- Page 1 USER'S GUIDE CARE AND MAINTENANCE MODEL TT3X - FS3X Via Cavour, 28 15040 Pomaro Monferrato (AL) Tel. +39 0521 785732 / +39 0142 60536 w w w. i t a l c i l . i t i n f o @ i t a l c i l . i t...
- Page 2 Pull out one barrier-bags, pour the cooling liquid (included) into the basin...
- Page 3 3 pag. 4 Time working pag. 5 Important recommendations pag. 6 Maintenance: repairs / cleaning pag. 7 Maintenance: Remedies for some defects pag. 8 Maintenance: Edited by Fast Chiller Service pag. 10 Technical data pag. 11 Electrical connection pag. 12...
-
Page 4: Setup And Installation
+10 C° and a maximal temperature of +30° C. Beware: the machine increases the room temperature during its functioning. BE SURE THAT FAST CHILLER IS ALWAYS CONNECTED TO AN ELECTRIC INSTALLATION EQUIPPED WITH SAFETY DEVICE AND EARTH CONNECTION. - Page 5 FAST CHILLER USE USE: 1. Insert , gently, bottle which has to be cooled, in chosen cooling well on Fast Chiller. 2. Do not wheel bottle once inserted in the crate. 3. Diel timers electronic button (one for each well) up to achieve requested cooling time.
-
Page 6: Time Working
FAST CHILLER USE TIME WORKING: - On display are two zeros when it is just switched on. - Push the button once in order to plan the count (1 minute a time). - Hold the button pushed in order to increase the count more quickly. -
Page 7: Important Recommendations
IMPORTANT RECOMMENDATIONS 1) Let liquid inner Fast Chiller cools for 3-4 hours before using it. 2) Use the machine following specifications. 3) Pay attention to insert and remove bottles from the well: if there is a resistance do not force it, verify that in the cooling well are not blockings. -
Page 8: Maintenance
MAINTENANCE REPAIRS: The user must not operate in case of malfunctioning of the machine, but s/he has to contact specialized personnel (refrigerator technicians) or the warranty will be invalidated. The user is responsible for cleaning and check such as: a) every week control the main conductive and plug conditions, visually. b) Control that machine has not liquid losses. - Page 9 MAINTENANCE REMEDIES AND SOME INCONVENIENCIES: 1. Machine doesn't work . Verify plug is well inserted and that there is electric current. 2. A crate for bottles breaks and liquid enters. Replace it with a new one. A. Remove the cap and lift it to gain access to the crates. B.
- Page 10 MAINTENANCE D. Insert the new crate, before inserting the small iron which supports bottles. E. Bend the end of the crate around plastic opening again and hang up the bottles support iron. F. Fix the screw of metallic band, cover the machine with its cap.
- Page 11 Control there are not damages to the electric part of the machine. e) Replace FAST CHILLER TRANSFER LIQUID with an original liquid , where it needs. f) Replace the bottles support crates, if it needs.
-
Page 12: Technical Data
Climatic classe N Noisiness: <75dB Dimensions (mm): TT3X - w 550 x d 503 x h 429 FS3X - w 630 x d 370 x h 720 Weight: TT3X - 45 Kg (incluso liquido) FS3X - 70 Kg (incluso liquido) Basin volume 15 lt. -
Page 13: Electrical Connections
ELECTRICAL CONNECTIONS ELECTRICAL CONNECTIONS Eruption Engine-compressor Engine-fan Thermostat Earth ATTENTION: MACHINE HAS TO BE CONNECTED TO A PLUG EQUIPPED WITH AN EARTH CONNECTION. - Page 14 NOTES...
