Autani A05-02-1107-02 Quick Installation Sheet

EnOcean Temperature Sensor
Quick Installation Sheet
2

Installation

Handle the sensor housing
gently while dismantling the
sensor to avoid damaging
internal parts.
Use a 1/16" Allen Wrench to
removing the screws from the
bottom of the sensor housing.
Slightly open the bottom of the
sensor housing and then slide
up to disconnect from the top
of the base plate.
Autani, LLC | 7090 Columbia Gateway Drive, Suite 140
Copyright Autani, LLC 2020. All rights reserved. For warranty and other legal information, go to www.autani.com/legal.
Dismantle
Bo om
Conec on
Sensor
Housing
Screw
Allen Wrench
| Columbia, MD 21046 USA
Document Number : 80287 | March 2020
Color versions available @ autani.com
1
On the provided list of device serial numbers,
document the location for each Sensor.
sn:auxxxxxxxxx
EXAMPLE EXAMPLE
Moun ng
Hole
Base
Plate
S c r
e w
Moun ng Hole
Base Plate
| (443) 320-2233 | www.autani.com
Moun ng
L L
W A
Continued.....
