DIMON TECHNOLOGY HAAE Instruction Manual

Bracket 2
∅20mm(0.79")
12mm(0.47")
150mm(5.91")
220mm(8.66")
337mm(13.27")
2 . 3.
o
90
M12
19
NON-DIMMABLE
DIMMABLE
N L
N
L
N
DIM+/DA1
L
DIM-/DA2
Wiring Diagram
L brown black
DIM+ / DA1
N blue white
DIM- / DA2
yellow/green green
GND
?
Troubleshooting
1.
Problem
LEDs stop working
LEDs flash on and off
Warranty
5 years warranty for original purchaser of LED product that is identified on seller's invoice
reflecting its original purchase (the "Product").
1. In order to make a warranty claim, you must notify seller in writing within sixty(60) days after your
o
60
discovery of the defect, provide proof of purchase such as the invoice and comply with seller's other
warranty requirements. Upon receiving that notice, to ascertain why fixtures stop working, evidences
would be needed for seller's QC Team to analyze. Seller may require you to promptly return the Product
to Seller when necessary, freight prepaid.
o
30 2. The determination of whether the Product is defective shall be made by Seller in its sole discretion with
consideration given to the over all performance of the Product.
3. If seller determines the Product is defective, Seller will elect, in its sole discretion, repair the Product
or replace the Product. Seller reserves the right to utilize new, reconditioned, refurbished, repaired or
remanufactured products or parts in the warranty repair or replacement process. Such products and
parts will be comparable in function and performance to an original product or part, as determined by
Seller in its sole discretion, and warranted for the remainder of the original warranty period. However,
cost of labor and equipment to remove the defective product and install a repaired or a replacement
Product at the end-user facility are excluded. Supplier's aggregate liability with respect to a defective
DIM+
DIM-
L
N
product shall in any event be limited to the money paid to buyer for that defective product.
/DA1 /DA2
The following circumstances will not be warranted:
1. Damage caused by force majeure such as war, riots, sabotage, cyclones, earthquakes, tidal waves,
flooding, lighting strikes, explosions, fire, flood, etc.
2. Damage caused by user's improper delivery, defects caused by wrong operation, wrong treatment
and destruction of machinery.
3. Dismantling or modification or improper maintenance or repairing of the products without the
supplier's authorization.
4. Damage caused by buyer or installer using bad quality cable or other mismatching electronic parts.
5. This warranty is invalid if the product is not used for the purpose for which is originally designed. Any
disputes occurred shall be applied to the laws and regulations of P.R.C.
The seller has the sole right to interpret and amend the above articles.
blue brown purple white
white blue gray black
Possible Cause Solutions
The power line is improperly connected. Reconnect the power cable.
The power plug is loose. Firmly plug the power in.
The LED driver malfunctions. Replace with new driver.
The LED chip is damaged. Replace with new LEDs.
The output of the driver is abnormal. Replace with new driver.
The LED chip breaks down. Replace with new LED chip.
LED Street Light
Instruction Manual
180W/240W/300W
Version 01
