Summary of Contents for ANEMOI AIRWALL
- Page 1 AIRWALL Installation Manual Issued March 2020 ANIM13CI Rev. C...
- Page 2 06 / 09 / 2019 Control Box up to 6 ud 16 / 03 / 2020 Update 2020 product Technical documents are regularly updated. Anemoi reserves the right to modify the contents of this manual, in full or in part, without warning.
-
Page 3: Table Of Contents
AIRWALL TABLE OF CONTENTS SAFETY .................................. 4 INTRODUCTION ............................5 TECHNICAL CHARACTERISTICS ....................... 6 DELIVERY ..............................7 Package Dimensions & Weight ......................7 Packing list ............................7 MECHANICAL INSTALLATION ........................8 Wall aperture measurements ......................... 9 Control box installation ........................10 ELECTRICAL INSTALLATION ........................ -
Page 4: Safety
AIRWALL SAFETY Before the installation, read the following warning and caution instructions: WARNING! Do NOT install, repair or clean the fan while it is in operation or connected to the power supply. Failure to do so may result in serious injury or death. -
Page 5: Introduction
1 INTRODUCTION The Anemoi AIRWALL fan has been designed to extract a large volume of air from the interior to the exterior of buildings. This fan is used to increase comfort, drawing hot air from inside buildings to the outside, allowing air renewal and extraction of stale indoor air. -
Page 6: Technical Characteristics
AIRWALL 2 TECHNICAL CHARACTERISTICS AIRWALL 100 AIRWALL 120 AIRWALL 150 GENERAL CHARACTERISTICS Diameter 0.95m 1.27m 1.43m Blades number Standard colour Galvanized steel MOTOR CHARACTERISTICS Motor power 0.73 kW 1 kW 1.2 kW 200VAC ~ 240VAC I, 50/60 Hz Supply Voltage... -
Page 7: Delivery
AIRWALL 3 DELIVERY The Anemoi AIRWALL fan is delivered completely assembled and packed in a single package. Handle the product carefully using appropriate lifting mechanisms to avoid possible damage. CAUTION! Use proper lifting equipment to handle the fan box. Otherwise, the fan could be damaged and there is risk of accident. -
Page 8: Mechanical Installation
The Anemoi AIRWALL fan has been designed for wall installation. Hollow, pre-frame and facade frame must be made to install the fan. The wall and frame must be sufficiently supportive to support the weight of the fan and fix it properly to avoid overturning. -
Page 9: Wall Aperture Measurements
4.1 Wall aperture measurements The frame and pre-frame measurements to be carried out for the correct assembly of the AIRWALL are established. These measures already include 1cm of security on each side that allow clearance for the correct placement of the fan. -
Page 10: Control Box Installation
4.2 Control box installation The Anemoi AIRBEAM is controlled by a very intuitive screen installed in the control box. The control box is designed to be screwed to the wall. For these purposes, the box has four holes in the corners. The measurements... -
Page 11: Electrical Installation
Install the control box at a distance less than 20m from the fan. Failure to do so the power supply of the equipment may be insufficient The Anemoi AIRWALL motor is controlled by an external control panel. To ensure the fan operation, the control box must be connected to the fan and the power supply. -
Page 12: Box Control
Motor Output Line 5.2 Modbus control (optional) The Anemoi AIRWALL fan can be controlled by external controller using modbus connexion, please see the Modbus Configuration Parameters document provided by Anemoi. The external control is connected direcly to the fan board using shielded cable type modbus RS485 2x2x0.50 mm² POSCY. -
Page 13: Multiple Fan Installation
AIRWALL 5.2.1 Multiple Fan Installation In installations with multiple fans, it is possible to control the fans using a single controller. In this case, the controller is connected to the different by using control connections A, B and GND. The following figure shows the detail of the control connectors: WARNING! The earth meshes of each cable section must remain together. -
Page 14: Recommendations
AIRWALL Recommendations 5.2.2 To ensure correct installation and functioning of the Modbus control fan, please keep in mind following recommendations: 1- Please strip the wire 5cm as a maximum as shown below: 2- Communication cables cannot be wound. If it were done, they could act as an antenna. Communication cables that are not used have to be cut and left inside the shielded tube as shown below. -
Page 15: Operation
AIRWALL 6 OPERATION Once the fan is powered, follow the next steps to start the fan: 1- Change the main switch placed on the side of the control box to the start position. 2- Check the status of the fan on the data display, as shown in table. -
Page 16: Basic Operations
AIRWALL 7 BASIC OPERATIONS The Anemoi AIRWALL fans have an external controller that allows to temporize and regulate the power of the fan. 7.1 Operating panel Control Panel Speed adjustment Settings Switch On/Off 7.2 The data display DISPLAY NAME FUNCTION... -
Page 17: Fault Diagnosis
AIRWALL 8 FAULT DIAGNOSIS In case of failure, refer to the following table for quick solutions: DISPLAY CODE PROBABLE CAUSE INSPECTION METHOD Unplug the fan from the power for 10s. E-STALL Blocked Restart. Check input voltage less than 282V. E-OV Voltage above level Check power connections. -
Page 18: Maintenance
AIRWALL 9 MAINTENANCE WARNING! Do NOT repair or clean the fan while it is in operation or connected to the power supply. Doing so may result in serious or fatal electrical shock. Please maintain the fan as follows: Every three months: •... - Page 19 www.anemoifans.com...
