Bush Hog
®
2446QT Quick Attach Front-Push Loaders
Bush Hog Quick Attach System
BUSH HOG
TOUGH FeATUreS
®
TOUGH Boxed Boom Design
TOUGH Large Diameter Cross Tubes
TOUGH robotic Welds
TOUGH High Strength Chrome Plated
Cylinder rods
TOUGH Bush Hog Made Buckets
TOUGH Powder Coat Paint
Specifications Based on 1997 ASAE STANDARDS
MODeL
Tractor PTO HP range
2WD/FWA
Maximum Lift Height - Measured at Pivot Pin
Maximum Lift Height - Under Level Bucket
Maximum Dump Angle
Digging Depth
Lift Capacity to Maximum Height - At Pivot Pin
Lift Capacity to Maximum Height - 31.5 inches Forward of Pivot Pin
Lift Capacity to 59 inch Height - At Pivot Pin
Lift Capacity to 59 inch Height - 31.5 inches Forward of Pivot Pin
Breakout Force - At Pivot Pin
Breakout Force - 31.5 inches- Forward of Pivot Pin
rollback Force at Maximum Height - 31.5 inches Forward of Pivot Pin
rollback Force at 59 inch Height - 31.5 inches Forward of Pivot Pin
rollback Force at Ground Level - 31.5 inches Forward of Pivot Pin
raising Time (Ground Level to Full Height)
Lowering Time (Full Height to Ground Level)
Bucket Dumping Time (Full Rollback to Full Dump)
Bucket rollback Time (Full Dump to Full Rollback)
Hydraulics
Two 2.25 inch Bore, 22.81 inch Stroke Double Acting Bucket Cylinders and Two 2.25 inch Bore, 23.19 inch Stroke Double Acting Lift Cylinders
Specifications Based on Tractor System of
Bush Hog Quick Attach Buckets
Bush Hog Quick Attach Heavy Duty Buckets
Options
Warranty
FeATUreS
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
TOUGH
2450 PSI hyd. Pressure & 11 GPM pump capacity
Forklift Attachment (42 inch tines), Round Bale Spear, Grapple Fork, Bucket Tine Teeth,
Bolt-On Digging Teeth, Side Cutting Edges, Spill Guard Attachment, Hydraulic Self-Leveling, and Grill Guards
2446QT
35 - 75
2WD/FWA
117 inches
108 inches
50°
4.5 inches
2870 lbs
1985 lbs
3220 lbs
2390 lbs
3955 lbs
2940 lbs
3155 lbs
3880 lbs
3015 lbs
4 seconds
3 seconds
4 seconds
2.5 seconds
Available in 60, 72 and 80 inch widths
Available in 60, 72 and 84 inch widths
1 year limited warranty
Available in major tractor colors
