Summary of Contents for Valen Hyland 920
- Page 1 VALEN 920 WIND TURBINE OWNERS MANUAL AUSTRALIA NEW ZEALAND 1300 734 253 0800 734 253 sales@valen.com.au sales@valen.co.nz www.valen.com.au www.valen.co.nz VERSION 1 AUGUST 2021...
-
Page 2: How To Use This Manual
Controller. You are now the owner of the world’s most powerful small wind turbine. To ensure you get the very best performance out of your Hyland 920, we recommend you read this manual prior to installation of the wind turbine and charge controller. -
Page 3: Safety Instructions
Please contact us if you have any further questions. Due to the nature of small wind turbines such as the Hyland 920, there are a number of potential mechanical and electrical hazards as follows. -
Page 4: Technical Specifications
Dangers during installation or maintenance Only work on the Hyland 920 during appropriate weather conditions to prevent injury of personnel. Do not stand under unsecured objects during installation. Please ensure all batteries are disconnected from the system prior to conducting work, and the Turbine is connected to the controller with it switched to ‘short’... - Page 5 INDUSTRIAL BATTERY & ENERGY STORAGE SOLUTION PROVIDER Estimated annual production Wind Speed Rayleigh for a given annual mean wind 4 m/s 380 kWh 311 kWh speed. We note that the stan- 5 m/s 731 kWh 393 kWh dardised Rayleigh wind re- 6 m/s 1,175 kWh 608 kWh...
-
Page 6: Power Curve
8. The power curve of the Hyland 920 is presented below. The Hyland 920 wind turbine system includes a Diffuse Energy maximum power point tracking (MPPT) controller that optimises the amount of power extracted for a given wind speed. - Page 7 17. Assuming there is wind - the MPPT controller will now power up. Note: The controller will not be active without turbine power. Note: See following ‘Hyland 920 Controller User Manual’ for controller setup instructions. AUS 1300 734 253 NZ 0800 734 253...
- Page 8 2. Feed the system power cable (recommend 12 AWG) through the mounting pole. 3. Attach the Hyland 920 power cable to the system power cable. 4. Insert the yaw mechanism base on the pole, ensuring that it is fully inserted.
- Page 9 INDUSTRIAL BATTERY & ENERGY STORAGE SOLUTION PROVIDER Commissioning Please verify correct installation of your Hyland 920 Wind Turbine using the checklist below.. Hyland 920 Commissioning Chart Completed Page TOWER Installed as per manufacturer’s instructions Turbine Plumbed vertical ELECTRICAL SYSTEM 20A breaker installed between controller and...
-
Page 10: Start And Stop
Operation Guidelines Please refer to the Hyland 920 controller operation guidelines for information on ‘starting’ and ‘stopping’ turbine operation, and operation during high wind conditions. Start and stop The turbine can be slowed by switching the brake on, this will stop it in light wind conditions or significantly reduce power in medium winds The turbine can be brought to a very slow rotation by switching the short button. -
Page 11: Troubleshooting
INDUSTRIAL BATTERY & ENERGY STORAGE SOLUTION PROVIDER Trouble Shooting If problems occur after installation of your new Hyland 920 wind turbine, most can be solved using the following trouble shooting guide. Hyland 920 Blades are not Spinning Possible Source Test... - Page 12 Zero Power Output Possible Source Test Solution of the Error Wait for higher wind speeds. NOTE: The Hyland 920 should begin Not enough wind Test wind speed producing power at wind speeds greater than 3.5 m/s. Turbine is switched Check SHORT/RUN switch and...
-
Page 13: Further Support
Wiring Specifications If blades are damaged, Damaged blades Check blades for visual damage contact sales@valen.com.au Further Support If you require further assistance, please contact us using the details on the back page. AUS 1300 734 253 NZ 0800 734 253... - Page 14 Company Details Legal Entity Valen Power Pty Ltd 134 028 961 Telephone 1300 734 253 OBSEQUENTIA OBSEQUENTIA OBSEQUENTIA ENVIRONMENT CERTIFIED QUALITY CERTIFIED SAFETY CERTIFIED ISO 14001:2015 IS0 9001 :2015 ISO 45001 : 2018...
