LIGMAN BA-10613 Installation And Service Manual

INSTALLATION AND SERVICE MANUAL
For Installation of Bamboo 3,4 bollard.
Model. BA-10613,BA-10623,BA-10633 and BA-10643
Product drawing (dimensions)
MOUNTING DETAIL
BA-10613,BA-10623
■ LIGMAN standard products are supplied with the control gear 220-240V 50/60Hz.
The control gear for other voltages and frequencies is available upon request, please consult us for more details.
■ LIGMAN luminaires are designed to conform IEC 60598 2-1 standard.
Technical amendments and modifications techniques reserved.
