Summary of Contents for AVYCON Control4
- Page 1 Control4 Composer Software MANUAL...
- Page 2 Introduction Thank you for using our network camera products. Our network camera products are integrated and developed for network video monitoring, including Storage Network Bullet, Wireless Storage Network Bullet, IR Network Dome, IR Network Weather-Proof Cameras and High-Speed Network Ball. High-performance single SOC chips are used in media processor for audio/video acquisition, compression and transmission/transfer.
- Page 3 Instruction Necessary steps: 1. Installer Control4 Composer 2.10.6 2. Copy our driver file to “C:\Users\8590\Documents\Control4\Drivers” 8590 is the user name, please select your own user name accordingly. 3. Run Control4 Composer, and select Local System in the menu.
- Page 4 Composer Software User Manual 4. In the following window, it will display all Control4 devices being found in same LAN. 5. Select your device, click ”Connect”, or double click on the device, you will connect successfully.
- Page 5 Composer Software User Manual 6. Following step is adding our recorder. On the right of the interface, in “Items” -”Search”, type “AVYCON” in the seach bar, then you will find the right driver as below:...
- Page 6 Composer Software User Manual 7. Select “AVYCON_RECORDER”, and double click, you can add our AVYCON recorder successfully. 8. Rename the camera, set appropriate IP address, port, UID/PSW, etc.
- Page 7 Composer Software User Manual 9. If you can not get right device info listed with above method, please right click on your recorder, select “Update Driver” to update your driver. Select driver location“C:\Users\8590\Documents\Control4\Drivers” to choose the driver file “recorder_AVYCON.c4z”.
- Page 8 Composer Software User Manual 10. Input the right IP address, port, UID/PSW, Control4 should be able to connect to our camera now, and show our device parameters, FW version, model number in “Advanced Properties”. 11. Switch channels: In drop down arrow of Channel list, it includes all online channel No., click ”set”, in other drop down menu or text box, they will show current...
- Page 9 Composer Software User Manual 12. Change parameter settings on current channels: like frame rate for main stream, Under “MainStreamFPS” menu, click “Up” or “Down”arrow to adjust the value, click ”Set” to save. Other parameters can be changed in the same way. 13. Live preview: Please follow step 11 to select right channel first，then change “Video Mode”...
- Page 10 Composer Software User Manual You can find stream type is mainstream already, click “test” you to see if you can get the right stream.
- Page 11 Composer Software User Manual If you find that “Your GStreamer installation is missing a plug-in”, that is because Control4 support H264 only. If your encoding format is in H.265, please change your encoding format to H264 and test again.
- Page 12 Composer Software User Manual At this time, double click the recorder in the list, you will get live video pop up as below: It is defaulted to snapshot status, change “Image View” to “H264”, then you can change to live preview mode. 14.
- Page 13 Composer Software User Manual Change stream type in playback, please follow step 13. If “Test failure”, that is maybe during that period, there is no recording data for that channel, or maybe the encoding format is in H265.
- Page 14 Composer Software User Manual 16. AVYCON recorder driver is communicating via API protocol, so before connecting to our recorder, please enter device GUI, and enable API server first, which is under network settings, below “port” menu. The authentication method is BASIC.
- Page 15 Composer Software User Manual Scan the following QR Code with your smart phone to visit our website and learn more. AVYCON 16682 Millikan Ave Irvine, CA 92606 Email: info@avycon.com Website: avycon.com Tel: 949-752-7606 Toll Free: 888-8334611 (Canada) Fax: 949-250-7076...
- Page 16 Copyright © AVYCON. All rights reserved. Specifications and pricing are subject to change without notice. phone: 949-752-7606 email: info@avycon.com social: @avycon_aivo website: avycon.com...
