- Page 1 Installation and Operating Guide Document No. 1788-48 WhisperFlow® Portable HEPA Filtration System © Copyright 2021 Terra Universal Inc. All rights reserved. Terra Universal, Inc. • TerraUniversal.com • 800 S. Raymond Ave. • Fullerton, CA 92831 • TEL: (714) 578-6000 • FAX: (714) 578-6020...
-
Page 2: Table Of Contents
Installation and Operating Guide WhisperFlow® Portable Filtration System © Copyright 2021 Terra Universal Inc. All rights reserved. • Document No. 1788-48 Table of Contents SAFETY ................................3 GENERAL INFORMATION ..........................4 OPERATION ..............................5 PECIFICATIONS ............................... 6 ILTER ............................... 6 MAINTENANCE ............................... -
Page 3: Safety
Installation and Operating Guide WhisperFlow® Portable Filtration System © Copyright 2021 Terra Universal Inc. All rights reserved. • Document No. 1788-48 1. Safety Proprietary Notice Safety Notice This manual pertains to proprietary devices manufactured by A thorough familiarity with all operating guidelines is essential to safe operation of Terra Universal, Inc. -
Page 4: General Information
© Copyright 2021 Terra Universal Inc. All rights reserved. • Document No. 1788-48 2. General Information The WhisperFlow® portable HEPA filtration system is a mobile, self-contained, hospital-grade air purifier designed to easily convert any room to a negative pressure isolation room to meet OSHA and CDC TB guidelines. This medical grade air filtration system can be configured for either recirculation or exhaust. -
Page 5: Operation
Installation and Operating Guide WhisperFlow® Portable Filtration System © Copyright 2021 Terra Universal Inc. All rights reserved. • Document No. 1788-48 3. Operation For installation, plug in the portable HEPA filter system into a power receptacle. The HEPA filter is 99.97% efficient at 0.3µm particle diameter. -
Page 6: Specifications
50/60 3.2 Fan Filter Unit The Smart® WhisperFlow® has an electronically commutated (EC) brushless motor that allows for quiet, energy- efficient operation and infinitely variable speed control. The wide range is ideal for applications involving high static pressure. This unit includes an internal microprocessor that can be incorporated into Building Management Systems (BMS) to allow remote monitoring and control. -
Page 7: Maintenance
Installation and Operating Guide WhisperFlow® Portable Filtration System © Copyright 2021 Terra Universal Inc. All rights reserved. • Document No. 1788-48 4. Maintenance 4.1 Filter Replacement Step 1: Remove the screws from the body and the back panel. Step 2: Remove the back panel from the body. - Page 8 Installation and Operating Guide WhisperFlow® Portable Filtration System © Copyright 2021 Terra Universal Inc. All rights reserved. • Document No. 1788-48 Step 3: Remove the screws from the clip holding the fan filter unit in place. Step 4: Remove the clip from the holder.
- Page 9 Installation and Operating Guide WhisperFlow® Portable Filtration System © Copyright 2021 Terra Universal Inc. All rights reserved. • Document No. 1788-48 Step 5: Remove the FFU from the unit. Step 6: Remove the screws from the FFU housing and filter.
- Page 10 Installation and Operating Guide WhisperFlow® Portable Filtration System © Copyright 2021 Terra Universal Inc. All rights reserved. • Document No. 1788-48 Step 7: Remove the filter from the housing and replace it with the new filter.
-
Page 11: Trouble Shooting
Adjust the fan speed to a lower output. 6. Testing WhisperFlow® fan filter units are thoroughly tested at the factory before shipment. All filters are tested with properly calibrated equipment to IEST-RP-00034 and all filters are UL 900 recognized. However, because of the rigors of shipping, Terra Universal encourages re-test after installation. Terra Universal recommends that the customer contact an independent organization, with technicians trained and experienced in performance evaluation and maintenance of clean air equipment. -
Page 12: Replacement Orders
Installation and Operating Guide WhisperFlow® Portable Filtration System © Copyright 2021 Terra Universal Inc. All rights reserved. • Document No. 1788-48 7. Replacement Orders Provide sales associate with pertinent information, such as serial number, model number and date, for replacement parts or a new portable HEPA filtration system. -
Page 13: Warranty
Terra Universal. All claims must be made in writing within 90 days of the date the product was shipped. Any claims not made within this time limit shall be deemed waived by the customer.
