Displays2go FSBEVCART4 Assembly Instructions

ASSEMBLY INSTRUCTIONS
FSBEVCART4 - Beverage Cart with Wine Glass Holder & Wheels

Parts List

A x1pc
E x2pc
8mm
J x1pc
Step 1. Attach Side Frames (E) to Grid Rack Base (D).
Use Screws (L) and tighten with included Hex Key (J) from
both sides as shown.
E
L
L
D
B x1pc
F x2pcs
6mm
6x25mm
K x8pcs
E
L
C x2pcs
G x2pcs
8x25mm
L x12pcs
Step 2. Place one Cross Rack (C) in between 2 side panels
and align the holes on C and E. Use Screws (K) and Cap (M)
to fix the rack. Hand tighten the screws and caps first and then
use Wrench (N) and Hex Key (J) to securely tighten them.
Assemble the other Rack (C) the same way.
K
K
M
K
K
L
M
D x1pc
H x2pcs
6mm
M x12pcs
C
M
N
E
C
M
M
M
V20.04
10mm
I x1pc
6mm
N x1pc
K
M
M
K
