permanently, Mazda vehicles built for use in Canada could be eligible for exportation to the United States with specific vehicle modifications to comply with the United States Federal Motor Vehicle Safety Standards (FMVSS).
Page 343: Registering Your Vehicle In A Foreign
Parts, servicing techniques, and tools necessary to maintain and repair your vehicle may be unavailable. There might not be an Authorized Mazda Dealer in the country you plan to take your vehicle. The Mazda warranty is valid only in certain countries.
Page 344: Add-On Non-Genuine Parts And Accessories
Non-genuine parts and accessories for Mazda vehicles can be found in stores. These may fit your vehicle, but they are not approved by Mazda for use with Mazda vehicles. When you install non-genuine parts or accessories, they could affect your vehicle's performance or safety systems;...
Page 345: Cell Phones
RX-8_8V89-EA-06F_Edition1 Page344 Friday, May 19 2006 9:53 AM Customer Information and Reporting Safety Defects Cell Phones Cell Phones Warning Please comply with the legal regulations concerning the use of communication equipment in vehicles in your country: Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous.
Page 346: Type Approval Of Equipment
RX-8_8V89-EA-06F_Edition1 Page345 Friday, May 19 2006 9:53 AM Black plate (345,1) Customer Information and Reporting Safety Defects Type Approval of Equipment Type Approval of Equipment Immobilizer system 9-15 Form No.8V89-EA-06F...
Page 347: Uniform Tire Quality Grading System
RX-8_8V89-EA-06F_Edition1 Page346 Friday, May 19 2006 9:53 AM Customer Information and Reporting Safety Defects Uniform Tire Quality Grading System (UTQGS) Uniform Tire Quality Grading System (UTQGS) This information relates to the tire grading system developed by the U.S. National Highway Traffic Safety Administration for grading tires by tread wear, traction, and temperature performance.
Page 348 These grades will be added to the sidewalls of passenger vehicle tires over the next several years according to a schedule established by the NHTSA and the tire manufacturers. The grade of tires available as standard or optional equipment on Mazda vehicles may vary with respect to grade.
Page 349: Tire Information (U.s.a.)
RX-8_8V89-EA-06F_Edition1 Page348 Friday, May 19 2006 9:53 AM Black plate (348,1) Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Tire Labeling Federal law requires tire manufacturers to place standardized information on the sidewall of all tires. This information identifies and describes the fundamental characteristics of the tire and also provides a tire identification number for safety standard certification and in case of a recall.
Page 350 RX-8_8V89-EA-06F_Edition1 Page349 Friday, May 19 2006 9:53 AM 11. Tread wear, traction and temperature grades 12. Max. permissible inflation pressure 13. SAFETY WARNING P215/65R15 95H is an example of a tire size and load index rating. Here is an explanation of the various components of that tire size and load index rating.
Page 351 RX-8_8V89-EA-06F_Edition1 Page350 Friday, May 19 2006 9:53 AM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) H is the speed rating. The speed rating denotes the maximum speed for which the use of the tire is rated. Letter Rating * For tires with a maximum speed capability over 149 mph, tire manufacturers sometimes use the letters ZR.
Page 352 RX-8_8V89-EA-06F_Edition1 Page351 Friday, May 19 2006 9:53 AM Tread Wear, Traction and Temperature Grades Tread wear: The tread wear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 353 RX-8_8V89-EA-06F_Edition1 Page352 Friday, May 19 2006 9:53 AM Black plate (352,1) Customer Information and Reporting Safety Defects Tire Information (U.S.A.) qInformation on Temporary Tires Please refer to the diagram below. 1. Temporary tires 2. Nominal width of tire in millimeters 3.
Page 354 RX-8_8V89-EA-06F_Edition1 Page353 Friday, May 19 2006 9:53 AM 70 is the aspect ratio. This two-digit number indicates the tire's ratio of height to width. D is the tire construction symbol. D indicates diagonal ply construction . 16 is the wheel rim diameter in inches. 90 is the Load Index.
Page 355: Location Of The Tire Label
RX-8_8V89-EA-06F_Edition1 Page354 Friday, May 19 2006 9:53 AM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Location of the Tire Label (Placard) You will find the tire label containing tire inflation pressure by tire size and other important information on the driver's side B-pillar or on the edge of the rear door on the driver's side. SAMPLE qRecommended Tire Inflation Pressure On the tire label you will find the recommended tire inflation pressure in both kPa and psi...
Page 356 RX-8_8V89-EA-06F_Edition1 Page355 Friday, May 19 2006 9:53 AM Always check the tire inflation pressures on a regular basis according to the recommended tire inflation pressure on the tire label and in conjunction with the information in this owner's manual: Driving your vehicle with under-inflated tires is dangerous. Under-inflation is the most common cause of failures in any kind of tire and may result in severe cracking, tread separation or blowout , with unexpected loss of vehicle control and increased risk of injury.
Page 357 RX-8_8V89-EA-06F_Edition1 Page356 Friday, May 19 2006 9:53 AM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) NOTE Warm tires normally exceed recommended pressures. Don't release air from warm tires to adjust the pressure. Under-inflation can cause serious failures and accidents. Over-inflation can produce a harsh ride and the greater possibility of damage from road hazards.
Page 358: Tire Maintenance
RX-8_8V89-EA-06F_Edition1 Page357 Friday, May 19 2006 9:53 AM Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Here are some important maintenance points: qTire Inflation Pressure Inspect all tire pressure monthly (including the spare) when the tires are cold. Maintain recommended pressures for the best ride, top handling, and minimum tire wear.
Page 359 RX-8_8V89-EA-06F_Edition1 Page358 Friday, May 19 2006 9:53 AM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Rotate unidirectional tires and radial tires that have an asymmetrical tread pattern or studs only from front to rear, not from side to side. Tire performance will be weakened if rotated from side to side.
Page 360 RX-8_8V89-EA-06F_Edition1 Page359 Friday, May 19 2006 9:53 AM NOTE Tires degrade over time, even when they are not being used on the road. It is recommended that tires generally be replaced when they are 6 years or older. Heat caused by hot climates or frequent high loading conditions can accelerate the aging process.
Page 361: Vehicle Loading
RX-8_8V89-EA-06F_Edition1 Page360 Friday, May 19 2006 9:53 AM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Do not taw a trailer with this vehicle: Towing a trailer with this vehicle is dangerous because it has not been designed to tow a trailer and doing so will affect the drive system which could result in vehicle damage.
Page 362 RX-8_8V89-EA-06F_Edition1 Page361 Friday, May 19 2006 9:53 AM Base Curb Weight is the weight of the vehicle including a full tank of fuel and all standard equipment. It does not include passengers, cargo, or optional equipment. Vehicle Curb Weight is the weight of your new vehicle when you picked it up from your dealer plus any aftermarket equipment.
Page 363 RX-8_8V89-EA-06F_Edition1 Page362 Friday, May 19 2006 9:53 AM Black plate (362,1) Customer Information and Reporting Safety Defects Tire Information (U.S.A.) SAMPLE CARGO Cargo Weight includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight.
Page 364 RX-8_8V89-EA-06F_Edition1 Page363 Friday, May 19 2006 9:53 AM Examples: Based on a single occupant weight of 68 kg, and a value of 385 kg for the combination weight of occupants and cargo should never exceed : The cargo weight limit with one occupant is 385 kg _ 68 kg = 317 kg The cargo weight limit with two occupants is 385 kg _ (68 ×...
Page 365 RX-8_8V89-EA-06F_Edition1 Page364 Friday, May 19 2006 9:53 AM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) SAMPLE Exceeding Axle Weight Rating Limits: Exceeding the Safety Certification Label axle weight rating limits is dangerous and could result in death or serious injury as a result of substandard vehicle handling, performance, engine, transmission and/or structural damage, serious damage to the vehicle, or loss of control.
Page 366 RX-8_8V89-EA-06F_Edition1 Page365 Friday, May 19 2006 9:53 AM GCW (Gross Combination Weight) is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combination Weight Rating) is the maximum allowable weight of the vehicle and the loaded trailer - including all cargo and passengers - that the vehicle can handle without risking damage.
Page 367 RX-8_8V89-EA-06F_Edition1 Page366 Friday, May 19 2006 9:53 AM Customer Information and Reporting Safety Defects Tire Information (U.S.A.) Exceeding GVWR or GAWR Specifications: Exceeding the GVWR or the GAWR specified on the certification label is dangerous. Exceeding any vehicle rating limitation could result in a serious accident, injury, or damage to the vehicle.
Page 368 RX-8_8V89-EA-06F_Edition1 Page367 Friday, May 19 2006 9:53 AM Steps for Determining the Correct Load Limit: Steps for Determining Correct Load Limit: (1) Locate the statement The combination weight of occupants and cargo should never exceed XXX kg or XXX lbs on your vehicle's placard. (2) Determine the combination weight of the driver and passengers that will be riding in your vehicle.
Page 369: Reporting Safety Defects
Administrator, NHTSA, 400 Seventh Street, SW., Washington, DC 20590. You can also obtain other information about motor vehicle safety from http:// www.safercar.gov. NOTE If you live in the U.S.A., all correspondence to Mazda Motor Corporation should be forwarded to: Mazda North American Operations 7755 Irvine Center Drive Irvine, California 92618-2922 P.O.
Page 370 RX-8_8V89-EA-06F_Edition1 Page369 Friday, May 19 2006 9:53 AM Reporting Safety Defects (Canada) Canadian customers who wish to report a safety-related defect to Transport Canada, Defect Investigations and Recalls, may telephone the toll free hotline 1-800-333-0510, or contact Transport Canada by mail at: Transport Canada, ASFAD, Place de Ville Tower C, 330 Sparks Street, Ottawa ON K1A 0N5.
Page 371: Service Publications
Factory-authorized Mazda service publications are available for owners who wish to do some of their own maintenance and repair. When requesting any of our publications through an Authorized Mazda Dealer, refer to the chart below. If they don't have what you need in stock, they can order it for you.
Page 372 RX-8_8V89-EA-06F_Edition1 Page371 Friday, May 19 2006 9:53 AM Specifications Technical information about your Mazda. Identification Numbers ... 10-2 Vehicle Information Labels ... 10-2 Specifications ... 10-4 Specifications ... 10-4 Form No.8V89-EA-06F Black plate (371,1) 10-1...
Page 373: Identification Numbers
RX-8_8V89-EA-06F_Edition1 Page372 Friday, May 19 2006 9:53 AM Identification Numbers Vehicle Information Labels qVehicle Identification Number The vehicle identification number legally identifies your vehicle. The number is on a plate attached to the left top side of the dashboard. This plate can easily be seen through the windshield.
Page 374 RX-8_8V89-EA-06F_Edition1 Page373 Friday, May 19 2006 9:53 AM qTire Pressure Label qEngine Number Forward Form No.8V89-EA-06F Black plate (373,1) Identification Numbers 10-3...
Page 375: Specifications
Quality Lubricant Engine oil Manual transmission oil Automatic transmission fluid Rear differential oil Brake/Clutch fluid * Not available from Mazda 10-4 Form No.8V89-EA-06F Specifications Model Rotary engine 654 ml × 2 (654 cc × 2, 40.0 cu in × 2) 10.0...
Page 376 RX-8_8V89-EA-06F_Edition1 Page375 Friday, May 19 2006 9:53 AM qCapacities (Approximate Quantities) Item With oil filter replacement Engine oil Without oil filter replacement Coolant Manual transmission oil Automatic transmission fluid Rear differential oil Fuel tank Check oil and fluid levels with dipsticks or reservoir gauges. qDimensions Item Overall length...
Page 377 NOTE The tires have been optimally matched with the chassis of your vehicle. When replacing tires, Mazda recommends that you replace tires of the same type originally fitted to your vehicle. For details, contact an Authorized Mazda Dealer. í...
Page 378 RX-8_8V89-EA-06F_Edition1 Page377 Friday, May 19 2006 9:53 AM Check the tire pressure label for tire size and inflation pressure. Refer to Tire Inflation Pressure on page 8-24. Tire size 225/55R16 94V 225/45R18 91W Vehicle capacity weight: 308 kg (680 lbs) qFuses Refer to the fuse rating on page 8-36.
Page 379 RX-8_8V89-EA-06F_Edition1 Page378 Friday, May 19 2006 9:53 AM Black plate (378,1) 10-8 Form No.8V89-EA-06F...
Page 380: Index
RX-8_8V89-EA-06F_Edition1 Page379 Friday, May 19 2006 9:53 AM Black plate (379,1) Index 11-1 Form No.8V89-EA-06F...
Page 381 RX-8_8V89-EA-06F_Edition1 Page380 Friday, May 19 2006 9:53 AM Index Accessory Socket ... 6-54 Add-On Non-Genuine Parts and Accessories ... 9-13 Advanced Key ... 3-2 Advanced key maintenance ... 3-5 Advanced key suspend function ... 3-17 Auxiliary key ... 3-16 Locking, unlocking with request switch ...
Page 382 RX-8_8V89-EA-06F_Edition1 Page381 Friday, May 19 2006 9:53 AM Child Restraint Child restraint precautions ... 2-19 Installing child-restraint systems ... 2-23 LATCH child-restraint systems ... 2-29 Cigarette Lighter ... 6-48 Climate Control System ... 6-2 Gas specifications ... 10-5 Clock ... 6-47 Coin Box ...
Page 383 RX-8_8V89-EA-06F_Edition1 Page382 Friday, May 19 2006 9:53 AM Index Front Seats (Manually Operated Seats) ... 2-2 Fuel Filler lid and cap ... 3-40 Gauge ... 5-37 Requirements ... 4-2 Tank capacity ... 10-5 Fuses ... 8-36 Panel description ... 8-38 Replacement ...
Page 384 RX-8_8V89-EA-06F_Edition1 Page383 Friday, May 19 2006 9:53 AM Lane-Change Signals ... 5-57 Light Bulbs Replacement ... 8-29 Specifications ... 10-6 Lighter ... 6-48 Lighting Control ... 5-55 Lubricant Quality ... 10-4 Maintenance Introduction ... 8-2 Owner maintenance precautions... 8-9 Owner maintenance schedule ... 8-8 Scheduled ...
Page 385 RX-8_8V89-EA-06F_Edition1 Page384 Friday, May 19 2006 9:53 AM Index Seats Front seat (Electrically operated seats) ... 2-5 Front seat (Manually operated seats) ... 2-2 Rear seat ... 2-8 Security System Immobilizer system (with advanced key) ... 3-45 Immobilizer system (without advanced key) ... 3-48 Service Publications ...
Page 386 RX-8_8V89-EA-06F_Edition1 Page385 Friday, May 19 2006 9:53 AM Warning Lights ... 5-39 ABS ... 5-41 Air bag system ... 5-44 Automatic transmission ... 5-46 Brake system ... 5-41 Charging system ... 5-42 Check engine ... 5-44 Door-ajar ... 5-46 Engine coolant level ... 5-43 Engine oil level ...
Page 387 RX-8_8V89-EA-06F_Edition1 Page386 Friday, May 19 2006 9:53 AM Black plate (386,1) 11-8 Form No.8V89-EA-06F...
Page 388: Before Use
NAVIGATION SYSTEM Preparation See page for specific information. Immediate use See page for specific information. Advanced use See page for specific information. If necessary See page for specific information. Before Use Getting started Routing Address Book Navigation Set Up necessary...
Page 389: Accessories
Accessories Please contact an Authorized Mazda Dealer if you are missing the following accessory. lMap Disc CAUTION: THIS PRODUCT IS A CLASS I LASER PRODUCT. HOWEVER THIS PRODUCT USES A VISIBLE/ INVISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF DIRECTED.
Page 390 MEMO...
Page 391: Contents
Contents Preparation Before Use Accessories... 2 Laser products: ... 2 Contents ... 4 Safety Information ... 6 Introduction ... 8 (Use This Product Safety), (Navigation System), (Screens) Names and Functions ... 10 Immediate use Getting started Activation... 12 (Removing the Map Disc), (Buttons on the screen) Screen Names and Functions...
Page 392 Advanced use Address Book Address Book ... 34 (Memory Point Storage), (Memory Point Confirmation and Modification), (Preset Destinations or Home storage), (Memory Point Deletion), (All Memory Point Deletion), (Displays Icons at Memory Points), (Avoid Area Storage), (Avoid Area Confirmation and Modification), (Avoid Area Deletion), (All Avoid Area Deletion), (Category Name Modification), (Previous Destination Deletion), (All Preset Destination Deletion)
Page 393: Safety Information
Expert dealer, we recommend an Authorized Mazda Dealer. Using the unit in an out-of-order condition may lead to accidents, fires, or electric shocks.
Page 394 The presence of this Caution symbol in the text is intended to alert you to the importance of heeding the operation Caution instructions. Failure to heed the instructions may result in injury Caution or material damage. Do not use the product where it is exposed to water, moisture, or dust. Exposure to water, moisture, or dust may lead to smoke, fire, or other damage to the unit.
Page 395: Introduction
If the system does not operate thereafter, consult an Authorized Dealer, we recommend an Authorized Mazda Dealer. This navigation system utilizes GPS* satellite signals, a speed sensor and gyrosensor to track and display your vehicle’s current position, and to guide you from your starting point to your...
Page 396 MEMO...
Page 397: Names And Functions
Names and Functions MENU key Displays menu. MENU page 15) VOICE key lInitiates vocal guidance for route VOICE maneuvers. lAdjusts screen quality. page 15)
Page 398 Joystick lSelects items ENTER by tilting it up, down, right, and left. lScrolls map. POS (Position) key Displays your current position. ZOOM key Changes the map scale. ZOOM page 16) ENTER key ENTER lExecutes a selected item. lDisplays pop up menu. RET key Returns to the previous screen.
Page 399: Activation
1 hour. Wipe the condensation off the map disc with a soft cloth. If the unit does not operate correctly after 1 hour, consult an Authorized Mazda Dealer. (CAUTION) screen TILT TILT...
Page 400 Read CAUTION carefully, and select and press ENTER lThe Current Position screen appears. Note lYou can select the language by select selected language using Language Selection. ( lThe CAUTION screen remains on the display unless you select Removing the Map Disc When the ignition switch is in the ACC position and press EJECT Buttons on the screen...
Page 401: Screen Names And Functions
Screen Names and Functions Screens Before Setting Route ENTER (1) Map Orientation control page 16) (2) GPS (Global Positioning System) marker page 50) (3) Clock Clock will be displayed when you set up Clock on Navigation Set Up On. (4) Vehicle marker Shows the current position and direction of your vehicle.
Page 402 Menu appears when pressing Screen adjustments and settings Display Menu screen will be shown when you press Note Display Menu screen will be disappeared when they have been unused during a few seconds. Adjusting the screen quality lAdjusts the screen brightness Select "ADJ", and then "BRIGHT".
Page 403: Screen Change
Screen change Do not keep your eyes fixed on the monitor screen or operate the system while driving Do not change the settings and destination locations while driving. Minimize the time Warning spent viewing the monitor screen and listening to the voice guidance while driving. Operating the system will distract the driver from looking ahead of the vehicle and may cause an accident.
Page 404 MEMO...
Page 405: Destination Entry And Route Search
Destination Entry and Route Search lYou can set the destination using various methods provided by the system. Before Steps MENU Open the [DESTINATION ENTRY] Menu Change (Change Search Area) Open the [DESTINATION ENTRY] Menu Address select ENTER Select Select When narrowing down to city name Select When narrowing...
Page 406 Warnings Select the desired Search Area : ID, OR, WA, : CA, NV : AZ, CO, MT, NM, UT, WY : IA, KS, MN, MO, ND, NE, SD : OK, TX : IL, IN, KY, MI, OH, WI narrowing to city name Cancel the city selection.
Page 407 Destination Entry and Route Search Open the [DESTINATION ENTRY] Menu Point of interest When entering Select the destination point directly Select When narrowing down to city name Select When narrowing down to category name Select When narrowing down to the nearest facility Select When narrowing...
Page 408 elect own to city Cancel the city selection. elect Displays list of 5 city names nearest the current position. Displays the city name input screen. Select the category own to category name from the list elect own to the for facilities close to the earest facility nearest city hall.
Page 409 Destination Entry and Route Search Select Emergency When stopped Displays the police station select screen. Displays the hospital select screen. When driving Sets the destination to the nearest police station automatically. Sets the destination to the nearest hospital automatically. Select the so : Sorts the the hospital by D : Sorts the...
Page 410 Select the sort methods Select the name from : Sorts the police station or the list the hospital by Distance. : Sorts the police station or the hospital by name. Select...
Page 411 Destination Entry and Route Search Before Steps MENU Open the [DESTINATION Memory Point ENTRY] Menu Home Preset Destination Previous Destination Intersection Freeway On/ Off Ramp Coordinates Select from select ENTER Select Select Select Select Select Select Select Select Select the desi Select the Prev Enter/Select th 1st street name...
Page 412 Select the desired Memory Point : Display up to five previous suggestions. : Display the five previous suggestions. : The order of the displayed list can be changed. Select the desired Preset Destination. Select the Previous Destination. Enter/Select the Enter/Select the 2nd 1st street name street name Enter/Select the...
Page 413: Quick Poi
Quick POI lYou can select one of the Six Categories on the menu or List Categories and then select the POI(s) to be displayed on the map. Before Steps ENTER Open the [QUICK POI] Displaying POI(s) on a Local Search Deleting Markers Displaying POI(s) on a Map (...
Page 414: Character Entry
Character Entry Select the first several characters on the screen. (Step 1) Select To enter the street name, city name, and : Move the cursor to the previous other. position and delete a character. : The list appears. Examples Street: CANAL Enter by selecting characters: Street: MAIN STREET Enter by selecting characters:...
Page 415: Direct Destination Input
Direct Destination Input Direct Destination Input Operate after Step 3 of [Direct Destination Input] Selecting Route Position the ENTER cursor on your destination on the map Scroll the map and change the map scale if necessary. ENTER Select ENTER Select Route calculation will be carried out and the entire route will be displayed on the map.
Page 416: Poi Icons On Maps / Delete Destination
POI Icons on Maps / Delete Destination POI (Point of Interest) Icons The following are POI icons shown on maps. Restaurant All restaurants American Chinese Continental Fast Food French Italian Japanese Mexican Seafood Thai Other Restaurants Shopping Grocery Store Shopping Mall Automotive Automobile Club Gas Station...
Page 417: Route Options
Route Options Before Steps MENU Open the [ROUTE OPTIONS] Menu Route Preferences Modification Destination or Way Point Positions Deletion of Destination or Way Points Detour Turn List lDuring route guidance you can change the route options, stop or check the route. select ENTER Select...
Page 418 Warning Select roads, major roads, and ferry and restricted roads. The route will not necessarily follow the specified conditions. Select (Change Location). Shows the map for the destination/way points. Select Searches the detour routes at one, three, and five miles from the present position to the selected routes.
Page 419 Route Options Before Steps MENU Open the [ROUTE OPTIONS] Menu Display Preview Route Preview select ENTER Select ENTER Select Use the button : Move the s : Carry out a be displaye : Stop the s : Carry out a be displaye : Move to th : Displays th...
Page 420 Use the buttons displayed on-screen to carry out a simulation run. : Move the start point. : Carry out a simulation run in the direction of the start point. When the Simulation starts the button will be displayed as , and when selected, it will cause the Simulation to advance quickly. : Stop the simulation run.
Page 421: Address Book
Address Book Before Steps MENU Open the Memory Point [ADDRESS Storage BOOK] Memory Point Confirmation Modification Preset Destinations or Home storage Memory Point Deletion All Memory Point Deletion Displays Icons at Memory Points lYou can, edit, or delete any marked point. select ENTER Select...
Page 422 Set a memory point using your preferred method. Select a memory point to be modified Select a memory point to be stored in Preset Destinations or Home. Select a memory point to be deleted. : Cancel the deletion. : Allows the display icon to be selected.
Page 423: (Category Name Modification), (Previous Destination Deletion)
Address Book Before Steps MENU Open the Avoid Area [ADDRESS Storage BOOK] Avoid Area Confirmation Modification Avoid Area Deletion All Avoid Area Deletion Category Name Modification Previous Destination Deletion All Preset Destination Deletion select ENTER Select Select...
Page 424 : Changes the detour position Select an avoid : Reduces the size of the area using your avoid area. preferred method. : Increases the size of the avoid area. Select an avoid area : Allows the name to be to be modified. changed.
Page 425: Volume Adjustment
Volume Adjustment You can adjust the volume control for the voice guidance. Before Steps MENU Open the [VOLUME] screen select ENTER Select the appropriate button to set the volume between (minimum) and (maximum). :Sound output will be muted. Press the button to return to the current vehicle position screen.
Page 426 MEMO...
Page 427: Navigation Set Up
Navigation Set Up lYou can alter the map display conditions, the route guidance conditions and show the system information. Stop your vehicle before the following operations. Do not change the settings and destination locations while driving. Minimize the time spent viewing the monitor screen and listening to the voice guidance while driving. Warning Operating the system will distract the driver from looking ahead of the vehicle and may cause an accident.
Page 428 Navigation Set Up MENU ENTER Before Steps select ENTER Open the [USER SETTINGS] screen User Setting select ENTER Map Color Select a screen color from Map Mode Auto : The display will automatically switch between Day and Night illumination mode when the headlights are turned off and on respectively.
Page 429 Navigation Set Up MENU Before Steps ENTER Open the [USER SETTINGS] screen select ENTER select Arrival Time The time which is displayed until reaching the destination or a way point can be set as an estimated arrival time or the remaining time.
Page 430 Navigation Set Up This function allows you set the categories on the area displayed when the (Point of Interest) menu is selected on the map. Quick POI enables you store up to six different kinds of categories which you use most regularly. select MENU ENTER...
Page 431 Navigation Set Up This function allows you to correct any error in the position or direction of your vehicle display. Before Steps MENU ENTER Adjusting Current Position and Direction select ENTER Open the [Calibrate Position] screen Move select Distance This function automatically corrects any error in the display of the current position that might occur after tire replacement.
Page 432 Set Clock The current time is set using this function. Since time notification is provided by a GPS satellite. ENTER Open the [SET CLOCK] screen Note Minutes are adjusted by the GPS, however, it is necessary to adjust hours under the following conditions: lDriving across different time zones lDaylight saving time start and end Map Version...
Page 433 Navigation Set Up This function replaces all the settings in the mobile navigation system with the initial default settings. MENU Before Steps ENTER Open the [SYSTEM DEFAULTS] screen If you execute Restore System Defaults, all of your stored setting data will be deleted. [Default List] Item Menu names...
Page 434 Navigation Set Up Language You can change the language of the menu and the voice guidance. select MENU ENTER ENTER Before Steps select ENTER ENTER Open the [LANGUAGE] screen Select your preferred language from the list.
Page 435: Map Screen
Navigation Set Up MENU Before Steps ENTER Open the [MAP CONFIGURATION] screen Map Configuration select ENTER select Map Screen Select single or dual map display. Dual map Single map Turn Guidance Enlarged Junction Diagram Before a fork in the road, an enlarged diagram of the junction automatically appears in a second screen.This is to make route guidance even clearer.
Page 436: Precautions/System Performance
Precautions/System Performance The navigation system is just a support system for the driver. The driver should always pay attention to the traffic situation to safely make decisions. You may be unable at times to arrive at your destination due to out-of-date information Warnings on a map disc.
Page 437: Map Matching
lIf you are using the system for the first time, or if you have not used it for some time, it takes about 5 minutes (or about 2 minutes in open areas) to calculate your vehicle’s position. GPS signal reception is poor in the following places In tunnels Among high-rise buildings Under elevated roads lThe GPS satellites are controlled by the U.S.
Page 438 Precautions/System Performance Positioning Accuracy In the following situations, your vehicle position may not be displayed correctly on the map. But, as you keep driving, your vehicle position will be automatically corrected utilizing map matching and GPS data. Running on an Making a turn after elevated road driving on a long...
Page 439 The navigation system is just a support system for the driver. The driver should always pay attention to the traffic situation to safely make decisions. You may be unable to arrive at your destination due to out-of-date information on a map disc. You should be especially careful Warning when selecting an urgent destination such as a hospital or a police station.
Page 440: Troubleshooting
There may be some problems due to operational errors or mistakes. Please read this manual again and verify that there really is a problem before calling an Expert Dealer, we recommend an Authorized Mazda Dealer to ask for repair services. Symptom No picture lCheck if a fuse has blown.
Page 441 Symptom No GPS symbols are displayed The vehicle position is not displayed No voice guidance Buttons on the remote control do not beep Check point lGPS signals may not be received because of obstructions. After moving the vehicle away from obstructions, the GPS signals can be received.
Page 442 Troubleshooting Error message lThe disc is not installed. Please insert a Check if the disk is installed. If installed, check if the MAP DVD. installed disk is correct. MAP DVD-Read Error lThe disc is wet, dirty, scratched, or upside down, or the disc cannot be played with this unit or the incorrect disk is installed.
Page 443: Maintenance
Never use solvents such as benzene and thinners, they could mar the surface of the unit. Map disc If you require the latest map disc, consult an Expert Dealer, we recommend an Authorized Mazda Dealer. Handling and Care of Map Discs How to hold the disc lDo not touch the underside of the disc.
