JAR Systems QC-8000 Manual

Universal usb-c charging dock
Hide thumbs
1
2

Advertisement

Table of Contents

UNIVERSAL USB-C CHARGING DOCK
FEATURING QUICK-SENSE CHARGING TECHNOLOGY

SETUP

1
Insert dividers into slots on the top of the dock.
3
Plug the USB-C to USB-C charging cables that come
with the charging dock into the charging ports.

START CHARGING!

Plug the power cable into a standard 15A outlet. LEDs will illuminate white to indicate the dock is connected to a
power source. Connect USB-C devices with supplied charging cables. LEDs will cycle between white, blue, and green
according to the level of current being drawn by the device. Refer to the device itself for the level of charge.
Connecting Devices Without a USB-C Port: Devices that do not feature a USB-C charging port can be charged with
the Universal USB-C dock using USB-C PD emulator cables available from JAR Systems.
IMPORTANT! Only connect laptops, Chromebooks, tablets, cell phones, and approved mobile devices. Connecting
incompatible devices will void all warranties. Always observe the warnings on the back side of this manual.
For additional assistance, contact JAR Systems. 866.393.4202 | www.JAR-Systems.com/Support
2
Push dividers backward to lock in place.
4
LEDs
Charging Ports
Lift the dock up to view the underside. Connect the
power cable to the back of the charger.
Model: QC-8000 Manual Version B
(Not Included)
