- Page 1 720P WiFi IP camera Outdoor ref. 123981 ref. 123981 720p 720p •REC •REC (Not included) (Not included) 2.4GHz 2.4GHz www.avidsen.com...
-
Page 2: Table Of Contents
720P WIFI IP CAMERA CONTENTS A - SAFETY INSTRUCTIONS 1 - OPERATING PRECAUTIONS 2 - MAINTENANCE AND CLEANING 3 - RECYCLING B - PRODUCT DESCRIPTION 1 - KIT CONTENTS 2 - CAMERA 3 - MAINS ADAPTOR C - INSTALLATION 1 - INSTALLING THE CAMERA 2 - INSERTING A MICRO SD CARD (NOT INCLUDED) 3 - CONNECTING THE CAMERA D - CONFIGURATION... - Page 3 720P WIFI IP CAMERA F - RESETTING G - FAQ H - TECHNICAL AND LEGAL INFORMATION 1 - TECHNICAL CHARACTERISTICS 2 - WARRANTY 3 - HELP AND ADVICE 4 - PRODUCT RETURNS/AFTER SALES SERVICE 5 - EC DECLARATION OF CONFORMITY...
-
Page 5: A - Safety Instructions
720P WIFI IP CAMERA A - SAFETY INSTRUCTIONS 1 - OPERATING PRECAUTIONS 3 - RECYCLING • The cameras must not be installed where the This logo denotes that devices which are lens filter may be vulnerable to scratching and no longer in use must not be disposed of dirt. -
Page 6: B - Product Description
720P WIFI IP CAMERA B - PRODUCT DESCRIPTION 1 - CONTENTS OF THE KIT Camera Wall plugs for wall-mounting 230V A/C 50 Hz mains adaptor / Screws for wall-mounting 12V DC/1A Antenna to be screwed to rear of camera 2 - CAMERA... -
Page 7: Mains Adaptor
720P WIFI IP CAMERA B - PRODUCT DESCRIPTION QRCode to be scanned when starting up using the Protect-Home app Slot cover for microSD card (not included) of up to 128GB Loudspeaker grid Positioning of microphone (on the rear side) Adjustable base (all positions may be locked/unlocked with the Allen key supplied) RJ45 socket for network connection (optional use) Mains adaptor power supply (included) Reset button... -
Page 8: C - Installation
720P WIFI IP CAMERA C - INSTALLATION 1 - INSTALLING THE CAMERA • The camera can be attached to either wall or ceiling. • Mount the camera using suitable screws and wall plugs for the type of surface (the screws and plugs supplied are suitable for solid walls). -
Page 9: Connecting The Camera
720P WIFI IP CAMERA C - INSTALLATION • Please insert the microSD card Note: These operations must be carried out with the camera disconnected from the mains power supply. 3 - CONNECTING THE CAMERA... -
Page 10: D - Configuration
720P WIFI IP CAMERA D - CONFIGURATION 1 - CONFIGURING THE CAMERA AND started up. It plays a standby tune when it is ready. ADDING IT TO THE APP Click on “Ready music played” to continue. Note: the screenshots displayed have been taken from the Android version of the Protect-Home app. -
Page 11: Access To All Settings
720P WIFI IP CAMERA D - CONFIGURATION few seconds, once the camera has managed to join the network indicated by your smartphone, the camera plays a tune. When your smartphone detects the presence of your camera on the network, it asks you which time zone it should use: The time indicated is inset in the video recordings made by the camera. -
Page 12: Configuration
720P WIFI IP CAMERA D - CONFIGURATION It is easier if you rename your camera here after pairing Change of camera access password, which changes when the camera is started up MicroSD card management (not included) and formatting Movement detection management: starting/stopping the recording on the microSD card when a movement is detected... -
Page 13: E - Operation
720P WIFI IP CAMERA E - OPERATION 1 - LIVE VIDEO Simultaneous display of up to 4 cameras Smartphone microphone activation to speak From the list of cameras (home screen of the app through the camera’s speaker after start-up), click on the image or name of your Start/stop of video recording (recording onto camera to display the live video: smartphone memory) - Page 14 720P WIFI IP CAMERA E - OPERATION When a recorded video is viewed, it appears instead of the live image Review start/stop On/off of sound on recorded video Taking an immediate photo of the recording being viewed (saved to the smartphone memory) Start/stop of video recording saved to the smartphone memory for the video recording...
-
Page 15: F - Resetting
720P WIFI IP CAMERA F - RESETTING If there is a problem, the WiFi configuration may be reset by pressing and holding the Reset button on the cable until a beep is heard. Once reset, the camera will start up again. After 30 seconds, it is available for reconfiguration. -
Page 16: G - Faq
720P WIFI IP CAMERA G - FAQ Symptoms Possible causes Solutions Please contact the technical You have an out-of-date or support of your device's incompatible version of Android manufacturer in order to obtain a on your device recent Android version Unable to install the Protect- Google Play checks all the key Home app... -
Page 17: H - Technical And Legal Information
720P WIFI IP CAMERA H - TECHNICAL AND LEGAL INFORMATION 1 - TECHNICAL CHARACTERISTICS Camera 12V DC/1A Power supply WiFi IEEE 802.11 b/g/n 2.4Ghz Compatible WPA/WPA2 Network interface RJ45 Ethernet 10/100Mbps Optical sensor ¼’’ CMOS Minimum luminous intensity 0 lux Automatic (dusk-to-dawn sensor) Night vision Range: 25m... -
Page 18: Warranty
The warranty will be void if the device is tampered http://sav.avidsen.com with. Avidsen undertakes to keep a stock of spare parts 3 - HELP AND SUGGESTIONS for this product throughout the contractual warranty period. • If, in spite of the care we have taken in designing... - Page 20 SmartHome France 19 avenue Marcel Dassault ZAC des Deux Lions - 37200 Tours - France...
