Scion Tech SC03.1404 User Manual Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
1. Introduction The SC03.1404 quad multi-viewer has 12 segmentation modes for viewing 4 x HDMI signals on the same screen, including 4 equal segments as one of the modes. The unit can also be used as a seamless switch for viewing individual inputs. -
Page 4: Specifications
Scion Tech SC03.1404 User Manual 4. Specifications Input Connectivity Signal: 4 x HDMI Type A, 19-Pin Female Power: DC Jack Socket Output Connectivity Signal: 1 x HDMI Type A, 19-Pin Female Signal Signal Input: HDMI Standards: HDMI 1.3, HDCP 1.4 Bandwidth: 4.95Gbps... -
Page 5: Panel Description
Scion Tech SC03.1404 User Manual 5. Panel Description SCION 1:4 Multiviewer Power Audio Mode SC03.1404 Input 1 Input 2 Input 3 Input 4 HDMI Output DC 12V 1. Infrared receiver window 2. Power LED 3. HDMI input LED indicators 4. Audio selection switch 5. -
Page 6: Infrared Remote Control
Scion Tech SC03.1404 User Manual 6. Infrared Remote Control 720p Power / Standby 720p / 1080p Switch 1080p Outputs 1 - 4 Audio Switch Audio Mute Mute Output Mode Selection 4 x 1 Quad Multi-Viewer Remote Control 7. Connection Diagram Page 4 www.scion-tech.co.uk... -
Page 7: Segmentations
Scion Tech SC03.1404 User Manual 8. Segments Options IN 1 IN 2 IN 3 IN 4 IN 2 IN 1 IN 2 IN 1 IN 2 IN 3 IN 4 IN 1 IN 4 IN 3 IN 3 IN 4... -
Page 8: Maintenance
Scion Tech SC03.1404 User Manual 9. Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzene to clean these devices. 9.1 Servicing Damage requiring service: This product should be serviced by a qualified service engineer if: ●... -
Page 9: Warranty Limits And Exclusions
Scion Tech SC03.1404 User Manual 9.4 Limited warranty limits and exclusions This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages which occurred...
