Summary of Contents for Atlas SH500
- Page 1 OPERATION AND MAINTENANCE MANUAL PIZZA ROLLER MODEL: ATLAS – SH500 SERIAL NO:...
- Page 2 WARRANTY COMMENCES FROM DATE OF SALE ABP ATLAS WILL NOT BE HELD RESPONSIBLE FOR DAMAGE CAUSED WHILST ITEMS ARE IN STORAGE AND NOT IN USE. ABP ATLAS WILL NOT BE HELD RESPONSIBLE FOR DAMAGE INCURRED DURING TRANSPORT OR WHERE THE PURCHASED ITEM IS FORWARDED ONTO ANOTHER DESTINATION BY THE ORIGINAL RECEIVER OF THE GOODS.
- Page 3 DESCRIPTION The SH500 Pizza Roller was designed in accordance with Australian regulations and has been manufactured to protect the user from the risks associated with its use. For this reason, the machine is equipped with special safety devices to avoid risks during contact with moving parts.
- Page 4 SH500 PIZZA ROLLER IMPORTANT NOTICE: Safety devices, protective devices, and controls of the machine are for the protection of the operator as well as an essential part of machine function. These devices must be kept in original working order and condition. Any alterations carried out to the machinery without the manufacturers or importers authorisation may render the machine unsafe, and will result in breach of the warranty conditions.
- Page 5 SH500 PIZZA ROLLER OPERATING INSTRUCTIONS CONTINUED FLOUR DOUGH ON BOTH SIDES and place the Dough Ball (slightly squashed) into TOP STAINLESS CHUTE, this will then exit as a flat oval base. Note: Fingers or hands should never be forced into this Chute as rollers are at the base which can cause harm.
-
Page 6: Installation
1. Dough is NOT floured on BOTH sides 2. Dough is mixed incorrectly 3. Dough not rested long enough If all the above have been checked and your Dough Roller still does not operate correctly contact ABP ATLAS ON 03 9878 6900. SH500 6 OF 18... -
Page 7: Maintenance
SH500 PIZZA ROLLER MAINTENANCE 1. Lift top panel, wipe rollers and internal section with damp cloth. NEVER drop or close the top lid of the machine with force, as this can Note: cause damage to the safety switch and the machine will not operate. - Page 8 SH500 PIZZA ROLLER Dough Chute Top Lid Stop Button Exit Cover Start Button Right Cover Left Cover Emergency Stop Button Adjust Centre Base Flour Tray Arc Casting Plastic Front Cover Spring loaded Adjusting Knob Conveyor Belt Plastic Thumb Screws Belt Adjust...
- Page 9 SH500 PIZZA ROLLER (SECTIONAL VIEW) Top Roller Scraper No. 1 Roller Blade No. 2 Adjusting Block Exit Scraper Roller No 2 Blade Roller No. 3 Adjusting Block Roller No 3 Roller No. 4 Scraper Blade Scraper Scraper Blade Tension Arm Gear Box Roller No.
- Page 10 SH500 - PARTS DRAWING SH500 10 OF 18...
- Page 11 SH500 - PARTS LIST PART NO DESCRIPTION PART NO DESCRIPTION ADJUSTABLE ARC CASTING SIDE PLATE RIGHT SIDE COVER LEFT SIDE COVER CHAIN GREEN START BUTTON SCREW (M10 x 16) RED STOP BUTTON RING FLOUR TRAY BEARING (6203zz) PLASTIC FRONT COVER...
- Page 12 SH500 - ROLLER ASSEMBLY (TOP) DRAWING SH500 12 OF 18...
- Page 13 SH500 - ROLLER ASSEMBLY (TOP) PARTS LIST PART NO DESCRIPTION PART NO DESCRIPTION RING CHAIN GEAR (18 TEETH) CHAIN GEAR (18 TEETH) BEARING (6204zz) ADJUST SCREW SCREW (M6 x 20) BEARING SUPPORT BEARING SUPPORT R1 - TOP ROLLER NO 1 R2 - BOTTOM ROLLER NO.
- Page 14 SH500 - ROLLER ASSEMBLY (BOTTOM) DRAWING SH500 14 OF 18...
- Page 15 SH500 - ROLLER ASSEMBLY (BOTTOM) PARTS LIST PART NO DESCRIPTION PART NO DESCRIPTION SPRING SCRAPER TENSION ARMS WASHER SCREW BUSH SCREW SCREW SPRING RING RING CHAIN GEAR (18 TEETH) CHAIN GEAR (18 TEETH) BEARING (6204zz) BEARING (6204zz) BEARING SUPPORT SCREW SCREW R3 - SHAFT NO.
- Page 16 SH500 - CONVEYOR PARTS DRAWING SH500 16 OF 18...
- Page 17 SH500 - CONVEYOR PARTS LIST PART NO DESCRIPTION PART NO DESCRIPTION RING RING WASHER ADJUSTING BLOCK BEARING (6204zz) ADJUSTING SHAFT FRONT PULLEY PULLEY SHAFT RING BEARING (6204zz) ADJUSTING ARM FIXED SUPPORT WASHER ADJUSTMENT SHEET RING SCREW BELT SUPPORT ARM ADJUSTING FIXED SCREW...
- Page 18 SH500 - ELECTRICAL DRAWING SH500 18 OF 18...
