- Page 1 Quick Guide CMic Slim UTM DIGIMIC Under table solution for microphone unit CMic Article no.: 05.1090...
- Page 2 Introduction and connectors Introduction and connectors A microphone unit mounted almost invisibly. This is exactly what the CMic Slim UTM from Brähler Systems offers you. The microphone unit is mounted under the table in simple aluminium housing - only what is really needed is visible: Microphone jack and button.
- Page 3 Operating The CMic Slim UTM is designed for installation in the smallest of places - for example under the table. Please refer to the following drawings for the required space. (Please note that you also need space for cables and plugs).
- Page 4 Now first connect CMic Slim UTM and microphone button and socket. Only use suitable cables. You then establish a connection between your CMic Slim UTM and your DIGIMIC system. Connect the CMic Slim UTM with your central unit or a previous unit (PREV, RJ45 plug) and the following units (NEXT, RJ45 plug).
- Page 5 Chairman Version The CMic Slim UTM is also available in a Chairman version. It gives special priority to the chairman of a conference. Press the Override button to mute all delegate units. Two variants can be set on the Central Unit: Permanent: Permanent: Press the Override button to mute all delegate units.
- Page 6 CMic Slim UTM DIGIMIC Quick Guide Quick Guide Quick Guide Quick Guide Further information about our products can be found on the Internet under: www.braehler-systems.com © 2019 Copyright by BRÄHLER Systems GmbH, Königswinter All rights reserved, in particular (also in extracts) those of translation, reprinting, reproduction by copying or similar procedures.
