GpsGate GPS1195 Installation And Maintenance Manual

Automatic barrier gate

Hide thumbs

Table Of Contents

GLOBAL PARKING SYSTEMS INC.

TEL:

FAX:

905-405-9800

905-405-9801

GPS1195 Automatic Barrier Gate

INSTALLATION AND MAINTENANCE MANUAL

E-MAIL:

Info@gpsgates.com

WEB SITE:

www.gpsgates.com

DOCUMENT VERSION 4 - 2018

Table of Contents

Need help?

Do you have a question about the GPS1195 and is the answer not in the manual?

Questions and answers

Summary of Contents for GpsGate GPS1195

Page 1 GLOBAL PARKING SYSTEMS INC. TEL: FAX: 905-405-9800 905-405-9801 GPS1195 Automatic Barrier Gate INSTALLATION AND MAINTENANCE MANUAL E-MAIL: Info@gpsgates.com WEB SITE: www.gpsgates.com DOCUMENT VERSION 4 - 2018...
Page 2 GPS1195 Auto Gate Manual Version 3 LIMITED WARRANTY GLOBAL PARKING SYSTEMS INC. Global parking systems warrants that it’s product will be free from defects in workmanship and materials when installed, used and serviced as intended, as follows:  Electronic, Computerized equipment, Accessories, Electrical & Mechanical equipment, for a period of 1 year from the date of shipment.
Page 3: Table Of Contents
GPS1195 Auto Gate Manual Version 3 Table of Contents Warranty Page 2 Table of Contents Page 3 Installation Setup Page 4A – 4B Features Page 5 Loop Detector Page 6 Loop Installation Page 7A -7B -7C PLC Version 2 Wiring Connections Page 8A - 8B - 8C - 8D –...
Page 4: Installation Setup
GPS1195 Auto Gate Manual Version 3 Installation Set Up Installation of all equipment should be performed by trained personnel, skilled in the type of work involved. All installations should be inspected by appropriate authorities, or a factory trained representative, before the system is put into operation.
Page 5 GPS1195 Auto Gate Manual Version 3 The GPS1195 when sold with a round aluminum arm, you will find an aluminum spacer attached to the outside of the main shaft. After removing the hardware attached, re-attach the spacer lining up the 3 holes with the main shaft holes by using a piece of tape to keep the spacer in place.
Page 6: Features
GPS1195 Auto Gate Manual Version 3 Features The GPS1195 Auto Gate is unique in the Parking Industry. It comes with a full size PLC controller for Maximum flexibility, functionality and reliability, while maintaining traditional economy and serviceability. There is no Onsite programming required Features Listed Below: ...
Page 7: Loop Detector
GPS1195 Auto Gate Manual Version 3 Vehicle Loop Detector The standard GPS vehicle detector is 120V. The standard version is designed to detect standard four wheel Passenger Vehicles, Vans, Pickup trucks, Sport utility vehicles plus all other forms of traffic, like motorcycles, RV’s, High bed trucks, Trailers, Construction vehicles, etc.
Page 8: Loop Installation
GPS1195 Auto Gate Manual Version 3 Loop Installation 1) Loop geometry will depend on the particular requirements of the installation. Generally for most parking control applications can be satisfied using a standard 2 ½’ x 6’ PVC or a saw cut loop.
Page 9 GPS1195 Auto Gate Manual Version 3 11) Use a four inch base for the loop. Once the base has been laid, secure in place using a wooden stake wedged into each corner of the loop. Height of the wooden stakes above four inch base not to exceed top inch thickness of top coat.
Page 10 GPS1195 Auto Gate Manual Version 3 Calculating Loop Inductance The following formula can be used to calculate the approximate inductance of a loop. N = Number of Turns L = N2 X 5 X 1 P = Loop perimeter in feet...
Page 11: Plc Version 2 Wiring Connections
GPS1195 Auto Gate Manual Version 3 PLC Version 2 Controller Wiring Connections Connector 1 (120Vac Line Voltage Connections) Terminal 1 – Up Motor – Red Wire Terminal 2 – Down Motor – Black Wire Terminal 3 – 120Vac Neutral – White Wire Terminal 4 –...
Page 12 GPS1195 Auto Gate Manual Version 3 Terminal 7 – Free detector enable Terminal 8 – Free detector enable Terminal 9 – Close detector enable Terminal 10 – Close detector enable Terminal 11 – Down Limit switch NO input - Red Terminal 12 - +24V –...
Page 13 GPS1195 Auto Gate Manual Version 3 Terminal 12 – Arming Detector – Contact B Terminal 13 – Down limit contact Terminal 14 – Down limit contact Terminal 15 – Up Limit contact Terminal 16 – Up Limit contact Connector 4 (Outputs and Isolated relays) Terminal 1 –...
Page 14 GPS1195 Auto Gate Manual Version 3 Connector 5 (Relay Contacts) Terminal 1 – Relay 1 contact 2 – Common Terminal 2 – Relay 1 contact 2 – Normally Closed Terminal 3 – Relay 1 contact 2 – Normally Open Terminal 4 – Relay 2 contact 2 – Common Terminal 5 –...
Page 15 GPS1195 Auto Gate Manual Version 3 Terminal 9 – +24Vdc Terminal 10 – 24Vdc common Terminal 11 – 24Vdc common Terminal 12 – 24Vdc common Dip Switch Settings Switch 1 – On = Reset Loop Enabled Switch 1 – Off = Reset Loop Disabled Switch 2 –...
Page 16: Operating Instructions
GPS1195 Auto Gate Manual Version 3 Operating Instructions 1) Make sure field wiring is completed in accordance with Field Connection drawings supplied with the equipment. Install the barrier arm, and apply power 2) Turn the power switch on which is located on the lower left side of the gate 3) The first test with the gate is using the Auto / Manual switch to raise the arm till it stops and then lower the arm till it stops.
Page 17: Maintenance
GPS1195 Auto Gate Manual Version 3 Maintenance The GPS1195 barrier gate will provide many years of reliable service if the following maintenance is performed. Monthly Maintenance  Check the drive belt tension regularly. Belt should be tight to provide for smooth gate arm travel ...
Page 18: Spring Adjustment
Version 3 Spring Adjustment, Balancing the Arm The GPS1195 Auto Gate starting with 12ft round aluminum arms are spring balanced. There is a choice of 2 spring sizes depending on the length of barrier arm. 12FT to 15FT round aluminum arm requires the GPS 5.5 spring...
Page 19: Power Failure
GPS1195 Auto Gate Manual Version 3 Power Failure WARNING: Turn the on / off power disconnect switch to the off position. If the power returns while you are turning the pulley, the gate may start automatically if it is left in the on position and could cause injury.
Page 20: Leveling The Arm
GPS1195 Auto Gate Manual Version 3 Leveling the Arm 1) Bring the gate to the down position using the Auto / Manual switch located on the right side of the PLC controller board nearest the door opening, placing the switch in Auto 2) To adjust the level of the arm for the close position, loosen the wing nut on the down limit cam, adjust forward or backwards, cycle the gate once up and then down.
Page 21: Limit Switch Adjustment
GPS1195 Auto Gate Manual Version 3 Limit Switch Adjustment The up and down limits are adjusted by moving the position of the limit cams located on the main shaft inside the upper part of the gate. The up limit switch is marked with a tag UP and the down limit switch...
Page 22: Trouble Shooting
GPS1195 Auto Gate Manual Version 3 Trouble Shooting Service should be performed by technicians who are properly trained to repair this equipment The PLC controller has input and output displays located on the top of the PLC. When the gate is in working mode the green indicators light up to display which input or output is on.
Page 23 GPS1195 Auto Gate Manual Version 3 Trouble shooting Safety Edge When the barrier arm reverses up Input 10 flashes and output 1 flashes once When the up switch is made Input 4 lights up and holds There is a 45 second delay before the arm resets...
Page 24 GPS1195 Auto Gate Manual Version 3 Trouble Shooting Single Pushbutton station Turn the power switch on, when the arm is down, the PLC Display will light Inputs 0 1 2 3 4 up indicating which inputs and outputs are on...
Page 25 GPS1195 Auto Gate Manual Version 3 Trouble shooting Latching Keyswitch When you latch the keyswitch to open the barrier arm input 5 and output 1 light up Output 1 drops out and input 4 and 5 stay lit when the up switch is made When you release the latching keyswitch input 4 and 5 drop out, Output 0 lights up and when the down switch is made output 0 drops out and input 3 stays on.
Page 26 GPS1195 Auto Gate Manual Version 3 Spare Parts List GPS-1195-LBAS PLC LOGIC BD Version 2 GPS-1195-LSC LIMIT SWITCH COVER GPS-1195-LS-15 15 AMP LIMIT SWITCH GPS-1195-LCA LIMIT CAM ASSEMBLY GPS-1195-MR 120V 1/3 HP MOTOR GPS-1195-CH60 GEAR REDUCER GPS-1195-1.5P 1.5” X 5/8” MOTOR PULLEY GPS-1195-2P 2”...
Page 27 GPS1195 Auto Gate Manual Version 3 Spare Parts List GPS-1195-DL DOOR C/W LOCK GPS-1195-MS MAIN SHAFT GPS-1195-MSK MAIN SHAFT KEY GPS-1195-MCA MAIN SHAFT CONNECTING ARM GPS-1195-AS BARRIER ARM FLAT BAR SPACER GPS-1195-L REMOVABLE LID GPS-1195-CR CONNECTING ROD GPS-1195-33VB 4L 330V BELT...
