- Page 1 User’s Manual Artist Commercial Audio System Solution Revision A3-2020-10...
- Page 2 MANUALOFARTIST Contents Safety precautions Trouble shooting Wire connection Appearance Point source speaker installation dimensions and application Line array speaker installation dimensions and application Column speaker installation dimensions and application Subwoofer installation dimensions and application Specifications...
- Page 3 Please finish reading the manual before usage,to make sure the best performance of Artist Commercial Audio System.Please keep the manual for reference in the future.
- Page 4 Please consult distributor if there are still problems. Wire connection Artist applied Phoenix socket terminal, which is specially designed for speakers, mainly for safety and reliability. The positive and negative terminals in paralleling can be connected to another speaker. Dynamic Audio Solutions...
- Page 5 The total impedance of a single group of parallel speakers is equal to the impedance of a single speaker divided by the number of speakers. Connection diagram Artist T3/TW8/TW118 Artist T4 Artist TW28...
- Page 6 MANUALOFARTIST Appearance Artist T3 Artist T4 Artist T6 Artist T8 Artist T43 Artist T83 Artist T65 Artist TW8 Artist TW28 Artist TW118 Dynamic Audio Solutions...
- Page 7 . Artist T-Box40 application When Artist T3 or T4 is used at constant voltage mode, it needs to be used with Artist T-Box40, which is an external transformer box for impedance and voltage output switch.
- Page 8 MANUALOFARTIST W02 Universal rotating bracket Material: steel; Surface treatment: black fine sand (white is optional) Horizontal angle adjustment Vertical angle adjustment 0° Line array speaker installation dimensions and application Artist T8 Artist T6 418mm 259mm 344mm 218mm Dynamic Audio Solutions...
- Page 9 R3.5mm 133mm 166mm 250mm R3.5mm Φ11mm Φ11mm 190mm Vertical angle adjustment examples for Artist T6 / T8 Artist T6 vertical hanging frame Artist T8 vertical hanging frame 48mm 68mm 441mm 469mm Accessories for line array wall mounting frame 1 Accessories for line array wall mounting frame 2 312.5mm...
- Page 10 MANUALOFARTIST Applications examples for Artist flying frame T6 / T8 Applications examples for Artist wall mounting Line array wall mounting frame and accessories T6 / T8 line array Dynamic Audio Solutions...
- Page 11 MANUALOFARTIST Column speaker installation dimensions and application Artist T43 146mm When the knob at 8Ω, it is in the impedance output 8Ω 8Ω working mode. When the knob at (100V 60W/ 30W/15W, 70V 60W/30W/15W/7.5W), it is in the voltage output working mode.
- Page 12 W03 vertical wall mounting bracket W04 horizontal wall mounting bracket 63mm 53mm 76mm 63mm 52mm 62mm 86mm (Thefollowingthreemodelsare0°，2.5°，and5°adjustableequippedwiththebracket) 2.5° 0° 5° Artist T43 Artist T83 Artist T65 Application examples for W04 horizontal wall mounting bracket Artist T83 Artist T43 Dynamic Audio Solutions...
- Page 13 MANUALOFARTIST Artist TW8 Artist TW8 U-shaped wall mounting bracket 238mm 15mm 145mm 15mm 80mm 116mm 146mm 610mm Artist TW28 Artist TW28 U-shaped wall mounting bracket 346mm 15mm 205mm 15mm 80mm 116mm 254mm 760mm Dynamic Audio Solutions...
- Page 14 MANUALOFARTIST Artist TW118 568mm 536mm Dynamic Audio Solutions...
- Page 15 MANUALOFARTIST...
