COLOR TELEVISION RECEIVER Chassis : S62A(P)_OZ Model : WS32Z30HEAXBWT WS32Z30HEAXSAP SERVICE Manual COLOR TELEVISION RECEIVER FEATURES Slimfit (Low Depth) CRT ■ ■ ■ DNIe Lite Adopted 480P/576P/1080i ■ ■ ■ Full 100Hz WS-32Z30HE...
When Check the AC power cord for possible damages. Keep voltage exceeds the specified limits, check each special the part or the lead away from any heat-emitting part. materials. Samsung Electronics...
Page 6
Critical safety parts should be bracketed with ( Use only regular parts for replacements (in particular, flame resistance and dielectric strength specifications). Irregular parts or materials may cause electric shock or fire. Samsung Electronics...
5. Check for insulation between the blade of the AC plug 10. The sharp edges of the metal material may cause and that of any conductive materials (i.e. the metal physical damage, so ensure wearing protective gloves panel, input terminal, earphone jack, etc). during the repair. Samsung Electronics...
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Samsung Electronics...
5. Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause fire or electric shock. Samsung Electronics...
- MSP3411G : Provides SiF, analog audio and digital audio signal input and decoding functions. - CXA2165Q : H-out, VD-P, VD-N, RGB out, Video and Deflection Signal Processing. - SDA5550M : ⅡC-Comunication, Master Control Micom - M27W201 : ROM MICOM Samsung Electronics...
5. When replacing the CRT Ass'y : No adjustments required. 6. When replacing the front panel master power switch : No adjustments required. 7. When replacing the Side AV : No adjustments required. 8. When replacing the control switch : No adjustments required. Samsung Electronics...
Option (XX XX XX) ROM Checksum (0000) Reset / XX-XX-XX 3. Functions of the Keys within Service Mode MENU Show all menus Move the cursor to select an item. ▲ / ▼ Adjust the selected configuration value ◀ / ▶ Samsung Electronics...
Page 22
0~63 Adjust G Drive 0~63 B Drive 0~63 Adjust Sub Bright 0~63 Adjust Sub Contrast 0~15 Adjust Sub secam color Sub Color 0~23 Sub Tint 0~63 CTI Level 0~03 COL Axis 0~03 LTI mode 0~03 LTI Level 0~03 Samsung Electronics...
Page 23
Sync Phase (480) Sync Phase (576P) Sync Phase (1080) Sync Phase (VGA) RF_DNIe R_active HP HI 0~15 RF_DNIe R_active HP LO 0~255 RF_DNIe H_Sync out P HI 0~15 RF_DNIe H_Sync out P LO 0~255 RF_DNIe_HSYNC_OUT_W HI 0~15 RF_DNIe_HSYNC_OUT_W HI 0~255 Samsung Electronics...
Page 24
14 R cutoff offset Cool 1 -20~+20 15 B cutoff offset Cool 1 -20~+20 16 R drive offset Cool 2 -20~+20 17 B drive offset Cool 2 -20~+20 18 R cutoff offset Cool 2 -20~+20 19 B cutoff offset Cool 2 -20~+20 Samsung Electronics...
Page 29
Brightness (RGB) Conrast (RGB) U Saturation (RGB) V Saturation RGB) Brightness (DVD) Conrast (DVD) U Saturation (DVD) V Saturation (DVD) 9407 Y Gain 9407 U Gain Luminance Delay 9407 V Gain CrCb_Gain_480p,576p CrCb_Gain_1080i 480i sub_bright 480i sub_contrast Samsung Electronics 3-13...
Page 30
LNA PLUS STEP6 Clamping duration(main) 170 HV looping counter 171 HV Range Min 172 HV Range Max 246 H-PLL(AV) 248 RF color sens 249 AV color sens 250 SDV (PROGRESSIVE MODE) 251 SDH (PROGRESSIVE MODE) 253 LPF adjustment(MST9883) 3-14 Samsung Electronics...
Page 31
ON : Australia, Newzealand TTX LIST On / Off OFF : Other Area On / Off On : 2T PIP LNA All Model SEARCH_LNA On / Off Off: 1TUNER / No PIP DNIe option On / Off Samsung Electronics 3-15...
② Press "Info → Menu → Mute → Power On" using the remote control and enter Factory Mode. ③ Enter Deflection Mode. ④ Adjust the V-AMP, V-SHIFT, H-AMP and H-SHIFT items so that the width becomes 5 and the height becomes 4. 3-16 Samsung Electronics...
Page 33
⑦ When the adjustments are complete, display the Lion pattern and check that the picture size has not been changed. If there is no change, finish the adjustments. Samsung Electronics 3-17...
After Adjustment Focus VR 6. Slowly turn the Dynamic Focus VR clockwise so that the 2nd line is the most clearly displayed. After Adjustment 7. Check the entire screen focus and repeat steps 3 to 6, if necessary. 3-18 Samsung Electronics...
Page 35
5. Adjust the Screen VR of FEB so that the highest point of the Pedestal Level is 175V. 175V Screen Adjust Method the Screen Voltage for Toshiba Pattern by Oscilloscope ※ Screen Voltage Measurement Data Item Data Required Adjustment The Highest Voltage among RK, GK and Screen Voltage Screen Voltage BK 175Vp-p-3V Samsung Electronics 3-19...
Page 36
4. When the adjustment is finished, check the following checklist. - If there is a spot on the screen when turning the TV set off/on, adjust the Screen Voltage again. - If there is a ghost line on the screen, adjust the Screen Voltage again. 3-20 Samsung Electronics...
Exploded View & Part List 4. Exploded View & Part List 4-1 WS32Z30HEAXBWT Yon can search for the updated part code through ITSELF web site. URL:http://itself.sec.samsung.co.kr Loc.No. Code No. Description Specification Q'ty SA/SNA Remark M0006 CIS3 BP64-00331B DECORATION-POWER PJTV,ABS,HB,GR503,SVM30 S.N.A...
2)Check that the Master Switch has been pressed. 3) Check that the transmitter is turned on. 4) Check that transmitter device selection is set to TV. 5) Check that the signal cable is properly connected. 6) Check that channel setting has been set. Samsung Electronics...
Page 92
When the screen is not properly displayed and the left or right side of the picture is shrunk, or the top or bottom of the screen is expanded or shrunk, check if the Deflection Board is out of order. Samsung Electronics...
Page 93
Is the cable connecting the Power Board and the System/Deflection Board properly connected? Replace the Is a CRT high voltage Power Board been measured? Is the cable from the Connect System Board to the CRT Ass’y properly the cable. connected? Samsung Electronics...
Cannot select an A/V channel. out, you cannot select an A/V channel. Check if the connector is properly connected. Cannot select a menu. Check if the menu is grayed out. If a menu is grayed out, it cannot be selected. Samsung Electronics...
Page 95
■ Set the auto volume control to ON. There is a lot of noise. Keep the antenna away from the power cord or connectors if possible. The selected language does not Press the Multiplex button to select the TV. appear. Samsung Electronics...
Page 96
This noise may occur when the plastic material inside the TV expands or contracts according The TV makes a noise as if to the seasonal temperature or humidity. This is like the noise from a furniture/cabinet/sink something is dropping inside. unit, and there is no need for concern. Samsung Electronics...
You can check the checksum according in the following order. Factory Mode → Checksum → Right Button → Calculate Checksum → Output Checksum (e.g. 0xab2b) ■ Checksum Examples T_COREOAKR1_1010 : checksum = 0xab2b T_COREOAKR1_1014 : checksum = 0x4faa Samsung Electronics...
- Market defect cases: The screen is pushed to the right side or the picture is divided into two on the screen. - Power supply: 5V - Check for input defects: Y/Pb/Pr signal - Check for output defects: Y/Pb/Pr, H/V signal Component Input Component Output Y/Pb/Pr, H/V OUT Samsung Electronics 6-15...
Page 106
If the signal color is out of order or noise appears in the Color Bar pattern, check the R/G/B Digital output cable. - Power supply : 3.3V - Check for input defects : 480P, 720P, 1080i Y/Pb/Pr signal - Check for output defects : R/G/B 24BIT H/V/Clock B 8Bit G 8Bit 480P 이상 6-16 Samsung Electronics...
Page 107
This removes noise from the signal processed by the EAGLE IC for better visual quality. It provides a clearer and near natural color picture. Defects in DNIe are rare. - Power supply : 1.8V, 3.3V - Check for input defects : R/G/B 24BIT H/V/Clock - Check for output defects : Y/Pb/Pr H/V Samsung Electronics 6-17...
Page 108
This receives the Y/Pb/Pr input from DNIe and outputs to R/G/B. It also outputs V/H Drive and E/W, and controls the operation of ABL.EHT. If V-Drive output fails, check for an IC defect. - Power supply : 5V, 15V - Check for input defects : Y/Pb/Pr H/V - Check for output defects : R/G/B, ABL, EW, V/H-DRIVE 6-18 Samsung Electronics...
Page 109
This receives the SiF signal from the Tuner, and the external input signal 1/2/3/4, and performs signal processing for the signals. It can input and output the I2S signal for the Audio Delay. - Power supply : 5V, 8V - Check for input defects : SiF, Scart 1/2/3/4 - Check for output defects : Lt/Rt, Monitor Out Samsung Electronics 6-19...
Page 110
This receives the signal from the Audio Processor (MSP4440) and outputs the signal in 10W + 10W sound. - Power supply : 16V - Check for input defects : Lt/Rt - Check for output defects : L+, L-, R+,R- 6-20 Samsung Electronics...
Page 111
→ 70Vpp. ▶ If the correction signal is not measured, check that the Lead of L304 (N/S TRANS) is disconnected. If L304 is normal, check the soldering status of C305 and C439. The correction signal is approximately 70Vpp. Samsung Electronics 6-21...
Wiring Diagram 8. Wiring Diagram 8-1 Overall Wiring FBT Power Supply CRT Power Supply Side AV Input Supply Secondary Power to the System Board Control Signal Power Switch / Remote Control Sensor Supply Secondary Power to the System Board Samsung Electronics...
*VJ10 : This is a 10 pin port connected to the Side AV, and receives S-Video2 and AV4 external inputs. *SJ20 : This is a 4 pin port connected to the Speaker, and sends the signal from the AMP to the speakers. Samsung Electronics...
Page 122
Connected to the CRT Ass'y Connected to the Side AV Port PIN No. Pin Name PIN No. Pin Name S-Y2 B-OUT S-C2 G-OUT R-OUT AV4-L AV4-R POWER TILT SJ20 Connected to the Side AV Port PIN No. Pin Name Samsung Electronics...
Page 123
PCB Diagram MJ20 MJ10 Connected to the Master Ass'y Connected to the Control Ass'y PIN No. Pin Name PIN No. Pin Name KEY3 STD-LED KEY1 KEY2 Samsung Electronics...
* CN301 : This is a 4 pin port connected to the DY, and supplies voltage for CRT R/G/B. * GT101 : This is a ground port to prevent high voltage due to lightning, and is connected to the Power Board. Samsung Electronics...
* CN802 : This is a 3 pin port connected to the AC power cable. It is connected to the power cable socket. * GT805, GT806 : This is a port connected to the D-Coil surrounding the CRT. Samsung Electronics...
Page 127
Supplies power to the System Board Supplies power to the Deflection Board Pin Name PIN No. Pin Name PIN No. Pin NAME VCC_S5V VCC_S5V VCC_142V VCC_142V RELAY RELAY POWER POWER 1080i 1080i VCC_15V VCC_16V VCC_16V VCC_15V VCC-7.5V-B VCC-7.5V-B ON/OFF S-MUTE S-MUTE GND_S_AMP GND_S_AMP Samsung Electronics...
* CNC02 : This is a port that receives power for the CRT and AMP from the Deflection Board. * FV1 : A port to connect the VM signal to the DY Ass'y. * FN1 : A port to connect signals to the Tilt Coil and is required for the screen slant adjustment. Samsung Electronics...
Page 129
PIN No. Pin NAME PIN No. Pin NAME VCC-200V HEATER VCC_-16.5V VCC_20V VCC_142V Connects the VM signal to the DY Ass'y Connects the signal to the Tilt Coil PIN No. Pin NAME PIN No. Pin NAME TILT TILT Samsung Electronics...
Schematic Diagram 10-4 DEFLECTION This Document can not be used without Samsung’s authorization. TP10 Power Signal TP23 TP10 TP23 10-4 Samsung Electronics...
Schematic Diagram 10-5 LED Module 10-6 Master S/W This Document can not be used without Samsung’s authorization. This Document can not be used without Samsung’s authorization. Samsung Electronics 10-5...
Schematic Diagram 10-8 System Board 10-8-1 System Board 1 This Document can not be used without Samsung’s authorization. TP18 Power Signal TP21 TP19 TP20 TP20 TP19 TP18 TP21 Samsung Electronics 10-7...
Page 138
Schematic Diagram 10-8-2 System Board 2 This Document can not be used without Samsung’s authorization. Power Signal 10-8 Samsung Electronics...
Page 139
Schematic Diagram 10-8-3 System Board 3 This Document can not be used without Samsung’s authorization. Power Signal Samsung Electronics 10-9...
Page 140
Schematic Diagram 10-8-4 System Board 4 This Document can not be used without Samsung’s authorization. Power Signal TP09 TP09 10-10 Samsung Electronics...
Page 141
Schematic Diagram 10-8-5 System Board 5 This Document can not be used without Samsung’s authorization. Power Signal TP12 TP13 TP14 TP14 TP13 TP12 Samsung Electronics 10-11...
Page 142
Schematic Diagram 10-8-6 System Board 6 This Document can not be used without Samsung’s authorization. TP15 TP03 TP06 TP03 TP07 Power Signal TP04 TP05 TP16 TP08 TP05 TP04 TP06 TP15 TP07 TP16 TP08 TP17 TP17 10-12 Samsung Electronics...
Page 143
Schematic Diagram 10-8-7 System Board 7 This Document can not be used without Samsung’s authorization. Power Signal TP01 TP02 TP01 TP02 Samsung Electronics 10-13...
Page 144
Schematic Diagram 10-8-8 System Board 8 This Document can not be used without Samsung’s authorization. TP11 TP22 Power Signal TP22 TP11 10-14 Samsung Electronics...
Also used to select items on the on-screen menu. ⑦ POWER Press to turn the TV on and off. ∧ CH ∨ ④ ④ ∨ Press to change channels. Also press to move between items on the on-screen menu. Samsung Electronics 11-1...
Page 146
Use the rear panel jacks to connect an A/V component that will be connected continuously, such as a VCR or a DVD player. Because there are three sets of input jacks, you can connect three different A/V components (i.e., a VCR and a DVD, 2 VCRs, etc.) 11-2 Samsung Electronics...
Page 147
You can use the remote control up to about 23 feet from the TV. When using the remote, always point it directly at the TV. You can also use your remote control to operate your VCR, DVD, Cable box, and Samsung Set-top Boxes.
① Remove the 4 screws fixing the Terminal Board and the Board Jacks. : RH, +, B, M4, L15, ZPC(BLK), SWRCH18A 6003-001026 ② Lift the fixing holder up at and pull the Terminal Board to separate it from the unit. Samsung Electronics 12-1...
Page 150
② To separate the power cord, slide the fixing clip and lift the cable up. ① Separate the CRT Ass'y from the CRT ② Separate the TBC wire, GND, VM and Tilt cables from the CRT Ass'y sequentially. 12-2 Samsung Electronics...
Page 151
In addition, separate the wires on a flat and clean surface so as to prevent scratching of the material and the PCB. Pull the wires while pressing on the fixing clip. Samsung Electronics 12-3...
Page 152
Notice: Since pulling the wire by force may damage the coating of the wire, separate the wire holding the metal part with the tool. ① Remove the 3 screws fixing the Deflection Ass'y. : PWH, +, B, M3, L10, ZPC(YEL), SWRCH18A 6003-001023 12-4 Samsung Electronics...
Page 153
② Since there is a holder fixing the Power Board, lift the part where screws have been installed and slide the board to sepa- rate it. Notice: Lifting the Power Board by force may damage the fix- ing holder and the PCB, therefore separate the board with care. Samsung Electronics 12-5...
Page 154
① Remove the 3 screws from the Bottom Shield Case. : PWH, +, B, M3, L10, ZPC(YEL), SWRCH18A 6003-001023 ② Since the Optical Jack ( ) protrudes out of the case, lift the AMP side up, slide forward and separate the board. 12-6 Samsung Electronics...
- A circuit for correcting the spool shape which appears on the left and right part of a picture. This is caused by the difference between the distances from the center of a picture to each corner. KA393, FQP630 etc. (Adopt PWM circuit) Samsung Electronics 13-1...
- Consists of L304, C305, C439, R312. Symmetrize the up and down amplitude using the saturable reactor of L304 and adjust N/S Gain by controlling the capacity value of C305 and C439 If the correction vector is excessive, one can slightly reduce the resistance of R312 13-2 Samsung Electronics...
Page 157
Circuit Description ⓑ Comparison before and after of N/S signal correction Samsung Electronics 13-3...
Page 158
..D415 : moves to the right of a picture ..D417 : moves to the left of a picture Total Length of a Picture Moved (m/m) Condition Left Center Right To Left To Right To Left To Right To Left To Right After 13-4 Samsung Electronics...
Page 159
There are H,V, PIN-COMP as well in Factory data and these correct the high voltage regulation. If the H-COMP capacity value increases, correction vector increases too and this causes a strong picture swaying. On the other hand, if the H-COMP Samsung Electronics 13-5...
Page 160
COMP capacity value, therefore, should be varied +/- 1step from the factory- adjusted condition, since a gain widely varies dependant on the SET distribution. ▶Before and After of E/W Circuit Correction 13-6 Samsung Electronics...
Ex: For LCD 15:9 devices, "Wide" is displayed on the OSD instead of "16:9". 4. The picture size can be changed even in the blue screen. However, the picture size should be controlled by the product specifications if the change is impossible due to hardware restrictions. Samsung Electronics 14-1...
You can use this AV interface for users by controlling connected AV devices function to study English by watching AFKN or CC marked through the Anynet menu when AV devices of Samsung video tapes. Electronics are connected.
Page 165
COLOR TELEVISION RECEIVER Chassis : S62A(P)_OZ Model : WS32Z30HEAXBWT WS32Z30HEAXSAP SERVICE Manual COLOR TELEVISION RECEIVER FEATURES Slimfit (Low Depth) CRT ■ ■ ■ DNIe Lite Adopted 480P/576P/1080i ■ ■ ■ Full 100Hz WS-32Z30HE...
