BI COMMUNICATIONS TX8000 Quick Start Operating Instructions

Replacing Batt eries
Remove 4 fi xing screws and lift of cover. Remove
batt eries and replace with either 4 x AA Alkaline
batt eries or Nickel Metal Hydride (rechargeable).Ensure
correct polarity when refi tti ng. Refi t cover and screws.
4
Technical Specifi cati on
Ranges meters 7, 15, 30, 60, 120, 250, 500, 1km, 2km, 3km, 6km
feet 23, 49, 98, 197, 394, 820, 1640, 3280, 6560, 9850, 19000
Range Selecti on Manual range control
Dual cursors with a distance measurement between cursors
Accuracy 1% of selected range*
Resoluti on Approx 1% of range
Sensiti vity Min 3 pixel return at 4km on 0,6mm Æ , PE , TP
Velocity Factor Adjustable from 1% to 99%
Output Pulse 5 volts peak to peak. Into open circuit
Output Impedance Selectable 25, 50, 75 & 100 ohms
Output pulse Width 3 ns to 3 ms, Automati c with range
Scan Rate 2 scans / second or scan held
Tone Generator 810 – 1100Hz
Batt ery Life 7 hours typical use
Power Supply 6 volts, 4 x 1.5 AA Alkaline cells
Power Down Selectable 1, 2, 3, 5 minutes or disabled
Back Lit Display and keyboard (Display 320x240 QVGA)
Voltage Detecti on 250 volts AC
Operati ng Temp -10º / 50ºC
Storage Temp -20º / 70ºC
Dimensions 220x98x58 mm
Weight 0.5 Kg
Safety IEC 61010-1
EN 60950
EMC BS/EN 61326-1
Protecti on Class IP67
The TX8000 is 6Km range Time Domain Refl ectometer housed in
a rugged over moulded case being water proof to IP67 and drop
resistant, designed for outside use, but suffi ciently small and light
weight for widespread use. Using a 3.5-inch QCGA colour display
informati on is clearly displayed; an illuminated key pad makes the
TX8000 ideal for use in poorly lit areas.
Using 11 range scales with a fi rst range of 7 meters near end
faults are clearly visible. Using the scan hold facility faults may be
retained on screen for closer examinati on or when in scan mode
intermitt ent faults may be easily identi fi ed. The user variable gain
control allows small events on the waveform to be magnifi ed for
clearer identi fi cati on. With dual cursors each cursor giving its
length measurement and a diff erenti al distance between cursors
the length of a fault may be identi fi ed. To assist in the identi fi ca-
ti on of faults a number of known fault types may be super im-
posed over the displayed fault for easier identi fi cati on
5
TX8000
Quick Start
Operating Instructions
