- Page 1 A15 Household Healthcare Oxygen Concentrator User Manual Version 2.0 Thank you for choosing AVICHE oxygen concentrator. Please read this User Manual carefully before use and maintenance and keep it properly for future reference.
-
Page 3: Table Of Contents
Table of Contents ……………………………………… Ⅰ. Company Profile …………………………… Ⅱ. Device and Accessories …………………………………… Ⅲ. Safety Instructions ………………………………… Ⅳ. Product Introduction ………………………… Ⅴ. Product Parts Introduction ………… Ⅵ. Operations before Oxygen Inhalation ………… Ⅶ. Screen and Function Keys Operation …………………………… Ⅷ. Usage of Nasal Cannula IX. -
Page 4: Ⅰ. Company Profile
AVICHE Shandong Medical Technology Co., Ltd. (AVICHE) is invested and established by AVIC Avionics Systems. Adhering to the concept of AVIC and making use of its technical strength, AVICHE has composed a strong team of comprehensive innovation, fast productization, and quick response with the expert teams from medical, optical, computer, electronics, machinery, management and other fields. -
Page 5: Ⅱ. Device And Accessories
A15 Household Healthcare Oxygen Concentrator User Manual Version 2.0 Thank you for choosing AVICHE oxygen concentrator. Please read this User Manual carefully before use and maintenance and keep it properly for future reference. Main Unit × 1 Remote Controller × 1 User Manual (including Warranty Card) ×... -
Page 6: Ⅲ. Safety Instructions
Ⅲ. Safety Instructions 1. Precautions Before Use ·It is forbidden to dump the product during handling. ·The voltage of product is AC220V±22V and do not use industrial power. When the voltage is unstable, please install the voltage regulator before use. ·Be sure to use qualified socket and wiring boards. -
Page 7: Ⅳ. Product Introduction
Ⅳ. Product Introduction 1. Design Features ·All-plastic shell, safe and reliable. ·Large touch control screen is convenient for the elderly. ·Remote controller function, use more comfortable. ·Timing function is helpful to sleep. ·Anion function can improve oxygen inhalation environment and enhance oxygen absorption. -
Page 8: Ⅴ. Product Parts Introduction
Ⅴ. Product Parts Introduction Display Screen Control Buttom Area Humidifier Bottle Unload Button Oxygen Outlet Humidifier Bottle Nebulization Outlet Fuse Base Power Switch Power Cord Socket Air Inlet Filter Call For Help Power On/Off Oxygen Flow + Timing - Timing + Oxygen Flow - Nebulization Function Radio On/Off... -
Page 9: Ⅵ. Operations Before Oxygen Inhalation
Ⅵ. Operations before Oxygen Inhalation 1. Press the humidifier bottle unload button (Figure 3) and Humidifier Bottle remove the humidifier bottle. Unload Button Oxygen Outlet 2. Take out the humidifier bottle lid and fill the humidifier bottle with purified water or distilled water Humidifier Bottle of room temperature. -
Page 10: Ⅶ. Screen And Function Keys Operation
6. Connect oxygen tube. Connect one end of the oxygen tubing to the oxygen outlet of humidifier bottle, and the other end (mask or nasal cannula) is worn by the user to inhale oxygen. ( See Ⅷ. Usage of Nasal Cannula for reference) Ⅶ. - Page 11 1. Power On The device enters the standby mode after connection to the power supply, and the power on/off key will be lit. Press the power on/off key on control screen or telecontroller and both operation button and display screen will be lit, The device will enter the calibration status, which will take about 1 minute.
- Page 12 5. SOS Function When users had sudden diseases and can not call for help, they can press on the “SOS” key in the control panel or the telecontroller for help, and the device will continue to voice out “help me” to seek for help. To turn off the SOS function, just click on any function key on the control panel to close the SOS function.
-
Page 13: Ⅷ. Usage Of Nasal Cannula
Ⅷ. Usage of Nasal Cannula Figure 7 Usage of Nasal Cannula Put the prongs of nasal cannula into the nostrils, and hook the tube around the ears with the locking hoop fixing the tube tight (as shown in Figure 7). After the device finishes calibration and enters the normal working condition, connect the other end of the nasal cannula to the upper oxygen outlet of device to inhale oxygen. -
Page 14: Ⅹ. Maintenance
Ⅹ. Maintenance Make sure to turn off the power supply before maintenance of the oxygen concentrator. In order to avoid electric shock, non-professionals are not allowed to disassemble the device. 1. Clean the Outer Covering ·It is recommended to wipe and clean the outer covering once a month. ·Disconnect the power supply firstly and wipe it with a soft sponge or wet cloth dipped in moderate cleanser. - Page 15 ·Air Inlet Filter can protect compressor and molecular sieve, prolong service life of equipmentand reduce noise. Please be sure to replace it in time. ·Replace frequency: Please replace air inlet filter in time when it becomes black after a long-time usage. Recommend to replace it in 6-12 months. ·When replacing the air inlet filter, please firstly pull out the old filter and then plug in a new filter.
-
Page 16: Ⅺ. Troubleshooting Guide
Ⅺ. Troubleshooting Guide Trouble Analysis Solution The voltage is too high to cause the Replace the Fuse fuse to fail The power is turned on and the display Do not use the power extension screen is not lit No power input cable or move the device to another power connector The oxygen tube is tied or blocked... -
Page 17: Ⅻ. Other Precautions
(Service Hotline: +86-400-800-9850) 1. Implement the national policy of Three Guarantees. 2. Free maintenance will be provided by AVICHE in case of quality problems within one year from the date of purchase (Three years warranty for com- pressor). In case of there is any problem within warranty period, User can... - Page 18 A15 Household Healthcare Oxygen Concentrator Warranty Card Model From Warranty Period Name Purchaser Address Phone Name Sales Unit Address Phone 1. Warranty a. Since the date of purchase, the warranty period will last for 1 year, and free mainte- nance will be provided (except for force majeure and human factors).
