- Page 1 Grade 2 Boxed Power Supply 0.5 Amp QUICK GUIDE & INSTRUCTION MANUAL...
- Page 2 INSTALLING CONFIDENCE At CSL we give you the right tools for maximum support and minimum hassle. It’s service that’s built around you. csl-group.com/installer 24/7 HELP DESK LIVE CHAT TRAINING VIDEOS COVERAGE MAPS APPS...
-
Page 3: Installation
This product is suitable for use in systems designed to comply with PD6662:2010, EN50131-6 Grade 2 and Environmental Class 2. It is a Type A power supply. Rated Output = 0.5 Amp INSTALLATION Mount the metal enclosure onto the wall. Connect the Live, Neutral and Earth terminals to the un-switched fused spur. - Page 4 EXTERNAL POWER SUPPLY (EPS) (AC SUPPLY) The power supply has a three way terminal block for Live, Neutral and Earth connections, and is protected by a 20mm anti-surge fuse rated at 230V, 315mA. A replacement fuse MUST be the same type and rating.
-
Page 5: Battery Protection
BATTERY PROTECTION The battery and electronic circuitry are protected against reverse polarity connection by a self resetting electronic fuse. The battery is also protected against deep discharge, which will be invoked when the battery terminal voltage has dropped to 10.8V. MAINTENANCE This unit is to be used by service personnel only. -
Page 6: Specifications
C to +4 Case Size 265 x 320 x 100mm Weight 3.2 Kg SUPPORT For more information on this and other products please contact CSL Technical Support: UK Tel: +44 (0)1895 474 444 Ireland Tel: 1800 855 695 Email: support@csl-group.com Hours: 08.30 to 18.00 weekdays, 10.00 to 16.00 Saturday...
