- Page 1 Digital Weighing Indicator User Manual WWW.DEELAT.COM...
-
Page 2: Main Specification
User Manual Digital Weighing Indicator Digital Weighing Indicator Contents Main Specification Main Specification Model Deelat Floor Scale weighing indicator Installation Accuracy GradeIII, n=3000 Front and Back View of the Indicator Sample Rate 10 times / second A/D conversion: Δ -∑... -
Page 3: Installation
UserManual User Manual Digital Weighing Indicator Digital Weighing Indicator Key Functions Installation Keep pressing this button for 5 seconds more in weighing mode, it will Front and Back View of the Indicator FUNC come into operator setting mode; less than 5 seconds, it will come into counting mode. -
Page 4: Operation
UserManual User Manual Digital Weighing Indicator Digital Weighing Indicator Connecting Load Cell to Indicator Operation The 5-pin (2.54MM) socket is used to connect to the load cell, as indicated in the graph below. Power On and Zero Auto Please Note: Pin 1 EX+; Pin 2 EX-; Pin 3 SHIELD; Pin 4 IN+; Pin 5: In- The indicator will perform “999999-000000”... - Page 5 UserManual User Manual Digital Weighing Indicator Digital Weighing Indicator Counting RS232 output mode option X=1: No transmission (RS232 stop) In weighing mode, press [Func] to enter into the counting state. It will display “count”, and pressing the X=2: Continuous transmission [*] key will display “C00000”.
- Page 6 UserManual User Manual Digital Weighing Indicator Digital Weighing Indicator Communication mode as follows: Digital filtering intensity X=1: high In continuous mode: X=2: medium The data transmitted is weight (Gross weight or net weight) X=3: The format of G.W.: ww000.000kg or ww000.000lb The format of N.W: wn000.000kg or wn000.000lb Stable time Note:The position of above decimal is decided by the decimal set on the indicator.
-
Page 7: Error Indication
UserManual User Manual Digital Weighing Indicator Digital Weighing Indicator Fast calibration for full range point: Calibration Fast calibration for full range point: At any point before it shows [AdLOAD], press [ACCU] and it will keep the original division, decimal point, full range, zero point calibration and enter into the full range Connect the load cell properly and then turn on the indicator and press the [#] key during initial- point calibration mode. -
Page 8: Maintenance
UserManual User Manual Digital Weighing Indicator Digital Weighing Indicator Maintenance Notes To ensure proper function of the indicator, it should not be placed directly under sunshine and should be placed in a well ventilated space. The indicator should not be installed in a place with severe dust or where vibrations are present The Load cell requires a solid connection with the indicator, and the system should always be grounded. - Page 9 WWW.DEELAT.COM...
