Assembly; Plow Blade Installation - Champion Power Equipment 100398 Operator's Manual

100398
ENGLISH
Your snow plow requires some assembly .
If you have any questions regarding the assembly of your
snow plow, call our help line at 1-877-338-0999 . Please
have your serial number and model number available .

Plow Blade Installation

NOTE
Before starting the assembly of the blade and tubes
see Hybrid Mount installation instructions to ensure
it will work with your ATV .
NOTE
Install all hardware loose at first . Once all hardware
is correctly installed, tighten all bolts .
1 . Install the left (6) and right
support bracket (2) using the
19 . 1 mm) standard carriage bolts
This will create the blade frame assembly .
6
7.1
7.2
Figure 1 - Blade Frame Assembly
NOTE
There are 2 different neck lengths on a carriage bolt,
short and standard . See Figure 3 for differences .
2 . Attach the blade frame assembly to the blade in
location (A) using ⁄
5
16
neck carriage bolts (7.5)
3 . Next attach the wear bar
by installing the five
standard carriage bolts
the cutter blade (4), plow blade
bracket (2) . Secure the carriage bolts with
(7 .9 mm) nuts (7.2) . See Figure 2 .
4 . Install the blade feet
the ⁄ × 1 ⁄ in . (7 .9 × 31 .8 mm) standard carriage
5 1
16 4
bolts (7.4) .
(5) blade gussets to the
⁄ × ⁄ in . (7 .9 ×
5 3
16 4
(7.1) and nuts (7.2) .
5
2
× ⁄ in . (7 .9 × 19 . 1 mm) short
3
4
and nuts (7.2) . See Figure 2 .
(4) to the plow blade
⁄ × 1 in . (7 .9 × 25 .4 mm)
5
16
(7.3) in the center through
(1) and support
⁄
5
16
(3) as shown in Figure 2 using
Plow Blade Installation Cont'd.
NOTE
Adjust the feet by loosening the nuts and sliding
the feet up and down to the desired position . Start
with feet in minimum height position and adjust for
type of ground surface .
5 . Tighten down all bolts .
7.2
7.4
7.3
Figure 2 - Cutter Blade, Frame and Feet Install
(1)
in .
7.2 7.2
1
7.5
7.4
7.5
SHORT NECK
CARRIAGE BOLT
STANDARD
CARRIAGE BOLT
7.1, 7.3, 7.4
Figure 3 - Carriage Bolt Diagram

ASSEMBLY

A
3
4
4
