ADP QuickPunch
®
Installation Guide for the ADP InTouch
Overview
The ADP QuickPunch Plus finger scan device enables your organization to require biometric verification or identification
when employees use the InTouch. The system administrator configures the biometrics settings on the host system and the
manager uses the biometrics features on the InTouch to enroll employees in the system.
Parts
Before you begin
•
If you are installing the InTouch and the power is already off, skip to Step 1.
•
If the InTouch is assembled and running:
a. Use the security wrench to remove the cover.
b. Disconnect the power and the optional backup battery.
For more information, see the InTouch installation guide.
Plus Finger Scan Device
Revision B
Advertisement
Table of Contents
Summary of Contents for Adp QuickPunch Plus
- Page 1 Installation Guide for the ADP InTouch Overview The ADP QuickPunch Plus finger scan device enables your organization to require biometric verification or identification when employees use the InTouch. The system administrator configures the biometrics settings on the host system and the manager uses the biometrics features on the InTouch to enroll employees in the system.
- Page 2 Step 1: Remove the blank plate from the front cover of the InTouch Step 2: Insert the finger scan plate into the slot on the front cover Ensure that the two tabs on either side of the finger scan plate line up with the slots on the front cover. The finger scan plate snaps into place.
- Page 3 Step 3: Attach the cable to the micro-USB connector Note: If you plan to install the Wi-Fi option, first complete the ADP QuickPunch Plus installation. The cable (as shown in the following illustration) must be in place before you fasten the Wi-Fi assembly to the CPU board.
- Page 4 Step 4: Complete the installation • If the InTouch is not fully installed, or if there are other options to install, go back to the InTouch installation guide or to the installation guide for the next option. • If the InTouch is installed, see the InTouch installation guide and do the following: a.
- Page 5 Legal Statement The information in this document is subject to change without notice and should not be construed as a commitment by ADP, Inc. ADP is not responsible for any technical inaccuracies or typographical errors which may be contained in this publication. Changes are periodically made to the information herein, and such changes will be incorporated in new editions of this publication.
- Page 6 SJ/T11363-2006 遵循信息 SJ/T11363-2006 遵循信息 《中华人民共和国电子行业标准》 ， 《电子信息产品中有毒有害物质的限量要求》 （标准号：SJ/T11363-2006） 根据 《电子信息产品污染控制标识要求》 （标准号：SJ/T11364-2006）的规定，上述符号表示在产品或部件的 任一均质材料中包含超出以下最大浓度值的物质 （如下表详述） ： (a) 铅、汞、六价铬、多溴联苯、多溴二苯醚 的含量不超过 0.1% （按重量）或 (b) 镉含量不超过 0.01% （按重量） 。 除非 Kronos 另有书面说明，否则此信 息表示 Kronos 了解的全部信息 （根据第三方供应商向 Kronos 提供的信息） 。 上述符号中的数字参考不应视为表示产品寿命或延长产品保修期。 有害物质或成分的名称和含量 低于 O： 表示部件所有均质材料中的有害物质含量均 SJ/T11363-2006 中的限制要求 高于...
