Silver Eagle SE240 Quick Start Manual

Air belt sander 1/2" x 18"

Advertisement

Quick Links

www.matcotools.com
Study, understand and follow all instructions provided with this
product. Read these instructions carefully before installing,
operating, servicing or repairing this tool. Keep these instructions
in a safe accessible place.

INTENDED USE OF THE TOOL

This belt sander is designed to rapidly sand down materials and
remove rust, paint and welds in hard to reach areas. Do not use
this tool outside of the designed intent. Never modify the tool for
any other purpose or use.

WARNING

• Use of this product can expose you to chemicals including
ethylene glycol, gasoline vapors and engine exhaust, which
are known to the State of California to cause cancer, birth
defects, or reproductive harm. For more information, visit
www.P65Warnings.ca.gov. Always wear ANSI approved
safety equipment, safety glasses and clothing when using
this product. Study, understand, and follow all instructions
provided with this product. Failure to read and follow all
warnings and operating instructions may result in damages
and serious injury or death.
• Always wear ANSI approved goggles when using this
product. (Users and bystanders).
• Never use this tool for any application other than for
which it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
• Improper operation and/or maintenance of the tool,
modification of the tool or use of the tool with accessories
not designed for it could result in serious injury or death.
• Always select accessories of the correct size and design for
the job that you are attempting to perform.
• Always work in a clean, safe, well-lit, organized and
adequately equipped area.
• Do not begin repairs without assurance that vehicle is in
secure position and will not move during repair.
AIR BELT SANDER
1/2" x 18"
Model:
SE240
MADE IN TAIWAN
Product Type:
AIR BELT SANDER 1/2" x 18"

1 YEAR LIMITED WARRANTY

• The manufacturer warrants products to the original owner against defective material
or workmanship for a period of 1 year (except where noted on our price schedule)
from the date of 1st use. The manufacturer reserves the right to determine whether
the product failed because of defective material, workmanship or other causes and to
charge back for missing parts. The manufacturer, at its discretion, will repair products
covered under this warranty free of charge. The distributor should direct the original
owner to return the product (with the exceptions listed below) with the distributor's
name, address, adequate proof of date of purchase or a copy of warranty card, and a
short note explaining the problem. Failures caused by accident, alteration or
misuse are not covered by this warranty.
• The manufacturer or its authorized service representatives must perform all
warranty repairs. Any repair to the product by unauthorized service representatives
voids this warranty. The rights under this warranty are limited to the original owner
and may not be transferred to subsequent owners.
• This warranty is in lieu of all other warranties, expressed or implied, including
warranties of merchantability and fitness for a particular purpose. Some states do not
allow the exclusion of limitations of incidental or consequential damages so the
above limitations may not apply to you.
When unpacking, check the parts diagram and part number
listing on page 4 to make sure all parts are included. If any
parts are missing or damaged, please call your distributor.

PRODUCT INFORMATION:

• Wide rubber coated roller drastically improves
sanding belt life without losing aggressiveness
• Simple belt tension lever
• Variable speed control
• Angle offset handle allows for accessing difficult to reach
spot-welds comfortably.
• Included in the kit:
1 - 36 Grit 1/2" x 18" (SE140-36B)
1 - 40 Grit 1/2" x 18" (SE140-40B)
1 - 60 Grit 1/2" x 18" (SE140-60B)
• Non-wearing steel roller assembly available (3037PAS)

SPECIFICATIONS:

Free Speed: 17,000RPM
Size of Belt: 1/2" x 18"
Air Consumption: 4.5cfm
Overall Length: 15.15" (385mm)
Net Weight: 1.87 lbs. (0.85kg)
Air Inlet: 1/4"
Air Pressure: 90psi
DO NOT DISCARD – GIVE TO USER
Page 1

BEFORE USE

1809270-14
